Image preview - the first page of the document
>> Download 98DN_8T documenatation <<
Text preview - extract from the document
DN POWER MIRROR SYSTEMS 8T - 1
POWER MIRROR SYSTEMS
CONTENTS
page page
EXTERIOR MIRRORS . . . . . . . . . . . . . . . . . . . . . . 1 INTERIOR MIRRORS . . . . . . . . . . . . . . . . . . . . . . 4
EXTERIOR MIRRORS
INDEX
page page
GENERAL INFORMATION DIAGNOSIS AND TESTING
INTRODUCTION . . . . . . . . . . . .............. 1 POWER MIRROR SYSTEM . . . . . . . . . . . . . . . . . 1
POWER MIRROR SYSTEM . . . .............. 1 REMOVAL AND INSTALLATION
DESCRIPTION AND OPERATION POWER MIRROR . . . . . . . . . . . . . . . . . . . . . . . . . 3
POWER MIRROR . . . . . . . . . . . .............. 1 POWER MIRROR SWITCH . . . . . . . . . . . . . . . . . 2
POWER MIRROR SWITCH . . . .............. 1
GENERAL INFORMATION movement, and the other controls right-and-left
movement.
INTRODUCTION The power mirror assembly cannot be repaired. If
Power operated outside rear view mirrors are an any component of the power mirror unit is faulty or
available factory-installed option on this model. Refer damaged, the entire assembly must be replaced.
to 8W-62 - Power Mirrors in Group 8W - Wiring Dia-
grams for complete circuit descriptions and diagrams. POWER MIRROR SWITCH
Both the right and left power outside mirrors are
POWER MIRROR SYSTEM controlled by a single multi-function switch unit
The power operated outside rear view mirrors located on and mounted to the upper flag area of the
allow the driver to adjust both outside mirrors elec- driver side door trim panel. The switch knob is
trically from the driver seat position by operating a rotated clockwise (right mirror control), or counter-
switch on the driver side front door trim panel. The clockwise (left mirror control) to select the mirror to
power mirrors receive a non-switched battery feed be adjusted. The switch knob is then moved in a joy-
through a fuse in the junction block so that the sys- stick fashion to control movement of the selected mir-
tem will remain operational, regardless of the igni- ror up, down, right, or left.
tion switch position. The power mirror switch cannot be repaired and, if
Following are general descriptions of the major faulty or damaged, it must be replaced. The power
components in the power mirror system. Refer to the switch knob is available for service replacement.
owner's manual in the vehicle glove box for more
information on the features, use and operation of the
DIAGNOSIS AND TESTING
power mirror system.
POWER MIRROR SYSTEM
DESCRIPTION AND OPERATION For circuit descriptions and diagrams, refer to
8W-62 - Power Mirrors in Group 8W - Wiring Dia-
POWER MIRROR grams.
Each power mirror head contains two electric (1) Check the fuses in the Power Distribution Cen-
motors, two drive mechanisms, and the mirror glass. ter (PDC) and the junction block. If OK, go to Step 2.
One motor and drive controls mirror up-and-down
8T - 2 POWER MIRROR SYSTEMS DN
DIAGNOSIS AND TESTING (Continued)
If not OK, repair the shorted circuit or component as not respond as indicated in the chart, replace the
required and replace the faulty fuse(s). faulty power mirror assembly. If the power mirror(s)
(2) Check for battery voltage at the fuse in the do respond as indicated in the chart, repair the cir-
junction block. If OK, go to Step 3. If not OK, repair cuits between the power mirror and the power mirror
the open circuit to the PDC as required. switch for a short or open as required.
(3) Disconnect and isolate the battery negative
cable. Remove the driver side door trim panel and
unplug the wire harness connector from the power
mirror switch. Connect the battery negative cable.
Check for battery voltage at the fused B(+) circuit
cavity in the door wire harness half of the power mir-
ror switch wire harness connector. If OK, go to Step
4. If not OK, repair the open circuit to the junction
block as required.
(4) Disconnect and isolate the battery negative
cable. Check for continuity between the ground cir-
cuit cavity in the door wire harness half of the power
mirror switch wire harness connector and a good
ground. There should be continuity. If OK, go to Step
5. If not OK, repair the circuit to ground as required.
(5) Check the power mirror switch continuity as
shown in (Fig. 1). If OK, go to Step 6. If not OK, Fig. 2 Power Mirror Test
replace the faulty switch.
REMOVAL AND INSTALLATION
POWER MIRROR SWITCH
(1) Disconnect and isolate the battery negative
cable.
(2) Pull the power mirror switch control knob rear-
ward to remove it from the switch stem (Fig. 3).
Fig. 3 Power Mirror Switch Control Knob Remove/
Install - Typical
Fig. 1 Power Mirror Switch Continuity (3) Remove the nut that secures the power mirror
(6) Unplug the wire harness connector at the inop- switch to the driver side door trim panel (Fig. 4).
erative power mirror. Use two jumper wires, one con- (4) Remove the trim panel from the inside of the
nected to a 12-volt battery feed, and the other driver side front door. Refer to Group 23 - Body for
connected to a good body ground. See the Power Mir- the procedures.
ror Test chart for the correct jumper wire connections (5) Pull the trim panel away from the inner door
to the power mirror half of the power mirror wire panel far enough to access the power mirror switch
harness connector (Fig. 2). If the power mirror(s) do wire harness connector.
DN POWER MIRROR SYSTEMS 8T - 3
REMOVAL AND INSTALLATION (Continued)
POWER MIRROR
(1) Remove the trim panel from the inside of the
front door. Refer to Group 23 - Body for the proce-
dures.
(2) Remove the mirror flag seal from the inner
door panel (Fig. 6).
Fig. 4 Power Mirror Switch Nut - Typical Fig. 6 Mirror Flag Seal Remove/Install
(6) Unplug the power mirror switch wire harness (3) Unplug the wire harness connector from the
connector (Fig. 5). power mirror (Fig. 7).
Fig. 7 Power Mirror Remove/Install
(4) Remove the three nuts that secure the power
mirror to the inner door panel.
Fig. 5 Door Trim Panel Wire Harness Connectors (5) Unseat the power mirror wire harness grom-
(7) Remove the power mirror switch from the back met by pushing it out through the hole in the door
of the door trim panel. flag from the inside.
(8) Reverse the removal procedures to install. (6) Pull the mirror from the outside of the door
while feeding the wire harness, grommet, and con-
nector out through the hole from the inside of the
door.
(7) Reverse the removal procedures to install.
Tighten the mounting nuts to 7.5 N◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
