Image preview - the first page of the document
sb


>> Download sb documenatation <<

Text preview - extract from the document
SEAT BELTS


H RESTRAINTS

                                                                                                                                                                    A




                                                                                                    SECTION                    SB
                                                                                                                         SEAT BELTS
                                                                                                                                                                    B



                                                                                                                                                                    C


                                                                                                                                                                    D


                                                                                                                                                                    E
                                                                  CONTENTS
PRECAUTIONS ......................................................... 2 .            REMOVAL OF REAR SEAT BELT RETRACTOR 7                                .....     F
 Precautions for Supplemental Restraint System                                       INSTALLATION OF REAR SEAT BELT RETRAC-
 (SRS) "AIR BAG" and "SEAT BELT PRE-TEN-                                             TOR ...................................................................... 7
                                                                                                                                                          .
 SIONER" ................................................................. 2
                                                                        .          Seat Belt Inspection ................................................. 8
                                                                                                                                                          .         G
 Precaution for Seat Belt Service ............................. 2       .            AFTER A COLLISION .......................................... 8       .
   AFTER A COLLISION .......................................... 2       .            PRELIMINARY CHECK ........................................ 8         .
SEAT BELTS ............................................................. 4
                                                                        .            SEAT BELT RETRACTOR ON-VEHICLE
                                                                                                                                                                    SB
 System Description ................................................. 4 .            INSPECTION ....................................................... 9 .
   SEAT BELT WARNING CHIME ........................... 4                .            SEAT BELT RETRACTOR OFF-VEHICLE
   SEAT BELT WARNING LAMP ............................. 4               .            INSPECTION ..................................................... 10  .
 Removal and Installation of Front Seat Belt ............ 4             .         LATCH (LOWER ANCHORS AND TETHER FOR                                                I
   REMOVAL OF FRONT SEAT BELT RETRAC-                                             CHILDREN) SYSTEM .............................................. 11      .
   TOR ...................................................................... 5
                                                                        .          Removal and Installation ....................................... 11    .
   INSTALLATION OF FRONT SEAT BELT                                                   REMOVAL .......................................................... 11.          J
   RETRACTOR ....................................................... 5  .            INSTALLATION .................................................. 11   .
   REMOVAL OF FRONT SEAT BELT BUCKLE ..... 5                                      TOP TETHER STRAP CHILD RESTRAINT ............ 12                        .
   INSTALLATION OF FRONT SEAT BELT                                                 Removal and Installation ....................................... 12    .
                                                                                                                                                                    K
   BUCKLE ............................................................... 5
                                                                        .            REMOVAL .......................................................... 12.
 Removal and Installation of Rear Seat Belt ............ 6              .            INSTALLATION .................................................. 12   .

                                                                                                                                                                    L



                                                                                                                                                                    M




Revision: 2004 November                                                     SB-1                                                         2004 FX35/FX45
                                              PRECAUTIONS

PRECAUTIONS                                                         PFP:00001

Precautions for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT
BELT PRE-TENSIONER"                                                                                           AHS000I8


The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING:
q    To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
     in the event of a collision which would result in air bag inflation, all maintenance must be per-
     formed by an authorized NISSAN/INFINITI dealer.
q    Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
     sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
     Bag Module, see the SRS section.
q    Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
     Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
     harness connectors.
Precaution for Seat Belt Service                                                                              AHS000I9


CAUTION:
q  Before removing the front seat belt pre-tensioner assembly, turn the ignition switch off, discon-
   nect the both battery cables and wait at least 3 minutes.
q  Do not use electrical test equipment for front seat belt pre-tensioner connector.
q  After replacing or reinstalling front seat belt pre-tensioner assembly, or reconnecting front seat
   belt pre-tensioner connector, check the system function. Refer to SRS-17, "SRS Operation Check"
   .
q  Deploy front seat belt pre-tensioner assembly before disposing. Refer to SRS-49, "DISPOSAL OF
   AIR BAG MODULE AND SEAT BELT PRE-TENSIONER" .
q  Do not use disassemble buckle or seat belt assembly.
q  Replace anchor bolts if they are deformed or worn out.
q  Never oil tongue and buckle.
q  If any component of seat belt assembly is questionable, do not repair. Replace the whole seat belt
   assembly.
q  If webbing is cut, frayed, or damaged, replace seat belt assembly.
q  When replacing seat belt assembly, use a genuine NISSAN seat belt assembly.
AFTER A COLLISION
WARNING:
Inspect all seat belt assemblies including retractors and attaching hardware after any collision.
NISSAN recommends that all seat belt assemblies in use during a collision be replaced unless the col-
lision was minor and the belts show no damage and continue to operate properly. Failure to do so
could result in serious personal injury in an accident. Seat belt assemblies not in use during a colli-
sion should also be replaced if either damage or improper operation is noted. Seat belt pre-tensioner
should be replaced even if the seat belts are not in use during a frontal collision in which the air bags
are deployed.
Replace any seat belt assembly (including anchor bolts) if:
q    The seat belt was in use at the time of a collision (except for minor collisions and the belts, retractors and
     buckles show no damage and continue to operate properly).
q    The seat belt was damaged in an accident. (i.e. torn webbing, bent retractor or guide).
q    The seat belt attaching point was damaged in an accident. Inspect the seat belt attaching area for damage
     or distortion and repair as necessary before installing a new seat belt assembly.
q    Anchor bolts are deformed or worn out.

Revision: 2004 November                               SB-2                                        2004 FX35/FX45
                                            PRECAUTIONS

q   The front seat belt pre-tensioner should be replaced even if the seat belts are not in use during the colli-
    sion in which the air bags are deployed.                                                                       A


                                                                                                                   B



                                                                                                                   C


                                                                                                                   D


                                                                                                                   E



                                                                                                                   F


                                                                                                                   G


                                                                                                                   SB



                                                                                                                    I


                                                                                                                    J



                                                                                                                   K


                                                                                                                   L



                                                                                                                   M




Revision: 2004 November                             SB-3                                       2004 FX35/FX45
                                                       SEAT BELTS

SEAT BELTS                                                                                                     PFP:86884

System Description                                                                                                   AHS000IA

SEAT BELT WARNING CHIME
q    With ignition switch turned ON and seat belt unfastened (seat belt switch ON), warning chime will sound
     for approximately 6 seconds.
q    If warning chime does not sound, refer to DI-77, "Seat Belt Warning Chime Does Not Operate" .
SEAT BELT WARNING LAMP
q    Fasten driver's seat belt.
q    The seat belt warning lamp should go out.
q    If the seat belt warning lamp does not go out, refer to DI-40, "Wiring Diagram -- WARN --" .
Removal and Installation of Front Seat Belt                                                                          AHS000IB




                                                                                                              PHIA0678E

    1.    Seat belt pre-tensioner connector   2.   Retractor                          3.   Screw
    4.    Anchor bolt                         5.   Retaining washer                   6.   Bolt
    7.    Seat belt adjuster                  8.   Retaining washer                   9.   Spacer
    10. Adjuster cover                        11. Through anchor                      12. Anchor bolt
    13. Fiber washer                          14. Plain washer                        15. Outer anchor
    16.   Anchor bolt                         17. Seat cushion outer finisher cover

CAUTION:
Before servicing SRS, turn the ignition switch OFF, disconnect both battery cables and wait at least 3
minutes.




Revision: 2004 November                                        SB-4                                      2004 FX35/FX45
                                             SEAT BELTS

REMOVAL OF FRONT SEAT BELT RETRACTOR
1. Remove the adjuster cover on the through anchor.                                                              A
2. Remove the anchor bolt.
3. Remove the seat cushion outer finisher cover, and remove the anchor bolt.
                                                                                                                 B
   NOTE:
   Set the front and rear cushion lifter to the down position.
4. Remove the center pillar upper and lower garnish. Refer to EI-37, "Removal and Installation" .
                                                                                                                 C
5. Disconnect the seat belt pre-tensioner connector.
CAUTION:
q  For installing/removing seat belt pre-tensioner connector,
   insert thin screwdriver wrapped in tape into notch, lift lock                                                 D
   and remove connector.
q  Install connector with lock raised, and push lock into con-
   nector.                                                                                                       E



                                                                                                                 F


                                                                                                     PHIA0341E
                                                                                                                 G
6.   Remove the seat belt pre-tensioner retractor fixing screw and anchor bolt, and then remove the seat belt
     retractor.
                                                                                                                 SB
INSTALLATION OF FRONT SEAT BELT RETRACTOR
CAUTION:
Before servicing SRS, turn ignition switch OFF, disconnect both battery cables and wait at least 3 min-
utes.                                                                                                             I
Install in the reverse order of removal.
REMOVAL OF FRONT SEAT BELT BUCKLE
                                                                                                                  J
1.   Remove the front seat. Refer to SE-101, "Removal and Installa-
     tion" .
2.   Disconnect the buckle switch connector.
                                                                                                                 K
3.   Remove the anchor bolt, and remove the buckle.


                                                                                                                 L



                                                                                                                 M
                                                                                                     PHIA0346E


INSTALLATION OF FRONT SEAT BELT BUCKLE
Install in the reverse order of removal.




Revision: 2004 November                            SB-5                                     2004 FX35/FX45
                                               SEAT BELTS

Removal and Installation of Rear Seat Belt                                                                     AHS000IC




                                                                                                        PHIA0679E

  1.    Center seat belt retractor   2.    Anchor bolt                    3.    Retaining washer
  4.    Bolt                         5.    Seat belt adjuster             6.    Retaining washer
  7.    Spacer                       8.    Adjuster cover                 9.    Through-anchor
  10. Anchor bolt                    11. Outer side seat belt retractor   12. Anchor bolt
  13. Anchor bolt                    14. Outer anchor                     15. Spacer
  16.   Fiber washer                 17.   Inner anchor (upper)           18.   Inner anchor (lower)




Revision: 2004 November                                  SB-6                                      2004 FX35/FX45
                                           SEAT BELTS

REMOVAL OF REAR SEAT BELT RETRACTOR
1.   Remove the rear seat. Refer to SE-109, "REMOVAL" .                                                  A
2.   Remove the rear wheel house finisher assembly and luggage side finisher assembly. Refer to EI-44,
     "Removal and Installation" .
3.   Remove the center seat retractor cover.                                                             B
4.   Remove the roof rear garnish assembly. Refer to EI-44, "Removal and Installation" .
5.   Remove the outer and inner anchor bolts.
                                                                                                         C
6.   Remove the outer side retractor and center seat retractor mounting anchor bolts.
7.   Remove the seat belt assembly.
INSTALLATION OF REAR SEAT BELT RETRACTOR                                                                 D
Install in the reverse order of removal.

                                                                                                         E



                                                                                                         F


                                                                                                         G


                                                                                                         SB



                                                                                                          I


                                                                                                          J



                                                                                                         K


                                                                                                         L



                                                                                                         M




Revision: 2004 November                         SB-7                                  2004 FX35/FX45
                                                SEAT BELTS

Seat Belt Inspection                                                                                         AHS000ID

AFTER A COLLISION
WARNING:
Inspect all seat belt assemblies including retractors and attaching hardware after any collision.
NISSAN recommends that all seat belt assemblies in use during a collision be replaced unless the col-
lision was minor and the belts show no damage and continue to operate properly. Failure to do so
could result in serious personal injury in an accident. Seat belt assemblies not in use during a colli-
sion should also be replaced if either damage or improper operation is noted. Seat belt pre-tensioners
should be replaced even if the seat belts are not in use during a frontal collision in which the air bags
are deployed.
Replace any seat belt assembly (including anchor bolts) if:
q    The seat belt was in use at the time of a collision (except for minor collisions and the belts, retractors and
     buckles show no damage and continue to operate properly).
q    The seat belt was damaged in an accident. (i.e. torn webbing, bent retractor or guide).
q    The seat belt attaching point was damaged in an accident. Inspect the seat belt attaching area for damage
     or distortion and repair as necessary before installing a new seat belt assembly.
q    Anchor bolts are deformed or worn out.
q    The front seat belt pre-tensioner should be replaced even if the seat belts are not in use during the colli-
     sion in which the air bags are deployed.
PRELIMINARY CHECK
1.   Check the seat belt warning lamp/chime for proper operation as follows:
a.   Turn ignition switch ON. The seat belt warning lamp should illuminate. Also, the seat belt warning chime
     should sound for about six seconds.
b.   Fasten driver's seat belt. The seat belt warning lamp should go out and the chime (if sounding) should
     stop.
2.   If the air bag warning lamp is blinking, perform self-diagnosis using CONSULT-II, and air bag warning
     lamp. Refer to SRS-17, "SRS Operation Check" .
3.   Make sure that the seat belt retractor, seat belt anchor and buckle bolts are securely attached.
4.   Check the shoulder seat belt guide and shoulder belt height adjuster for front seats. Ensure guide swivels
     freely and that webbing lays flat and does not bind in guide. Ensure height adjuster operates properly and
     holds securely.
5.   Check retractor operation:
a.   Fully extend the seat belt webbing and check for twists, tears or other damage.
b.   Allow the seat belt to retract. Ensure that webbing returns smoothly and completely into the retractor. If
     the seat belt does not return smoothly, wipe the inside of the loops with a clean paper cloth, because dirt
     built up in the loops of the upper anchors can cause the seat belts to retract slowly.
c.   Fasten the seat belt. Check the seat belt returns smoothly and completely to the retractor. If the webbing
     does not return smoothly, the cause may be an accumulation of dust or dirt. Use the "SEAT BELT TAPE
     SET" and perform the following steps.
     Inspect the front seat belt through-anchor:
     1. Pull the seat belt out to a length of 500 mm (19.69 in) or more.
     2. Use a clip or other device to the fix the seat belt at the center pillar webbing opening.
     3. Pass a thin wire through the through-anchor webbing opening. Hold both ends of the wire and pull taut
        while moving it up and down several times along the webbing opening surface to remove dirt.
     4. Any dirt that cannot be removed with the wire can be removed by cleaning the opening with a clean
        cloth.
     5. Apply tape at the point where the webbing contacts the through-anchor webbing opening.
        NOTE:
        Apply the tape so that there is no looseness or wrinkling.
     6. Remove the clip fixing the seat belt and ensure that the webbing returns smoothly.
     7. Repeat steps above as necessary to check the other seat belts.




Revision: 2004 November                               SB-8                                       2004 FX35/FX45
                                               SEAT BELTS

SEAT BELT RETRACTOR ON-VEHICLE INSPECTION
Emergency Locking Retractors (ELR) and Automatic Locking Retractors (ALR)                                            A
NOTE:
All seat belt retractors are of the Emergency Locking Retractors (ELR) type. In an emergency (sudden stop)
the retractor will lock and prevent the webbing from extending any further. All 3-point type seat belt retractors    B
except the driver's seat belt also have an Automatic Locking Retractors (ALR) mode. The ALR mode (also
called child restraint mode) is used when installing child seats. The ALR mode is activated when the seat belt
is fully extended. When the webbing is then retracted partially, the ALR mode automatically locks the seat belt      C
in a specific position so the webbing cannot be extended any further. To cancel the ALR mode, allow the seat
belt to fully wind back into the retractor.
Check the seat belt retractors using the following test(s) to determine if a retractor assembly is operating prop-
erly.                                                                                                                D
Stationary Inspection for ELR Function
Grasp the shoulder webbing and pull forward quickly. The retractor should lock and prevent the belt from             E
extending further.
Stationary Inspection for ALR Function
1.   Pull out entire length of seat belt from retractor until a click is heard.                                      F
2.   Retract the webbing partially. A clicking noise should be heard as the webbing retracts indicating that the
     retractor is in the Automatic Locking Retractor (ALR) mode.
3.   Grasp the seat belt and try to pull out the retractor. The webbing must lock and not extend any further. If     G
     necessary replace the retractor assembly.
4.   Allow the entire length of the webbing to retract to cancel the automatic locking mode.
Moving Inspection for ELR Function                                                                                   SB
WARNING:
Perform the following test in a safe, open area clear of other vehicles and obstructions (for example, a
large, empty parking lot). Road surface must be paved and dry. DO NOT perform the following test on                   I
wet or gravel roads or on public streets and highways. This could result in an accident and serious
personal injury. The driver and passenger must be prepared to brace themselves in the event the
retractor does not lock.                                                                                              J
1. Fasten driver's seat belt. Buckle a passenger into the seat for the belt that is to be tested.
2. Proceed to the designated safe area.
3. Drive the vehicle at approximately 16 km/h (10 MPH). Notify any passengers of a pending sudden stop.              K
    The driver and passenger must be prepared to brace themselves in the event the retractor does not lock.
    Apply brakes firmly and make a very hard stop.
During stop, seat belts should lock and not be extended. If the seat belt retractor assembly does not lock, per-     L
form the retractor off-vehicle inspection.

                                                                                                                     M




Revision: 2004 November                              SB-9                                       2004 FX35/FX45
                                              SEAT BELTS

SEAT BELT RETRACTOR OFF-VEHICLE INSPECTION
1.   Remove the seat belt retractor assembly.
2.   Slowly pull out webbing while tilting the retractor assembly forward from the mounted position without
     twisting the retractor assembly as shown in the figure.




                                                                                                 PHIA0257E


        15 degrees or less tilt     : Webbing can be pulled out.
        35 degrees or more tilt     : Webbing locks and cannot be pulled out.
     If NG, replace the retractor assembly.




Revision: 2004 November                           SB-10                                    2004 FX35/FX45
        LATCH (LOWER ANCHORS AND TETHER FOR CHILDREN) SYSTEM

LATCH (LOWER ANCHORS AND TETHER FOR CHILDREN) SYSTEM                     PFP:75466
                                                                                        A
Removal and Installation                                                     AHS000IE


CAUTION:
Replace anchor bolts if they are deformed or worn out.                                  B
REMOVAL
1.   Remove the rear seat. Refer to SE-109, "REMOVAL" .
2.   Remove LATCH (Lower Anchor and Tether for Children) system.                        C


                                                                                        D


                                                                                        E


                                                                          PHIA0344E
                                                                                        F
INSTALLATION
Install in the reverse order of removal.
                                                                                        G


                                                                                        SB



                                                                                         I


                                                                                         J



                                                                                        K


                                                                                        L



                                                                                        M




Revision: 2004 November                        SB-11               2004 FX35/FX45
                            TOP TETHER STRAP CHILD RESTRAINT

TOP TETHER STRAP CHILD RESTRAINT                                     PFP:88000

Removal and Installation                                                  AHS000IF


CAUTION:
Replace anchor bolts if they are deformed or worn out.
REMOVAL
1.   Remove the roof rear garnish assembly. Refer to EI-44,
     "Removal and Installation" .
2.   Remove the top tether strap child restraint.




                                                                      PHIA0345E


INSTALLATION
Install in the reverse order of removal.




Revision: 2004 November                       SB-12            2004 FX35/FX45



◦ Jabse Service Manual Search 2022 ◦ Jabse PravopisonTap.bg ◦ Other service manual resources online : FixyaeServiceinfo
