Image preview - the first page of the document



>> Download 00dn_8O documenatation <<

Text preview - extract from the document

DN                                                                              POWER DISTRIBUTION SYSTEMS                   8O - 1



                             POWER DISTRIBUTION SYSTEMS
                                                TABLE OF CONTENTS

                                                           page                                                                page

DESCRIPTION AND OPERATION                                           REMOVAL AND INSTALLATION
 POWER DISTRIBUTION SYSTEM. . . . . . . . . . . . . 1                POWER DISTRIBUTION CENTER . . . . . . . . . . . . . 4
 POWER DISTRIBUTION CENTER . . . . . . . . . . . . . 1               GENERATOR CARTRIDGE FUSE . . . . . . . . . . . . . . 6
 GENERATOR CARTRIDGE FUSE . . . . . . . . . . . . . . 2              JUNCTION BLOCK . . . . . . . . . . . . . . . . . . . . . . . . 6
 JUNCTION BLOCK . . . . . . . . . . . . . . . . . . . . . . . . 2    IGNITION-OFF DRAW FUSE . . . . . . . . . . . . . . . . . 7
 IGNITION-OFF DRAW FUSE . . . . . . . . . . . . . . . . . 3          RELAY AND FUSE BLOCK . . . . . . . . . . . . . . . . . . 8
 RELAY AND FUSE BLOCK . . . . . . . . . . . . . . . . . . 4

DESCRIPTION AND OPERATION                                           electrical distribution points for the vehicle techni-
                                                                    cian to use when conducting diagnosis and repair of
POWER DISTRIBUTION SYSTEM                                           faulty circuits. The power distribution system can
                                                                    also prove useful for the sourcing of additional elec-
DESCRIPTION                                                         trical circuits that may be required to provide the
   This group covers the various standard and                       electrical current needed to operate many accessories
optional power distribution components used on this                 that the vehicle owner may choose to have installed
model. The power distribution system for this vehicle               in the aftermarket.
consists of the following components:
