Image preview - the first page of the document
rax


>> Download rax documenatation <<

Text preview - extract from the document
REAR AXLE


D DRIVELINE/AXLE

                                                                                                                                                                  A




                                                                                  SECTION                    RAX          REAR AXLE
                                                                                                                                                                  B



                                                                                                                                                                  C


                                                                                                                                                                  RAX


                                                                                                                                                                  E
                                                                  CONTENTS
PRECAUTIONS ......................................................... 2 .            INSTALLATION .................................................... 6 .        F
 Caution .................................................................... 2
                                                                        .          Disassembly and Assembly ..................................... 6      .
PREPARATION .......................................................... 3.            DISASSEMBLY .................................................... 6  .
 Special Service Tools (SST) .................................... 3     .            INSPECTION AFTER DISASSEMBLY ................. 7                    .        G
 Commercial Service Tools ....................................... 3     .            ASSEMBLY .......................................................... 7
                                                                                                                                                         .
NOISE, VIBRATION AND HARSHNESS (NVH)                                                 INSPECTION AFTER ASSEMBLY ....................... 8                 .
TROUBLESHOOTING ............................................... 4       .         REAR DRIVE SHAFT ................................................ 9    .
                                                                                                                                                                  H
 NVH Troubleshooting Chart .................................... 4       .          Removal and Installation ......................................... 9  .
WHEEL HUB ............................................................. 5
                                                                        .            REMOVAL ............................................................ 9
                                                                                                                                                         .
 On-Vehicle Inspection and Service ......................... 5          .            INSPECTION AFTER REMOVAL ........................ 9                 .
   WHEEL BEARING INSPECTION ........................ 5                  .            INSTALLATION .................................................... 9 .         I
 Removal and Installation ......................................... 5   .          Disassembly and Assembly ................................... 10       .
   REMOVAL ............................................................ 5
                                                                        .            DISASSEMBLY .................................................. 10   .
   INSPECTION AFTER REMOVAL ........................ 6                  .            INSPECTION AFTER DISASSEMBLY ............... 11                     .        J
                                                                                     ASSEMBLY ........................................................ 12.
                                                                                  SERVICE DATA ....................................................... 15.
                                                                                   Wheel Bearing ....................................................... 15
                                                                                                                                                         .
                                                                                                                                                                  K
                                                                                   Drive Shaft ............................................................. 15
                                                                                                                                                         .


                                                                                                                                                                  L



                                                                                                                                                                  M




Revision: 2005 July                                                        RAX-1                                                                   2005 FX
                                           PRECAUTIONS

PRECAUTIONS                                                                                       PFP:00001

Caution                                                                                              ADS000C0


Observe the following precautions when disassembling and servicing drive shaft.
q  Perform work in a location which is as dust-free as possible.
q  Before disassembling and servicing, clean the outside of parts.
q  Prevention of the entry of foreign objects must be taken into account during disassembly of the service
   location.
q  Disassembled parts must be carefully reassembled in the correct order. If work is interrupted, a clean
   cover must be placed over parts.
q  Paper shop cloths must be used. Fabric shop cloths must not be used because of the danger of lint adher-
   ing to parts.
q  Disassembled parts (except for rubber parts) should be cleaned with kerosene which shall be removed by
   blowing with air or wiping with paper shop cloths.




Revision: 2005 July                              RAX-2                                             2005 FX
                                            PREPARATION

PREPARATION                                                                                                  PFP:00002
                                                                                                                              A
Special Service Tools (SST)                                                                                        ADS000C1


The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
    Tool number
                                                                                                                              B
     (Kent-Moore No.)                                                      Description
    Tool name
                                                                                                                              C
                                                                           q   Removing wheel hub
                                                                           q   Removing wheel bearing outer side
    ST33251000                                                                 inner race
    (     -- )                                                                                                                RAX
    Drift                                                                  q   Installing wheel hub
                                                                           q   Inspection of wheel bearing rotating
                                                                               torque
                                                              ZZA0982D
                                                                                                                              E

    ST35300000
    (     --  )                                                            q   Installing wheel hub
                                                                                                                              F
    Drift                                                                  q   Inspection of wheel bearing rotating
    a: 45 mm (1.77 in) dia.                                                    torque
    b: 59 mm (2.32 in) dia.
                                                                                                                              G
                                                              ZZA0881D




    KV40100900                                                                                                                H
    (     --   )
                                                                           Wheel bearing rotating torque
    Drift
                                                                           inspection
    a: 52 mm (2.05 in) dia.
    b:      --                                                                                                                 I
                                                              ZZA0539D




                                                                                                                              J
    KV38100500
    (     --   )
    Drift                                                                  Installing drive shaft plug
    a: 80 mm (3.15 in) dia.                                                                                                   K
    b: 60 mm (2.36 in) dia.
                                                              ZZA0701D


                                                                                                                              L
    KV38102200
    (     --    )
    Drift                                                                  Installing drive shaft plug                        M
    a: 90 mm (3.54 in) dia.
    b: 31 mm (1.22 in) dia.
                                                              ZZA0920D



Commercial Service Tools                                                                                           ADS000C2



    Tool name                                                              Description

                                                                           q   Removing wheel nuts
                                                                           q   Removing brake caliper assembly
                                                                           q   Removing wheel hub and bearing
    Power tool                                                                 assembly
                                                                           q   Removing suspension links
                                                                           q   Removing drive shaft fixing bolts
                                                              PBIC0190E
                                                                               and nuts




Revision: 2005 July                                RAX-3                                                      2005 FX
          NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING

NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING                                                                                                                                                                                                                                                                                                                            PFP:00003

NVH Troubleshooting Chart                                                                                                                                                                                                                                                                                                                                                                            ADS000C3


Use chart below to help you find the cause of the symptom. If necessary, repair or replace these parts.




                                                                                                                                                                                                                                                                                                                                          Refer to DRIVE SHAFT in this chart.
                                                                                                                                                                                                                                                              Refer to REAR AXLE in this chart.
                                                                                                                                                                                                                            NVH in FAX and FSU section
                                                                                                                                                                                                       NVH in RFD section




                                                                                                                                                                                                                                                                                                  NVH in WT section

                                                                                                                                                                                                                                                                                                                      NVH in WT section



                                                                                                                                                                                                                                                                                                                                                                                 NVH in BR section
                                                                                                                                                                                   NVH in PR section




                                                                                                                                                                                                                                                                                                                                                                                                        NVH in PS section
                                                                                   RAX-9



                                                                                                                           RAX-5
                                                           --



                                                                                                               --



                                                                                                                                                              --
 Reference page




                                                                                                                                                                                                                            FRONT AXLE AND FRONT SUSPENSION
                                                                                                                           Improper installation, looseness
                                                                                    Joint sliding resistance


 Possible cause and SUSPECTED PARTS




                                                                                                                                                                                   PROPELLER SHAFT
                                                           Excessive joint angle




                                                                                                                                                              Parts interference



                                                                                                                                                                                                       DIFFERENTIAL




                                                                                                                                                                                                                                                                                                                      ROAD WHEEL

                                                                                                                                                                                                                                                                                                                                          DRIVE SHAFT
                                                                                                                                                                                                                                                              REAR AXLE




                                                                                                                                                                                                                                                                                                                                                                                                        STEERING
                                                                                                               Imbalance




                                                                                                                                                                                                                                                                                                                                                                                 BRAKES
                                                                                                                                                                                                                                                                                                  TIRES
                  DRIVE    Noise
