Image preview - the first page of the document
>> Download 98DN_8W documenatation <<
Text preview - extract from the document
DN WIRING DIAGRAMS 8W - 1
WIRING DIAGRAMS
CONTENTS
page page
AIR CONDITIONING/HEATER . . . . . . . . . . . 8W-42-1 OVERHEAD CONSOLE. . . . . . . . . . . . . . . . . 8W-49-1
AIRBAG SYSTEM . . . . . . . . . . . . . . . . . . . . 8W-43-1 POWER DISTRIBUTION . . . . . . . . . . . . . . . 8W-10-1
ALL-WHEEL ANTI-LOCK BRAKES. . . . . . . . 8W-35-1 POWER DOOR LOCKS . . . . . . . . . . . . . . . . 8W-61-1
AUDIO SYSTEM . . . . . . . . . . . . . . . . . . . . . 8W-47-1 POWER MIRRORS . . . . . . . . . . . . . . . . . . . 8W-62-1
CENTRAL TIMER MODULE. . . . . . . . . . . . . 8W-45-1 POWER SEAT . . . . . . . . . . . . . . . . . . . . . . . 8W-63-1
CHARGING SYSTEM . . . . . . . . . . . . . . . . . . 8W-20-1 POWER WINDOWS. . . . . . . . . . . . . . . . . . . 8W-60-1
COMPONENT INDEX . . . . . . . . . . . . . . . . . . 8W-02-1 REAR LIGHTING . . . . . . . . . . . . . . . . . . . . . 8W-51-1
CONNECTOR LOCATIONS . . . . . . . . . . . . . . 8W-90-1 REAR WHEEL ANTI-LOCK BRAKES . . . . . . 8W-34-1
CONNECTOR PIN-OUTS . . . . . . . . . . . . . . . 8W-80-1 REAR WINDOW DEFOGGER. . . . . . . . . . . . 8W-48-1
FRONT LIGHTING . . . . . . . . . . . . . . . . . . . . 8W-50-1 SPLICE INFORMATION . . . . . . . . . . . . . . . . 8W-70-1
FUEL/IGNITION SYSTEMS . . . . . . . . . . . . . 8W-30-1 SPLICE LOCATIONS . . . . . . . . . . . . . . . . . . 8W-95-1
FUSE/FUSE BLOCK . . . . . . . . . . . . . . . . . . . 8W-11-1 STARTING SYSTEM . . . . . . . . . . . . . . . . . . 8W-21-1
GENERAL INFORMATION . . . . . . . . . . . . . . 8W-01-1 TRAILER TOW. . . . . . . . . . . . . . . . . . . . . . . 8W-54-1
GROUND DISTRIBUTION . . . . . . . . . . . . . . 8W-15-1 TRANSMISSION CONTROL SYSTEM . . . . . 8W-31-1
HORN/CIGAR LIGHTER/POWER OUTLET . . 8W-41-1 TURN SIGNALS. . . . . . . . . . . . . . . . . . . . . . 8W-52-1
INSTRUMENT CLUSTER . . . . . . . . . . . . . . . 8W-40-1 VEHICLE SPEED CONTROL . . . . . . . . . . . . 8W-33-1
INTERIOR LIGHTING. . . . . . . . . . . . . . . . . . 8W-44-1 VEHICLE THEFT SECURITY SYSTEM . . . . . 8W-39-1
JUNCTION BLOCK. . . . . . . . . . . . . . . . . . . . 8W-12-1 WIPERS. . . . . . . . . . . . . . . . . . . . . . . . . . . . 8W-53-1
DN 8W - 01 GENERAL INFORMATION 8W - 01 - 1
8W-01 GENERAL INFORMATION
INDEX
page page
DESCRIPTION AND OPERATION TROUBLESHOOTING TOOLS . . . . . . . . . . . . . . . . 8
CIRCUIT FUNCTIONS . . . . . . . . . . . . . . . . . . ....4 TROUBLESHOOTING WIRING PROBLEMS . . . . . 10
CIRCUIT INFORMATION . . . . . . . . . . . . . . . . ....4 SERVICE PROCEDURES
CONNECTOR INFORMATION . . . . . . . . . . . . ....7 CONNECTOR AND TERMINAL
ELECTROSTATIC DISCHARGE (ESD) REPLACEMENT . . . . . . . . . . . . . . . . . . . . . . . . 12
SENSITIVE DEVICES . . . . . . . . . . . . . . . . . . . . .8 CONNECTOR REPLACEMENT. . . . . . . . . . . . . . . 11
INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . .1 DIODE REPLACEMENT . . . . . . . . . . . . . . . . . . . . 14
NOTES, CAUTIONS, and WARNINGS . . . . . . . . . .7 TERMINAL REPLACEMENT . . . . . . . . . . . . . . . . . 13
SECTION IDENTIFICATION . . . . . . . . . . . . . . . . . .5 TERMINAL/CONNECTOR REPAIR-MOLEX
SPLICE LOCATIONS . . . . . . . . . . . . . . . . . . . . . . .7 CONNECTORS . . . . . . . . . . . . . . . . . . . . . . . . . 11
SYMBOLS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 TERMINAL/CONNECTOR REPAIR--THOMAS
TAKE OUTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 AND BETTS CONNECTORS . . . . . . . . . . . . . . . 11
DIAGNOSIS AND TESTING WIRING REPAIR . . . . . . . . . . . . . . . . . . . . . . . . . 10
INTERMITTENT AND POOR CONNECTIONS. ....8 SPECIAL TOOLS
TROUBLESHOOTING TESTS . . . . . . . . . . . . ....9 WIRING/TERMINAL . . . . . . . . . . . . . . . . . . . . . . . 14
DESCRIPTION AND OPERATION Components are shown two ways. A solid line
around a component indicates that the component is
INTRODUCTION complete. A dashed line around a component indi-
Chrysler wiring diagrams are designed to provide cates that the component being shown is not com-
information regarding the vehicles wiring content. In plete. Incomplete components have a reference
order to effectively use Chrysler wiring diagrams to number to indicate the page where the component is
diagnose and repair a Chrysler vehicle, it is impor- shown complete.
tant to understand all of their features and charac- It is important to realize that no attempt is made
teristics. on the diagrams to represent components and wiring
Diagrams are arranged such that the power (B+) as they appear on the vehicle. For example, a short
side of the circuit is placed near the top of the page, piece of wire is treated the same as a long one. In
and the ground (B-) side of the circuit is placed near addition, switches and other components are shown
the bottom of the page. as simply as possible, with regard to function only.
All switches, components, and modules are shown
in the at rest position with the doors closed and the
key removed from the ignition.
8W - 01 - 2 8W - 01 GENERAL INFORMATION DN
DESCRIPTION AND OPERATION (Continued)
DN 8W - 01 GENERAL INFORMATION 8W - 01 - 3
DESCRIPTION AND OPERATION (Continued)
8W - 01 - 4 8W - 01 GENERAL INFORMATION DN
DESCRIPTION AND OPERATION (Continued)
CIRCUIT INFORMATION CIRCUIT FUNCTIONS
Each wire shown in the diagrams contains a code All circuits in the diagrams use an alpha/numeric
which identifies the main circuit, part of the main code to identify the wire and its function. To identify
circuit, gage of wire, and color (Fig. 1). which circuit code applies to a system, refer to the
Circuit Identification Code Chart. This chart shows
the main circuits only and does not show the second-
ary codes that may apply to some models.
CIRCUIT FUNCTION
A BATTERY FEED
B BRAKE CONTROLS
C CLIMATE CONTROLS
D DIAGNOSTIC CIRCUITS
E DIMMING ILLUMINATION CIRCUITS
F FUSED CIRCUITS
G MONITORING CIRCUITS (GAUGES)
H OPEN
I NOT USED
Fig. 1 Wire Code Identification J OPEN
STANDARD K POWERTRAIN CONTROL MODULE
COLOR CODE COLOR TRACER L EXTERIOR LIGHTING
COLOR M INTERIOR LIGHTING
BL BLUE WT N NOT USED
BK BLACK WT O NOT USED
BR BROWN WT P POWER OPTION (BATTERY FEED)
DB DARK BLUE WT Q POWER OPTIONS (IGNITION FEED)
DG DARK GREEN WT R PASSIVE RESTRAINT
GY GRAY BK S SUSPENSION/STEERING
LB LIGHT BLUE BK T TRANSMISSION/TRANSAXLE/
LG LIGHT GREEN BK TRANSFER CASE
OR ORANGE BK U OPEN
PK PINK BK or WT V SPEED CONTROL, WIPER/WASHER
RD RED WT W OPEN
TN TAN WT X AUDIO SYSTEMS
VT VIOLET WT Y OPEN
WT WHITE BK Z GROUNDS
YL YELLOW BK
* WITH TRACER
DN 8W - 01 GENERAL INFORMATION 8W - 01 - 5
DESCRIPTION AND OPERATION (Continued)
SECTION IDENTIFICATION GROUP TOPIC
The wiring diagrams are grouped into individual
8W-01 thru 8W-09 General Information and
sections. If a component is most likely found in a par-
Diagram Overview
ticular group, it will be shown complete (all wires,
connectors, and pins) within that group. For exam- 8W-10 thru 8W-19 Main Sources of Power and
ple, the Auto Shutdown Relay is most likely to be Vehicle Grounding
found in Group 30, so it is shown there complete. It 8W-20 thru 8W-29 Starting and Charging
can, however, be shown partially in another group if 8W-30 thru 8W-39 Powertrain/Drivetrain
it contains some associated wiring. Systems
SYMBOLS 8W-40 thru 8W-49 Body Electrical items and A/C
International symbols are used throughout the wir- 8W-50 thru 8W-59 Exterior Lighting, Wipers, and
ing diagrams. These symbols are consistent with Trailer Tow
those being used around the world 8W-60 thru 8W-69 Power Accessories
8W-70 Splice Information
8W-80 Connector Pin Outs
8W-90 Connector Locations
(including grounds)
8W-95 Splice Locations
8W - 01 - 6 8W - 01 GENERAL INFORMATION DN
DESCRIPTION AND OPERATION (Continued)
Wiring Diagram Symbols
DN 8W - 01 GENERAL INFORMATION 8W - 01 - 7
DESCRIPTION AND OPERATION (Continued)
CONNECTOR INFORMATION Section 8W-80 shows each connector and the cir-
cuits involved with that connector. The connectors
CAUTION: Not all connectors are serviced. Some are identified using the name/number on the Dia-
connectors are serviced only with a harness. A typ- gram pages.
ical example might be the Supplemental Restraint
System connectors. Always check parts availability SPLICE LOCATIONS
before attempting a repair. Splice Location charts in Section 8W-70 show the
entire splice, and provide references to other sections
the splice serves.
IDENTIFICATION Section 8W-95 contains illustrations that show the
In-line connectors are identified by a number, as general location of the splices in each harness. The
follows: illustrations show the splice by number, and provide
