Image preview - the first page of the document
rf


>> Download rf documenatation <<

Text preview - extract from the document
ROOF


I BODY

                                                                                                                                                                A




                                                                                                  SECTION                    RF           ROOF
                                                                                                                                                                B



                                                                                                                                                                C


                                                                                                                                                                D


                                                                                                                                                                E
                                                                CONTENTS
PRECAUTIONS ......................................................... 2
                                                                      .             ANTI-PINCH FUNCTION ................................... 12         .        F
 Precautions for Supplemental Restraint System                                      MEMORY RESET PROCEDURE ...................... 12                   .
 (SRS) "AIR BAG" and "SEAT BELT PRE-TEN-                                            INITIALIZATION PROCEDURE ......................... 12              .
 SIONER" ................................................................. 2
                                                                      .           CAN Communication System Description ............. 13                .        G
 Precautions ............................................................. 2
                                                                      .           CAN Communication Unit ...................................... 13     .
PREPARATION .......................................................... 3
                                                                      .           Wiring Diagram -- SROOF -- ............................... 14        .
 Special Service Tools .............................................. 3
                                                                      .           Terminals and Reference Value for BCM .............. 15              .
                                                                                                                                                                H
 Commercial Service Tools ....................................... 3   .           Terminals and Reference Value for Sunroof Motor
SQUEAK AND RATTLE TROUBLE DIAGNOSES..... 4                                        Assembly ............................................................... 15
                                                                                                                                                       .
 Work Flow ............................................................... 4
                                                                      .           Work Flow .............................................................. 16
                                                                                                                                                       .
   CUSTOMER INTERVIEW .................................... 4          .           CONSULT-II Function (BCM) ................................ 16        .        RF
   DUPLICATE THE NOISE AND TEST DRIVE ...... 5                        .             ACTIVE TEST .................................................... 17.
   CHECK RELATED SERVICE BULLETINS .......... 5                       .             WORK SUPPORT .............................................. 17     .
   LOCATE THE NOISE AND IDENTIFY THE                                                DATE MONITOR ................................................ 17   .         J
   ROOT CAUSE ..................................................... 5 .           Trouble Diagnosis Chart by Symptom ................... 18            .
   REPAIR THE CAUSE .......................................... 5      .           Power Supply and Ground Circuit Check of BCM... 18
   CONFIRM THE REPAIR ...................................... 6        .           Sunroof Motor Assembly Power Supply and Ground
                                                                                                                                                                K
 Generic Squeak and Rattle Troubleshooting .......... 6               .           Circuit Check ......................................................... 19
                                                                                                                                                       .
   INSTRUMENT PANEL ......................................... 6       .           Sunroof Switch System Check .............................. 20        .
   CENTER CONSOLE ............................................ 6      .           Door Switch Check ................................................ 22.
   DOORS ................................................................ 6
                                                                      .           Wind Deflector Inspection ...................................... 24  .        L
   TRUNK ................................................................. 7
                                                                      .           Link and Wire Assembly ........................................ 24   .
   SUNROOF/HEADLINING .................................... 7          .           Fitting Adjustment .................................................. 24
                                                                                                                                                       .
   SEATS .................................................................. 7
                                                                      .             LID WEATHERSTRIP OVERLAP ADJUST-                                            M
   UNDERHOOD ...................................................... 7 .             MENT AND SURFACE MISMATCH ADJUST-
 Diagnostic Worksheet ............................................. 8 .             MENT ................................................................. 25
                                                                                                                                                       .
SUNROOF ............................................................... 10
                                                                      .           Removal and Installation ....................................... 25  .
 Component Parts and Harness Connector Location 10                    ...           SUNROOF UNIT ASSEMBLY ............................ 27              .
 System Description ................................................11.             GLASS LID ......................................................... 28
                                                                                                                                                       .
   TILT UP / SLIDE CLOSE OPERATION ...............11                  .             SUNSHADE ....................................................... 29.
   TILT DOWN / SLIDE OPEN OPERATION ..........11                      .             WIND DEFLECTOR ........................................... 29      .
   AUTO OPERATION ............................................11      .             SUNROOF MOTOR ASSEMBLY ....................... 29                  .
   RETAINED POWER OPERATION ......................11                  .




Revision: 2005 July                                                        RF-1                                                                  2005 FX
                                              PRECAUTIONS

PRECAUTIONS                                                         PFP:00001

Precautions for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT
BELT PRE-TENSIONER"                                                                                           AIS003AR


The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING:
q    To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
     in the event of a collision which would result in air bag inflation, all maintenance must be per-
     formed by an authorized NISSAN/INFINITI dealer.
q    Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
     sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
     Bag Module, see the SRS section.
q    Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
     Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
     harness connectors.
Precautions                                                                                                   AIS003AS


q    Disconnect both battery cables in advance.
q    Do not tamper with or force air bag lid open, as this may adversely affect air bag performance.
q    Be careful not to scratch pad and other parts.
q    When removing or disassembling any part, be careful not to damage or deform it. Protect parts, which
     may get in the way with cloth.
q    When removing parts with a screwdriver or other tool, protect parts by wrapping them with vinyl or tape.
q    Keep removed parts protected with cloth.
q    If a clip is deformed or damaged, replace it.
q    If an unreusable part is removed, replace it with a new one.
q    Tighten bolts and nuts firmly to the specified torque.
q    After re-assembly has been completed, make sure each part functions correctly.
q    Remove stains in the following way.
Water-soluble stains:
Dip a soft cloth in warm water, and then squeeze it tightly. After wiping the stain, wipe with a soft dry cloth.
Oil stain:
Dissolve a synthetic detergent in warm water (density of 2 to 3% or less), dip the cloth, then clean off the stain
with the cloth. Next, dip the cloth in fresh water and squeeze it tightly. Then clean off the detergent completely.
Then wipe the area with a soft dry cloth.
q    Do not use any organic solvent, such as thinner or benzine.




Revision: 2005 July                                   RF-2                                                 2005 FX
                                            PREPARATION

PREPARATION                                                                                              PFP:00002
                                                                                                                       A
Special Service Tools                                                                                       AIS003AT


The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
    Tool number
                                                                                                                       B
    (Kent-Moore No.)                                                   Description
    Tool name
                                                                                                                       C


    (J39570)
                                                                       Locating the noise                              D
    Chassis ear


                                                       SIIA0993E
                                                                                                                       E


    (J43980)                                                                                                           F
    NISSAN Squeak and                                                  Repairing the cause of noise
    Rattle Kit

                                                                                                                       G
                                                       SIIA0994E



Commercial Service Tools                                                                                    AIS003AU

                                                                                                                       H
    Tool name                                                          Description


                                                                                                                       RF
    (J39565)
                                                                       Locating the noise
    Engine ear
                                                                                                                        J
                                                       SIIA0995E



                                                                                                                       K


                                                                                                                       L



                                                                                                                       M




Revision: 2005 July                                 RF-3                                                 2005 FX
                        SQUEAK AND RATTLE TROUBLE DIAGNOSES

SQUEAK AND RATTLE TROUBLE DIAGNOSES                                                                         PFP:00000

Work Flow                                                                                                           AIS003AV




                                                                                                           SBT842


CUSTOMER INTERVIEW
Interview the customer if possible, to determine the conditions that exist when the noise occurs. Use the Diag-
nostic Worksheet during the interview to document the facts and conditions when the noise occurs and any
customer's comments; refer to RF-8, "Diagnostic Worksheet" . This information is necessary to duplicate the
conditions that exist when the noise occurs.
q    The customer may not be able to provide a detailed description or the location of the noise. Attempt to
     obtain all the facts and conditions that exist when the noise occurs (or does not occur).
q    If there is more than one noise in the vehicle, be sure to diagnose and repair the noise that the customer
     is concerned about. This can be accomplished by test driving the vehicle with the customer.
q    After identifying the type of noise, isolate the noise in terms of its characteristics. The noise characteristics
     are provided so the customer, service adviser and technician are all speaking the same language when
     defining the noise.
q    Squeak --(Like tennis shoes on a clean floor)
     Squeak characteristics include the light contact/fast movement/brought on by road conditions/hard sur-
     faces=higher pitch noise/softer surfaces=lower pitch noises/edge to surface=chirping
q    Creak--(Like walking on an old wooden floor)
     Creak characteristics include firm contact/slow movement/twisting with a rotational movement/pitch
     dependent on materials/often brought on by activity.
q    Rattle--(Like shaking a baby rattle)
     Rattle characteristics include the fast repeated contact/vibration or similar movement/loose parts/missing
     clip or fastener/incorrect clearance.
q    Knock --(Like a knock on a door)
     Knock characteristics include hollow sounding/sometimes repeating/often brought on by driver action.
q    Tick--(Like a clock second hand)
     Tick characteristics include gentle contacting of light materials/loose components/can be caused by driver
     action or road conditions.
q    Thump--(Heavy, muffled knock noise)
     Thump characteristics include softer knock/dead sound often brought on by activity.
q    Buzz--(Like a bumble bee)
     Buzz characteristics include high frequency rattle/firm contact.
q    Often the degree of acceptable noise level will vary depending upon the person. A noise that you may
     judge as acceptable may be very irritating to the customer.
q    Weather conditions, especially humidity and temperature, may have a great effect on noise level.


Revision: 2005 July                                    RF-4                                                  2005 FX
                       SQUEAK AND RATTLE TROUBLE DIAGNOSES

DUPLICATE THE NOISE AND TEST DRIVE
If possible, drive the vehicle with the customer until the noise is duplicated. Note any additional information on      A
the Diagnostic Worksheet regarding the conditions or location of the noise. This information can be used to
duplicate the same conditions when you confirm the repair.
If the noise can be duplicated easily during the test drive, to help identify the source of the noise, try to dupli-    B
cate the noise with the vehicle stopped by doing one or all of the following:
1) Close a door.
2) Tap or push/pull around the area where the noise appears to be coming from.
3) Rev the engine.                                                                                                      C
4) Use a floor jack to recreate vehicle "twist".
5) At idle, apply engine load (electrical load, half-clutch on M/T model, drive position on A/T model).
6) Raise the vehicle on a hoist and hit a tire with a rubber hammer.                                                    D
q    Drive the vehicle and attempt to duplicate the conditions the customer states exist when the noise occurs.
q    If it is difficult to duplicate the noise, drive the vehicle slowly on an undulating or rough road to stress the
     vehicle body.                                                                                                      E
CHECK RELATED SERVICE BULLETINS
After verifying the customer concern or symptom, check ASIST for Technical Service Bulletins (TSBs) related
to that concern or symptom.                                                                                             F
If a TSB relates to the symptom, follow the procedure to repair the noise.
LOCATE THE NOISE AND IDENTIFY THE ROOT CAUSE
                                                                                                                G
1.   Narrow down the noise to a general area. To help pinpoint the source of the noise, use a listening tool
     (Chassis Ear: J39570, Engine Ear and mechanics stethoscope).
2.   Narrow down the noise to a more specific area and identify the cause of the noise by:
                                                                                                                H
q    removing the components in the area that you suspect the noise is coming from.
     Do not use too much force when removing clips and fasteners, otherwise clips and fastener can be broken
     or lost during the repair, resulting in the creation of new noise.
                                                                                                               RF
q    tapping or pushing/pulling the component that you suspect is causing the noise.
     Do not tap or push/pull the component with excessive force, otherwise the noise will be eliminated only
     temporarily.
q    feeling for a vibration with your hand by touching the component(s) that you suspect is (are) causing the J
     noise.
q    placing a piece of paper between components that you suspect are causing the noise.
q    looking for loose components and contact marks.                                                            K
     Refer to RF-6, "Generic Squeak and Rattle Troubleshooting" .
REPAIR THE CAUSE                                                                                                        L
q   If the cause is a loose component, tighten the component securely.
q   If the cause is insufficient clearance between components:



◦ Jabse Service Manual Search 2022 ◦ Jabse PravopisonTap.bg ◦ Other service manual resources online : FixyaeServiceinfo
