Image preview - the first page of the document
rsu


>> Download rsu documenatation <<

Text preview - extract from the document
REAR SUSPENSION


E SUSPENSION

                                                                                                                                                                   A




                                                                                 SECTION                     RSU
                                                                                               REAR SUSPENSION
                                                                                                                                                                   B



                                                                                                                                                                   C


                                                                                                                                                                   D


                                                                                                                                                                   RSU
                                                                 CONTENTS
PRECAUTIONS ......................................................... 2.         SUSPENSION ARM ................................................. 11      .        F
 Cautions .................................................................. 2
                                                                       .          Removal and Installation ....................................... 11     .
PREPARATION .......................................................... 3
                                                                       .            REMOVAL .......................................................... 11 .
 Special Service Tools (SST) .................................... 3    .            INSPECTION AFTER REMOVAL ...................... 11                    .        G
 Commercial Service Tools ....................................... 3    .            INSTALLATION .................................................. 12    .
NOISE, VIBRATION AND HARSHNESS (NVH)                                             RADIUS ROD ........................................................... 13.
TROUBLESHOOTING ............................................... 4      .          Removal and Installation ....................................... 13     .
                                                                                                                                                                   H
 NVH Troubleshooting Chart .................................... 4      .            REMOVAL .......................................................... 13 .
REAR SUSPENSION ASSEMBLY ............................ 5                .            INSPECTION AFTER REMOVAL ...................... 13                    .
 On-Vehicle Inspection and Service ......................... 5         .            INSTALLATION .................................................. 13    .
   INSPECTION OF SUSPENSION ARM BALL                                             FRONT LOWER LINK ............................................. 14        .         I
   JOINT END PLAY ................................................ 5   .          Removal and Installation ....................................... 14     .
   SHOCK ABSORBER INSPECTION .................... 5                    .            REMOVAL .......................................................... 14 .
 Wheel Alignment Inspection .................................... 5     .            INSPECTION AFTER REMOVAL ...................... 14                    .        J
   DESCRIPTION ..................................................... 5 .            INSTALLATION .................................................. 14    .
   PRELIMINARY CHECK ....................................... 5         .         REAR LOWER LINK & COIL SPRING .................... 15                    .
   CAMBER INSPECTION ....................................... 5         .          Removal and Installation ....................................... 15     .
                                                                                                                                                                   K
   TOE-IN ................................................................. 6
                                                                       .            REMOVAL .......................................................... 15 .
 Components ............................................................ 7
                                                                       .            INSPECTION AFTER REMOVAL ...................... 15                    .
 Removal and Installation ......................................... 8  .            INSTALLATION .................................................. 15    .
   REMOVAL ............................................................ 8
                                                                       .         STABILIZER BAR .................................................... 16   .        L
   INSTALLATION .................................................... 8 .          Removal and Installation ....................................... 16     .
SHOCK ABSORBER ................................................. 9     .            REMOVAL .......................................................... 16 .
 Removal and Installation ......................................... 9  .            INSPECTION AFTER REMOVAL ...................... 16                    .        M
   REMOVAL ............................................................ 9
                                                                       .            INSTALLATION .................................................. 16    .
   INSPECTION AFTER REMOVAL ........................ 9                 .         REAR SUSPENSION MEMBER .............................. 17                 .
   INSTALLATION .................................................... 9 .          Removal and Installation ....................................... 17     .
 Disassembly and Assembly .................................... 9       .            REMOVAL .......................................................... 17 .
   DISASSEMBLY .................................................... 9  .            INSPECTION AFTER REMOVAL ...................... 17                    .
   INSPECTION AFTER DISASSEMBLY .............. 10                      .            INSTALLATION .................................................. 17    .
   ASSEMBLY ........................................................ 10.         SERVICE DATA ....................................................... 18  .
                                                                                  Wheel Alignment ................................................... 18  .
                                                                                  Ball Joint ................................................................ 18
                                                                                                                                                          .
                                                                                  Wheelarch Height (Unladen*) ................................ 18         .




Revision: 2004 November                                                   RSU-1                                                      2004.5 FX35/FX45
                                            PRECAUTIONS

PRECAUTIONS                                                                                           PFP:00001

Cautions                                                                                                 AES000MF


q   When installing rubber bushings, final tightening must be carried out under unladen conditions with tires
    on level ground. Oil will shorten the life of rubber bushings. Be sure to wipe off any spilled oil.
q   Unladen conditions means that fuel, engine coolant and lubricant are full. Spare tire, jack, hand tools and
    mats are in designated positions.
q   After servicing suspension parts, be sure to check wheel alignment.
q   Caulking nuts are not reusable. Always use new ones when installing. Since new caulking nuts are pre-
    oiled, tighten as they are.




Revision: 2004 November                           RSU-2                                     2004.5 FX35/FX45
                                            PREPARATION

PREPARATION                                                                                                 PFP:00002
                                                                                                                           A
Special Service Tools (SST)                                                                                     AES000MG


The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
 Tool number                                                                                                               B
 (Kent-Moore No.)                                                           Description
 Tool name
 ST3127S000                                                                                                                C
 (See J25742-1)
 Preload gauge
 1. GG91030000
         Torque wrench (J25765)                                             Measuring rotating torque of ball joint        D
 2. HT62940000 ( -- )
          Socket adapter (1/2)
 3. HT62900000 ( -- )
          Socket adapter (3/8)
                                                                NT124                                                      RSU

Commercial Service Tools                                                                                        AES000MH


 Tool name                                                                  Description                                    F


                                                                            q   Removing wheel nuts                        G
                                                                            q   Removing brake caliper assembly
 Power tool
                                                                            q   Removing rear suspension component
                                                                                parts                                      H
                                                                PBIC0190E




                                                                                                                            I


                                                                                                                           J



                                                                                                                           K


                                                                                                                           L



                                                                                                                           M




Revision: 2004 November                            RSU-3                                        2004.5 FX35/FX45
          NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING

NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING                                                                                                                                                                                                                                                                                                                                                                                         PFP:00003

NVH Troubleshooting Chart                                                                                                                                                                                                                                                                                                                                                                                                                                          AES000MI


Use chart below to help you find the cause of the symptom. If necessary, repair or replace these parts.




                                                                                                                                                                                                                                                                                                                                              NVH in FAX and FSU section
                                                                                                                                                                                                                                                                                                                         NVH in RFD section




                                                                                                                                                                                                                                                                                                                                                                                                                        NVH in RAX section
                                                                                                                                                                                                                                                                                                                                                                                NVH in WT section

                                                                                                                                                                                                                                                                                                                                                                                                    NVH in WT section
                                                                                                                                                                                                                                                                                                     NVH in PR section




                                                                                                                                                                                                                                                                                                                                                                                                                                               NVH in BR section

                                                                                                                                                                                                                                                                                                                                                                                                                                                                      NVH in PS section
                                                                                                                                                                                                                                                                            RSU-16
                                                         RSU-7

                                                                                            RSU-9




                                                                                                                                                                                                                         RSU-7

                                                                                                                                                                                                                                                RSU-5
                                                                                                                                               --

                                                                                                                                                                                   --

                                                                                                                                                                                                        --
 Reference page




                                                                                            Shock absorber deformation, damage or deflection




                                                                                                                                                                                                                                                                                                                                              FRONT AXLE AND FRONT SUSPENSION
                                                                                                                                               Bushing or mounting deterioration
                                                         Improper installation, looseness




 Possible cause and SUSPECTED PARTS




                                                                                                                                                                                                                                                Incorrect wheel alignment
                                                                                                                                                                                                                         Suspension looseness




                                                                                                                                                                                                                                                                                                     PROPELLER SHAFT
                                                                                                                                                                                                                                                                            Stabilizer bar fatigue
                                                                                                                                                                                   Parts interference




                                                                                                                                                                                                                                                                                                                                                                                                    ROAD WHEEL
                                                                                                                                                                                                                                                                                                                         DIFFERENTIAL




                                                                                                                                                                                                                                                                                                                                                                                                                        DRIVE SHAFT
                                                                                                                                                                                                        Spring fatigue




                                                                                                                                                                                                                                                                                                                                                                                                                                                                      STEERING
                                                                                                                                                                                                                                                                                                                                                                                                                                               BRAKES
                                                                                                                                                                                                                                                                                                                                                                                TIRES
                                  Noise
