Image preview - the first page of the document
rfd


>> Download rfd documenatation <<

Text preview - extract from the document
REAR FINAL DRIVE


D DRIVELINE/AXLE

                                                                                                                                                           A




                                                                                  SECTION                  RFD
                                                                                               REAR FINAL DRIVE
                                                                                                                                                           B



                                                                                                                                                           C


                                                                                                                                                           RFD


                                                                                                                                                           E
                                                                CONTENTS
PRECAUTIONS ......................................................... 2
                                                                      .         REAR FINAL DRIVE ASSEMBLY ........................... 14          .        F
  Service Notice or Precautions ................................. 2   .          Removal and Installation ....................................... 14
                                                                                                                                                  .
PREPARATION .......................................................... 3
                                                                      .            COMPONENTS .................................................. 14
                                                                                                                                                  .
  Special Service Tools .............................................. 3
                                                                      .            REMOVAL .......................................................... 14
                                                                                                                                                  .        G
  Commercial Service Tools ....................................... 6  .            INSTALLATION .................................................. 15
                                                                                                                                                  .
NOISE, VIBRATION AND HARSHNESS (NVH)                                             Disassembly and Assembly ................................... 16  .
TROUBLESHOOTING ............................................... 7     .            COMPONENTS .................................................. 16
                                                                                                                                                  .
                                                                                                                                                           H
  NVH Troubleshooting Chart .................................... 7    .            ASSEMBLY INSPECTION AND ADJUSTMENT 17                          ...
DESCRIPTION ........................................................... 8
                                                                      .            DISASSEMBLY .................................................. 21
                                                                                                                                                  .
  Cross-Sectional View .............................................. 8
                                                                      .            INSPECTION AFTER DISASSEMBLY ............... 25                .
DIFFERENTIAL GEAR OIL ....................................... 9       .            ADJUSTMENT AND SELECTION OF ADJUST-                                      I
  Changing Differential Gear Oil ................................ 9   .            ING WASHERS .................................................. 25
                                                                                                                                                  .
   DRAINING ............................................................ 9
                                                                      .            ASSEMBLY ........................................................ 30
                                                                                                                                                  .
   FILLING ................................................................ 9
                                                                      .         SERVICE DATA AND SPECIFICATIONS (SDS) ..... 36                    .        J
  Checking Differential Gear Oil ................................. 9  .          General Specifications ........................................... 36
                                                                                                                                                  .
   OIL LEAKAGE AND OIL LEVEL .......................... 9             .          Inspection and Adjustment .................................... 36.
FRONT OIL SEAL ................................................... 10 .            DRIVE GEAR RUNOUT ..................................... 36     .
                                                                                                                                                           K
  Removal and Installation ....................................... 10 .            DIFFERENTIAL SIDE GEAR CLEARANCE ...... 36                     .
   REMOVAL .......................................................... 10
                                                                      .            PRELOAD TORQUE .......................................... 36   .
   INSTALLATION ...................................................11 .            BACKLASH ........................................................ 36
                                                                                                                                                  .
SIDE OIL SEAL ....................................................... 12
                                                                      .            COMPANION FLANGE RUNOUT ...................... 36              .        L
  Removal and Installation ....................................... 12 .            SELECTIVE PARTS ........................................... 36 .
   REMOVAL .......................................................... 12
                                                                      .
   INSTALLATION .................................................. 12 .                                                                                    M




Revision: 2005 July                                                      RFD-1                                                               2005 FX
                                            PRECAUTIONS

PRECAUTIONS                                                                                            PFP:00001

Service Notice or Precautions                                                                             ADS001AF


q   Check for the correct installation status prior to removal or disassembly. If matching marks are required,
    be certain they do not interfere with the function of the parts when applied.
q   Overhaul should be done in a clean work area, it is preferable to work in dustproof area.
q   Before disassembly, using steam or white gasoline, completely remove sand and mud from the exterior of
    the unit, preventing them from entering into the unit during disassembly or assembly.
q   Check appearance of the disassembled parts for damage, deformation, and unusual wear. Replace them
    with a new ones if necessary.
q   Gaskets, seals and O-rings should be replaced any time when the unit is disassembled.
q   In principle, tighten bolts or nuts gradually in several steps working diagonally from inside to outside. If
    tightening sequence is specified, observe it.
q   Clean and flush the parts sufficiently and blow-dry them.
q   Be careful not to damage sliding surfaces and mating surfaces.
q   When applying sealant, remove the old sealant from the mounting surface; then remove any moisture, oil,
    and foreign materials from the application and mounting surfaces.
q   Always use shop paper for cleaning the inside of components.
q   Avoid using cotton gloves or shop rags to prevent entering of lint.
q   During assembly, observe the specified tightening torque, and apply new gear oil, petroleum jelly, or multi-
    purpose grease as specified for each vehicle, if necessary.




Revision: 2005 July                                RFD-2                                               2005 FX
                                                       PREPARATION

PREPARATION                                                                                                                      PFP:00002
                                                                                                                                                A
Special Service Tools                                                                                                                ADS001AG

The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
  Tool number                                                                                                                                   B
  (Kent-Moore No.)                                                                       Description
  Tool name

  KV40104000                                                                             Removing and installing drive pinion lock nut
                                                                                                                                                C
  (    --    )
  Flange wrench
  a: 85 mm (3.35 in)
  b: 65 mm (2.56 in)                                                                                                                            RFD

                                                                        NT659


  KV381054S0                                                                             Removing front oil seal
                                                                                                                                                E
  (J-34286)
  Puller
                                                                                                                                                F


                                                                        ZZA0601D
                                                                                                                                                G
  ST30720000                                                                             q   Installing front oil seal
  (J-25405)                                                                              q   Installing pinion rear bearing outer race
  Drift
                                                                                                                                                H
  a: 77 mm (3.03 in) dia.
  b: 55.5 mm (2.185 in) dia.

                                                                                                                                                 I
                                                                        ZZA0811D


  KV40104100                                                                             Removing side flange (For VQ35DE models)
  (    --    )
  Attachment                                                                                                                                    J



                                                                                                                                                K
                                                                        ZZA0804D


  KV40101000                                                                             Removing side flange (For VK45DE models)
  (    --    )                                                                                                                                  L
  Attachment


                                                                                                                                                M

                                                                        NT159


  ST36230000                                                                             Removing side flange
  (J-25840-A)
  Sliding hammer




                                                                        ZZA0803D


  KV38100200                                                                             Installing side oil seal
  (J-26233)
  Drift
  a: 65 mm (2.56 in) dia.
  b: 49 mm (1.93 in) dia.


                                                                        ZZA1143D




Revision: 2005 July                                            RFD-3                                                             2005 FX
                                         PREPARATION

  Tool number
  (Kent-Moore No.)                                          Description
  Tool name

  KV38107900                                                Installing side flange
  (J-39352)
  Protector




                                                S-NT129


  KV38100800                                                Fixing unit assembly
  (J-25604-01)
  Attachment
  a: 541 mm (21.30 in)
  b: 200 mm (7.87 in)


                                                SDIA0267E


  ST3127S000                                                Measuring pinion bearing preload and total
  (J-25765-A)                                               preload
  Preload gauge
  1: GG91030000
     (J-25765)
     Torque wrench
  2: HT62940000
     (    --    )
     Socket adapter (1/2)
  3: HT62900000                                 NT124

     (    --    )
     Socket adapter (3/8)
  KV10111100                                                Removing rear cover
  (J-37228)
  Seal cutter




                                                S-NT046


  ST3306S001                                                Removing and installing side bearing inner
  (J-22888-D)                                               race
  Differential side bearing puller set
  1: ST33051001
     (J-22888-20)
     Puller
  2: ST33061000
     (J-8107-2)
     Base
                                                NT072
     a: 28.5 mm (1.122 in) dia.
     b: 38 mm (1.50 in) dia.
  ST30031000                                                Removing pinion rear bearing inner race
  (J-22912-01)
  Replacer




                                                ZZA0700D




Revision: 2005 July                         RFD-4                                               2005 FX
                               PREPARATION

  Tool number
  (Kent-Moore No.)                                Description                                       A
  Tool name

  KV40105230                                      Installing pinion rear bearing outer race
  (     --   )                                                                                      B
  Drift
  a: 92 mm (3.62 in) dia.
  b: 86 mm (3.39 in) dia.
  c: 45 mm (1.77 in) dia.                                                                           C

                                      PDIA0591E


  ST30613000                                      Installing pinion front bearing outer race        RFD
  (J-25742-3)
  Drift
  a: 72 mm (2.83 in) dia.
  b: 48 mm (1.89 in) dia.                                                                           E


                                      ZZA1000D
                                                                                                    F
  ST30611000                                      Installing pinion front bearing outer race (Use
  (J-25742-1)                                     with ST30613000)
  Drift bar
                                                                                                    G



                                      S-NT090
                                                                                                    H
  ST30901000                                      Installing pinion rear bearing inner race
  (J-26010-01)
  Drift                                                                                              I
  a: 79 mm (3.11 in) dia.
  b: 45 mm (1.77 in) dia.
  c: 35.2 mm (1.386 in) dia.
                                                                                                    J
                                      ZZA0978D


  KV38100300                                      Installing side bearing inner race
  (J-25523)                                                                                         K
  Drift
  a: 54 mm (2.13 in) dia.
  b: 46 mm (1.81 in) dia.
  c: 32 mm (1.26 in) dia.                                                                           L

                                      ZZA1046D


  (J-8129)                                        Measuring turning torque                          M
  Spring gauge




                                      NT127




Revision: 2005 July               RFD-5                                                  2005 FX
                                    PREPARATION

  Tool number
  (Kent-Moore No.)                                     Description
  Tool name

  (J-34309)                                            Adjusting bearing preload and pinion gear
  Differential shim selector tool                      height




                                           NT134


  (J-25269-4)                                          Selecting pinion height adjusting washer
  Side bearing disc (2 Req'd)




                                           NT136



Commercial Service Tools                                                                            ADS001AH



  Tool name                                            Description

  Spacer                                               Installing pinion front bearing inner race
  a: 60 mm (2.36 in) dia.
  b: 36 mm (1.42 in) dia.
  c: 30 mm (1.18 in)



                                           ZZA1133D


  Power tool                                           Loosening nuts and bolts




                                           PBIC0190E




Revision: 2005 July                    RFD-6                                                  2005 FX
