Image preview - the first page of the document
>> Download fax documenatation <<
Text preview - extract from the document
FRONT AXLE
D DRIVELINE/AXLE
A
SECTION FAX FRONT AXLE
B
C
FAX
E
CONTENTS
2WD FRONT WHEEL HUB AND KNUCKLE ................... 10 . F
On-Vehicle Inspection and Service ........................ 10 .
PREPARATION .......................................................... 2
. WHEEL BEARING INSPECTION ...................... 10 .
Special Service Tools (SST) .................................... 2. Removal and Installation ....................................... 10 . G
Commercial Service Tools ....................................... 2. REMOVAL .......................................................... 10
.
NOISE, VIBRATION AND HARSHNESS (NVH) INSPECTION AFTER REMOVAL ...................... 11 .
TROUBLESHOOTING ............................................... 3 . INSTALLATION .................................................. 11 .
NVH Troubleshooting Chart .................................... 3 . H
FRONT DRIVE SHAFT ............................................ 12 .
FRONT WHEEL HUB AND KNUCKLE ..................... 4 . Removal and Installation (Left Side) ...................... 12 .
On-Vehicle Inspection and Service ......................... 4 . REMOVAL .......................................................... 12
.
WHEEL BEARING INSPECTION ........................ 4 . INSPECTION AFTER REMOVAL ...................... 12 . I
Removal and Installation ......................................... 4
. INSTALLATION .................................................. 12 .
REMOVAL ............................................................ 4
. Removal and Installation (Right Side) ................... 13 .
INSPECTION AFTER REMOVAL ........................ 5 . REMOVAL .......................................................... 13
. J
INSTALLATION .................................................... 5
. INSPECTION AFTER REMOVAL ...................... 13 .
SERVICE DATA ......................................................... 6
. INSTALLATION .................................................. 14 .
Wheel Bearing ......................................................... 6
. Disassembly and Assembly (Left Side) ................. 14 .
K
DISASSEMBLY .................................................. 14 .
AWD INSPECTION AFTER DISASSEMBLY ............... 15 .
ASSEMBLY ........................................................ 16.
PRECAUTIONS ......................................................... 7 . Disassembly and Assembly (Right Side) ............... 20 . L
Caution .................................................................... 7
. DISASSEMBLY .................................................. 20 .
PREPARATION .......................................................... 8. INSPECTION AFTER DISASSEMBLY ............... 21 .
Special Service Tools (SST) .................................... 8 . ASSEMBLY ........................................................ 22. M
Commercial Service Tools ....................................... 8 . SERVICE DATA ....................................................... 26.
NOISE, VIBRATION AND HARSHNESS (NVH) Wheel Bearing ....................................................... 26
.
TROUBLESHOOTING ............................................... 9 . Drive Shaft ............................................................. 26
.
NVH Troubleshooting Chart .................................... 9 . Tightening Torque .................................................. 26
.
Revision: 2005 July FAX-1 2005 FX
PREPARATION
[2WD]
PREPARATION
[2WD] PFP:00002
Special Service Tools (SST) ADS000HM
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Tool number
(Kent-Moore No.) Description
Tool name
HT72520000
(J25730-A)
Ball joint remover q Removing steering outer socket
a: 33 mm (1.30 in) q Removing transverse link
b: 50 mm (1.97 in)
r: 11.5 mm (0.453 in)
NT546
Commercial Service Tools ADS000HN
Tool name Description
q Removing wheel nuts
q Removing brake caliper assembly
Power tool q Removing strut lower side
q Removing wheel hub and bearing
assembly
PBIC0190E
Revision: 2005 July FAX-2 2005 FX
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING
[2WD]
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING PFP:00003
A
NVH Troubleshooting Chart ADS000HO
Use chart below to help you find the cause of the symptom. If necessary, repair or replace these parts.
B
NVH in WT section
NVH in WT section
NVH in PS section
FAX-4
FAX-4
--
Reference page
C
FAX
Improper installation, looseness
Wheel bearing damage
E
Parts interference
Possible cause and SUSPECTED PARTS
ROAD WHEEL
F
STEERING
TIRES
G
