Image preview - the first page of the document
>> Download rax documenatation <<
Text preview - extract from the document
REAR AXLE
D DRIVELINE/AXLE
A
SECTION RAX REAR AXLE
B
C
RAX
E
CONTENTS
PRECAUTIONS ......................................................... 2 . INSTALLATION .................................................... 6 . F
Caution .................................................................... 2
. Disassembly and Assembly ..................................... 6 .
PREPARATION .......................................................... 3. DISASSEMBLY .................................................... 6 .
Special Service Tools (SST) .................................... 3 . INSPECTION AFTER DISASSEMBLY ................. 7 . G
Commercial Service Tools ....................................... 3 . ASSEMBLY .......................................................... 7
.
NOISE, VIBRATION AND HARSHNESS (NVH) INSPECTION AFTER ASSEMBLY ....................... 8 .
TROUBLESHOOTING ............................................... 4 . REAR DRIVE SHAFT ................................................ 9 .
H
NVH Troubleshooting Chart .................................... 4 . Removal and Installation ......................................... 9 .
WHEEL HUB ............................................................. 5
. REMOVAL ............................................................ 9
.
On-Vehicle Inspection and Service ......................... 5 . INSPECTION AFTER REMOVAL ........................ 9 .
WHEEL BEARING INSPECTION ........................ 5 . INSTALLATION .................................................... 9 . I
Removal and Installation ......................................... 5 . Disassembly and Assembly ................................... 10 .
REMOVAL ............................................................ 5
. DISASSEMBLY .................................................. 10 .
INSPECTION AFTER REMOVAL ........................ 6 . INSPECTION AFTER DISASSEMBLY ............... 11 . J
ASSEMBLY ........................................................ 12.
SERVICE DATA ....................................................... 15.
Wheel Bearing ....................................................... 15
.
K
Drive Shaft ............................................................. 15
.
L
M
Revision: 2004 November RAX-1 2004.5 FX35/FX45
PRECAUTIONS
PRECAUTIONS PFP:00001
Caution ADS000C0
Observe the following precautions when disassembling and servicing drive shaft.
q Perform work in a location which is as dust-free as possible.
q Before disassembling and servicing, clean the outside of parts.
q Prevention of the entry of foreign objects must be taken into account during disassembly of the service
location.
q Disassembled parts must be carefully reassembled in the correct order. If work is interrupted, a clean
cover must be placed over parts.
q Paper shop cloths must be used. Fabric shop cloths must not be used because of the danger of lint adher-
ing to parts.
q Disassembled parts (except for rubber parts) should be cleaned with kerosene which shall be removed by
blowing with air or wiping with paper shop cloths.
Revision: 2004 November RAX-2 2004.5 FX35/FX45
PREPARATION
PREPARATION PFP:00002
A
Special Service Tools (SST) ADS000C1
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Tool number
B
(Kent-Moore No.) Description
Tool name
C
q Removing wheel hub
q Removing wheel bearing outer side
ST33251000 inner race
( -- ) RAX
Drift q Installing wheel hub
q Inspection of wheel bearing rotating
torque
ZZA0982D
E
ST35300000
( -- ) q Installing wheel hub
F
Drift q Inspection of wheel bearing rotating
a: 45 mm (1.77 in) dia. torque
b: 59 mm (2.32 in) dia.
G
ZZA0881D
KV40100900 H
( -- )
Wheel bearing rotating torque
Drift
inspection
a: 52 mm (2.05 in) dia.
b: -- I
ZZA0539D
J
KV38100500
( -- )
Drift Installing drive shaft plug
a: 80 mm (3.15 in) dia. K
b: 60 mm (2.36 in) dia.
ZZA0701D
L
KV38102200
( -- )
Drift Installing drive shaft plug M
a: 90 mm (3.54 in) dia.
b: 31 mm (1.22 in) dia.
ZZA0920D
Commercial Service Tools ADS000C2
Tool name Description
q Removing wheel nuts
q Removing brake caliper assembly
q Removing wheel hub and bearing
Power tool assembly
q Removing suspension links
q Removing drive shaft fixing bolts
PBIC0190E
and nuts
Revision: 2004 November RAX-3 2004.5 FX35/FX45
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING PFP:00003
NVH Troubleshooting Chart ADS000C3
Use chart below to help you find the cause of the symptom. If necessary, repair or replace these parts.
Refer to DRIVE SHAFT in this chart.
Refer to REAR AXLE in this chart.
NVH in FAX and FSU section
NVH in RFD section
NVH in WT section
NVH in WT section
NVH in BR section
NVH in PR section
NVH in PS section
RAX-9
RAX-5
--
--
--
Reference page
FRONT AXLE AND FRONT SUSPENSION
Improper installation, looseness
Joint sliding resistance
Possible cause and SUSPECTED PARTS
PROPELLER SHAFT
Excessive joint angle
Parts interference
DIFFERENTIAL
ROAD WHEEL
DRIVE SHAFT
REAR AXLE
STEERING
Imbalance
BRAKES
TIRES
