Image preview - the first page of the document
>> Download fsu documenatation <<
Text preview - extract from the document
FRONT SUSPENSION
E SUSPENSION
A
SECTION
FRONT SUSPENSION
FSU B
C
D
FSU
CONTENTS
PRECAUTIONS ......................................................... 2 . INSTALLATION .................................................. 11 . F
Caution .................................................................... 2
. Disassembly and Assembly ................................... 12 .
PREPARATION .......................................................... 3. DISASSEMBLY .................................................. 12 .
Special Service Tools (SST) .................................... 3 . INSPECTION AFTER DISASSEMBLY ............... 12 . G
Commercial Service Tools ....................................... 4 . ASSEMBLY ........................................................ 13 .
NOISE, VIBRATION AND HARSHNESS (NVH) TRANSVERSE LINK ................................................ 14 .
TROUBLESHOOTING ............................................... 5 . Removal and Installation ....................................... 14 .
H
NVH Troubleshooting Chart .................................... 5 . REMOVAL .......................................................... 14 .
FRONT SUSPENSION ASSEMBLY .......................... 6 . INSPECTION AFTER REMOVAL ...................... 14 .
On-Vehicle Inspection and Service ......................... 6 . INSTALLATION .................................................. 15 .
INSPECTION OF TRANSVERSE LINK BALL STABILIZER BAR .................................................... 16 . I
JOINT END PLAY ................................................ 6 . Removal and Installation ....................................... 16 .
STRUT INSPECTION .......................................... 6 . REMOVAL .......................................................... 16 .
Wheel Alignment Inspection .................................... 6 . INSPECTION AFTER REMOVAL ...................... 16 . J
DESCRIPTION ..................................................... 6 . INSTALLATION .................................................. 16 .
PRELIMINARY CHECK ....................................... 6 . FRONT SUSPENSION MEMBER ............................ 17 .
INSPECTION OF CAMBER, CASTER AND Removal and Installation ....................................... 17 .
K
KINGPIN INCLINATION ANGLES ....................... 6 . REMOVAL .......................................................... 17 .
Components ............................................................ 8
. INSPECTION AFTER REMOVAL ...................... 17 .
Removal and Installation ......................................... 9 . INSTALLATION .................................................. 17 .
REMOVAL ............................................................ 9
. SERVICE DATA ....................................................... 18 . L
INSTALLATION .................................................. 10 . Wheel Alignment (Unladen) ................................... 18 .
COIL SPRING AND STRUT .....................................11 . Ball Joint ................................................................ 18
.
Removal and Installation ........................................11 . Wheelarch Height (Unladen*) ................................ 18 . M
REMOVAL ...........................................................11.
Revision; 2004 April FSU-1 2003 FX
PRECAUTIONS
PRECAUTIONS PFP:00001
Caution AES000MZ
q When installing rubber bushings, final tightening must be carried out under unladen conditions with tires
on ground. Oil will shorten the life of rubber bushings. Be sure to wipe off any spilled oil.
q Unladen conditions mean that fuel, engine coolant and lubricant are full. Spare tire, jack, hand tools and
mats are in designated positions.
q After servicing suspension parts, be sure to check wheel alignment.
q Caulking nuts are not reusable. Always use new ones when installing. Since new caulking nuts are pre-
oiled, tighten as they are.
q Avoid burden to front cross bar.
Revision; 2004 April FSU-2 2003 FX
PREPARATION
PREPARATION PFP:00002
A
Special Service Tools (SST) AES000N0
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Tool number
B
(Kent-Moore No.) Description
Tool name
KV991040S0 C
( -- )
CCK gauge attachment
1. Plate
D
2. Guide bolts
3. Nuts
4. Springs
5. Center plate FSU
Measuring wheel alignment
6. KV9910 4020 Adapter A
a: 72 mm (2.83 in) dia.
7. KV9910 4030 Adapter B
b: 65 mm (2.56 in) dia. S-NT498 F
8. KV9910 4040 Adapter C
c: 57 mm (2.24 in) dia.
9. KV9910 4050 Adapter D
d: 53.4 mm (2.102 in) dia. G
HT72520000
(J25730-A) H
Ball joint remover q Removing steering outer socket
a: 33 mm (1.30 in) q Removing transverse link
b: 50 mm (1.97 in)
r: 11.5 mm (0.453 in) I
NT546
J
ST35652000
( -- ) Disassembling and assembling strut
Strut attachment
K
ZZA0807D
ST3127 S000 L
(See J25742-1)
Preload gauge
1. GG91030000
Torque wrench (J25765) Measuring rotating torque of ball joint M
2. HT62940000 ( -- )
Socket adapter (1/2)
3. HT62900000 ( -- )
NT124
Socket adapter (3/8)
Revision; 2004 April FSU-3 2003 FX
PREPARATION
Commercial Service Tools AES000N1
Tool name Description
Spring compressor Removing coil spring
S-NT717
q Removing wheel nuts
q Removing brake caliper assembly
q Removing undercover
Power tool
q Removing steering gear
q Removing drive shaft (For AWD models)
PBIC0190E q Removing suspension components parts
Revision; 2004 April FSU-4 2003 FX
