Image preview - the first page of the document
pr


>> Download pr documenatation <<

Text preview - extract from the document
PROPELLER SHAFT


D DRIVELINE/AXLE

                                                                                                                                                          A




                                                                                              SECTION
                                                                                          PROPELLER SHAFT
                                                                                                                        PR                                B



                                                                                                                                                          C


                                                                                                                                                          PR


                                                                                                                                                          E
                                                              CONTENTS
PREPARATION .......................................................... 2
                                                                   .            APPEARANCE AND NOISE INSPECTION ......... 7                     .         F
 Special Service Tools .............................................. 2
                                                                   .            PROPELLER SHAFT VIBRATION ....................... 7             .
 Commercial Service Tools ....................................... 2.          Components ............................................................ 8
                                                                                                                                                .
NOISE, VIBRATION AND HARSHNESS (NVH)                                          Removal and Installation ......................................... 9
                                                                                                                                                .         G
TROUBLESHOOTING ............................................... 3  .            REMOVAL ............................................................ 9
                                                                                                                                                .
 NVH Troubleshooting Chart .................................... 3  .            INSPECTION ..................................................... 10
                                                                                                                                                .
FRONT PROPELLER SHAFT ................................... 4        .            INSTALLATION .................................................. 11
                                                                                                                                                .
                                                                                                                                                          H
 On-Vehicle Inspection ............................................. 4
                                                                   .          Disassembly and Assembly of Center Bearing ..... 12               .
   APPEARANCE AND NOISE INSPECTION ......... 4                     .            DISASSEMBLY .................................................. 12
                                                                                                                                                .
   PROPELLER SHAFT VIBRATION ....................... 4             .            ASSEMBLY ........................................................ 13
                                                                                                                                                .
 Components ............................................................ 4
                                                                   .         SERVICE DATA AND SPECIFICATIONS (SDS) ..... 14                     .          I
 Removal and Installation ......................................... 5
                                                                   .          General Specifications ........................................... 14
                                                                                                                                                .
   REMOVAL ............................................................ 5
                                                                   .            2WD MODELS ................................................... 14
                                                                                                                                                .
   INSPECTION ....................................................... 5
                                                                   .            AWD MODELS ................................................... 14
                                                                                                                                                .         J
   INSTALLATION .................................................... 6
                                                                   .          Journal Axal Play ................................................... 14
                                                                                                                                                .
REAR PROPELLER SHAFT ..................................... 7       .          Propeller Shaft Runout .......................................... 14
                                                                                                                                                .
 On-Vehicle Inspection ............................................. 7
                                                                   .
                                                                                                                                                          K


                                                                                                                                                          L



                                                                                                                                                          M




Revision: 2005 July                                                     PR-1                                                                2005 FX
                                                       PREPARATION

PREPARATION                                                                                                                  PFP:00002

Special Service Tools                                                                                                             ADS001A4

The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
  Tool number
  (Kent-Moore No.)                                                                       Description
  Tool name

  KV40104000                                                                             Removing and installing center flange lock nut
  (    --    )
  Flange wrench
  a: 85 mm (3.35 in)
  b: 65 mm (2.56 in)


                                                                         NT659


  ST30031000                                                                             Removing rear propeller shaft center bearing
  (J-22912-01)
  Puller
  a: 90 mm (3.54 in) dia.
  b: 50 mm (1.97 in) dia.


                                                                         NT411



Commercial Service Tools                                                                                                          ADS001A5



  Tool name                                                                              Description

  Power tool                                                                             Loosening bolts and nuts




                                                                         PBIC0190E




Revision: 2005 July                                             PR-2                                                          2005 FX
                                                  Symptom
