Image preview - the first page of the document
00AN_13


>> Download 00AN_13 documenatation <<

Text preview - extract from the document
AN                                                                                                     FRAME AND BUMPERS                      13 - 1



                                              FRAME AND BUMPERS
                                                      TABLE OF CONTENTS

                                                                  page                                                                          page

BUMPERS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1   FRAME . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4



                                                              BUMPERS

                                                            TABLE OF CONTENTS
                                                                  page                                                                          page

DESCRIPTION AND OPERATION                                                     FRONT BUMPER FASCIA . . . . . . . . . . . . . . . . . . . 1
 BUMPERS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1      REAR BUMPER . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
REMOVAL AND INSTALLATION                                                      VALANCE PANEL. . . . . . . . . . . . . . . . . . . . . . . . . . 3
 FRONT BUMPER . . . . . . . . . . . . . . . . . . . . . . . . . . 1

DESCRIPTION AND OPERATION                                                     (5) Pull the front wheelhouse liner back at the
                                                                            bumper and remove bolts attaching outer bumper
BUMPERS                                                                     brackets to frame rail (Fig. 1).
                                                                              (6) Remove the bolts attaching the bumper to the
DESCRIPTION                                                                 inner bumper bracket.
  Bumpers are used at the front and rear of the                               (7) Separate front bumper with outer bracket
vehicle. Bumpers are incorporated into the design of                        attached from vehicle.
the front and rear fascias. They are mounted to the
frame with brackets and may contain some lamp ele-                          INSTALLATION
ments.                                                                        When the front bumper is installed, there should
                                                                            be a 19 mm gap between the bumper and front
OPERATION                                                                   fender.
  Bumpers are designed to protect the exterior sheet-                         (1) Place the bumper on a suitable lifting device
metal in low impact situations. The bumpers are                             and position the bumper at the vehicle.
attached to the frame and provide mounting points                             (2) Install the bolts attaching front bumper to
for some optional accessories such as fog lights and                        inner bumper bracket. Tighten to 94 N
