Image preview - the first page of the document
>> Download SE documenatation <<
Text preview - extract from the document
BODY INTERIOR
A
SECTION SE SEAT
B
C
D
E
CONTENTS
BASIC INSPECTION ................................... 4
. POWER RETURN SWITCH .............................. 16 F
DIAGNOSIS AND REPAIR WORKFLOW ......... 4
. LH ..............................................................................16
.
WorkFlow ................................................................. 4
. LH : Description ......................................................16 .
G
LH : Component Function Check ..........................16 .
FUNCTION DIAGNOSIS .............................. 5
. LH : Diagnosis Procedure .......................................16 .
LH : Component Inspection ....................................17 .
POWER SEAT .................................................... 5
. H
System Description .................................................. 5
. RH .............................................................................17
.
Component Parts Location ....................................... 5
. RH : Description .....................................................17 .
Component Description ............................................ 6
. RH : Component Function Check .........................17 .
I
RH : Diagnosis Procedure ......................................18 .
HEATED SEAT ................................................... 7
. RH : Component Inspection ...................................19 .
System Description .................................................. 7
.
Component Parts Location ....................................... 7
. REAR SEATBACK SWITCH ............................ 20 SE
Component Description ............................................ 7
.
LH ..............................................................................20
.
LUMBAR SUPPORT .......................................... 8
. LH : Description ......................................................20 .
LH : Component Function Check ..........................20 . K
System Description .................................................. 8
.
Component Parts Location ....................................... 8
. LH : Diagnosis Procedure .......................................20 .
Component Description ............................................ 8
. LH : Component Inspection ....................................21 .
L
REAR SEATBACK RELEASE CONTROL ........ 9
. RH .............................................................................21
.
System Description .................................................. 9
. RH : Description .....................................................21 .
Component Parts Location ....................................... 9
. RH : Component Function Check .........................22 .
M
Component Description ............................................ 9
. RH : Diagnosis Procedure ......................................22 .
RH : Component Inspection ...................................23 .
REAR SEATBACK POWER RETURN SYS-
TEM ...................................................................10
. PRIMARY POSITION LIMIT SWITCH .............. 24 N
System Diagram ..................................................... 10
. LH ..............................................................................24
.
System Description ................................................ 10
. LH : Description ......................................................24 .
Component Parts Location ..................................... 13
. LH : Component Function Check ...........................24 . O
Component Description .......................................... 14
. LH : Diagnosis Procedure .......................................24 .
LH : Component Inspection ....................................25 .
COMPONENT DIAGNOSIS ........................ 15
.
P
RH .............................................................................26
.
POWER SUPPLY AND GROUND CIRCUIT .....15
. RH : Description .....................................................26 .
REAR SEATBACK POWER RETURN CONTROL RH : Component Function Check ...........................26 .
UNIT .......................................................................... 15
. RH : Diagnosis Procedure ......................................26 .
REAR SEATBACK POWER RETURN CONTROL RH : Component Inspection ...................................27 .
UNIT : Diagnosis Procedure .................................. 15 .
RETURN COMPLETE LIMIT SWITCH ............. 29
Revision: 2007 November SE-1 2008 EX35
LH ............................................................................. 29
. Reference Value .................................................... 60.
LH : Description ..................................................... 29 . Wiring Diagram - REAR SEATBACK POWER RE-
LH : Component Function Check .......................... 29 . TURN SYSTEM - ................................................... 63 .
LH : Diagnosis Procedure ...................................... 29 . Fail Safe ................................................................ 69
.
LH : Component Inspection ................................... 30 .
SYMPTOM DIAGNOSIS ............................ 71
RH ............................................................................. 31
.
RH : Description .................................................... 31 . REAR SEATBACK POWER RETURN SYS-
RH : Component Function Check .......................... 31 . TEM DOES NOT OPERATE ............................ 71
.
RH : Diagnosis Procedure ..................................... 31 .
RH : Component Inspection .................................. 32 . BOTH SIDES ............................................................ 71
.
BOTH SIDES : Diagnosis Procedure ..................... 71 .
MOTOR SENSOR ............................................. 34
.
LH ............................................................................. 71
.
LH ............................................................................. 34
. LH : Diagnosis Procedure ...................................... 71 .
LH : Description ..................................................... 34 .
RH ............................................................................. 72
.
LH : Component Function Check .......................... 34 .
RH : Diagnosis Procedure ..................................... 72 .
LH : Diagnosis Procedure ...................................... 34 .
RH ............................................................................. 35
. MALFUNCTION DETECTION BUZZER
RH : Description .................................................... 35 . SOUNDS DURING POWER RETURN MO-
RH : Component Function Check .......................... 35 . TOR INVERSE ROTATION .............................. 74
.
RH : Diagnosis Procedure ..................................... 36 .
LH ............................................................................. 74
.
POWER RETURN MOTOR .............................. 38
. LH : Diagnosis Procedure ...................................... 74 .
LH ............................................................................. 38
. RH ............................................................................. 74
.
LH : Description ..................................................... 38 . RH : Diagnosis Procedure ..................................... 74 .
LH : Component Function Check ......................... 38 .
DOES NOT RETURN BUT MALFUNCTION
LH : Diagnosis Procedure ...................................... 38 .
DETECTION BUZZER SOUNDS ..................... 76
.
RH ............................................................................. 39
.
LH ............................................................................. 76
.
RH : Description .................................................... 39 .
LH : Diagnosis Procedure ...................................... 76 .
RH : Component Function Check ........................ 39 .
RH : Diagnosis Procedure ..................................... 39 . RH ............................................................................. 76
.
RH : Diagnosis Procedure ..................................... 76 .
VEHICLE SPEED SIGNAL CIRCUIT ............... 41
.
Description ............................................................. 41
. ANTI-PINCH FUNCTION DOES NOT OPER-
Component Function Check .................................. 41 . ATE ................................................................... 77
.
Diagnosis Procedure ............................................. 41 . Diagnosis Procedure .............................................. 77
.
POWER SEAT .................................................. 43
. SQUEAK AND RATTLE TROUBLE DIAG-
Wiring Diagram - POWER SEAT FOR DRIVER NOSES .............................................................. 78
.
SIDE (WITHOUT AUTOMATIC DRIVE POSI-
Work Flow .............................................................. 78
.
TIONER) - .............................................................. 43
.
Inspection Procedure ............................................. 80.
Wiring Diagram - POWER SEAT FOR PASSEN-
Diagnostic Worksheet ............................................ 82 .
GER SIDE - ........................................................... 46
.
PRECAUTION ............................................ 84
HEATED SEAT ................................................. 49
.
Wiring Diagram - HEATED SEAT - ........................ 49
. PRECAUTIONS ................................................ 84
.
Precaution for Supplemental Restraint System
LUMBAR SUPPORT ........................................ 53
.
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
Wiring Diagram - LUMBAR SUPPORT SYSTEM - 53
...
SIONER" ................................................................ 84
.
REAR SEATBACK RELEASE CONTROL ...... 56
. Precaution Necessary for Steering Wheel Rota-
Wiring Diagram - REAR SEATBACK RELEASE tion after Battery Disconnect .................................. 84 .
CONTROL - ........................................................... 56
. Service Notice ........................................................ 84
.
Precaution for Work ............................................... 85
.
ECU DIAGNOSIS ....................................... 60
.
PREPARATION .......................................... 86
REAR SEAT BACK POWER RETURN CON-
TROL UNIT ....................................................... 60
. PREPARATION ................................................ 86
.
Special Service Tool .............................................. 86
.
Revision: 2007 November SE-2 2008 EX35
Commercial Service Tool ....................................... 86
. Removal and Installation ...................................... 106
.
A
ON-VEHICLE REPAIR ................................ 87
. LUMBAR SUPPORT SWITCH ........................ 107
Exploded View ...................................................... 107
.
FRONT SEAT ....................................................87
. Removal and Installation ...................................... 107
.
Exploded View ....................................................... 87
. B
Removal and Installation ........................................ 90
. HEATED SEAT SWITCH ................................ 108
Disassembly and Assembly ................................... 91 . Exploded View ...................................................... 108
.
Removal and Installation ...................................... 108
. C
REAR SEAT ......................................................98
.
Exploded View ....................................................... 98
. POWER RETURN SWITCH ............................ 109
Removal and Installation ........................................ 99
. Exploded View ...................................................... 109
.
Disassembly and Assembly ................................. 101 . Removal and Installation ...................................... 109
. D
REAR SEAT BACK POWER RETURN CON- REAR SEATBACK SWITCH .......................... 110
TROL UNIT ...................................................... 105
. Exploded View ...................................................... 110
. E
Exploded View ..................................................... 105
. Removal and Installation ...................................... 110
.
Removal and Installation ...................................... 105
.
REAR SEATBACK RELEASE SWITCH ........ 111
POWER SEAT SWITCH .................................. 106
. Exploded View ...................................................... 111
. F
Exploded View ..................................................... 106
. Removal and Installation ...................................... 111
.
G
H
I
SE
K
L
M
N
O
P
Revision: 2007 November SE-3 2008 EX35
DIAGNOSIS AND REPAIR WORKFLOW
< BASIC INSPECTION >
BASIC INSPECTION
DIAGNOSIS AND REPAIR WORKFLOW
WorkFlow INFOID:0000000003642128
DETAILED FLOW
1.OBTAIN INFORMATION ABOUT SYMPTOM
Interview the customer to obtain the malfunction information (conditions and environment when the malfunc-
tion occurred) as much as possible when the customer brings the vehicle in.
>> GO TO 2.
2.REPRODUCE THE MALFUNCTION INFORMATION
Check the malfunction on the vehicle that the customer describes.
Inspect the relation of the symptoms and the condition when the symptoms occur.
>> GO TO 3.
3.IDENTIFY THE MALFUNCTIONING SYSTEM WITH "SYMPTOM DIAGNOSIS"
Use "Symptom diagnosis" from the symptom inspection result in step 2 and then identify where to start per-
forming the diagnosis based on possible causes and symptoms.
>> GO TO 4.
4.IDENTIFY THE MALFUNCTIONING PARTS WITH "COMPONENT DIAGNOSIS"
Perform the diagnosis with "Component diagnosis" of the applicable system.
>> GO TO 5.
5.REPAIR OR REPLACE THE MALFUNCTIONING PARTS
Repair or replace the specified malfunctioning parts.
>> GO TO 6.
6.FINAL CHECK
Check that malfunctions are not reproduced when obtaining the malfunction information from the customer,
referring to the symptom inspection result in step 2.
Are the malfunctions corrected?
YES >> INSPECTION END
NO >> GO TO 3.
Revision: 2007 November SE-4 2008 EX35
POWER SEAT
< FUNCTION DIAGNOSIS >
FUNCTION DIAGNOSIS A
POWER SEAT
System Description INFOID:0000000003642138
B
BCM can operate regardless of the ignition switch position, because battery power is supplied at all times to
power seat switch.
C
SLIDING OPERATION
While operating the sliding switch located in power seat switch, sliding motor operates and makes possible the
seat front and back position adjustment.
D
RECLINING OPERATION
While operating the reclining switch located in power seat switch, reclining motor operates and makes possi-
ble the seat back forward and backward position adjustment. E
LIFTING OPERATION
While operating the lifting switch located in power seat switch, lifting motor operates and makes possible the
seat cushion up and down position adjustment. F
Component Parts Location INFOID:0000000003642139
G
H
I
SE
K
L
M
N
JMJIA1540ZZ
1. Sliding switch and lifting switch (driv- 2. Reclining switch (driver side) B414 3. Reclining motor (driver side) B415 O
er side) B414
4. Lifting motor (rear) (driver side) B418 5. Lifting motor (front) (driver side) 6. Sliding motor (driver side) B416
B417 P
A. View with seat cushion pad and seat B. Backside of seat cushion
back pad are removed.
Revision: 2007 November SE-5 2008 EX35
POWER SEAT
< FUNCTION DIAGNOSIS >
Component Description INFOID:0000000003642140
Item Function
BCM Supplies at all times the power received from battery to power seat switch
Power seat switch Built-in reclining switch, sliding switch and lifting switch, controls the power supplied to each motor
With the power supplied from power seat switch, operates forward and backward movement of
Reclining motor
seatback
Sliding motor With the power supplied from power seat switch, operates forward and backward slide of seat
Lifting motor (front/rear) With the power supplied from power seat switch, operates up and down movement of seat cushion
Revision: 2007 November SE-6 2008 EX35
HEATED SEAT
< FUNCTION DIAGNOSIS >
HEATED SEAT
A
System Description INFOID:0000000003642141
Heated seat is a system that operates when ignition switch is in ON or START position. B
HEATER OPERATION
