Image preview - the first page of the document
acc


>> Download acc documenatation <<

Text preview - extract from the document
ACCELERATOR CONTROL SYSTEM


B ENGINE

                                                                                                                                                          A




                                              ACCELERATOR CONTROL SYSTEM
                                                                               SECTION                 ACC                                                ACC



                                                                                                                                                          C


                                                                                                                                                          D


                                                                                                                                                          E
                                                               CONTENTS
PRECAUTIONS ......................................................... 2
                                                                     .         ACCELERATOR CONTROL SYSTEM ...................... 3              .         F
 Precautions for Supplemental Restraint System                                  Removal and Installation ......................................... 3
                                                                                                                                                .
 (SRS) "AIR BAG" and "SEAT BELT PRE-TEN-                                         REMOVAL ............................................................ 3
                                                                                                                                                .
 SIONER" ................................................................. 2
                                                                     .           INSTALLATION .................................................... 3
                                                                                                                                                .         G
                                                                                 INSPECTION AFTER INSTALLATION ................. 3              .

                                                                                                                                                          H



                                                                                                                                                           I


                                                                                                                                                          J



                                                                                                                                                          K


                                                                                                                                                          L



                                                                                                                                                          M




Revision: 2005 July                                                     ACC-1                                                               2005 FX
                                              PRECAUTIONS

PRECAUTIONS                                                         PFP:00001

Precautions for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT
BELT PRE-TENSIONER"                                                                                           ABS00A37


The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING:
q    To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
     in the event of a collision which would result in air bag inflation, all maintenance must be per-
     formed by an authorized NISSAN/INFINITI dealer.
q    Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
     sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
     Bag Module, see the SRS section.
q    Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
     Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
     harness connectors.




Revision: 2005 July                                  ACC-2                                                 2005 FX
                                       ACCELERATOR CONTROL SYSTEM

ACCELERATOR CONTROL SYSTEM                                                                         PFP:18005
                                                                                                                    A
Removal and Installation                                                                                 ABS005ZA




                                                                                                                    ACC



                                                                                                                    C


                                                                                                                    D


                                                                                                                    E



                                                                                                                    F


                                                                                                                    G
                                                                                                  SBIA0332E

     1.   Accelerator pedal assembly

REMOVAL                                                                                                             H
1.    Disconnect accelerator pedal position sensor harness connector.
2.    Loosen mounting nuts, and remove accelerator pedal assembly.
      CAUTION:                                                                                                       I
      q Do not disassemble accelerator pedal assembly. Do not remove accelerator pedal position sen-
        sor from accelerator pedal assembly.
      q Avoid impact from dropping etc. during handling.                                                            J
      q Be careful to keep accelerator pedal assembly away from water.

INSTALLATION                                                                                                        K
Installation is the reverse order of removal.
INSPECTION AFTER INSTALLATION
q     Make sure accelerator pedal moves smoothly within the whole operation range when it is fully depressed        L
      and released.
q     Make sure accelerator pedal securely returns to the fully released position.
q     For the electrical inspection of accelerator pedal position sensor, refer to the following.                   M
