Image preview - the first page of the document
>> Download 00dn_8A documenatation <<
Text preview - extract from the document
DN BATTERY 8A - 1
BATTERY
TABLE OF CONTENTS
page page
DESCRIPTION AND OPERATION REMOVAL AND INSTALLATION
BATTERY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 BATTERY HOLD DOWNS . . . . . . . . . . . . . . . . . . 18
BATTERY CABLES . . . . . . . . . . . . . . . . . . . . . . . . 3 BATTERY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
BATTERY HOLD DOWNS . . . . . . . . . . . . . . . . . . . 4 BATTERY TRAY. . . . . . . . . . . . . . . . . . . . . . . . . . 20
BATTERY TRAY. . . . . . . . . . . . . . . . . . . . . . . . . . . 4 CLEANING AND INSPECTION
DIAGNOSIS AND TESTING BATTERY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
BATTERY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 SPECIFICATIONS
BATTERY CABLES . . . . . . . . . . . . . . . . . . . . . . . 14 BATTERY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
SERVICE PROCEDURES
BATTERY CHARGING . . . . . . . . . . . . . . . . . . . . . 16
DESCRIPTION AND OPERATION A large capacity, maintenance-free storage battery
(Fig. 1) is standard factory-installed equipment on
BATTERY this model. Male post type terminals made of a soft
lead material protrude from the top of the molded
DESCRIPTION plastic battery case to provide the means for connect-
ing the battery to the vehicle electrical system. The
battery positive terminal post is visibly larger in
diameter than the negative terminal post, for easy
identification. The letters POS and NEG are also
molded into the top of the battery case adjacent to
their respective positive and negative terminal posts
for additional identification confirmation. Refer to
Battery Cables in the index of this service manual
for the location of more information on the battery
cables that connect the battery to the vehicle electri-
cal system.
This battery is designed to provide a safe, efficient
and reliable means of storing electrical energy in a
chemical form. This means of energy storage allows
the battery to produce the electrical energy required
to operate the engine starting system, as well as to
operate many of the other vehicle accessory systems
for limited durations while the engine and/or the
charging system are not operating. The battery is
made up of six individual cells that are connected in
series. Each cell contains positively charged plate
Fig. 1 Maintenance-Free Battery - Typical groups that are connected with lead straps to the
