Image preview - the first page of the document
>> Download 98DN_8F documenatation <<
Text preview - extract from the document
DN AUDIO SYSTEMS 8F - 1
AUDIO SYSTEMS
CONTENTS
page page
GENERAL INFORMATION AUDIO SYSTEM . . . . . . . . . . . . . . . . . . . . . . . . . 2
AUDIO SYSTEM . . . . . . . . . . . . . . . . . . . . . . . . . 1 RADIO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . 1 RADIO FREQUENCY INTERFERENCE . . . . . . . . . 6
DESCRIPTION AND OPERATION SPEAKER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
ANTENNA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 REMOVAL AND INSTALLATION
IGNITION-OFF DRAW FUSE . . . . . . . . . . . . . . . . 1 AMPLIFIER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
RADIO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 ANTENNA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
RADIO NOISE SUPPRESSION . . . . . . . . . . . . . . 2 RADIO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
SPEAKER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 SPEAKER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
DIAGNOSIS AND TESTING SPECIAL TOOLS
ANTENNA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 ANTENNA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
GENERAL INFORMATION icies and Procedures manual for a current listing of
authorized radio repair stations.
INTRODUCTION For more information on radio features, setting
An audio system is standard factory-installed procedures, and control functions refer to the owner's
equipment on this model, unless the vehicle is manual in the vehicle glove box.
ordered with an available radio delete option. Refer
to 8W-47 Audio System in Group 8W - Wiring Dia- IGNITION-OFF DRAW FUSE
grams for complete circuit descriptions and diagrams. All vehicles are equipped with an Ignition-Off
Draw (IOD) fuse that is removed when the vehicle is
AUDIO SYSTEM shipped from the factory. This fuse feeds various
Several combinations of radio receivers and accessories that require battery current when the
speaker systems are offered on this model. The stan- ignition switch is in the Off position, including the
dard equipment audio system includes an AM/FM/ clock. The fuse is removed to prevent battery dis-
cassette (RAS sales code) receiver, and speakers in charge during vehicle storage.
four locations. When removing or installing the IOD fuse, it is
Following are general descriptions of the major important that the ignition switch be in the Off posi-
components in the standard and optional factory-in- tion. Failure to place the ignition switch in the Off
stalled audio systems. Refer to the owner's manual in position can cause the radio display to become scram-
the vehicle glove box for more information on the fea- bled when the IOD fuse is removed and replaced.
tures, use and operation of each of the available Removing and replacing the IOD fuse again, with the
audio systems. ignition switch in the Off position, will correct the
scrambled display condition.
The IOD fuse should be checked if the radio or
DESCRIPTION AND OPERATION clock displays are inoperative. The IOD fuse is
located in the junction block. Refer to the label on
RADIO the back of the junction block fuse access panel for
Available factory-installed radio receivers for this IOD fuse identification and location.
model include an AM/FM/cassette (RAS sales code),
or an AM/FM/CD/cassette/3-band graphic equalizer SPEAKER
(RAZ sales code). All factory-installed receivers are The standard equipment speaker system includes
stereo Electronically Tuned Radios (ETR) and include speakers in four locations. One full-range 16.5 centi-
an electronic digital clock function. meter (6.50 inch) diameter speaker is located in each
The radio can only be serviced by an authorized front door, and one full-range 16.5 centimeter (6.50
radio repair station. Refer to the latest Warranty Pol- inch) speaker is also located in each rear door.
8F - 2 AUDIO SYSTEMS DN
DESCRIPTION AND OPERATION (Continued)
