Image preview - the first page of the document
gw


>> Download gw documenatation <<

Text preview - extract from the document
GLASSES, WINDOW SYSTEM & MIRRORS


I BODY

                                                                                                                                                                A




                            GLASSES, WINDOW SYSTEM & MIRRORS
                                                                                       SECTION                     GW                                           B



                                                                                                                                                                C


                                                                                                                                                                D


                                                                                                                                                                E
                                                                CONTENTS
PRECAUTIONS ......................................................... 3
                                                                      .           WITH FRONT AND REAR WINDOW ANTI-                                              F
 Precautions for Supplemental Restraint System                                    PINCH SYSTEM ................................................ 16     .
 (SRS) "AIR BAG" and "SEAT BELT PRE-TEN-                                          MANUAL OPERATION ....................................... 17          .
 SIONER" ................................................................. 3
                                                                      .           AUTO OPERATION ............................................ 19       .        G
 Handling for Adhesive and Primer .......................... 3        .           POWER WINDOW SERIAL LINK ...................... 20                   .
 Wiring Diagrams and Trouble Diagnosis ................. 3            .           POWER WINDOW LOCK .................................. 20              .
PREPARATION .......................................................... 4
                                                                      .           RETAINED POWER OPERATION ..................... 21                    .
                                                                                                                                                                H
 Special Service Tools .............................................. 4
                                                                      .           ANTI-PINCH SYSTEM ....................................... 21         .
 Commercial Service Tools ....................................... 4   .           POWER WINDOW CONTROL BY THE KEY
SQUEAK AND RATTLE TROUBLE DIAGNOSES..... 5                                        CYLINDER SWITCH .......................................... 21        .
 Work Flow ............................................................... 5
                                                                      .         CAN Communication System Description ............. 22                  .        GW
   CUSTOMER INTERVIEW .................................... 5          .         CAN Communication Unit ...................................... 22       .
   DUPLICATE THE NOISE AND TEST DRIVE ...... 6                        .         Schematic/With Front Power Window Anti-pinch
   CHECK RELATED SERVICE BULLETINS .......... 6                       .         System ................................................................... 23
                                                                                                                                                       .        J
   LOCATE THE NOISE AND IDENTIFY THE                                            Wiring Diagram -- WINDOW --/With Front Power
   ROOT CAUSE ..................................................... 6 .         Window Anti-pinch System .................................... 24       .
   REPAIR THE CAUSE .......................................... 6      .         Terminal and Reference Value for BCM / With Front
                                                                                                                                                                K
   CONFIRM THE REPAIR ...................................... 7        .         Power Window Anti-pinch System ......................... 28            .
 Generic Squeak and Rattle Troubleshooting .......... 7               .         Terminal and Reference Value for Power Window
   INSTRUMENT PANEL ......................................... 7       .         Main Switch / With Front Power Window Anti-pinch
   CENTER CONSOLE ............................................ 7      .         System ................................................................... 29
                                                                                                                                                       .        L
   DOORS ................................................................ 7
                                                                      .         Terminal and Reference Value for Front Power Win-
   TRUNK ................................................................. 8
                                                                      .         dow Switch (Passenger Side) / With Front Power
   SUNROOF/HEADLINING .................................... 8          .         Window Anti-pinch System .................................... 30       .        M
   SEATS .................................................................. 8
                                                                      .         Schematic/With Front and Rear Power Window
   UNDERHOOD ...................................................... 8 .         Anti-pinch System .................................................. 31.
 Diagnostic Worksheet ............................................. 9 .         Wiring Diagram -- WINDOW --/With Front and
WINDSHIELD GLASS ..............................................11     .         Rear Power Window Anti-pinch System ................ 32                .
 Removal and Installation ........................................11  .         Terminal and Reference Value for BCM / With Front
   REMOVAL ...........................................................11
                                                                      .         and Rear Power Window Anti-pinch ...................... 37             .
   INSTALLATION .................................................. 12 .         Terminal and Reference Value for Power Window
BACK DOOR WINDOW GLASS ............................. 13               .         Main Switch / With Front and Rear Power Window
 Removal and Installation ....................................... 13  .         Anti-pinch System .................................................. 38.
   REMOVAL .......................................................... 13
                                                                      .         Terminal and Reference Value for (Front and Rear)
   INSTALLATION .................................................. 14 .         Power Window Switch / With Front and Rear Win-
POWER WINDOW SYSTEM ................................... 15            .         dow Anti-pinch System .......................................... 39    .
 Component Parts and Harness Connector Location 15                    ...       Work Flow .............................................................. 39
                                                                                                                                                       .
 System Description ............................................... 16.         CONSULT-II Inspection Procedure ........................ 40            .
   WITH FRONT POWER WINDOW ANTI-PINCH                                             ACTIVE TEST .................................................... 41  .
   SYSTEM ............................................................ 16
                                                                      .           WORK SUPPORT .............................................. 41       .


Revision: 2004 November                                                   GW-1                                                    2004.5 FX35/FX45
    DATE MONITOR ................................................ 41     .            DOOR GLASS ....................................................80     .
  Trouble Diagnosis Symptom Chart / With Front                                        REGULATOR ASSEMBLY ..................................81               .
  Power Window Anti-pinch System ......................... 42            .          Disassembly and assembly ...................................82          .
  Trouble Diagnosis Symptom Chart / With Front and                                    REGULATOR ASSEMBLY ..................................82               .
  Rear Power Window Anti-pinch System ................ 43                .          Inspection after Installation ....................................82    .
  BCM Power Supply and Ground Circuit Check ..... 44                     .            SETTING OF LIMIT SWITCH (WITH ANTI-
  Power Window Main Switch Power Supply Circuit                                       PINCH SYSTEM ONLY) .....................................82            .
  Check .................................................................... 45
                                                                         .            FITTING INSPECTION .......................................83          .
  Front Power Window Switch (Passenger Side)                                      INSIDE MIRROR ......................................................84    .
  Power Supply and Ground Circuit Check .............. 46                .          Wiring Diagram --I/MIRR-- ...................................84         .
  Rear Power Window Switch (LH or RH) Power Sup-                                    Removal and Installation ........................................85     .
  ply and Ground Circuit Check / With Front and Rear                                  REMOVAL ...........................................................85 .
  Power Window Anti-pinch System ......................... 47            .            INSTALLATION ...................................................85    .
  Front Power Window Motor (Driver Side) Circuit                                      COMPASS ..........................................................85  .
  Check .................................................................... 48
                                                                         .        REAR WINDOW DEFOGGER .................................86                  .
  Front Power Window Motor (Passenger Side) Cir-                                    Component Parts and Harness Connector Location                          ...86
  cuit Check .............................................................. 49
                                                                         .          System Description ................................................86   .
  Rear Power Window Motor (LH) Circuit Check / With                                 CAN Communication System Description .............88                    .
  Front Anti-pinch Power Window System ............... 50                .          CAN Communication Unit ......................................88         .
  Rear Power Window Motor (RH) Circuit Check / With                                 Schematic ..............................................................89
                                                                                                                                                            .
  Front Anti-pinch Power Window System ............... 52                .          Wiring Diagram -- DEF -- .....................................90        .
  Rear Power Window Motor (LH or RH) Circuit Check                                  Terminal and Reference Value for BCM .................94                .
  / With Front and Rear Power Window Anti-pinch                                     Terminal and Reference Value for IPDM E/R .........94                   .
  System ................................................................... 55
                                                                         .          Work Flow ..............................................................94
                                                                                                                                                            .
  Limit Switch Circuit Check (Driver Side) ................ 56           .          CONSULT-II Inspection Procedure ........................95              .
  Limit Switch Circuit Check (Passenger Side) ........ 57                .            DATA MONITOR .................................................96      .
  Limit Switch Circuit Check (Rear LH or RH) / With                                   ACTIVE TEST .....................................................96   .
  Front and Rear Anti-pinch System ........................ 59           .          Trouble Diagnoses Symptom Chart .......................97               .
  Encoder Circuit Check (Driver Side) ...................... 61          .          BCM Power Supply and Ground Circuit Check .....97                       .
  Encoder Circuit Check (Passenger Side) .............. 63               .          Rear Window Defogger Switch Circuit Check ........98                    .
  Encoder Circuit Check (Rear LH or RH) / With Front                                Rear Window Defogger Power Supply Circuit
  and Rear Power Window Anti-pinch System ......... 65                   .          Check ................................................................... 100
                                                                                                                                                            .
  Door Switch Check ................................................ 67  .          Rear Window Defogger Circuit Check ................. 102                .
  Front Door Key Cylinder Switch Check ................. 69              .          Door Mirror Defogger Power Supply Circuit Check.103
  Power Window Serial Link Check (Passenger Side) 71                     ...        Driver Side Door Mirror Defogger Circuit Check .. 104                   .
  Power Window Serial Link Check (Rear LH or RH)                                    Passenger Side Door Mirror Defogger Circuit Check
  / With Front and Rear Power Window Anti-pinch                                                                                                             .105
  System ................................................................... 73
                                                                         .          Rear Window Defogger Signal Check ................. 106                 .
  Power Window Lock Switch Check ....................... 73              .          Filament Check .................................................... 107 .
SIDE WINDOW GLASS ........................................... 74         .          Filament Repair .................................................... 107.
  Removal and Installation ....................................... 74    .            REPAIR EQUIPMENT ...................................... 107           .
    REMOVAL .......................................................... 74.            REPAIRING PROCEDURE .............................. 108                .
    INSTALLATION ................................................... 75  .        DOOR MIRROR ...................................................... 109    .
FRONT DOOR GLASS AND REGULATOR ............ 76                           .          Wiring Diagram -- MIRROR --/For Manual Oper-
  Removal and Installation ....................................... 76    .          ation Door Mirror .................................................. 109.
    DOOR GLASS .................................................... 76   .          Wiring Diagram -- MIRROR --/For Automatic Drive
    REGULATOR ASSEMBLY ................................. 77              .          Positioner Interlocking Door ................................. 110      .
  Disassembly and assembly ................................... 78        .          Trouble Diagnosis ................................................ 112  .
    REGULATOR ASSEMBLY ................................. 78              .          Removal and Installation ...................................... 113     .
  Inspection after Installation .................................... 78  .            REMOVAL ......................................................... 113 .
    SETTING OF LIMIT SWITCH ............................. 78             .            INSTALLATION ................................................. 113    .
    FITTING INSPECTION ....................................... 78        .          Disassembly and Assembly ................................. 113          .
REAR DOOR GLASS AND REGULATOR .............. 80                          .            DISASSEMBLY ................................................. 113     .
  Removal and Installation ....................................... 80    .            ASSEMBLY ....................................................... 114  .




Revision: 2004 November                                                     GW-2                                                      2004.5 FX35/FX45
                                              PRECAUTIONS

PRECAUTIONS                                                         PFP:00001
                                                                                                                         A
Precautions for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT
BELT PRE-TENSIONER"                                                                                           AIS0039V


The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along                            B
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front              C
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING:                                                                                                                 D
q    To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
     in the event of a collision which would result in air bag inflation, all maintenance must be per-
     formed by an authorized NISSAN/INFINITI dealer.                                                                     E
q    Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
     sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
     Bag Module, see the SRS section.                                                                                    F
q    Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
     Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
     harness connectors.
                                                                                                                         G
Handling for Adhesive and Primer                                                                              AIS0039W


q   Do not use an adhesive which is past its usable date. Shelf life of this product is limited to six months after
    the date of manufacture. Carefully adhere to the expiration or manufacture date printed on the box.              H
q   Keep primers and adhesive in a cool, dry place. Ideally, they should be stored in a refrigerator.
q   Open the seal of the primer and adhesive just before application. Discard the remainder.
                                                                                                                    GW
q   Before application, be sure to shake the primer container to stir the contents. If any floating material is
    found, do not use it.
q   If any primer or adhesive contacts the skin, wipe it off with gasoline or equivalent and wash the skin with
                                                                                                                     J
    soap.
q   When using primer and adhesive, always observe the precautions in the instruction manual.
Wiring Diagrams and Trouble Diagnosis                                                                         AIS0039X   K
When you read wiring diagrams, refer to the following:
q  GI-15, "How to Read Wiring Diagrams".
                                                                                                                         L
q  PG-3, "POWER SUPPLY ROUTING CIRCUIT".
When you perform trouble diagnosis, refer to the following:
q  GI-11, "HOW TO FOLLOW TEST GROUPS IN TROUBLE DIAGNOSES".                                                              M
q  GI-27, "How to Perform Efficient Diagnosis for an Electrical Incident".
Check for any service bulletins before servicing the vehicle.




Revision: 2004 November                              GW-3                                       2004.5 FX35/FX45
                                            PREPARATION

PREPARATION                                                                                              PFP:00002

Special Service Tools                                                                                        AIS0039Y


The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
    Tool number
    (Kent-Moore No.)                                                   Description
    Tool name




    (J39570)
                                                                       Locating the noise
    Chassis ear


                                                       SIIA0993E




    (J43980)
    NISSAN Squeak and                                                  Repairing the cause of noise
    Rattle Kit


                                                       SIIA0994E



Commercial Service Tools                                                                                     AIS0039Z



    Tool name                                                          Description




    Engine ear                                                         Locating the noise



                                                       SIIA0995E




Revision: 2004 November                            GW-4                                         2004.5 FX35/FX45
                       SQUEAK AND RATTLE TROUBLE DIAGNOSES

SQUEAK AND RATTLE TROUBLE DIAGNOSES                                                                       PFP:00000
                                                                                                                            A
Work Flow                                                                                                        AIS003A0




                                                                                                                            B



                                                                                                                            C


                                                                                                                            D


                                                                                                                            E



                                                                                                                            F



                                                                                                        SBT842
                                                                                                                            G

CUSTOMER INTERVIEW
Interview the customer if possible, to determine the conditions that exist when the noise occurs. Use the Diag- H
nostic Worksheet during the interview to document the facts and conditions when the noise occurs and any
customer's comments; refer to GW-9, "Diagnostic Worksheet" . This information is necessary to duplicate the
conditions that exist when the noise occurs.
                                                                                                                       GW
q    The customer may not be able to provide a detailed description or the location of the noise. Attempt to
     obtain all the facts and conditions that exist when the noise occurs (or does not occur).
q    If there is more than one noise in the vehicle, be sure to diagnose and repair the noise that the customer
                                                                                                                        J
     is concerned about. This can be accomplished by test driving the vehicle with the customer.
q    After identifying the type of noise, isolate the noise in terms of its characteristics. The noise characteristics
     are provided so the customer, service adviser and technician are all speaking the same language when
     defining the noise.                                                                                                K
q    Squeak --(Like tennis shoes on a clean floor)
     Squeak characteristics include the light contact/fast movement/brought on by road conditions/hard sur-
     faces=higher pitch noise/softer surfaces=lower pitch noises/edge to surface=chirping                               L
q    Creak--(Like walking on an old wooden floor)
     Creak characteristics include firm contact/slow movement/twisting with a rotational movement/pitch
     dependent on materials/often brought on by activity.                                                               M
q    Rattle--(Like shaking a baby rattle)
     Rattle characteristics include the fast repeated contact/vibration or similar movement/loose parts/missing
     clip or fastener/incorrect clearance.
q    Knock --(Like a knock on a door)
     Knock characteristics include hollow sounding/sometimes repeating/often brought on by driver action.
q    Tick--(Like a clock second hand)
     Tick characteristics include gentle contacting of light materials/loose components/can be caused by driver
     action or road conditions.
q    Thump--(Heavy, muffled knock noise)
     Thump characteristics include softer knock/dead sound often brought on by activity.
q    Buzz--(Like a bumble bee)
     Buzz characteristics include high frequency rattle/firm contact.
q    Often the degree of acceptable noise level will vary depending upon the person. A noise that you may
     judge as acceptable may be very irritating to the customer.
q    Weather conditions, especially humidity and temperature, may have a great effect on noise level.


Revision: 2004 November                              GW-5                                      2004.5 FX35/FX45
                       SQUEAK AND RATTLE TROUBLE DIAGNOSES

DUPLICATE THE NOISE AND TEST DRIVE
If possible, drive the vehicle with the customer until the noise is duplicated. Note any additional information on
the Diagnostic Worksheet regarding the conditions or location of the noise. This information can be used to
duplicate the same conditions when you confirm the repair.
If the noise can be duplicated easily during the test drive, to help identify the source of the noise, try to dupli-
cate the noise with the vehicle stopped by doing one or all of the following:
1) Close a door.
2) Tap or push/pull around the area where the noise appears to be coming from.
3) Rev the engine.
4) Use a floor jack to recreate vehicle "twist".
5) At idle, apply engine load (electrical load, half-clutch on M/T models, drive position on A/T models).
6) Raise the vehicle on a hoist and hit a tire with a rubber hammer.
q    Drive the vehicle and attempt to duplicate the conditions the customer states exist when the noise occurs.
q    If it is difficult to duplicate the noise, drive the vehicle slowly on an undulating or rough road to stress the
     vehicle body.
CHECK RELATED SERVICE BULLETINS
After verifying the customer concern or symptom, check ASIST for Technical Service Bulletins (TSBs) related
to that concern or symptom.
If a TSB relates to the symptom, follow the procedure to repair the noise.
LOCATE THE NOISE AND IDENTIFY THE ROOT CAUSE
1.   Narrow down the noise to a general area. To help pinpoint the source of the noise, use a listening tool
     (Chassis Ear: J39570, Engine Ear and mechanics stethoscope).
2.   Narrow down the noise to a more specific area and identify the cause of the noise by:
q    removing the components in the area that you suspect the noise is coming from.
     Do not use too much force when removing clips and fasteners, otherwise clips and fastener can be broken
     or lost during the repair, resulting in the creation of new noise.
q    tapping or pushing/pulling the component that you suspect is causing the noise.
     Do not tap or push/pull the component with excessive force, otherwise the noise will be eliminated only
     temporarily.
q    feeling for a vibration with your hand by touching the component(s) that you suspect is (are) causing the
     noise.
q    placing a piece of paper between components that you suspect are causing the noise.
q    looking for loose components and contact marks.
     Refer to GW-7, "Generic Squeak and Rattle Troubleshooting" .
REPAIR THE CAUSE
q   If the cause is a loose component, tighten the component securely.
q   If the cause is insufficient clearance between components:



◦ Jabse Service Manual Search 2022 ◦ Jabse PravopisonTap.bg ◦ Other service manual resources online : FixyaeServiceinfo
