Image preview - the first page of the document
>> Download 00dn_8W documenatation <<
Text preview - extract from the document
DN WIRING DIAGRAMS 8W - 1
WIRING DIAGRAMS
CONTENTS
page page
AIR CONDITIONING/HEATER . . . . . . . . . . . 8W-42-1 OVERHEAD CONSOLE. . . . . . . . . . . . . . . . . 8W-49-1
AIRBAG SYSTEM . . . . . . . . . . . . . . . . . . . . 8W-43-1 POWER DISTRIBUTION . . . . . . . . . . . . . . . 8W-10-1
ALL-WHEEL ANTI-LOCK BRAKES. . . . . . . . 8W-35-1 POWER DOOR LOCKS . . . . . . . . . . . . . . . . 8W-61-1
AUDIO SYSTEM . . . . . . . . . . . . . . . . . . . . . 8W-47-1 POWER MIRRORS . . . . . . . . . . . . . . . . . . . 8W-62-1
CENTRAL TIMER MODULE. . . . . . . . . . . . . 8W-45-1 POWER SEAT . . . . . . . . . . . . . . . . . . . . . . . 8W-63-1
CHARGING SYSTEM . . . . . . . . . . . . . . . . . . 8W-20-1 POWER WINDOWS. . . . . . . . . . . . . . . . . . . 8W-60-1
COMPONENT INDEX . . . . . . . . . . . . . . . . . . 8W-02-1 REAR LIGHTING . . . . . . . . . . . . . . . . . . . . . 8W-51-1
CONNECTOR LOCATIONS . . . . . . . . . . . . . . 8W-90-1 REAR WHEEL ANTI-LOCK BRAKES . . . . . . 8W-34-1
CONNECTOR PIN-OUTS . . . . . . . . . . . . . . . 8W-80-1 REAR WINDOW DEFOGGER. . . . . . . . . . . . 8W-48-1
FRONT LIGHTING . . . . . . . . . . . . . . . . . . . . 8W-50-1 SPLICE INFORMATION . . . . . . . . . . . . . . . . 8W-70-1
FUEL/IGNITION SYSTEMS . . . . . . . . . . . . . 8W-30-1 SPLICE LOCATIONS . . . . . . . . . . . . . . . . . . 8W-95-1
FUSE/RELAY BLOCK . . . . . . . . . . . . . . . . . . 8W-11-1 STARTING SYSTEM . . . . . . . . . . . . . . . . . . 8W-21-1
GENERAL INFORMATION . . . . . . . . . . . . . . 8W-01-1 TRAILER TOW. . . . . . . . . . . . . . . . . . . . . . . 8W-54-1
GROUND DISTRIBUTION . . . . . . . . . . . . . . 8W-15-1 TRANSMISSION CONTROL SYSTEM . . . . . 8W-31-1
HORN/CIGAR LIGHTER/POWER OUTLET . . 8W-41-1 TURN SIGNALS. . . . . . . . . . . . . . . . . . . . . . 8W-52-1
INSTRUMENT CLUSTER . . . . . . . . . . . . . . . 8W-40-1 VEHICLE SPEED CONTROL . . . . . . . . . . . . 8W-33-1
INTERIOR LIGHTING. . . . . . . . . . . . . . . . . . 8W-44-1 VEHICLE THEFT SECURITY SYSTEM . . . . . 8W-39-1
JUNCTION BLOCK. . . . . . . . . . . . . . . . . . . . 8W-12-1 WIPERS. . . . . . . . . . . . . . . . . . . . . . . . . . . . 8W-53-1
DN 8W - 01 GENERAL INFORMATION 8W - 01 - 1
8W-01 GENERAL INFORMATION
INDEX
page page
DESCRIPTION AND OPERATION TROUBLESHOOTING WIRING PROBLEMS . . . . . . 9
CIRCUIT FUNCTIONS . . . . . . . . . . . . . . . . . . ....4 SERVICE PROCEDURES
CIRCUIT INFORMATION . . . . . . . . . . . . . . . . ....4 CONNECTOR AND TERMINAL
CONNECTOR INFORMATION . . . . . . . . . . . . ....7 REPLACEMENT . . . . . . . . . . . . . . . . . . . . . . . . 12
ELECTROSTATIC DISCHARGE (ESD) CONNECTOR REPLACEMENT . . . . . . . . . . . . . . 12
SENSITIVE DEVICES . . . . . . . . . . . . . . . . . . . . .8 DIODE REPLACEMENT . . . . . . . . . . . . . . . . . . . . 14
INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . .1 TERMINAL REPLACEMENT . . . . . . . . . . . . . . . . . 13
NOTES, CAUTIONS, and WARNINGS . . . . . . . . . .7 TERMINAL/CONNECTOR REPAIR- AUGAT
SECTION IDENTIFICATION . . . . . . . . . . . . . . . . . .5 CONNECTORS . . . . . . . . . . . . . . . . . . . . . . . . . 11
SPLICE LOCATIONS . . . . . . . . . . . . . . . . . . . . . . .7 TERMINAL/CONNECTOR REPAIR-MOLEX
SYMBOLS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 CONNECTORS . . . . . . . . . . . . . . . . . . . . . . . . . 10
TAKE OUTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 TERMINAL/CONNECTOR REPAIR--THOMAS
DIAGNOSIS AND TESTING AND BETTS CONNECTORS . . . . . . . . . . . . . . . 10
INTERMITTENT AND POOR CONNECTIONS. ....8 WIRING REPAIR . . . . . . . . . . . . . . . . . . . . . . . . . 10
TROUBLESHOOTING TESTS . . . . . . . . . . . . ....9 SPECIAL TOOLS
TROUBLESHOOTING TOOLS . . . . . . . . . . . . ....8 WIRING/TERMINAL . . . . . . . . . . . . . . . . . . . . . . . 15
DESCRIPTION AND OPERATION Components are shown two ways. A solid line
around a component indicates that the component is
INTRODUCTION complete. A dashed line around a component indi-
DaimlerChrysler wiring diagrams are designed to cates that the component being shown is not com-
provide information regarding the vehicles wiring plete. Incomplete components have a reference
content. In order to effectively use DaimlerChrysler number to indicate the page where the component is
wiring diagrams to diagnose and repair a Daimler- shown complete.
Chrysler vehicle, it is important to understand all of It is important to realize that no attempt is made
their features and characteristics. on the diagrams to represent components and wiring
Diagrams are arranged such that the power (B+) as they appear on the vehicle. For example, a short
side of the circuit is placed near the top of the page, piece of wire is treated the same as a long one. In
and the ground (B-) side of the circuit is placed near addition, switches and other components are shown
the bottom of the page. as simply as possible, with regard to function only.
All switches, components, and modules are shown
in the at rest position with the doors closed and the
key removed from the ignition.
8W - 01 - 2 8W - 01 GENERAL INFORMATION DN
DESCRIPTION AND OPERATION (Continued)
Wiring Diagram Example No.1
DN 8W - 01 GENERAL INFORMATION 8W - 01 - 3
DESCRIPTION AND OPERATION (Continued)
Wiring Diagram Example No.2
8W - 01 - 4 8W - 01 GENERAL INFORMATION DN
DESCRIPTION AND OPERATION (Continued)
CIRCUIT INFORMATION CIRCUIT FUNCTIONS
Each wire shown in the diagrams contains a code All circuits in the diagrams use an alpha/numeric
which identifies the main circuit, part of the main code to identify the wire and its function. To identify
circuit, gage of wire, and color (Fig. 1). which circuit code applies to a system, refer to the
Circuit Identification Code Chart. This chart shows
the main circuits only and does not show the second-
ary codes that may apply to some models.
CIRCUIT IDENTIFICATION CODE CHART
CIRCUIT FUNCTION
A BATTERY FEED
B BRAKE CONTROLS
C CLIMATE CONTROLS
D DIAGNOSTIC CIRCUITS
E DIMMING ILLUMINATION CIRCUITS
F FUSED CIRCUITS
G MONITORING CIRCUITS (GAUGES)
Fig. 1 Wire Code Identification H OPEN
