Image preview - the first page of the document



>> Download 98DN_19 documenatation <<

Text preview - extract from the document

DN                                                                                                        STEERING        19 - 1



                                                      STEERING
                                                        CONTENTS

                                                          page                                                              page

POWER STEERING . . . . . . . . . . . . . . . . . . . . . . . . 1   STEERING COLUMN . . . . . . . . . . . . . . . . . . . . . . 22
POWER STEERING GEAR . . . . . . . . . . . . . . . . . . 10         STEERING LINKAGE . . . . . . . . . . . . . . . . . . . . . . 26
POWER STEERING PUMP . . . . . . . . . . . . . . . . . . 4



                                                POWER STEERING

                                                              INDEX
                                                          page                                                              page

GENERAL INFORMATION                                                DIAGNOSIS AND TESTING
 STEERING SYSTEM . . . . . . . . . . . . . . . . . . . . . . 1       POWER STEERING SYSTEM . . . . . . . . . . . . . . . 2

GENERAL INFORMATION
STEERING SYSTEM
   The power steering system consist of a steering col-
umn attached to the steering gear by a upper and
lower intermediate shaft. The variable ratio power
steering gear is mounting the left frame rail (Fig. 1).
The gear has a pitman arm which is attached to the
steering linkage.
   Power assist is provided by an engine mounted
hydraulic pump (Fig. 1). The pump supplies hydrau-
lic fluid pressure to the steering gear. Some models
are equipped with an oil cooler (Fig. 1) which is
mounted below the power steering pump.
   Power steering systems consist of:
