Image preview - the first page of the document
epl_8ea


>> Download epl_8ea documenatation <<

Text preview - extract from the document
PL                                                                          INSTRUMENT PANEL AND SYSTEMS                  8E - 1



                           INSTRUMENT PANEL AND SYSTEMS
                                                           CONTENTS

                                                             page                                                          page

DIAGNOSIS AND TESTING                                                   FRONT FOG LAMP SWITCH . . . . . . . . . . . . . . 2
  FOG LAMP SWITCH TEST . . . . . . . . . . . . . . . .            1     HEADLAMP LEVELING SWITCH . . . . . . . . . . . 3
  HEADLAMP LEVELING SWITCH . . . . . . . . . . .                  1     REAR WINDOW DEFOGGER AND/OR REAR
  INSTRUMENT PANEL AND COMPONENTS . . .                           2       FOG LAMP SWITCH . . . . . . . . . . . . . . . . . . . 3
REMOVAL AND INSTALLATION
  END CAP RHD . . . . . . . . . . . . . . . . . . . . . . . . .   2

DIAGNOSIS AND TESTING                                                   (4) Push the fog lamp switch button. The test lamp
                                                                      should illuminate, and the LED indicator on the
FOG LAMP SWITCH TEST                                                  front of the switch.
   Refer to Group 8W, Wiring Diagrams for wiring or                     (5) If either the LED, or the test lamp fails to illu-
circuit information.                                                  minate, replace the switch.

FRONT
  (1) Remove the fog lamp switch and disconnect the
connector at the center stack.
  (2) Using two jumper wires connect Pin L7 to bat-
tery voltage, and connect Pin Z03 to ground (Fig. 1).
  (3) Push the fog lamp switch button. The LED
indicator on the front of the switch should illuminate.
Check Pin L35 with a test lamp for battery voltage.
  (4) If either the LED or the test lamp fails to illu-
minate, replace the switch.



                                                                                Fig. 2 Rear Fog Lamp Switch Test
                                                                      HEADLAMP LEVELING SWITCH
                                                                        (1) Remove the headlamp leveling switch from the
                                                                      instrument panel and disconnect the wire harness
                                                                      connector from the switch. Refer to Wiring Diagrams
                                                                      for the proper wire circuits and the wire connector
                                                                      connections.
                                                                        (2) If the L.E.D. is not illuminated, using a voltme-
                                                                      ter, connect B+ lead to Pin 4 of the Wire harness con-
                                                                      nector. Connect the negative lead to Pin 3. Turn ON
                                                                      the headlamp switch to the low beam position and
    Fig. 1 Front Fog Lamp Switch Circuit Diagram
                                                                      ensure the instrument panel dimmer switch is on
REAR                                                                  day light driving position. If voltage is present,
  (1) Remove the fog lamp switch. Refer to Rear                       replace switch. If no voltage, connect the ground lead
Window Defogger and/or Fog Lamp Switch Removal.                       to a good ground, if voltage, repair Pin 3 ground cir-
  (2) Using two jumper wires connect Pin 2 and Pin                    cuit as necessary, and if no voltage, refer to Wiring
4 of the switch to battery voltage.                                   Diagrams and test circuit back to headlamp switch.
  (3) Using a test lamp, connect the test lamp to Pin                   (3) Using a voltmeter, connect B+ lead to Pin 2 of
3 as shown in (Fig. 2). Refer to Group 8W, Wiring                     the Wire harness connector. Connect the negative
Diagrams for fog lamp switch circuit.                                 lead to Pin 3. Turn ON the headlamp switch to the
                                                                      low beam position. If battery voltage, go to Step 5. If
                                                                      not OK, go to Step 4.
8E - 2   INSTRUMENT PANEL AND SYSTEMS                                                                        PL
DIAGNOSIS AND TESTING (Continued)
  (4) Connect the ground lead to a good ground, if no      (3) Remove the end cap
voltage, refer to Wiring Diagrams and test circuit
back to headlamp switch. If battery voltage, repair      Installation
Pin 3 ground circuit as necessary.                         For installation, reverse the above procedures.
  (5) Turn headlamps OFF. Connect the wire har-
ness connector to the headlamp leveling switch. Turn     FRONT FOG LAMP SWITCH
ON the headlamp switch to the low beam position.
Check voltage at Pin 5, while rotating the headlamp      REMOVAL
leveling switch knob through the four positions. The       (1) Disconnect the wire connector in the center
voltage reading should change as the switch is           stack, BUX left side and RHD right side.
rotated to each position. If the voltage does not vary     (2) Remove the floor console and disconnect the
replace switch. If OK, test the headlamp leveling        two clips attaching the wire harness from the under-
motors and/or circuit to the motors.                     side of the floor console.
                                                           (3) Remove the switch bezel and wiring harness
                                                         assembly from the floor console (Fig. 4).

                                                         INSTALLATION
                                                           For installation, reverse the above procedures.




 Fig. 3 Headlamp Leveling Switch Circuit Diagram
INSTRUMENT PANEL AND COMPONENTS
CAUTION: Disconnect the battery negative cable
before servicing the instrument panel or compo-                     Fig. 4 Front Fog Lamp Switch
nents. When power is required for test purposes,
connect battery cable for test only. Disconnect the
battery negative cable after test and before continu-
ing service procedures.



REMOVAL AND INSTALLATION

END CAP RHD
Removal
  (1) Unlatch the glove box door and lower is to the
full open position.
  (2) Remove the left trim panel as necessary to
remove the end cap attaching screws.
PL                                                          INSTRUMENT PANEL AND SYSTEMS              8E - 3
REMOVAL AND INSTALLATION (Continued)
HEADLAMP LEVELING SWITCH                              REAR WINDOW DEFOGGER AND/OR REAR FOG
                                                      LAMP SWITCH
REMOVAL
  (1) Remove the top cover and cluster bezel assem-   REMOVAL
bly.                                                    (1) Remove the top cover and cluster bezel assem-
  (2) Disengage the headlamp leveling switch bezel    bly. Refer to Top Cover and Cluster Bezel Removal
from instrument panel (Fig. 5).                       above.
  (3) Pull the switch and bezel rearward from the       (2) Reach in and disengage the bezel latches and
opening and disconnect the wire connector.            remove the switch assembly (Fig. 6).
                                                        (3) Pull the bezel and switch(s) rearward from the
INSTALLATION                                          opening and disconnect the wire connector(s).
  For installation, reverse the above procedures.       (4) If either switch is defective, replace the entire
                                                      switch assembly.

                                                      INSTALLATION
                                                        For installation, reverse the above procedures.




          Fig. 5 Headlamp Leveling Switch




                                                       Fig. 6 Rear Window Defogger and Rear Fog Lamp
                                                                           Switch
