Image preview - the first page of the document
fl


>> Download fl documenatation <<

Text preview - extract from the document
FUEL SYSTEM


B ENGINE

                                                                                                                                                          A




                                                                                                 SECTION
                                                                                                          FUEL SYSTEM
                                                                                                                          FL                             FL



                                                                                                                                                         C


                                                                                                                                                         D


                                                                                                                                                          E
                                                             CONTENTS
PREPARATION .......................................................... 2
                                                                  .            INSPECTION AFTER INSTALLATION ................. 7                .         F
 Commercial Service Tool ........................................ 2
                                                                  .          Disassembly and Assembly ..................................... 8   .
FUEL SYSTEM .......................................................... 3
                                                                  .            DISASSEMBLY .................................................... 8
                                                                                                                                                .
 Checking Fuel Lines ................................................ 3
                                                                  .            ASSEMBLY .......................................................... 9
                                                                                                                                                .        G
 General Precautions ............................................... 3
                                                                  .         FUEL TANK ............................................................. 10
                                                                                                                                                .
FUEL LEVEL SENSOR UNIT, FUEL FILTER AND                                      Removal and Installation ....................................... 10.
FUEL PUMP ASSEMBLY .......................................... 4   .            REMOVAL .......................................................... 10
                                                                                                                                                .
                                                                                                                                                         H
 Removal and Installation ......................................... 4
                                                                  .            INSTALLATION .................................................. 11
                                                                                                                                                .
   REMOVAL ............................................................ 4
                                                                  .            INSPECTION AFTER INSTALLATION ............... 11                 .
   INSTALLATION .................................................... 6
                                                                  .         SERVICE DATA AND SPECIFICATIONS (SDS) ..... 12                      .
                                                                             Standard and Limit ................................................. 12
                                                                                                                                                .         I


                                                                                                                                                          J



                                                                                                                                                          K


                                                                                                                                                          L



                                                                                                                                                         M




Revision: 2004 November                                                FL-1                                                    2004 FX35/FX45
                          PREPARATION

PREPARATION                                                                      PFP:00002

Commercial Service Tool                                                             ABS005YW



 Tool name                                      Description

 Power tool                                     Loosening bolts and nuts




                                    PBIC0190E




Revision: 2004 November      FL-2                                          2004 FX35/FX45
                                             FUEL SYSTEM

FUEL SYSTEM                                                                                  PFP:17503
                                                                                                              A
Checking Fuel Lines                                                                               ABS005YX


Inspect fuel lines, fuel filler cap and fuel tank for improper attach-
ment, leaks, cracks, damage, loose connections, chafing or deterio-                                          FL
ration.
If necessary, repair or replace damaged parts.
                                                                                                             C


                                                                                                             D

                                                                                               SMA803A

                                                                                                              E
General Precautions                                                                               ABS005YY


WARNING:
When replacing fuel line parts, be sure to observe the following.                                             F
q  Put a "CAUTION: INFLAMMABLE" sign in the workshop.
q  Be sure to work in a well ventilated area and furnish workshop with a CO2 fire extinguisher.
q  Do not smoke while servicing fuel system. Keep open flames and sparks away from the work area.            G
CAUTION:
q  Before removing fuel line parts, carry out the following procedures:



◦ Jabse Service Manual Search 2022 ◦ Jabse PravopisonTap.bg ◦ Other service manual resources online : FixyaeServiceinfo
