Image preview - the first page of the document
>> Download EXT documenatation <<
Text preview - extract from the document
BODY EXTERIOR, DOORS, ROOF & VEHICLE SECURITY
A
SECTION EXT EXTERIOR
B
C
D
E
CONTENTS
SYMPTOM DIAGNOSIS .............................. 3
. FENDER PROTECTOR .................................... 25 F
SQUEAK AND RATTLE TROUBLE DIAG- FENDER PROTECTOR ............................................25 .
NOSES ............................................................... 3
. FENDER PROTECTOR : Exploded View ..............25 .
G
Work Flow ................................................................ 3
. FENDER PROTECTOR : Removal and Installa-
Inspection Procedure ............................................... 5
. tion ..........................................................................25
.
Diagnostic Worksheet .............................................. 7
.
REAR WHEEL HOUSE PROTECTOR .....................26 . H
PRECAUTION .............................................. 9
. REAR WHEEL HOUSE PROTECTOR : Exploded
View ........................................................................27
.
PRECAUTIONS .................................................. 9
. REAR WHEEL HOUSE PROTECTOR : Removal
I
Precaution for Supplemental Restraint System and Installation .......................................................27
.
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" .................................................................. 9
.
CENTER MUD GUARD ..................................... 29
Exploded View ........................................................29
. J
Precaution Necessary for Steering Wheel Rota-
tion after Battery Disconnect .................................... 9. Removal and Installation ........................................29
.
Precaution for Procedure without Cowl Top Cover 10 .... FLOOR SIDE FAIRING ..................................... 31
Precaution for Work ............................................... 10
. EXT
Exploded View ........................................................31
.
Removal and Installation ........................................31
.
PREPARATION .......................................... 11
.
FILLET MOLDING ............................................. 32 L
PREPARATION .................................................11
.
Exploded View ........................................................32
.
Special Service Tools ............................................. 11
.
Removal and Installation ........................................32
.
Commercial Service Tools .................................... 11
.
ROOF RAIL ....................................................... 34 M
ON-VEHICLE REPAIR ................................ 12
. Exploded View ........................................................34
.
FRONT BUMPER ..............................................12
. Removal and Installation ........................................34
.
Exploded View ....................................................... 12
. N
ROOF SIDE MOLDING ..................................... 37
Removal and Installation ........................................ 13
.
Exploded View ........................................................37
.
REAR BUMPER ................................................16
. Removal and Installation ........................................37
.
O
Exploded View ....................................................... 16
. DOOR SASH MOLDING ................................... 39
Removal and Installation ........................................ 17
.
Exploded View ........................................................39
.
FRONT GRILLE ................................................20
. Removal and Installation ........................................39
. P
Exploded View ....................................................... 20
. DOOR OUTSIDE MOLDING ............................. 41
Removal and Installation ........................................ 20
.
Exploded View ........................................................41
.
COWL TOP ........................................................22
. Removal and Installation ........................................41
.
Exploded View ....................................................... 22
. DOOR OUTSIDE LOWER MOLDING ............... 44
Removal and Installation ........................................ 23
. Exploded View ........................................................44
.
Revision: 2007 November EXT-1 2008 EX35
Removal and Installation ....................................... 44
. BACK DOOR FINISHER .................................. 48
.
Exploded View ....................................................... 48
.
DOOR PARTING SEAL .................................... 46
. Removal and Installation ........................................ 48
.
Exploded View ....................................................... 46
.
Removal and Installation ....................................... 46
.
Revision: 2007 November EXT-2 2008 EX35
SQUEAK AND RATTLE TROUBLE DIAGNOSES
< SYMPTOM DIAGNOSIS >
SYMPTOM DIAGNOSIS A
SQUEAK AND RATTLE TROUBLE DIAGNOSES
Work Flow INFOID:0000000003134274
B
C
D
E
F
G
SBT842
CUSTOMER INTERVIEW H
Interview the customer if possible, to determine the conditions that exist when the noise occurs. Use the Diag-
nostic Worksheet during the interview to document the facts and conditions when the noise occurs and any of
customer's comments; refer to EXT-7, "Diagnostic Worksheet". This information is necessary to duplicate the
conditions that exist when the noise occurs. I
