>> Download 00dn_8F documenatation <<Text preview - extract from the documentDN AUDIO SYSTEMS 8F - 1
AUDIO SYSTEMS
TABLE OF CONTENTS
page page
DESCRIPTION AND OPERATION POWER AMPLIFIER . . . . . . . . . . . . . . . . . . . . . . . 8
AUDIO SYSTEM . . . . . . . . . . . . . . . . . . . . . . . . . . 1 ANTENNA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
RADIO RECEIVER . . . . . . . . . . . . . . . . . . . . . . . . . 2 RADIO FREQUENCY INTERFERENCE . . . . . . . . . . 9
REMOTE RADIO SWITCH. . . . . . . . . . . . . . . . . . . 2 REMOVAL AND INSTALLATION
SPEAKER SYSTEM . . . . . . . . . . . . . . . . . . . . . . . . 3 RADIO RECEIVER . . . . . . . . . . . . . . . . . . . . . . . . 10
POWER AMPLIFIER . . . . . . . . . . . . . . . . . . . . . . . 3 REMOTE RADIO SWITCH. . . . . . . . . . . . . . . . . . 11
ANTENNA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 SPEAKER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
RADIO NOISE SUPPRESSION . . . . . . . . . . . . . . . 4 POWER AMPLIFIER . . . . . . . . . . . . . . . . . . . . . . 14
DIAGNOSIS AND TESTING ANTENNA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
AUDIO SYSTEM . . . . . . . . . . . . . . . . . . . . . . . . . . 4 RADIO NOISE SUPPRESSION COMPONENTS . . 17
RADIO RECEIVER . . . . . . . . . . . . . . . . . . . . . . . . . 6 SPECIAL TOOLS
REMOTE RADIO SWITCH. . . . . . . . . . . . . . . . . . . 6 AUDIO SYSTEMS . . . . . . . . . . . . . . . . . . . . . . . . 20
SPEAKER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
DESCRIPTION AND OPERATION Operation section of Group 8E - Instrument Panel
Systems for more information on this component.
AUDIO SYSTEM Refer to Audio System in the Contents of Group 8W
- Wiring Diagrams for complete circuit diagrams. Fol-
DESCRIPTION lowing are general descriptions of the remaining
An audio system is standard factory-installed major components in the standard and optional fac-
equipment on this model, unless the vehicle is tory-installed audio systems.
ordered with an available radio delete option. The
standard equipment audio system includes an OPERATION
AM/FM/cassette (RAS sales code) receiver, and See the owner's manual in the vehicle glove box for
speakers in four locations. Several combinations of more information on the features, use and operation
radio receivers and speaker systems are offered as of each of the available audio systems.
optional equipment on this model. The audio system
CENTRAL TIMER MODULE
uses an ignition switched source of battery current so
that the system will only operate when the ignition The high-line Central Timer Module (CTM) can
switch is in the On or Accessory positions. The audio also control some features of the audio system when
system includes the following components: the vehicle is equipped with the optional RAZ radio
