Image preview - the first page of the document
>> Download 00AN_24 documenatation <<
Text preview - extract from the document
AN HEATING AND AIR CONDITIONING 24 - 1
HEATING AND AIR CONDITIONING
TABLE OF CONTENTS
page page
DESCRIPTION AND OPERATION REFRIGERANT SYSTEM LEAKS . . . . . . . . . . . . . 19
ACCUMULATOR . . . . . . . . . . . . . . . . . . . . . . . . . . 2 SERVICE PROCEDURES
BLOWER MOTOR . . . . . . . . . . . . . . . . . . . . . . . . . 2 REFRIGERANT OIL LEVEL . . . . . . . . . . . . . . . . . 19
BLOWER MOTOR RELAY . . . . . . . . . . . . . . . . . . . 2 REFRIGERANT RECOVERY . . . . . . . . . . . . . . . . . 20
BLOWER MOTOR RESISTOR . . . . . . . . . . . . . . . . 3 REFRIGERANT SYSTEM CHARGE . . . . . . . . . . . 20
BLOWER MOTOR SWITCH. . . . . . . . . . . . . . . . . . 3 REFRIGERANT SYSTEM EVACUATE. . . . . . . . . . 20
COMPRESSOR . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 REFRIGERANT SYSTEM SERVICE
COMPRESSOR CLUTCH . . . . . . . . . . . . . . . . . . . . 4 EQUIPMENT. . . . . . . . . . . . . . . . . . . . . . . . . . . 20
COMPRESSOR CLUTCH RELAY . . . . . . . . . . . . . . 4 REMOVAL AND INSTALLATION
CONDENSER. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 ACCUMULATOR . . . . . . . . . . . . . . . . . . . . . . . . . 23
EVAPORATOR COIL . . . . . . . . . . . . . . . . . . . . . . . 5 BLOWER MOTOR . . . . . . . . . . . . . . . . . . . . . . . . 24
FIXED ORIFICE TUBE . . . . . . . . . . . . . . . . . . . . . . 5 BLOWER MOTOR RELAY . . . . . . . . . . . . . . . . . . 25
HEATER AND AIR CONDITIONER. . . . . . . . . . . . . 5 BLOWER MOTOR RESISTOR . . . . . . . . . . . . . . . 25
HEATER AND AIR CONDITIONER CONTROL . . . . 6 COMPRESSOR . . . . . . . . . . . . . . . . . . . . . . . . . . 26
HEATER CORE . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 COMPRESSOR CLUTCH . . . . . . . . . . . . . . . . . . . 27
HIGH PRESSURE CUT-OFF SWITCH . . . . . . . . . . 7 COMPRESSOR CLUTCH RELAY . . . . . . . . . . . . . 30
HIGH PRESSURE RELIEF VALVE . . . . . . . . . . . . . 7 CONDENSER. . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
LOW PRESSURE CYCLING CLUTCH SWITCH . . . 7 DUCTS AND OUTLETS . . . . . . . . . . . . . . . . . . . . 32
REFRIGERANT . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 EVAPORATOR COIL . . . . . . . . . . . . . . . . . . . . . . 34
REFRIGERANT LINE COUPLERS . . . . . . . . . . . . . 8 FIXED ORIFICE TUBE . . . . . . . . . . . . . . . . . . . . . 35
REFRIGERANT LINES . . . . . . . . . . . . . . . . . . . . . . 8 HEATER CORE . . . . . . . . . . . . . . . . . . . . . . . . . . 41
REFRIGERANT OIL . . . . . . . . . . . . . . . . . . . . . . . . 8 HEATER-A/C CONTROL . . . . . . . . . . . . . . . . . . . 35
REFRIGERANT SYSTEM SERVICE PORTS. . . . . . 9 HEATER-A/C HOUSING. . . . . . . . . . . . . . . . . . . . 36
VACUUM CHECK VALVE . . . . . . . . . . . . . . . . . . . . 9 HEATER-A/C HOUSING DOOR . . . . . . . . . . . . . . 40
VACUUM RESERVOIR . . . . . . . . . . . . . . . . . . . . . 9 HIGH PRESSURE CUT-OFF SWITCH . . . . . . . . . 42
DIAGNOSIS AND TESTING LIQUID LINE . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
A/C PERFORMANCE . . . . . . . . . . . . . . . . . . . . . . 10 LOW PRESSURE CYCLING CLUTCH SWITCH . . 43
BLOWER MOTOR . . . . . . . . . . . . . . . . . . . . . . . . 13 MODE DOOR VACUUM ACTUATOR . . . . . . . . . . 44
BLOWER MOTOR RELAY . . . . . . . . . . . . . . . . . . 13 REFRIGERANT LINE COUPLER . . . . . . . . . . . . . 45
BLOWER MOTOR RESISTOR . . . . . . . . . . . . . . . 14 SERVICE WARNINGS AND PRECAUTIONS . . . . 22
BLOWER MOTOR SWITCH. . . . . . . . . . . . . . . . . 15 SUCTION AND DISCHARGE LINE . . . . . . . . . . . 46
COMPRESSOR . . . . . . . . . . . . . . . . . . . . . . . . . . 15 TEMPERATURE CONTROL CABLE . . . . . . . . . . . 47
COMPRESSOR CLUTCH COIL . . . . . . . . . . . . . . 16 VACUUM CHECK VALVE . . . . . . . . . . . . . . . . . . . 48
COMPRESSOR CLUTCH RELAY . . . . . . . . . . . . . 16 VACUUM RESERVOIR . . . . . . . . . . . . . . . . . . . . 48
DUAL FUNCTION HIGH PRESSURE VACUUM SYSTEM . . . . . . . . . . . . . . . . . . . . . . . 50
SWITCH/HIGH PRESSURE CUT-OFF ADJUSTMENTS
SWITCH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 TEMPERATURE CONTROL CABLE . . . . . . . . . . . 55
HEATER PERFORMANCE . . . . . . . . . . . . . . . . . . 17 SPECIFICATIONS
HEATER-A/C CONTROL . . . . . . . . . . . . . . . . . . . 17 A/C APPLICATION TABLE . . . . . . . . . . . . . . . . . . 55
LOW PRESSURE CYCLING CLUTCH SWITCH . . 18
24 - 2 HEATING AND AIR CONDITIONING AN
DESCRIPTION AND OPERATION BLOWER MOTOR
ACCUMULATOR DESCRIPTION
The blower motor and blower wheel are located in
DESCRIPTION the passenger side end of the heater-A/C housing,
The accumulator is mounted in the engine com- below the glove box. The blower motor controls the
partment between the evaporator coil outlet tube and velocity of air flowing through the heater-A/C hous-
the compressor inlet. ing by spinning a squirrel cage-type blower wheel
within the housing at the selected speed. The blower
OPERATION motor and blower wheel can only be serviced with
Refrigerant enters the accumulator canister as a the heater-A/C housing removed from the passenger
low pressure vapor through the inlet tube. Any liq- compartment.
uid, oil-laden refrigerant falls to the bottom of the
canister, which acts as a separator. A desiccant bag is OPERATION
mounted inside the accumulator canister to absorb The blower motor will only operate when the igni-
any moisture which may have entered and become tion switch is in the On position, and the heater-A/C
trapped within the refrigerant system (Fig. 1). mode control switch knob is in any position, except
Off. The blower motor receives a fused battery feed
through the blower motor relay whenever the igni-
tion switch is in the On position.
The blower motor battery feed circuit is protected
by a fuse in the Power Distribution Center (PDC).
The blower motor relay control circuit is protected by
a fuse in the junction block. Blower motor speed is
controlled by regulating the ground path through the
heater-A/C mode control switch, the blower motor
switch, the blower motor resistor, and the voltage
reduction relay.
The blower motor and blower motor wheel cannot
be repaired and, if faulty or damaged, they must be
replaced. The blower motor and blower wheel are
each serviced separately.
BLOWER MOTOR RELAY
DESCRIPTION
The blower motor relay (also referred to as Voltage
Reduction Relay or VRR) is an International Stan-
dards Organization (ISO)-type relay. The relay is an
electromechanical device that switches battery cur-
rent from a fuse in the Power Distribution Center
(PDC) directly to the blower motor. The relay is ener-
gized when the relay coil is provided a voltage signal
by the ignition switch. This arrangement reduces the
amount of battery current that must flow through
Fig. 1 Accumulator - Typical the ignition switch.
