Image preview - the first page of the document
ma


>> Download ma documenatation <<

Text preview - extract from the document
MAINTENANCE


L MAINTENANCE

                                                                                                                                                              A




                                                                                            SECTION
                                                                                                            MAINTENANCE
                                                                                                                       MA                                     B



                                                                                                                                                              C


                                                                                                                                                              D


                                                                                                                                                              E
                                                               CONTENTS
PREPARATION .......................................................... 3
                                                                     .            INSPECTION AFTER INSTALLATION ............... 20                   .        F
 Special Service Tools .............................................. 3
                                                                     .          Changing Spark Plugs (Platinum-Tipped Type) ..... 20                 .
 Commercial Service Tools ....................................... 3  .            REMOVAL .......................................................... 20
                                                                                                                                                     .
GENERAL MAINTENANCE ...................................... 4         .            INSPECTION AFTER REMOVAL ...................... 20                 .        G
 Explanation of General Maintenance ...................... 4         .            INSTALLATION .................................................. 21 .
   OUTSIDE THE VEHICLE ..................................... 5       .          Checking EVAP Vapor Lines ................................. 21       .
   INSIDE THE VEHICLE ......................................... 5    .         ENGINE MAINTENANCE (VK45DE ENGINE) ........ 22                        .
                                                                                                                                                              H
   UNDER THE HOOD AND VEHICLE ................... 6                  .          Checking Drive Belts ............................................. 22.
PERIODIC MAINTENANCE ...................................... 7        .          Tension Adjustment ............................................... 22.
 Introduction of Periodic Maintenance ...................... 7       .          Changing Engine Coolant ...................................... 22    .
 Schedule 1 .............................................................. 8
                                                                     .            DRAINING ENGINE COOLANT ......................... 22               .         I
   EMISSION CONTROL SYSTEM MAINTE-                                                REFILLING ENGINE COOLANT ........................ 23               .
   NANCE ................................................................. 8
                                                                     .            FLUSHING COOLING SYSTEM ........................ 24                .
   CHASSIS AND BODY MAINTENANCE .............. 9                     .          Checking Fuel Lines .............................................. 25.        J
 Schedule 2 ............................................................ 10
                                                                     .          Changing Air Cleaner Filter ................................... 25   .
   EMISSION CONTROL SYSTEM MAINTE-                                                VISCOUS PAPER TYPE .................................... 25         .
   NANCE ............................................................... 10
                                                                     .          Changing Engine Oil .............................................. 25.
                                                                                                                                                              K
   CHASSIS AND BODY MAINTENANCE .............11                      .          Changing Oil Filter ................................................. 26
                                                                                                                                                     .
RECOMMENDED FLUIDS AND LUBRICANTS ..... 12                           .            REMOVAL .......................................................... 26
                                                                                                                                                     .
 Fluids and Lubricants ............................................ 12
                                                                     .            INSTALLATION .................................................. 26 .
 SAE Viscosity Number .......................................... 13  .            INSPECTION AFTER INSTALLATION ............... 27                   .        MA
   GASOLINE ENGINE OIL ................................... 13        .          Changing Spark Plugs (Platinum-Tipped Type) ..... 27                 .
 Anti-Freeze Coolant Mixture Ratio ........................ 13       .            REMOVAL .......................................................... 27
                                                                                                                                                     .
ENGINE MAINTENANCE (VQ35DE ENGINE) ........ 14                       .            INSPECTION AFTER REMOVAL ...................... 27                 .        M
 Checking Drive Belts ............................................. 14
                                                                     .            INSTALLATION .................................................. 28 .
 Tension Adjustment ............................................... 14
                                                                     .          Checking EVAP Vapor Lines ................................. 28       .
   ALTERNATOR AND POWER STEERING OIL                                           CHASSIS AND BODY MAINTENANCE .................. 29                    .
   PUMP BELT ....................................................... 15
                                                                     .          Checking Exhaust System ..................................... 29     .
   AIR CONDITIONER COMPRESSOR BELT ...... 15                         .          Checking A/T Fluid ................................................ 29
                                                                                                                                                     .
 Changing Engine Coolant ..................................... 15    .          Changing A/T Fluid ................................................ 31
                                                                                                                                                     .
   DRAINING ENGINE COOLANT ........................ 15               .          Checking Transfer Fluid ........................................ 31  .
   REFILLING ENGINE COOLANT ....................... 16               .          Changing Transfer Fluid ........................................ 32  .
   FLUSHING COOLING SYSTEM ........................ 17               .          Checking Propeller Shaft ....................................... 32  .
 Checking Fuel Lines .............................................. 17
                                                                     .          Checking Differential Gear Oil ............................... 32    .
 Changing Air Cleaner Filter ................................... 17  .          Changing Differential Gear Oil ............................... 33    .
   VISCOUS PAPER TYPE .................................... 17        .          Balancing Wheels (Bonding Weight Type) ............ 33               .
 Changing Engine Oil ............................................. 18.            REMOVAL .......................................................... 33
                                                                                                                                                     .
 Changing Oil Filter ................................................ 19
                                                                     .            WHEEL BALANCE ADJUSTMENT .................... 33                   .
   REMOVAL .......................................................... 19
                                                                     .          Tire Rotation .......................................................... 35
                                                                                                                                                     .
   INSTALLATION .................................................. 19.          Checking Brake Fluid Level and Leaks ................. 35            .


Revision: 2004 November                                                  MA-1                                                    2004.5 FX35/FX45
 Checking Brake Lines and Cables ........................ 35            .        SERVICE DATA AND SPECIFICATIONS (SDS) .....40                        .
 Changing Brake Fluid ............................................ 35   .         Standard and Limit .................................................40
                                                                                                                                                      .
 Checking Disc Brake ............................................. 36   .           BELT DEFLECTION AND TENSION (VQ35DE)...40
   ROTOR ............................................................... 36
                                                                        .           BELT DEFLECTION AND TENSION (VK45DE)...40
   CALIPER ............................................................ 36
                                                                        .           ENGINE COOLANT CAPACITY (APPROXI-
   PAD .................................................................... 36
                                                                        .           MATE) (VQ35DE) ...............................................40  .
 Checking Steering Gear and Linkage .................... 36             .           ENGINE COOLANT CAPACITY (APPROXI-
   STEERING GEAR .............................................. 36      .           MATE) (VK45DE) ................................................40 .
   STEERING LINKAGE ......................................... 36        .           RADIATOR ..........................................................40
                                                                                                                                                      .
 Checking Power Steering Fluid and Lines ............. 37               .           ENGINE OIL CAPACITY (APPROXIMATE)
 Axle and Suspension Parts .................................... 37      .           (VQ35DE) ...........................................................40
                                                                                                                                                      .
 Drive Shaft ............................................................. 38
                                                                        .           ENGINE OIL CAPACITY (APPROXIMATE)
 Lubricating Locks, Hinges and Hood Latch ........... 38                .           (VK45DE) ............................................................41
                                                                                                                                                      .
 Checking Seat Belt, Buckles, Retractors, Anchors                                   SPARK PLUG (PLATINUM-TIPPED TYPE)
 and Adjusters ......................................................... 39
                                                                        .           (VQ35DE) ...........................................................41
                                                                                                                                                      .
                                                                                    SPARK PLUG (PLATINUM-TIPPED TYPE)
                                                                                    (VK45DE) ............................................................41
                                                                                                                                                      .
                                                                                    WHEEL BALANCE .............................................41     .




Revision: 2004 November                                                    MA-2                                                   2004.5 FX35/FX45
                                                       PREPARATION

PREPARATION                                                                                                                   PFP:00002
                                                                                                                                            A
Special Service Tools                                                                                                            ALS000G2

The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
  Tool number                                                                                                                               B
  (Kent-Moore No.)                                                                       Description
  Tool name

  KV10115801                                                                             Removing and installing oil filter
                                                                                                                                            C
  (J38956)                                                                               a: 64.3 mm (2.531 in)
  Oil filter wrench

                                                                                                                                            D

                                                                         S-NT375

                                                                                                                                            E
Commercial Service Tools                                                                                                         ALS000G3



  Tool name
                                                                                         Description
  (Kent-Moore No.)                                                                                                                          F
  Power tool                                                                             Loosening bolts and nuts

                                                                                                                                            G


                                                                                                                                            H
                                                                         PBIC0190E


  Spark plug wrench                                                                      Removing and installing spark plug
                                                                                                                                             I


                                                                                                                                            J

                                                                         S-NT047


  Belt tension gauge                                                                     Checking drive belt tension (VQ35DE)               K
  (BT3373-F)


                                                                                                                                            MA


                                                                         AMA126
                                                                                                                                            M




Revision: 2004 November                                         MA-3                                               2004.5 FX35/FX45
                                   GENERAL MAINTENANCE

GENERAL MAINTENANCE                                                                               PFP:00000

Explanation of General Maintenance                                                                    ALS000G4


General maintenance includes those items which should be checked during the normal day-to-day operation
of the vehicle. They are essential if the vehicle is to continue operating properly. The owners can perform
checks and inspections themselves or have their INFINITI dealers do them.




Revision: 2004 November                           MA-4                                   2004.5 FX35/FX45
                                            GENERAL MAINTENANCE

OUTSIDE THE VEHICLE
The maintenance items listed here should be performed from time to time, unless otherwise specified.                                  A
  Item                                                                                                             Reference page
  Tires                    Check the pressure with a gauge, including the spare, at least once a month
                           and always prior to a long distance trips. Adjust to the specified pressure if                --           B
                           necessary. Check carefully for damage, cuts or excessive wear.
  Wheel nuts               When checking the tires, make sure no nuts are missing, and check for any
                                                                                                                         --
                           loose nuts. Tighten if necessary.
                                                                                                                                      C
                           Clean the windshield on a regular basis. Check the windshield at least every
  Windshield                                                                                                             --
                           six months for cracks or other damage. Repair as necessary.
  Tire rotation            Tires should be rotated every 12,000 km (7,500 miles).                                      MA-35          D
  Wheel alignment and      If the vehicle pulls to either side while driving on a straight and level road, or if
  balance                  you detect uneven or abnormal tire wear, there may be a need for wheel align-
                                                                                                                   MA-33, FSU-6
                           ment. If the steering wheel or seat vibrates at normal highway speeds, wheel
                           balancing may be needed.                                                                                   E
  Windshield wiper
                           Check for cracks or wear if they do not wipe properly.                                        --
  blades
  Doors and engine         Check that all doors and the engine hood operate smoothly as well as the
                                                                                                                                      F
  hood                     trunk lid and back hatch. Also make sure that all latches lock securely. Lubri-
                           cate if necessary. Make sure that the secondary latch keeps the hood from
                                                                                                                       MA-38
                           opening when the primary latch is released.                                                                G
                           When driving in areas using road salt or other corrosive materials, check lubri-
                           cation frequently.
  Lamps                    Make sure that the headlamps, stop lamps, tail lamps, turn signal lamps, and
                           other lamps are all operating properly and installed securely. Also check head-               --
                                                                                                                                      H
                           lamp aim. Clean the headlamps on a regular basis.

INSIDE THE VEHICLE                                                                                                                     I
The maintenance items listed here should be checked on a regular basis, such as when performing periodic maintenance, cleaning the
vehicle, etc.
  Item                                                                                                      Reference page
  Warning lamps and                                                                                                                   J
                            Make sure that all warning lamps and chimes are operating properly.                         --
  chimes
  Windshield wiper and      Check that the wipers and washer operate properly and that the wipers do not
                                                                                                                        --
  washer                    streak.                                                                                                   K
  Windshield defroster      Check that the air comes out of the defroster outlets properly and in sufficient
                                                                                                                        --
                            quantity when operating the heater or air conditioner.
  Steering wheel            Check that it has the specified play. Be sure to check for changes in the steer-                          MA
                            ing condition, such as excessive play, hard steering or strange noises.                     --
                             Free play: Less than 35 mm (1.38 in)
  Seats                     Check seat position controls such as seat adjusters, seatback recliner, etc. to                           M
                            make sure they operate smoothly and that all latches lock securely in every
                            position. Check that the head restrains move up and down smoothly and that                  --
                            the locks (if equipped) hold securely in all latched positions. Check that the
                            latches lock securely for folding-down rear seatbacks.
  Seat belts                Check that all parts of the seat belt system (e.g. buckles, anchors, adjusters
                            and retractors) operate properly and smoothly, and are installed securely.                MA-39
                            Check the belt webbing for cuts, fraying, wear or damage.
  Accelerator pedal         Check the pedal for smooth operation and make sure the pedal does not catch
                                                                                                                        --
                            or require uneven effort. Keep the floor mats away from the pedal.
  Brakes                    Check that the brake does not pull the vehicle to one side when applied.                    --
  Brake pedal and           Check the pedal for smooth operation and make sure it has the proper dis-
  booster                   tance under it when depressed fully. Check the brake booster function. Be               BR-6, BR-15
                            sure to keep the floor mats away from the pedal.




Revision: 2004 November                                         MA-5                                               2004.5 FX35/FX45
                                             GENERAL MAINTENANCE

  Item                                                                                                             Reference page
  Parking brake             Check that the pedal has the proper travel and make sure that the vehicle is
                                                                                                                       PB-2
                            held securely on a fairly steep hill when only the parking brake is applied.
  Automatic transmis-       Check that the lock release button on the selector lever operates properly and
  sion "Park" mecha-        smoothly. On a fairly steep hill check that the vehicle is held securely with the            --
  nism                      selector lever in the P (Park) position without applying any brakes.

UNDER THE HOOD AND VEHICLE
The maintenance items listed here should be checked periodically (e.g. each time you check the engine oil or refuel).
  Item                                                                                                           Reference page
  Windshield washer
                           Check that there is adequate fluid in the tank.                                               --
  fluid
  Engine coolant level     Check the coolant level when the engine is cold.                                         MA-15, MA-22
  Radiator and hoses       Check the front of the radiator and clean off any dirt, insects, leaves, etc., that
                           may have accumulated. Make sure the hoses have no cracks, deformation,                        --
                           deterioration or loose connections.
  Brake fluid level        Make sure that the brake fluid level is between the "MAX" and "MIN" lines on
                                                                                                                       MA-35
                           the reservoir.
  Battery                  Check the fluid level in each cell. It should be between the "MAX" and "MIN"
                                                                                                                   SC-5, "CHECKING
                           lines. Vehicles operated in high temperatures or under severe conditions
                                                                                                                 ELECTROLYTE LEVEL"
                           require frequent checks of the battery fluid level.
  Engine drive belts       Make sure that no belt is frayed, worn, cracked or oily.                                 MA-14, MA-22
  Engine oil level         Check the level on the oil level gauge after parking the vehicle on a level spot
                                                                                                                    MA-18, MA-25
                           and turning off the engine.
  Power steering fluid     Check the level on the dipstick with the engine off. Check the lines for improper
                                                                                                                       MA-37
  level and lines          attachment, leaks, cracks, etc.
  Exhaust system           Make sure there are no loose supports, cracks or holes. If the sound of the
                           exhaust seems unusual or there is a smell of exhaust fumes, immediately                     MA-29
                           locate the trouble and correct it.
  Underbody                The underbody is frequently exposed to corrosive substances such as those
                           used on icy roads or to control dust. It is very important to remove these sub-
                           stances, otherwise rust will form on the floor pan, frame, fuel lines and around
                                                                                                                         --
                           the exhaust system. At the end of winter, the underbody should be thoroughly
                           flushed with plain water, being careful to clean those areas where mud and dirt
                           can easily accumulate.
  Fluid leaks              Check under the vehicle for fuel, oil, water or other fluid leaks after the vehicle
                           has been parked for a while. Water dripping from the air conditioner after use is
                                                                                                                         --
                           normal. If you should notice any leaks or gasoline fumes are evident, check for
                           the cause and correct it immediately.




Revision: 2004 November                                         MA-6                                               2004.5 FX35/FX45
                                            PERIODIC MAINTENANCE

PERIODIC MAINTENANCE                                                                                                      PFP:00026
                                                                                                                                        A
Introduction of Periodic Maintenance                                                                                         ALS000G5


Two different maintenance schedules are provided, and should be used, depending upon the conditions in
which the vehicle is mainly operated. After 60,000 miles (96,000 km) or 48 months, continue the periodic                                B
maintenance at the same mileage/time intervals.
              Follow Periodic Maintenance Schedule 1 if the driving habits frequently include     Emission Control Sys-
              one or more of the following driving conditions:                                    tem Maintenance                       C
              q   Repeated short trips of less than 5 miles (8 km).
                                                                                                                           MA-8
              q   Repeated short trips of less than 10 miles (16 km) with outside temperatures
                  remaining below freezing.
                                                                                                                                        D
 Schedule 1   q   Operating in hot weather in stop-and-go "rush hour" traffic.
              q   Extensive idling and/or low speed driving for long distances, such as police,   Chassis and Body
                  taxi or door-to-door delivery use.                                              Maintenance
                                                                                                                                        E
              q   Driving in dusty conditions.                                                                             MA-9
              q   Driving on rough, muddy, or salt spread roads.
              q   Towing a trailer, using a camper or a car-top carrier.                                                                F
              Follow Periodic Maintenance Schedule 2 if none of driving conditions shown in       Emission Control Sys-
                                                                                                                           MA-10
              Schedule 1 apply to the driving habits.                                             tem Maintenance
 Schedule 2
                                                                                                  Chassis and Body                      G
                                                                                                                           MA-11
                                                                                                  Maintenance


                                                                                                                                        H



                                                                                                                                         I


                                                                                                                                        J



                                                                                                                                        K


                                                                                                                                        MA



                                                                                                                                        M




Revision: 2004 November                                        MA-7                                           2004.5 FX35/FX45
                                             PERIODIC MAINTENANCE

Schedule 1                                                                                                                               ALS000G6

EMISSION CONTROL SYSTEM MAINTENANCE
                             Abbreviations: R = Replace.    I = Inspect. Correct or replace if necessary.   [ ]: At the mileage intervals only
 MAINTENANCE OPERATION                                                  MAINTENANCE INTERVAL                                    Reference
 Perform at number of miles,       Miles x 1,000   3.75       7.50     11.25      15     18.75    22.5      26.25     30        Section -
 kilometers or months, which-      (km x 1,000)     (6)       (12)      (18)     (24)     (30)    (36)       (42)    (48)       Page or -
 ever comes first.                    Months         3          6        9        12       15      18         21      24       Content Title

                                                                                                                               MA-14, MA-
 Drive belts                        NOTE (1)
                                                                                                                                   22
                                                                                                                               MA-17, MA-
 Air cleaner filter                 NOTE (2)                                                                          [R]
                                                                                                                                   25
                                                                                                                               MA-21, MA-
 EVAP vapor lines                                                                                                      I*
                                                                                                                                   28
                                                                                                                               MA-17, MA-
 Fuel lines                                                                                                            I*
                                                                                                                                   25
 Fuel filter                        NOTE (3)                                                                                         -
                                                                                                                               MA-15, MA-
 Engine coolant                     NOTE (4)
                                                                                                                                   22
                                                                                                                               MA-18, MA-
 Engine oil                                          R          R        R        R        R        R        R         R
                                                                                                                                   25
 Engine oil filter [Use part No.
 15208 31U00 (for VK45DE),                                                                                                     MA-19, MA-
                                                     R          R        R        R        R        R        R         R
 15208 65F00 (for VQ35DE)                                                                                                          26
 or equivalent.]
 Spark plugs (PLATINUM-                                                                                                        MA-20, MA-
                                                                Replace every 105,000 miles (169,000 km).
 TIPPED type)                                                                                                                      27
                                                                                                                                 EM-89,
                                                                                                                              "Valve Clear-
 Intake & exhaust valve clear-
                                    NOTE (5)                                                                                   ance", EM-
 ance*
                                                                                                                               216, "Valve
                                                                                                                               Clearance"

 MAINTENANCE OPERATION                                                   MAINTENANCE INTERVAL                                   Reference
 Perform at number of miles,       Miles x 1,000    33.75       37.5     41.25     45     48.75     52.5     56.25      60      Section -
 kilometers or months, which-      (km x 1,000)      (54)       (60)      (66)    (72)     (78)     (84)      (90)     (96)     Page or -
 ever comes first.                    Months          27         30        33      36       39       42        45       48     Content Title

                                                                                                                               MA-14, MA-
 Drive belts                         NOTE (1)                                                                           I*
                                                                                                                                   22
                                                                                                                               MA-17, MA-
 Air cleaner filter                  NOTE (2)                                                                          [R]
                                                                                                                                   25
                                                                                                                               MA-21, MA-
 EVAP vapor lines                                                                                                       I*
                                                                                                                                   28
                                                                                                                               MA-17, MA-
 Fuel lines                                                                                                             I*
                                                                                                                                   25
 Fuel filter                         NOTE (3)                                                                                        -
                                                                                                                               MA-15, MA-
 Engine coolant                      NOTE (4)                                                                          R*
                                                                                                                                   22
                                                                                                                               MA-18, MA-
 Engine oil                                           R          R           R     R        R        R         R        R
                                                                                                                                   25
 Engine oil filter [Use part No.
 15208 31U00 (for VK45DE),                                                                                                     MA-19, MA-
                                                      R          R           R     R        R        R         R        R
 15208 65F00 (for VQ35DE)                                                                                                          26
 or equivalent.]




Revision: 2004 November                                          MA-8                                                2004.5 FX35/FX45
                                             PERIODIC MAINTENANCE

 MAINTENANCE OPERATION                                                       MAINTENANCE INTERVAL                                     Reference
                                                                                                                                      Section -      A
 Perform at number of miles,       Miles x 1,000      33.75        37.5      41.25         45      48.75     52.5    56.25     60
 kilometers or months, which-      (km x 1,000)        (54)        (60)       (66)        (72)      (78)     (84)     (90)    (96)    Page or -
 ever comes first.                    Months            27          30         33          36        39       42       45      48    Content Title

 Spark plugs (PLATINUM-                                                                                                               MA-20, MA-     B
                                                                     Replace every 105,000 miles (169,000 km).
 TIPPED type)                                                                                                                             27
                                                                                                                                        EM-89,
 Intake & exhaust valve clear-
                                                                                                                                     "Valve Clear-   C
                                     NOTE (5)                                                                                         ance", EM-
 ance*
                                                                                                                                      216, "Valve
                                                                                                                                      Clearance"
                                                                                                                                                     D
NOTE:
(1) After 60,000 miles (96,000 km) or 48 months, inspect every 15,000 miles (24,000 km) or 12 months. Replace the drive belts if found
     damaged or if the auto belt tensioner reading (only for VK45DE engine) reaches the maximum limit.
(2) If operating mainly in dusty conditions, more frequent maintenance may be required.                                                              E
(3) Maintenance-free item. For service procedures, refer to FL section.
(4) After 60,000 miles (96,000 km) or 48 months, replace every 30,000 miles (48,000 km) or 24 months.
(5) If valve noise increases, inspect valve clearance.
* Maintenance items and intervals with "*" are recommended by INFINITI for reliable vehicle operation. The owner need not perform                    F
such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are
required.

CHASSIS AND BODY MAINTENANCE                                                                                                                         G
                                                                     Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary.
 MAINTENANCE OPERATION                                                     MAINTENANCE INTERVAL                                       Reference
                                                                                                                                                     H
 Perform at number of miles,     Miles x 1,000     3.75       7.50        11.25       15         18.75     22.5     26.25     30      Section -
 kilometers or months,           (km x 1,000)       (6)       (12)         (18)      (24)         (30)     (36)      (42)    (48)     Page or -
 whichever comes first.             Months           3          6            9        12           15       18        21      24     Content Title

 Brake lines & cables                                                                                                                                 I
                                                                                      I                                        I        MA-35

 Brake pads & rotors
                                                               I                      I                     I                  I        MA-36        J
 Automatic transmission &                                                                                                               MA-29
 transfer fluid & differential    NOTE (1)                                            I                                        I        MA-31,
 gear oil                                                                                                                               MA-32        K
 Steering gear, linkage &
 transfer gear, axle & sus-                                                                                                             MA-36,
                                                               I                      I                     I                  I
 pension parts                                                                                                                          MA-37
                                                                                                                                                     MA

                                                                                                                                        MA-5,
 Tire rotation                    NOTE (2)
                                                                                                                                        MA-35
                                                                                                                                                     M
 Drive shaft boots and pro-                                                                                                             MA-38,
                                                               I                      I                     I                  I
 peller shaft (AWD models)                                                                                                              MA-32
 Exhaust system
                                                               I                      I                     I                  I        MA-29

 In-cabin microfilter
                                                                                      R                                       R        ATC-125


 MAINTENANCE OPERATION                                                     MAINTENANCE INTERVAL                                       Reference
 Perform at number of miles,     Miles x 1,000     33.75      37.5        41.25       45         48.75     52.5     56.25     60      Section -
 kilometers or months,           (km x 1,000)       (54)      (60)         (66)      (72)         (78)     (84)      (90)    (96)     Page or -
 whichever comes first.             Months           27        30           33        36           39       42        45      48     Content Title

 Brake lines & cables
                                                                                      I                                       I         MA-35

 Brake pads & rotors
                                                               I                      I                     I                 I         MA-36




Revision: 2004 November                                            MA-9                                                      2004.5 FX35/FX45
                                                 PERIODIC MAINTENANCE

 MAINTENANCE OPERATION                                                         MAINTENANCE INTERVAL                                    Reference
 Perform at number of miles,        Miles x 1,000    33.75      37.5       41.25        45         48.75   52.5   56.25      60        Section -
 kilometers or months,              (km x 1,000)      (54)      (60)        (66)       (72)         (78)   (84)    (90)     (96)       Page or -
 whichever comes first.                Months          27        30          33         36           39     42      45       48       Content Title

 Automatic transmission &                                                                                                                MA-29
 transfer fluid & differential        NOTE (1)                                          I                                       I        MA-31,
 gear oil                                                                                                                                MA-32
 Steering gear, linkage &
 transfer gear, axle & sus-                                                                                                              MA-36,
                                                                    I                   I                   I                   I
 pension parts                                                                                                                           MA-37


                                                                                                                                         MA-5,
 Tire rotation                        NOTE (2)
                                                                                                                                         MA-35
 Drive shaft boots and pro-                                                                                                              MA-38,
                                                                    I                   I                   I                   I
 peller shaft (AWD models)                                                                                                               MA-32
 Exhaust system
                                                                    I                   I                   I                   I        MA-29

 In-cabin microfilter
                                                                                        R                                       R       ATC-125

NOTE:
(1) If towing a trailer, using a camper or a car-top carrier, or driving on rough or muddy roads, change (not just inspect) fluid (A/T, trans-
fer)/oil at every 30,000 miles (48,000 km) or 24 months. Using automatic transmission fluid other than Genuine NISSAN Matic J
ATF will cause deterioration in driveability and automatic transmission durability, and may damage the automatic transmis-
sion, which is not covered by the INFINITI new vehicle limited warranty.
(2) Refer to "Tire rotation" under the "General maintenance" heading earlier in this section.

Schedule 2                                                                                                                                     ALS000G7

EMISSION CONTROL SYSTEM MAINTENANCE
                                 Abbreviations: R = Replace.    I = Inspect. Correct or replace if necessary.      [ ]: At the mileage intervals only
 MAINTENANCE OPERATION                                                          MAINTENANCE INTERVAL
                                                                                                                                    Reference Sec-
 Perform at number of miles,              Miles x 1,000         7.5      15     22.5         30     37.5    45    52.5     60       tion - Page or -
 kilometers or months, whichever          (km x 1,000)         (12)     (24)    (36)        (48)    (60)   (72)   (84)    (96)        Content Title
 comes first.                                Months              6       12      18          24      30     36     42      48
 Drive belts                                NOTE (1)                                                                       I*       MA-14, MA-22
 Air cleaner filter                                                                         [R]                           [R]       MA-17, MA-25
 EVAP vapor lines                                                                            I*                            I*       MA-21, MA-28
 Fuel lines                                                                                  I*                            I*       MA-17, MA-25
 Fuel filter                                NOTE (2)                                                                                       -
 Engine coolant                             NOTE (3)                                                                      R*        MA-15, MA-22
 Engine oil                                                     R        R         R         R        R     R      R       R        MA-18, MA-25
 Engine oil filter [Use part No.
 15208 31U00 (for VK45DE),
                                                                R        R         R         R        R     R      R       R        MA-19, MA-26
 15208 65F00 (for VQ35DE) or
 equivalent.]
 Spark plugs (PLATINUM-
                                                                        Replace every 105,000 miles (169,000 km).                   MA-20, MA-27
 TIPPED type)
                                                                                                                                     EM-89, "Valve
 Intake & exhaust valve clear-                                                                                                      Clearance", EM-
                                            NOTE (4)
 ance*                                                                                                                                216, "Valve
                                                                                                                                      Clearance"
NOTE:
(1) After 60,000 miles (96,000 km) or 48 months, inspect every 15,000 miles (24,000 km) or 12 months. Replace the drive belts if found
     damaged or if the auto belt tensioner reading (only for VK45DE engine) reaches the maximum limit.
(2) Maintenance-free item. For service procedures, refer to FL section.
(3) After 60,000 miles (96,000 km) or 48 months, replace every 30,000 miles (48,000 km) or 24 months.
(4) If valve noise increases, inspect valve clearance.


Revision: 2004 November                                                 MA-10                                                   2004.5 FX35/FX45
                                              PERIODIC MAINTENANCE

* Maintenance items and intervals with "*" are recommended by INFINITI for reliable vehicle operation. The owner need not perform
such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are          A
required

CHASSIS AND BODY MAINTENANCE
                                                                  Abbreviations: R = Replace.    I = Inspect. Correct or replace if necessary.   B
 MAINTENANCE OPERATION                                                     MAINTENANCE INTERVAL
                                                                                                                            Reference Sec-
 Perform at number of miles, kilo-     Miles x 1,000        7.5      15    22.5     30    37.5      45     52.5     60      tion - Page or -
 meters or months, whichever           (km x 1,000)        (12)     (24)   (36)    (48)   (60)     (72)    (84)    (96)       Content Title      C
 comes first.                             Months             6       12     18      24     30       36      42      48
 Brake lines & cables
                                                                      I             I                I               I          MA-35
                                                                                                                                                 D
 Brake pads & rotors
                                                                      I             I                I               I          MA-36


 Automatic transmission & trans-
                                                                                                                                MA-29            E
                                                                      I             I                I               I          MA-31,
 fer fluid & differential gear oil
                                                                                                                                MA-32
 Steering gear, linkage & transfer
                                                                                                                                MA-36,           F
 gear, axle & suspension parts                                                      I                                I
                                                                                                                                MA-37

                                                                                                                                MA-5,
 Tire rotation                           NOTE (1)                                                                                                G
                                                                                                                                MA-35
 Drive shaft boots and propeller                                                                                                MA-38,
                                                                      I             I                I               I
 shaft (AWD models)                                                                                                             MA-32
 Exhaust system
                                                                                                                                                 H
                                                                                    I                                I          MA-29

 In-cabin microfilter
                                                                     R              R               R               R          ATC-125
                                                                                                                                                  I
NOTE:
(1) Refer to "Tire rotation" under the "General maintenance" heading earlier in this section.
                                                                                                                                                 J



                                                                                                                                                 K


                                                                                                                                                 MA



                                                                                                                                                 M




Revision: 2004 November                                           MA-11                                                  2004.5 FX35/FX45
                                RECOMMENDED FLUIDS AND LUBRICANTS

RECOMMENDED FLUIDS AND LUBRICANTS                                                                                             PFP:00000

Fluids and Lubricants                                                                                                            ALS000G8


                                                   Capacity (Approximate)
                                                         Imp mea-                            Recommended Fluids/Lubricants
                                        US measure                          Liter
                                                           sure

               With oil fil-   VK45DE    6-3/4 qt         5-5/8 qt          6.4     For VK45DE engine
 Engine oil    ter change      VQ35DE      5 qt          4 - 1/8 qt         4.7     q   API Certification Mark*1
 Drain and                                                                          q   API grade SJ or SL, Energy Conserving*1
               Without oil     VK45DE    6-1/8 qt         5-1/8 qt          5.8
 refill
               filter                                                               q   ILSAC grade GF-II & GF-III*1
               change          VQ35DE    4-5/8 qt         3-7/8 qt          4.4
                                                                                    For VQ35DE engine
                               VK45DE    7-5/8 qt         6-3/8 qt          7.2     q   API Certification Mark*1
                                                                                    q   API grade SG/SH, Energy Conserving I & II or
 Dry engine (Overhaul)
                               VQ35DE    5-3/4 qt         4-3/4 qt          5.4         API grade SJ or SL, Energy Conserving*1
                                                                                    q   ILSAC grade GF-I, GF-II & GF-III *1

               With res-       VK45DE    10-5/8 qt        8-3/4 qt          10.0
               ervoir tank     VQ35DE    9-1/8 qt         7-5/8 qt          8.6
 Cooling                                                                            Genuine NISSAN Long Life Antifreeze/ Coolant
 system                        VK45DE     7/8 qt           3/4 qt           0.8     or equivalent
               Reservoir
               tank            VQ35DE     7/8 qt           3/4 qt           0.8
 Automatic transmission fluid            10-7/8 qt         9-1/8 qt         10.3    Genuine NISSAN Matic J ATF *2
                                Front    1-3/8 pt         1-1/8 pt          0.65
 Differential gear oil                                                              API GL-5, Viscosity SAE 80W-90 *3
                                Rear       3 pt           2-1/2 pt          1.40
                                                                                    Genuine NISSAN Matic D ATF (Continental U.S.
 Transfer fluid                          2-5/8 pt         2-1/4 pt          1.25    and Alaska) or Canada NISSAN Automatic
                                                                                    Transmission Fluid*4
 Power steering fluid (PSF)              1-1/8 qt          7/8 qt           1.0     Genuine NISSAN PSF or equivalent*5
                                                                                    Genuine NISSAN Super Heavy Duty Brake
 Brake fluid                                --



◦ Jabse Service Manual Search 2024 ◦ Jabse PravopisonTap.bg ◦ Other service manual resources online : FixyaeServiceinfo
