Image preview - the first page of the document
>> Download wt documenatation <<
Text preview - extract from the document
ROAD WHEELS & TIRES
E SUSPENSION
A
SECTION
ROAD WHEELS & TIRES
WT B
C
D
WT
CONTENTS
PREPARATION .......................................................... 2. CONSULT-II ........................................................ 17 . F
Special Service Tools .............................................. 2 . How to Perform Trouble Diagnosis for Quick and
Commercial Service Tools ....................................... 2 . Accurate Repair ..................................................... 19 .
NOISE, VIBRATION AND HARSHNESS (NVH) INTRODUCTION ................................................ 19 . G
TROUBLESHOOTING ............................................... 3 . WORK FLOW ..................................................... 19 .
NVH Troubleshooting Chart .................................... 3 . Preliminary Check ................................................. 20 .
ROAD WHEEL ........................................................... 4. Malfunction Code/Symptom Chart ......................... 21 .
H
Inspection ................................................................ 4
. TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC
ALUMINUM WHEEL ............................................ 4 . ITEMS ....................................................................... 22
.
STEEL WHEEL .................................................... 4 . Inspection 1: Transmitter or Low Tire Pressure
ROAD WHEEL TIRE ASSEMBLY ............................. 5 . Warning Control Unit ............................................. 22 . I
Balancing Wheels (Bonding Weight Type) .............. 5 . MALFUNCTION CODE NO. 21, 22, 23 OR 24 ... 22
REMOVAL ............................................................ 5
. Inspection 2: Transmitter - 1 .................................. 22 .
WHEEL BALANCE ADJUSTMENT ..................... 5 . MALFUNCTION CODE NO. 31, 32, 33, 34, 41, J
Tire Rotation ............................................................ 6
. 42, 43, 44, 45, 46, 47 OR 48 .............................. 22 .
LOW TIRE PRESSURE WARNING SYSTEM ........... 7 . Inspection 3: Transmitter - 2 .................................. 23 .
System Components ............................................... 7 . MALFUNCTION CODE NO. 35, 36, 37 OR 38 ... 23
K
System Description ................................................. 7 . Inspection 4: Vehicle Speed Signal ....................... 24 .
TRANSMITTER .................................................... 7 . MALFUNCTION CODE NO. 52 .......................... 24 .
LOW TIRE PRESSURE WARNING CONTROL TROUBLE DIAGNOSIS FOR SYMPTOMS ............. 25 .
UNIT ..................................................................... 7
. Inspection 1: Warning Lamp Does Not Come on L
ANTENNA ............................................................ 8
. When Ignition Switch is Turned on. ....................... 25 .
DISPLAY UNIT ..................................................... 8 . Inspection 2: Warning Lamp Stays on When Ignition
CAN COMMUNICATION ........................................... 9 . Switch is Turned on. .............................................. 26 . M
System Description ................................................. 9 . Inspection 3: Warning Lamp Blinks When Ignition
TROUBLE DIAGNOSES ......................................... 10 . Switch is Turned on. .............................................. 28 .
Schematic ............................................................. 10
. Inspection 4: Hazard Warning Lamp Blinks When
Wiring Diagram ......................................................11. Ignition Switch is Turned on. ................................. 29 .
Control Unit Input/Output Signal Standard ............ 14 . Inspection 5: "TIRE PRESSURE" Information in
ID Registration Procedure ..................................... 14 . Display Unit Does Not Exist. .................................. 30 .
ID REGISTRATION WITH TRANSMITTER Inspection 6: ID Registration Cannot be Completed. 30 ...
ACTIVATION TOOL ........................................... 14 . REMOVAL AND INSTALLATION ............................ 31 .
ID REGISTRATION WITHOUT TRANSMITTER Transmitter ............................................................ 31
.
ACTIVATION TOOL ........................................... 15 . REMOVAL .......................................................... 31 .
Transmitter Wake Up Operation ............................ 16 . INSTALLATION .................................................. 31 .
WITH TRANSMITTER ACTIVATION TOOL ....... 16 . SERVICE DATA ....................................................... 33 .
Self-Diagnosis ....................................................... 17
. Road Wheel ........................................................... 33 .
DESCRIPTION ................................................... 17 . Tire ........................................................................ 33
.
FUNCTION ......................................................... 17. Tightening Torque .................................................. 33 .
Revision: 2004 November WT-1 2004.5 FX35/FX45
PREPARATION
PREPARATION PFP:00002
Special Service Tools AES000JI
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Tool number
(Kent-Moore No.) Description
Tool name
(J45295)
ID registration
Transmitter activation tool
SEIA0462E
Commercial Service Tools AES000JJ
Tool name Description
Power tool Removing wheel nuts
PBIC0190E
Revision: 2004 November WT-2 2004.5 FX35/FX45
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING PFP:00003
A
NVH Troubleshooting Chart AES000JK
Use the chart below to help you find the cause of the symptom. If necessary, repair or replace these parts.
B
Refer to ROAD WHEEL in this chart.
NVH in RAX and RSU section
NVH in FAX and FSU section
Refer to TIRES in this chart.
C
NVH in FAX, RAX section
FAX-4, FSU-6
WT-4
NVH in RFD section
--
--
--
--
--
--
Reference page
NVH in PR section
NVH in BR section
NVH in PS section
D
WT
FRONT AXLE AND FRONT SUSPENSION
F
REAR AXLE AND REAR SUSPENSION
Improper installation, looseness
G
Possible cause and SUSPECTED PARTS Deformation or damage
Incorrect tire pressure
PROPELLER SHAFT
H
Incorrect tire size
Uneven tire wear
DIFFERENTIAL
ROAD WHEEL
DRIVE SHAFT
Non-uniformity
Out-of-round
STEERING
Imbalance
I
BRAKE
TIRES
