Image preview - the first page of the document
>> Download 00AN_8W documenatation <<
Text preview - extract from the document
AN WIRING DIAGRAMS 8W - 1
WIRING DIAGRAMS
CONTENTS
page page
AIR CONDITIONING/HEATER . . . . . . . . . . . 8W-42-1 OVERHEAD CONSOLE. . . . . . . . . . . . . . . . . 8W-49-1
AIRBAG SYSTEM . . . . . . . . . . . . . . . . . . . . 8W-43-1 POWER DISTRIBUTION . . . . . . . . . . . . . . . 8W-10-1
ALL-WHEEL ANTI-LOCK BRAKES. . . . . . . . 8W-35-1 POWER DOOR LOCKS . . . . . . . . . . . . . . . . 8W-61-1
AUDIO SYSTEM . . . . . . . . . . . . . . . . . . . . . 8W-47-1 POWER MIRRORS . . . . . . . . . . . . . . . . . . . 8W-62-1
CENTRAL TIMER MODULE. . . . . . . . . . . . . 8W-45-1 POWER SEAT . . . . . . . . . . . . . . . . . . . . . . . 8W-63-1
CHARGING SYSTEM . . . . . . . . . . . . . . . . . . 8W-20-1 POWER WINDOWS. . . . . . . . . . . . . . . . . . . 8W-60-1
COMPONENT INDEX . . . . . . . . . . . . . . . . . . 8W-02-1 REAR LIGHTING . . . . . . . . . . . . . . . . . . . . . 8W-51-1
CONNECTOR LOCATIONS . . . . . . . . . . . . . . 8W-90-1 REAR WHEEL ANTI-LOCK BRAKES . . . . . . 8W-34-1
CONNECTOR PIN-OUTS . . . . . . . . . . . . . . . 8W-80-1 SPLICE INFORMATION . . . . . . . . . . . . . . . . 8W-70-1
FRONT LIGHTING . . . . . . . . . . . . . . . . . . . . 8W-50-1 SPLICE LOCATIONS . . . . . . . . . . . . . . . . . . 8W-95-1
FUEL/IGNITION SYSTEMS . . . . . . . . . . . . . 8W-30-1 STARTING SYSTEM . . . . . . . . . . . . . . . . . . 8W-21-1
FUSE/RELAY BLOCK . . . . . . . . . . . . . . . . . . 8W-11-1 TRAILER TOW. . . . . . . . . . . . . . . . . . . . . . . 8W-54-1
GENERAL INFORMATION . . . . . . . . . . . . . . 8W-01-1 TRANSMISSION CONTROL SYSTEM . . . . . 8W-31-1
GROUND DISTRIBUTION . . . . . . . . . . . . . . 8W-15-1 TURN SIGNALS. . . . . . . . . . . . . . . . . . . . . . 8W-52-1
HORN/CIGAR LIGHTER/POWER OUTLET . . 8W-41-1 VEHICLE SPEED CONTROL . . . . . . . . . . . . 8W-33-1
INSTRUMENT CLUSTER . . . . . . . . . . . . . . . 8W-40-1 VEHICLE THEFT SECURITY SYSTEM . . . . . 8W-39-1
INTERIOR LIGHTING. . . . . . . . . . . . . . . . . . 8W-44-1 WIPERS. . . . . . . . . . . . . . . . . . . . . . . . . . . . 8W-53-1
JUNCTION BLOCK. . . . . . . . . . . . . . . . . . . . 8W-12-1
AN 8W - 01 GENERAL INFORMATION 8W - 01 - 1
8W-01 GENERAL INFORMATION
INDEX
page page
DESCRIPTION AND OPERATION TROUBLESHOOTING TESTS . . . . . . . . . . . . . . . . 9
INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . .1 TROUBLESHOOTING WIRING PROBLEMS . . . . . . 9
CIRCUIT INFORMATION . . . . . . . . . . . . . . . . . . . .4 SERVICE PROCEDURES
CIRCUIT FUNCTIONS . . . . . . . . . . . . . . . . . . . . . .4 WIRING REPAIR . . . . . . . . . . . . . . . . . . . . . . . . . 10
SECTION IDENTIFICATION . . . . . . . . . . . . . . . . . .5 TERMINAL/CONNECTOR REPAIR-MOLEX
SYMBOLS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 CONNECTORS . . . . . . . . . . . . . . . . . . . . . . . . . 10
CONNECTOR INFORMATION . . . . . . . . . . . . . . . .7 TERMINAL/CONNECTOR REPAIR--THOMAS
SPLICE LOCATIONS . . . . . . . . . . . . . . . . . . . . . . .7 AND BETTS CONNECTORS . . . . . . . . . . . . . . . 10
NOTES, CAUTIONS, and WARNINGS . . . . . . . . . .7 CONNECTOR REPLACEMENT. . . . . . . . . . . . . . . 11
TAKE OUTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 CONNECTOR AND TERMINAL
ELECTROSTATIC DISCHARGE (ESD) REPLACEMENT . . . . . . . . . . . . . . . . . . . . . . . . 12
SENSITIVE DEVICES . . . . . . . . . . . . . . . . . ....8 TERMINAL REPLACEMENT . . . . . . . . . . . . . . . . . 13
DIAGNOSIS AND TESTING DIODE REPLACEMENT . . . . . . . . . . . . . . . . . . . . 14
TROUBLESHOOTING TOOLS . . . . . . . . . . . . ....8 SPECIAL TOOLS
INTERMITTENT AND POOR CONNECTIONS. ....8 WIRING/TERMINAL . . . . . . . . . . . . . . . . . . . . . . . 15
DESCRIPTION AND OPERATION Components are shown two ways. A solid line
around a component indicates that the component is
INTRODUCTION complete. A dashed line around a component indi-
DaimlerChrysler wiring diagrams are designed to cates that the component being shown is not com-
provide information regarding the vehicles wiring plete. Incomplete components have a reference
content. In order to effectively use DaimlerChrysler number to indicate the page where the component is
wiring diagrams to diagnose and repair a Daimler- shown complete.
Chrysler vehicle, it is important to understand all of It is important to realize that no attempt is made
their features and characteristics. on the diagrams to represent components and wiring
Diagrams are arranged such that the power (B+) as they appear on the vehicle. For example, a short
side of the circuit is placed near the top of the page, piece of wire is treated the same as a long one. In
and the ground (B-) side of the circuit is placed near addition, switches and other components are shown
the bottom of the page. as simply as possible, with regard to function only.
All switches, components, and modules are shown
in the at rest position with the doors closed and the
key removed from the ignition.
8W - 01 - 2 8W - 01 GENERAL INFORMATION AN
DESCRIPTION AND OPERATION (Continued)
Wiring Diagram Example No.1
AN 8W - 01 GENERAL INFORMATION 8W - 01 - 3
DESCRIPTION AND OPERATION (Continued)
Wiring Diagram Example No.2
8W - 01 - 4 8W - 01 GENERAL INFORMATION AN
DESCRIPTION AND OPERATION (Continued)
CIRCUIT INFORMATION CIRCUIT FUNCTIONS
Each wire shown in the diagrams contains a code All circuits in the diagrams use an alpha/numeric
which identifies the main circuit, part of the main code to identify the wire and its function. To identify
circuit, gage of wire, and color (Fig. 1). which circuit code applies to a system, refer to the
Circuit Identification Code Chart. This chart shows
the main circuits only and does not show the second-
ary codes that may apply to some models.
CIRCUIT IDENTIFICATION CODE CHART
CIRCUIT FUNCTION
A BATTERY FEED
B BRAKE CONTROLS
C CLIMATE CONTROLS
D DIAGNOSTIC CIRCUITS
E DIMMING ILLUMINATION CIRCUITS
F FUSED CIRCUITS
G MONITORING CIRCUITS (GAUGES)
Fig. 1 Wire Code Identification H OPEN
