Image preview - the first page of the document
>> Download 98DN_8S documenatation <<
Text preview - extract from the document
DN POWER WINDOW SYSTEMS 8S - 1
POWER WINDOW SYSTEMS
CONTENTS
page page
GENERAL INFORMATION DIAGNOSIS AND TESTING
INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . 1 CIRCUIT BREAKER . . . . . . . . . . . . . . . . . . . . . . . 3
POWER WINDOW SYSTEM . . . . . . . . . . . . . . . . 1 POWER WINDOW MOTOR . . . . . . . . . . . . . . . . . 4
DESCRIPTION AND OPERATION POWER WINDOW SWITCH . . . . . . . . . . . . . . . . 3
CIRCUIT BREAKER . . . . . . . . . . . . . . . . . . . . . . . 2 POWER WINDOW SYSTEM . . . . . . . . . . . . . . . . 2
POWER WINDOW MOTOR . . . . . . . . . . . . . . . . . 2 REMOVAL AND INSTALLATION
POWER WINDOW SWITCH . . . . . . . . . . . . . . . . 1 POWER WINDOW MOTOR . . . . . . . . . . . . . . . . . 4
POWER WINDOW SWITCH . . . . . . . . . . . . . . . . 4
GENERAL INFORMATION DESCRIPTION AND OPERATION
INTRODUCTION POWER WINDOW SWITCH
Power windows are available as factory-installed The power windows are controlled by four two-way
optional equipment on this model. The Remote Key- switches and a power window lockout switch that are
less Entry (RKE) system and power lock system are integral to the power window and lock switch unit on
included on vehicles equipped with the power win- the driver side front door trim panel. Additionally,
dow option. Refer to 8W-60 - Power Windows in each of the passenger doors has a single gang two-
Group 8W - Wiring Diagrams for complete circuit way power window switch mounted in a bezel on
descriptions and diagrams. their respective door trim panels. A Light-Emitting
Diode (LED) in the paddle of each switch is illumi-
POWER WINDOW SYSTEM nated whenever the ignition switch is in the On posi-
The power window system allows each of the door tion. However, the LEDs for the passenger power
windows to be raised and lowered electrically by window switches are extinguished whenever the
actuating a switch on the trim panel of each respec- driver selects the Lock position with the power win-
tive door. A master switch on the driver side front dow lockout switch.
door trim panel allows the driver to raise or lower The power window switch for the driver side front
each of the passenger door windows, and to lock out door has an Auto label on it. This switch has a sec-
the individual switches on the passenger doors from ond detent position beyond the normal Down position
operation. The power window system receives battery that provides an automatic one-touch window down
feed through a circuit breaker in the junction block, feature. This feature is controlled by an electronic
only when the ignition switch is in the On position. circuit and a relay that are integral to the driver side
The power window system includes the power win- front door power window and lock switch unit.
dow switches on each door trim panel, the circuit The power window switches control the battery
breaker in the junction block, and the power window and ground feeds to the power window motors. All of
motors inside each door. This group covers diagnosis the passenger door power window switches receive
and service of only the electrical components in the their battery and ground feeds through the circuitry
power window system. For service of mechanical of the driver side master switch unit. When the
components, such as the regulator, lift plate, window power window lockout switch is in the Lock position,
tracks, or glass refer to Group 23 - Body. the battery feed for the individual passenger door
Following are general descriptions of the major power window switches is interrupted.
components in the power window system. Refer to The driver side power window and lock switch unit
the owner's manual in the vehicle glove box for more and the single gang passenger door power window
information on the features, use and operation of the switches cannot be repaired and, if faulty or dam-
power window system. aged, the entire switch unit or switch must be
replaced.
8S - 2 POWER WINDOW SYSTEMS DN
DESCRIPTION AND OPERATION (Continued)
POWER WINDOW MOTOR ONE WINDOW INOPERATIVE
A permanent magnet reversible motor moves the The window glass must be free to slide up and
window regulator through an integral gearbox mech- down for the power window motor to function prop-
anism. A positive and negative battery connection to erly. If the glass is not free to move up and down, the
the two motor terminals will cause the motor to motor will overload and trip the integral circuit
rotate in one direction. Reversing the current breaker. To determine if the glass is free, disconnect
through these same two connections will cause the the regulator plate from the glass. Then slide the
motor to rotate in the opposite direction. window up and down by hand.
In addition, each power window motor is equipped There is an alternate method to check if the glass
with an integral self-resetting circuit breaker to pro- is free. Position the glass between the up and down
tect the motor from overloads. The power window stops. Then, shake the glass in the door. Check that
motor and gearbox assembly cannot be repaired and, the glass can be moved slightly from side to side,
if faulty or damaged, the entire power window regu- front to rear, and up and down. Then check that the
lator assembly must be replaced. glass is not bound tight in the tracks. If the glass is
free, proceed with the diagnosis that follows. If the
CIRCUIT BREAKER glass is not free, refer to Group 23 - Body for the
An automatic resetting circuit breaker in the junc- door window glass and hardware service and adjust-
tion block is used to protect the power window sys- ment procedures.
tem circuit. The circuit breaker can protect the If the only inoperative window is in the driver side
system from a short circuit, or from an overload con- front door and the preceding checks have not identi-
dition caused by an obstructed or stuck window glass fied a problem, see Power Window Motor in the Diag-
or regulator. nosis and Testing section of this group. If the
The circuit breaker cannot be repaired and, if problem being diagnosed involves only the Auto-down
faulty, it must be replaced. feature for the driver side front door window, but all
of the power windows are operational, replace the
faulty power window and lock master switch unit. If
DIAGNOSIS AND TESTING the problem being diagnosed involves only an inoper-
ative power window switch Light-Emitting Diode
POWER WINDOW SYSTEM (LED), but the power window that the switch con-
For circuit descriptions and diagrams, refer to trols operates satisfactorily from that switch, replace
8W-60 - Power Windows in Group 8W - Wiring Dia- the faulty switch unit. For any other single power
grams. window problem proceed with diagnosis as follows:
(1) Disconnect and isolate the battery negative
ALL WINDOWS INOPERATIVE cable. Unplug the wire harness connector from the
(1) Check the circuit breaker in the junction block, power window switch unit on the door with the inop-
as described in this group. If OK, go to Step 2. If not erative power window. Check for continuity between
OK, replace the faulty circuit breaker. the ground circuit cavity of the power window switch
(2) Disconnect and isolate the battery negative wire harness connector and a good ground. There
cable. Remove the power window and lock master should be continuity. If OK, go to Step 2. If not OK,
switch unit from the driver side front door trim repair the open circuit to the power window and door
panel. Unplug the wire harness connector from the lock master switch as required.
master switch unit. (2) Connect the battery negative cable. Turn the
(3) Check for continuity between the ground cir- ignition switch to the On position. Check for battery
cuit cavity of the power window and lock master voltage at the fused ignition switch output (run) cir-
switch unit wire harness connector and a good cuit cavity in the body half of the power window
ground. If OK, go to Step 4. If not OK, repair the cir- switch unit wire harness connector. If OK, go to Step
cuit to ground as required. 3. If not OK, repair the open circuit to the power
(4) Connect the battery negative cable. Turn the window and door lock master switch as required.
ignition switch to the On position. Check for battery (3) Test the power window switch continuity. See
voltage at the fused ignition switch output (run) cir- Power Window Switch in the Diagnosis and Testing
cuit cavity of the power window and lock master section of this group. If OK, go to Step 4. If not OK,
switch unit wire harness connector. If OK, see Power replace the faulty power window switch unit.
Window Switch in the Diagnosis and Testing section (4) Refer to the circuit diagrams in 8W-60 - Power
of this group. If not OK, repair the circuit to the Windows in Group 8W - Wiring Diagrams. Check the
junction block as required. continuity in each circuit between the inoperative power
window switch wire harness connector cavities and the
DN POWER WINDOW SYSTEMS 8S - 3
DIAGNOSIS AND TESTING (Continued)
corresponding power window motor wire harness con- (4) Test the power window switch continuity. See the
nector cavities. If OK, see Power Window Motor in the Power Window Switch Continuity charts to determine if
Diagnosis and Testing section of this group. If not OK, the continuity is correct in the Off, Up and Down switch
repair the open circuit(s) as required. positions (Fig. 1) or (Fig. 2). If OK, see Power Window
Motor in the Diagnosis and Testing section of this
NOTE: All passenger door power window switches group. If not OK, replace the faulty switch.
receive their battery and ground feed for operating
the passenger door power window motors through
the driver side power window and lock master
switch and wire harness connector.
CIRCUIT BREAKER
For circuit descriptions and diagrams, refer to 8W-60
- Power Windows in Group 8W - Wiring Diagrams.
(1) Locate the circuit breaker in the junction block.
Pull out the circuit breaker slightly, but be certain
that the circuit breaker terminals still contact the
terminals in the junction block cavities.
(2) Connect the negative lead of a 12-volt DC volt-
meter to a good ground.
(3) With the voltmeter positive lead, check both
terminals of the circuit breaker for battery voltage.
If only one terminal has battery voltage, the circuit
breaker is faulty and must be replaced. If neither ter-
minal has battery voltage, repair the open circuit
from the Power Distribution Center (PDC) as
required. If the circuit breaker checks OK, but no
power windows operate, see Power Window System
in the Diagnosis and Testing section of this group.
POWER WINDOW SWITCH
The Light-Emitting Diode (LED) illumination lamps
for all of the power window and lock switch and bezel
unit switch paddles receive battery current through
the power window circuit breaker in the junction block.
If all of the LEDs are inoperative in both the power
window and lock switch units and the power windows
are inoperative, perform the diagnosis for Power Win-
dow System in this group. If the power windows oper-
ate, but any or all of the LEDs are inoperative, the
power window and lock switch units with the inopera-
tive LED(s) is faulty and must be replaced. For circuit
descriptions and diagrams, refer to 8W-60 - Power
Windows in Group 8W - Wiring Diagrams.
(1) Check the circuit breaker in the junction block.
If OK, go to Step 2. If not OK, replace the faulty cir-
cuit breaker.
(2) Turn the ignition switch to the On position.
Check for battery voltage at the circuit breaker in
the junction block. If OK, turn the ignition switch to
the Off position and go to Step 3. If not OK, repair
the circuit to the ignition switch as required. Fig. 1 Power Window Switch Continuity -
(3) Disconnect and isolate the battery negative Driver Side Front
cable. Remove the power window switch unit from
the door trim panel. Unplug the wire harness connec-
tor from the switch unit.
8S - 4 POWER WINDOW SYSTEMS DN
DIAGNOSIS AND TESTING (Continued)
NOTE: Because this switch contains active elec- operation in the other direction. Remember, if the
tronic elements for the Auto-down feature, this window is in the full up or full down position, the
switch function cannot be checked with a continuity motor will not operate in that direction by design. If
test. If the problem being diagnosed involves this OK, repair the circuits from the power window motor
function, reconnect the switch to its wire harness to the power window switch as required. If not OK,
connector, connect the battery negative cable and replace the faulty motor.
turn the ignition switch to the On position. Back (3) If the motor operates in both directions, check
probe the wire harness connector cavity for switch the operation of the window glass and lift mechanism
pin number 8 and check for the proper switch out- through its complete up and down travel. There
put while actuating the switch. With the switch in should be no binding or sticking of the window glass
the Up position, there should be continuity to or lift mechanism through the entire travel range. If
ground at pin 8. With the switch in the Down posi- not OK, refer to Group 23 - Body to check the win-
tion, there should be battery voltage at pin 8. dow glass, tracks, and regulator for sticking, binding,
or improper adjustment.
REMOVAL AND INSTALLATION
POWER WINDOW SWITCH
DRIVER SIDE FRONT DOOR
(1) Disconnect and isolate the battery negative
cable.
(2) Remove the trim panel from the inside of the
driver side front door. Refer to Group 23 - Body for
the procedures.
(3) From the back side of the trim panel, remove
the screws that secure the power window and lock
switch unit to the switch bezel in the door trim panel
opening.
(4) Remove the power window and lock switch and
the switch bezel from the door trim panel.
(5) Reverse the removal procedures to install.
Tighten the mounting screws to 2.2 N◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
