Image preview - the first page of the document
ffd


>> Download ffd documenatation <<

Text preview - extract from the document
FRONT FINAL DRIVE


D DRIVELINE/AXLE

                                                                                                                                                                A




                                                                                    SECTION
                                                                                            FRONT FINAL DRIVE
                                                                                                               FFD                                              B



                                                                                                                                                                C


                                                                                                                                                                FFD


                                                                                                                                                                E
                                                                CONTENTS
PRECAUTIONS ......................................................... 2
                                                                      .            COMPONENTS (VK45DE) ................................ 16             .        F
  Precautions ............................................................. 2
                                                                      .          Side Shaft .............................................................. 18
                                                                                                                                                       .
PREPARATION .......................................................... 3
                                                                      .            BEARING AND OIL SEAL REPLACEMENT ...... 18                          .
  Special Service Tools .............................................. 3
                                                                      .            EXTENSION TUBE REPLACEMENT ................ 19                      .        G
  Commercial Service Tools ....................................... 5  .            PRE-DISASSEMBLY INSPECTION ................... 19                   .
NOISE, VIBRATION AND HARSHNESS (NVH)                                               DISASSEMBLY AND ASSEMBLY ...................... 21                  .
TROUBLESHOOTING ............................................... 6     .          Differential Case Assembly ................................... 24     .
                                                                                                                                                                H
  NVH Troubleshooting Chart .................................... 6    .          Installation Drive Pinion Assembly ........................ 27        .
FRONT OIL SEAL ..................................................... 7.            DIFFERENTIAL CASE INSTALLATION ............. 28                     .
  Removal and Installation ......................................... 7.            TOOTH CONTACT INSPECTION ...................... 30                  .
    REMOVAL ............................................................ 7
                                                                      .            TOOTH CONTACT ADJUSTMENT .................... 31                    .         I
    INSTALLATION .................................................... 8
                                                                      .            TOTAL PRELOAD INSPECTION ....................... 33                 .
SIDE OIL SEAL ......................................................... 9
                                                                      .            DRIVE PINION PRELOAD ADJUSTMENT ........ 33                         .
  Removal and Installation ......................................... 9.          After Inspection ...................................................... 35
                                                                                                                                                       .         J
    REMOVAL ............................................................ 9
                                                                      .          Carrier Cover Installation ....................................... 37 .
    INSTALLATION .................................................... 9
                                                                      .         SERVICE DATA AND SPECIFICATIONS (SDS) ..... 38                         .
FRONT FINAL DRIVE ASSEMBLY ......................... 10               .          General Specifications ........................................... 38 .
                                                                                                                                                                K
  Removal and Installation (VQ35DE) ..................... 10          .          Drive Gear Runout ................................................. 38.
    REMOVAL .......................................................... 10
                                                                      .          Side Gear Adjustment ........................................... 38   .
    INSTALLATION .................................................. 10.            AVAILABLE SIDE GEAR THRUST WASHERS... 38
  Removal and Installation (VK45DE) .......................11         .            SIDE BEARING PRELOAD ADJUSTING SHIMS 38                             ...       L
    REMOVAL ...........................................................11
                                                                      .          Drive Pinion Height Adjustment ............................. 39       .
    INSTALLATION ...................................................11.            AVAILABLE PINION HEIGHT ADJUSTING
  Front Final Drive Breather Hose ........................... 12      .            WASHERS ......................................................... 39.        M
    REMOVAL AND INSTALLATION (VQ35DE) ...... 12                       .          Drive Pinion Preload Adjustment ........................... 39        .
    REMOVAL AND INSTALLATION (VK45DE) ...... 13                       .            AVAILABLE PINION HEIGHT ADJUSTING
  Components .......................................................... 14
                                                                      .            WASHERS ......................................................... 39.
    COMPONENTS (VQ35DE) ................................ 14           .          Total Preload Adjustment ....................................... 39   .




Revision; 2004 April                                                     FFD-1                                                                   2003 FX
                                         PRECAUTIONS

PRECAUTIONS                                                                                    PFP:00001

Precautions                                                                                        ADS000N3


CAUTION:
q  Before starting diagnosis of the vehicle, understand symptoms well. Perform correct and system-
   atic operations.
q  Check for the correct installation status prior removal or disassembly. When mating marks are
   required, be sure they do not interfere with the function of the parts they are applied to.
q  Carry out an overhaul in a clean work place, Using a dust proof room is recommended.
q  Before disassembly, using steam or white gasoline, completely remove sand and mud from the
   exterior the unit, preventing them from entering into the unit during disassembly or assembly.
q  Check appearance of the disassembled parts for damage, deformation, and abnormal wear. If a
   malfunction is detected, replace it with a new one.
q  Normally replace lock pins, oil seals, and bearings with new ones every times they are removed.
q  In principle, tighten bolts or nuts gradually in several steps working diagonally from inside to out-
   side. If tightening sequence is specified, observe it.
q  Clean and flush the parts sufficiently and blow them dry.
q  Be careful not to damage the sliding surfaces and mating surface.
q  When applying sealant, remove the old sealant from the mounting surface; then remove any mois-
   ture, oil, and foreign materials from the application and mounting surfaces.
q  Always use shop paper for cleaning the inside of components.
q  Avoid using cotton gloves or a shop cloth to prevent entering of lint.
q  During assembly, observe the specified tightening torque, and new differential oil, Vaseline, or
   multi-purpose grease, as specified for each vehicle, when necessary.




Revision; 2004 April                            FFD-2                                           2003 FX
                                            PREPARATION

PREPARATION                                                                                                    PFP:00002
                                                                                                                             A
Special Service Tools                                                                                             ADS000N4


The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
   Tool number (Kent-Moore No.)
                                                                                                                             B
                                                                        Description
   Tool name

                                                                                                                             C
   ST33400001 (J26082)                                                  q   Installing front oil seal
   a: 60 mm (2.36 in) dia.
   b: 47 mm (1.85 in) dia.                                              q   Installing right side oil sea
                                                                                                                             FFD
   Drift

                                                            ZZA0702D

                                                                                                                             E

                                                                        q   Removing side bearing outer race
   ST33290001 (J34286)
                                                                        q   Removing side oil seal                           F
   Outer race puller
                                                                        q   Removing front oil seal

                                                            ZZA0601D
                                                                                                                             G

   ST3306S001 (
