Image preview - the first page of the document
00dn_11


>> Download 00dn_11 documenatation <<

Text preview - extract from the document
DN                                                                                                             EXHAUST SYSTEM                  11 - 1



                                                    EXHAUST SYSTEM
                                                        TABLE OF CONTENTS

                                                                    page                                                                         page

DESCRIPTION AND OPERATION                                                     REMOVAL AND INSTALLATION
  EXHAUST SYSTEM. . . . . . . . . . . . . . . . . . . . . . . . 1              EXHAUST PIPE . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
  CATALYTIC CONVERTER. . . . . . . . . . . . . . . . . . . . 2                 CATALYTIC CONVERTER. . . . . . . . . . . . . . . . . . . . 5
  EXHAUST PIPE . . . . . . . . . . . . . . . . . . . . . . . . . . . 2         MUFFLER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
  MUFFLER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2      TAILPIPE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
  TAILPIPE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3    HEAT SHIELDS . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
  HEAT SHIELDS . . . . . . . . . . . . . . . . . . . . . . . . . . . 3        SPECIFICATIONS
DIAGNOSIS AND TESTING                                                          TORQUE SPECIFICATIONS . . . . . . . . . . . . . . . . . . 8
  EXHAUST SYSTEM. . . . . . . . . . . . . . . . . . . . . . . . 4

DESCRIPTION AND OPERATION                                                     converter(s), extension pipe (if needed), exhaust heat
                                                                              shields, muffler and exhaust tailpipe (Fig. 1).
EXHAUST SYSTEM                                                                  The exhaust system must be properly aligned to
                                                                              prevent stress, leakage and body contact. Minimum
DESCRIPTION                                                                   clearance between any exhaust component and the
                                                                              body or frame is 25.4 mm (1.0 in.). If the system con-
CAUTION: Avoid application of rust prevention                                 tacts any body panel, it may amplify objectionable
compounds or undercoating materials to exhaust                                noises from the engine or body.
system floor pan exhaust heat shields. Light over-
spray near the edges is permitted. Application of                             OPERATION
coating will result in excessive floor pan tempera-                             The exhaust system channels exhaust gases from
tures and objectionable fumes.                                                the engine and away from the vehicle.

  The gasoline engine exhaust system consists of
engine exhaust manifolds, exhaust pipes, catalytic




                                  Fig. 1 Exhaust System 4.7L, 5.2L and 5.9L Engines--Typical
1
