Image preview - the first page of the document
>> Download gi documenatation <<
Text preview - extract from the document
Revision: 2004 NovemberGENERAL INFORMATION
A GENERAL INFORMATION
GI
GENERAL INFORMATION
SECTION GI B
C
D
E
CONTENTS
PRECAUTIONS ......................................................... 3 . KEY TO SYMBOLS SIGNIFYING MEASURE- F
Description .............................................................. 3
. MENTS OR PROCEDURES .............................. 13 .
Precautions for Supplemental Restraint System How to Read Wiring Diagrams .............................. 15 .
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN- CONNECTOR SYMBOLS .................................. 15 . G
SIONER" ................................................................. 3
. SAMPLE/WIRING DIAGRAM - EXAMPL - ......... 16 .
Precautions for NVIS/IVIS (NISSAN/INFINITI DESCRIPTION ................................................... 17 .
VEHICLE IMMOBILIZER SYSTEM - NATS) (If Abbreviations ......................................................... 23
.
H
Equipped) ................................................................ 3
. SERVICE INFORMATION FOR ELECTRICAL INCI-
Precautions Necessary for Steering Wheel Rotation DENT ........................................................................ 24
.
After Battery Disconnect ......................................... 4 . How to Check Terminal .......................................... 24 .
OPERATION PROCEDURE ................................ 4 . CONNECTOR AND TERMINAL PIN KIT ........... 24 . I
General Precautions ............................................... 4 . HOW TO PROBE CONNECTORS ..................... 24 .
Precautions for Three Way Catalyst ........................ 6 . How to Perform Efficient Diagnosis for an Electrical
Precautions for Fuel (Unleaded Premium Gasoline Incident .................................................................. 27
. J
Recommended) ....................................................... 6 . WORK FLOW ..................................................... 27 .
Precautions for Fuel (Unleaded Premium Gasoline INCIDENT SIMULATION TESTS ....................... 27 .
Required) ................................................................ 7
. CIRCUIT INSPECTION ...................................... 30 .
K
Precautions for Multiport Fuel Injection System or Control Units and Electrical Parts .......................... 35 .
Engine Control System ........................................... 7 . PRECAUTIONS ................................................. 35 .
Precautions for Hoses ............................................. 7 . CONSULT-II CHECKING SYSTEM ......................... 37 .
HOSE REMOVAL AND INSTALLATION .............. 7 . Description ............................................................. 37
. L
HOSE CLAMPING ............................................... 8 . Function and System Application .......................... 37 .
Precautions for Engine Oils ..................................... 8 . Nickel Metal Hydride Battery Replacement ........... 38 .
HEALTH PROTECTION PRECAUTIONS ............ 8 . Checking Equipment ............................................. 38 . M
ENVIRONMENTAL PROTECTION PRECAU- CONSULT-II Start Procedure ................................. 38 .
TIONS .................................................................. 8
. CONSULT-II Data Link Connector (DLC) Circuit ... 40
Precautions for Air Conditioning .............................. 8 . INSPECTION PROCEDURE ............................. 41 .
HOW TO USE THIS MANUAL .................................. 9 . LIFTING POINT ........................................................ 42 .
Description .............................................................. 9
. Special Service Tools ............................................ 42 .
Terms ...................................................................... 9
. Garage Jack and Safety Stand .............................. 42 .
Units ........................................................................ 9
. 2-Pole Lift .............................................................. 43
.
Contents .................................................................. 9
. Board-On Lift ......................................................... 44
.
Components .......................................................... 10 . TOW TRUCK TOWING ............................................ 45 .
SYMBOLS .......................................................... 10 . Tow Truck Towing .................................................. 45 .
How to Follow Trouble Diagnoses ..........................11 . 2WD MODELS ................................................... 45 .
DESCRIPTION ....................................................11 . AWD MODELS ................................................... 46 .
HOW TO FOLLOW TEST GROUPS IN TROU- Vehicle Recovery (Freeing a Stuck Vehicle) .......... 46 .
BLE DIAGNOSES ...............................................11 . AUTOMATIC TRANSMISSION .......................... 46 .
HARNESS WIRE COLOR AND CONNECTOR TIGHTENING TORQUE OF STANDARD BOLTS ... 47
NUMBER INDICATION ...................................... 12 . Tightening Torque Table ........................................ 47 .
Revision: 2004 November GI-1 2004.5 FX35/FX45
RECOMMENDED CHEMICAL PRODUCTS AND ENGINE SERIAL NUMBER ................................51 .
SEALANTS .............................................................. 48
. AUTOMATIC TRANSMISSION NUMBER ..........51 .
Recommended Chemical Products and Sealants... 48 Dimensions ............................................................52
.
IDENTIFICATION INFORMATION ........................... 49 . Wheels & Tires .......................................................52
.
Model Variation ...................................................... 49
. TERMINOLOGY .......................................................53.
IDENTIFICATION NUMBER ............................... 50 . SAE J1930 Terminology List ..................................53 .
IDENTIFICATION PLATE ................................... 51 .
Revision: 2004 November GI-2 2004.5 FX35/FX45
PRECAUTIONS
PRECAUTIONS PFP:00001
GI
Description AAS000EV
Observe the following precautions to ensure safe and proper servicing. These precautions are not
described in each individual section. B
Precautions for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT
BELT PRE-TENSIONER" AAS000EW
C
The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front D
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual. E
WARNING:
q To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per- F
formed by an authorized NISSAN/INFINITI dealer.
q Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
G
Bag Module, see the SRS section.
q Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors. H
Precautions for NVIS/IVIS (NISSAN/INFINITI VEHICLE IMMOBILIZER SYSTEM -
NATS) (If Equipped) AAS000EX
I
NVIS/IVIS (NATS) will immobilize the engine if someone tries to start it without the registered key of NVIS/IVIS
(NATS).
Both of the originally supplied ignition key IDs have been NVIS/IVIS (NATS) registered. J
The security indicator is located on the instrument panel. The indicator blinks when the immobilizer system is
functioning.
Therefore, NVIS/IVIS (NATS) warns outsiders that the vehicle is equipped with the anti-theft system.
K
q When NVIS/IVIS (NATS) detects trouble, the security indicator lamp lights up while ignition switch is in
"ON" position.
This lighting up indicates that the anti-theft is not functioning, so prompt service is required.
L
q When servicing NVIS/IVIS (NATS) (trouble diagnoses, system initialization and additional registration of
other NVIS/IVIS (NATS) ignition key IDs), CONSULT-II hardware and CONSULT-II NVIS/IVIS (NATS)
software is necessary.
Regarding the procedures of NVIS/IVIS (NATS) initialization and NVIS/IVIS (NATS) ignition key ID regis- M
tration, refer to CONSULT-II operation manual, NVIS/IVIS (NATS).
Therefore, CONSULT-II NVIS/IVIS (NATS) software (program card and operation manual) must be kept
strictly confidential to maintain the integrity of the anti-theft function.
q When servicing NVIS/IVIS (NATS) (trouble diagnoses, system initialization and additional registration of
other NVIS/IVIS (NATS) ignition key IDs), it may be necessary to re-register original key identification.
Therefore, be sure to receive all keys from vehicle owner. A maximum of four or five key IDs can be regis-
tered into NVIS/IVIS (NATS).
q When failing to start the engine first time using the key of NVIS/IVIS (NATS), start as follows.
1. Leave the ignition key in "ON" position for approximately 5 seconds.
2. Turn ignition key to "OFF" or "LOCK" position and wait approximately 5 seconds.
3. Repeat step 1 and 2 again.
4. Restart the engine while keeping the key separate from any others on key-chain.
Revision: 2004 November GI-3 2004.5 FX35/FX45
PRECAUTIONS
Precautions Necessary for Steering Wheel Rotation After Battery Disconnect
AAS000L1
NOTE:
q This Procedure is applied only to models with Intelligent Key system and NVIS/IVIS (NISSAN/INFINITI
VEHICLE IMMOBILIZER SYSTEM - NATS).
q Remove and install all control units after disconnecting both battery cables with the ignition knob in the
LOCK position.
q Always use CONSULT-II to perform self-diagnosis as a part of each function inspection after finishing
work. If DTC is detected, perform trouble diagnosis according to self-diagnostic results.
For models equipped with the Intelligent Key system and NVIS/IVIS, an electrically controlled steering lock
mechanism is adopted on the key cylinder.
For this reason, if the battery is disconnected or if the battery is discharged, the steering wheel will lock and
steering wheel rotation will become impossible.
If steering wheel rotation is required when battery power is interrupted, follow the procedure below before
starting the repair operation.
OPERATION PROCEDURE
1. Connect both battery cables.
NOTE:
Supply power using jumper cables if battery is discharged.
2. Use the Intelligent Key or mechanical key to turn the ignition switch to the ACC position. At this time, the
steering lock will be released.
3. Disconnect both battery cables. The steering lock will remain released and the steering wheel can be
rotated.
4. Perform the necessary repair operation.
5. When the repair work is completed, return the ignition switch to the LOCK position before connecting
the battery cables. (At this time, the steering lock mechanism will engage.)
6. Perform a self-diagnosis check of all control units using CONSULT-II.
General Precautions AAS000EY
q Do not operate the engine for an extended period of time without
proper exhaust ventilation.
Keep the work area well ventilated and free of any inflammable
materials. Special care should be taken when handling any
inflammable or poisonous materials, such as gasoline, refriger-
ant gas, etc. When working in a pit or other enclosed area, be
sure to properly ventilate the area before working with hazard-
ous materials.
Do not smoke while working on the vehicle.
SGI285
q Before jacking up the vehicle, apply wheel chocks or other tire
blocks to the wheels to prevent the vehicle from moving. After
jacking up the vehicle, support the vehicle weight with safety
stands at the points designated for proper lifting before working
on the vehicle.
These operations should be done on a level surface.
q When removing a heavy component such as the engine or tran-
saxle/transmission, be careful not to lose your balance and drop
them. Also, do not allow them to strike adjacent parts, especially
the brake tubes and master cylinder.
SGI231
Revision: 2004 November GI-4 2004.5 FX35/FX45
PRECAUTIONS
q Before starting repairs which do not require battery power:
Turn off ignition switch. GI
Disconnect the negative battery terminal.
q If the battery terminals are disconnected, recorded memory of
radio and each control unit is erased. B
C
SEF289H
D
q To prevent serious burns:
Avoid contact with hot metal parts.
Do not remove the radiator cap when the engine is hot. E
q Dispose of drained oil or the solvent used for cleaning parts in
an appropriate manner.
q Do not attempt to top off the fuel tank after the fuel pump nozzle F
shuts off automatically.
Continued refueling may cause fuel overflow, resulting in fuel
spray and possibly a fire.
G
q Clean all disassembled parts in the designated liquid or solvent
prior to inspection or assembly. SGI233
q Replace oil seals, gaskets, packings, O-rings, locking washers, cotter pins, self-locking nuts, etc. with new H
ones.
q Replace inner and outer races of tapered roller bearings and needle bearings as a set.
q Arrange the disassembled parts in accordance with their assembled locations and sequence. I
q Do not touch the terminals of electrical components which use microcomputers (such as ECM).
Static electricity may damage internal electronic components.
q After disconnecting vacuum or air hoses, attach a tag to indicate the proper connection. J
q Use only the fluids and lubricants specified in this manual.
q Use approved bonding agent, sealants or their equivalents when required.
q Use hand tools, power tools (disassembly only) and recom- K
mended special tools where specified for safe and efficient ser-
vice repairs.
q When repairing the fuel, oil, water, vacuum or exhaust systems, L
check all affected lines for leaks.
M
PBIC0190E
q Before servicing the vehicle:
Protect fenders, upholstery and carpeting with appropriate cov-
ers.
Take caution that keys, buckles or buttons do not scratch paint.
SGI234
Revision: 2004 November GI-5 2004.5 FX35/FX45
PRECAUTIONS
WARNING:
To prevent ECM from storing the diagnostic trouble codes, do not carelessly disconnect the harness
connectors which are related to the engine control system and TCM (transmission control module)
system. The connectors should be disconnected only when working according to the WORK FLOW of
TROUBLE DIAGNOSES in EC and AT sections.
Precautions for Three Way Catalyst AAS000EZ
If a large amount of unburned fuel flows into the catalyst, the catalyst temperature will be excessively high. To
prevent this, follow the instructions.
q Use unleaded gasoline only. Leaded gasoline will seriously damage the three way catalyst.
q When checking for ignition spark or measuring engine compression, make tests quickly and only when
necessary.
q Do not run engine when the fuel tank level is low, otherwise the engine may misfire, causing damage to
the catalyst.
Do not place the vehicle on flammable material. Keep flammable material off the exhaust pipe and the three
way catalyst.
Precautions for Fuel (Unleaded Premium Gasoline Recommended) AAS000F0
Use unleaded regular gasoline with an octane rating of at least 87 AKI (Anti-Knock Index) number (Research
octane number 91).
For improved vehicle performance, NISSAN/INFINITI recommend the use of unleaded premium gasoline with
an octane rating of at least 91 AKI number (Research octane number 96).
CAUTION:
Do not use leaded gasoline. Using leaded gasoline will damage the three way catalyst. Using a fuel
other than that specified could adversely affect the emission control devices and systems, and could
also affect the warranty coverage validity.
Revision: 2004 November GI-6 2004.5 FX35/FX45
PRECAUTIONS
Precautions for Fuel (Unleaded Premium Gasoline Required) AAS000GS
GI
Use unleaded premium gasoline with an octane rating of at least 91 AKI (Anti-Knock Index) number (Research
octane number 96).
If unleaded premium gasoline is not available, unleaded regular gasoline with an octane rating of at least 87 B
AKI number (Research octane number 91) can be used, but only under the following precautions:
q have the fuel tank filled only partially with unleaded regular gasoline, and fill up with unleaded premium
gasoline as soon as possible. C
q avoid full throttle driving and abrupt acceleration.
However, for maximum vehicle performance, the use of unleaded premium gasoline is recommended.
D
CAUTION:
Do not use leaded gasoline. Using leaded gasoline will damage the three way catalyst. Using a fuel
other than that specified could adversely affect the emission control devices and systems, and could E
also affect the warranty coverage validity.
Precautions for Multiport Fuel Injection System or Engine Control System AAS000F1
F
q Before connecting or disconnecting any harness connector for
the multiport fuel injection system or ECM:
Turn ignition switch to "OFF" position.
Disconnect negative battery terminal. G
Otherwise, there may be damage to ECM.
q Before disconnecting pressurized fuel line from fuel pump to
injectors, be sure to release fuel pressure. H
q Be careful not to jar components such as ECM and mass air
flow sensor.
I
SGI787
Precautions for Hoses AAS000F2
HOSE REMOVAL AND INSTALLATION J
q To prevent damage to rubber hose, do not pry off rubber hose
with tapered tool or screwdriver.
K
L
M
SMA019D
q To reinstall the rubber hose securely, make sure that hose inser-
tion length and orientation is correct. (If tube is equipped with
hose stopper, insert rubber hose into tube until it butts up
against hose stopper.)
SMA020D
Revision: 2004 November GI-7 2004.5 FX35/FX45
PRECAUTIONS
HOSE CLAMPING
q If old rubber hose is re-used, install hose clamp in its original
position (at the indentation where the old clamp was). If there is
a trace of tube bulging left on the old rubber hose, align rubber
hose at that position.
q Discard old clamps; replace with new ones.
SMA021D
q After installing plate clamps, apply force to them in the direction
of the arrow, tightening rubber hose equally all around.
SMA022D
Precautions for Engine Oils AAS000F3
Prolonged and repeated contact with used engine oil may cause skin cancer. Try to avoid direct skin contact
with used oil.
If skin contact is made, wash thoroughly with soap or hand cleaner as soon as possible.
HEALTH PROTECTION PRECAUTIONS
q Avoid prolonged and repeated contact with oils, particularly used engine oils.
q Wear protective clothing, including impervious gloves where practicable.
q Do not put oily rags in pockets.
q Avoid contaminating clothes, particularly underpants, with oil.
q Heavily soiled clothing and oil-impregnated footwear should not be worn. Overalls must be cleaned regu-
larly.
q First aid treatment should be obtained immediately for open cuts and wounds.
q Use barrier creams, applying them before each work period, to help the removal of oil from the skin.
q Wash with soap and water to ensure all oil is removed (skin cleansers and nail brushes will help). Prepa-
rations containing lanolin replace the natural skin oils which have been removed.
q Do not use gasoline, kerosene, diesel fuel, gas oil, thinners or solvents for cleaning skin.
q If skin disorders develop, obtain medical advice without delay.
q Where practical, degrease components prior to handling.
q Where there is a risk of eye contact, eye protection should be worn, for example, chemical goggles or face
shields; in addition an eye wash facility should be provided.
ENVIRONMENTAL PROTECTION PRECAUTIONS
Dispose of used oil and used oil filters through authorized waste disposal contractors to licensed waste dis-
posal sites, or to the waste oil reclamation trade. If in doubt, contact the local authority for advice on disposal
facilities.
It is illegal to pour used oil on to the ground, down sewers or drains, or into water sources.
The regulations concerning pollution vary between regions.
Precautions for Air Conditioning AAS000F4
Use an approved refrigerant recovery unit any time the air conditioning system must be discharged. Refer to
ATC/MTC section "HFC-134a (R-134a) Service Procedure", "REFRIGERANT LINES" for specific instructions.
Revision: 2004 November GI-8 2004.5 FX35/FX45
HOW TO USE THIS MANUAL
HOW TO USE THIS MANUAL PFP:00008
GI
Description AAS000DW
This volume explains "Removal, Disassembly, Installation, Inspection and Adjustment" and "Trouble Diag-
noses". B
Terms AAS000DX
q The captions WARNING and CAUTION warn you of steps that must be followed to prevent personal
C
injury and/or damage to some part of the vehicle.
WARNING indicates the possibility of personal injury if instructions are not followed.
CAUTION indicates the possibility of component damage if instructions are not followed.
BOLD TYPED STATEMENTS except WARNING and CAUTION give you helpful information. D
Standard value:Tolerance at inspection and adjustment.
Limit value:The maximum or minimum limit value that should not be exceeded at inspection and adjust-
ment. E
Units AAS000GX
q The UNITS given in this manual are primarily expressed as the SI UNIT (International System of Unit),
and alternatively expressed in the metric system and in the yard/pound system. F
Also with regard to tightening torque of bolts and nuts, there are descriptions both about range and about
the standard tightening torque.
G
"Example"
Range
Outer Socket Lock Nut : 59 - 78 N◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
