Image preview - the first page of the document
ei


>> Download ei documenatation <<

Text preview - extract from the document
EXTERIOR & INTERIOR


I BODY

                                                                                                                                                              A




                                                                                    EXTERIOR & INTERIOR
                                                                                                           SECTION                   EI                       B



                                                                                                                                                              C


                                                                                                                                                              D


                                                                                                                                                              E
                                                                CONTENTS
PRECAUTIONS ......................................................... 3
                                                                      .            BUMPER FASCIA .............................................. 19  .         F
 Precautions for Supplemental Restraint System                                     REMOVAL AND INSTALLATION OF REAR
 (SRS) "AIR BAG" and "SEAT BELT PRE-TEN-                                           BUMPER CLOSING ........................................... 20    .
 SIONER" ................................................................. 3
                                                                      .            REMOVAL AND INSTALLATION OF DRAFTER                                        G
 Precautions for Procedures without Cowl Top Cover 3                  .....        GUARD .............................................................. 20
                                                                                                                                                    .
 Precautions for Work ............................................... 3
                                                                      .            REMOVAL AND INSTALLATION OF REAR FIL-
PREPARATION .......................................................... 4
                                                                      .            LET MOLDING ASSEMBLY ............................... 21          .
                                                                                                                                                              H
 Special Service Tools .............................................. 4
                                                                      .         FRONT GRILLE ....................................................... 22
                                                                                                                                                    .
 Commercial Service Tools ....................................... 4   .          Removal and Installation ....................................... 22.
SQUEAK AND RATTLE TROUBLE DIAGNOSES..... 5                                         REMOVAL .......................................................... 22
                                                                                                                                                    .
 Work Flow ............................................................... 5
                                                                      .            INSTALLATION .................................................. 22
                                                                                                                                                    .        EI
   CUSTOMER INTERVIEW .................................... 5          .         COWL TOP .............................................................. 23
                                                                                                                                                    .
   DUPLICATE THE NOISE AND TEST DRIVE ...... 6                        .          Removal and Installation ....................................... 23.
   CHECK RELATED SERVICE BULLETINS .......... 6                       .            REMOVAL .......................................................... 23
                                                                                                                                                    .         J
   LOCATE THE NOISE AND IDENTIFY THE                                               INSTALLATION .................................................. 23
                                                                                                                                                    .
   ROOT CAUSE ..................................................... 6 .         FENDER PROTECTOR ........................................... 24     .
   REPAIR THE CAUSE .......................................... 6      .          Removal and Installation ....................................... 24.
                                                                                                                                                              K
   CONFIRM THE REPAIR ...................................... 7        .            REMOVAL .......................................................... 24
                                                                                                                                                    .
 Generic Squeak and Rattle Troubleshooting .......... 7               .            INSTALLATION .................................................. 24
                                                                                                                                                    .
   INSTRUMENT PANEL ......................................... 7       .         DOOR OUTSIDE MOLDING .................................... 25        .
   CENTER CONSOLE ............................................ 7      .          Removal and Installation ....................................... 25.         L
   DOORS ................................................................ 7
                                                                      .            FRONT DOOR OUTSIDE MOLDING ................. 25                  .
   TRUNK ................................................................. 8
                                                                      .            REAR DOOR OUTSIDE MOLDING ................... 25                 .
   SUNROOF/HEADLINING .................................... 8          .         DOOR OUTSIDE LOWER MOLDING ..................... 26                 .         M
   SEATS .................................................................. 8
                                                                      .          Removal and Installation ....................................... 26.
   UNDERHOOD ...................................................... 8 .            FRONT AND REAR DOOR OUTSIDE LOWER
 Diagnostic Worksheet ............................................. 9 .            MOLDING ........................................................... 26
                                                                                                                                                    .
CLIP AND FASTENER .............................................11     .         DOOR PARTING SEAL ........................................... 27    .
 Clip and Fastener ...................................................11
                                                                      .          Removal and Installation ....................................... 27.
FRONT BUMPER .................................................... 14  .            REMOVAL .......................................................... 27
                                                                                                                                                    .
 Removal and Installation ....................................... 14  .            INSTALLATION .................................................. 28
                                                                                                                                                    .
   REMOVAL .......................................................... 15
                                                                      .         CENTER MUD GUARD ........................................... 29     .
   INSTALLATION .................................................. 16 .          Removal and Installation ....................................... 29.
   REMOVAL AND INSTALLATION OF FRONT                                               REMOVAL .......................................................... 29
                                                                                                                                                    .
   FILLET MOLDING ASSEMBLY ......................... 16               .            INSTALLATION .................................................. 29
                                                                                                                                                    .
REAR BUMPER ...................................................... 17 .         WINDSHIELD MOLDING ......................................... 30     .
 Removal and Installation ....................................... 17  .          Removal and Installation ....................................... 30.
   REMOVAL .......................................................... 18
                                                                      .            REMOVAL .......................................................... 30
                                                                                                                                                    .
   INSTALLATION .................................................. 19 .            INSTALLATION .................................................. 30
                                                                                                                                                    .
   DISASSEMBLY AND ASSEMBLY OF REAY


Revision: 2006 December                                                    EI-1                                                    2006 FX35/FX45
BACK DOOR WINDOW MOLDING ......................... 31                .           REAR) .................................................................39
                                                                                                                                                     .
 Removal and Installation ....................................... 31 .        FLOOR TRIM ............................................................40
                                                                                                                                                     .
  REMOVAL .......................................................... 31
                                                                     .         Removal and Installation ........................................40   .
  INSTALLATION ................................................... 31.           REMOVAL ...........................................................40
                                                                                                                                                     .
ROOF SIDE MOLDING ............................................ 33    .           INSTALLATION ...................................................41  .
 Removal and Installation ....................................... 33 .        HEADLINING ............................................................42
                                                                                                                                                     .
  REMOVAL .......................................................... 33
                                                                     .         Removal and Installation ........................................42   .
  INSTALLATION ................................................... 33.           REMOVAL ...........................................................43
                                                                                                                                                     .
ROOF RAIL .............................................................. 34
                                                                     .           INSTALLATION ...................................................43  .
 Removal and Installation ....................................... 34 .        LUGGAGE FLOOR TRIM ........................................44          .
  REMOVAL .......................................................... 34
                                                                     .         Removal and Installation ........................................44   .
  INSTALLATION ................................................... 34.           REMOVAL ...........................................................45
                                                                                                                                                     .
  REMOVAL AND INSTALLATION OF ROOF RAIL                                          INSTALLATION ...................................................45  .
  BRACKET ........................................................... 34
                                                                     .        BACK DOOR TRIM ..................................................46    .
DOOR FINISHER ..................................................... 35
                                                                     .         Removal and Installation ........................................46   .
 Removal and Installation ....................................... 35 .           REMOVAL ...........................................................46
                                                                                                                                                     .
  DOOR FINISHER (FRONT AND REAR) ............ 35                     .           INSTALLATION ...................................................46  .
BODY SIDE TRIM .................................................... 37
                                                                     .           BACK DOOR OUTSIDE FINISHER ....................46                   .
 Removal and Installation ....................................... 37 .
  CENTER PILLAR LOWER GARNISH ................ 37                    .
  CENTER PILLAR UPPER GARNISH ................. 38                   .
  DASH SIDE FINISHER ...................................... 38       .
  FRONT PILLAR GARNISH ................................ 39           .
  KICKING PLATE ................................................. 39 .
  CENTER MUDGUARD FINISHER (FRONT/




Revision: 2006 December                                                   EI-2                                                     2006 FX35/FX45
                                              PRECAUTIONS

PRECAUTIONS                                                         PFP:00001
                                                                                                                            A
Precautions for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT
BELT PRE-TENSIONER"                                                                                             NIS001TF


The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along                               B
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front                 C
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING:                                                                                                                    D
q    To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
     in the event of a collision which would result in air bag inflation, all maintenance must be per-
     formed by an authorized NISSAN/INFINITI dealer.                                                                        E
q    Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
     sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
     Bag Module, see the SRS section.                                                                                       F
q    Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
     Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
     harness connectors.
                                                                                                                            G
Precautions for Procedures without Cowl Top Cover                                                               NIS001TG


When performing the procedure after removing cowl top cover, cover
the lower end of windshield with urethane, etc.                                                                             H


                                                                                                                           EI


                                                                                                                            J


                                                                                                            PIIB3706J
                                                                                                                            K
Precautions for Work                                                                                            NIS001TH


q   After removing and installing the opening/closing parts, be sure to carry out fitting adjustments to check
    their operation.                                                                                                        L
q   Check the lubrication level, damage, and wear of each part. If necessary, grease or replace it.

                                                                                                                            M




Revision: 2006 December                                EI-3                                       2006 FX35/FX45
                                            PREPARATION

PREPARATION                                                                                              PFP:00002

Special Service Tools                                                                                        NIS001TI


The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
 Tool number
 (Kent-Moore No.)                                                       Description
 Tool name




 (J-39570)
                                                                        Locationg the noise
 Chassis ear


                                                      SIIA0993E




 (J-43980)
 NISSAN Squeak and Rattle                                               Repairing the cause of noise
 Kit


                                                      SIIA0994E



Commercial Service Tools                                                                                     NIS001TJ



 Tool name                                                              Description




 Engine ear                                                             Locating the noise



                                                      SIIA0995E




 Power tool



                                                      PIIB1407E




Revision: 2006 December                              EI-4                                         2006 FX35/FX45
                       SQUEAK AND RATTLE TROUBLE DIAGNOSES

SQUEAK AND RATTLE TROUBLE DIAGNOSES                                                                       PFP:00000
                                                                                                                             A
Work Flow                                                                                                         NIS001TK




                                                                                                                             B



                                                                                                                             C


                                                                                                                             D


                                                                                                                             E



                                                                                                                             F



                                                                                                         SBT842
                                                                                                                             G

CUSTOMER INTERVIEW
Interview the customer if possible, to determine the conditions that exist when the noise occurs. Use the Diag- H
nostic Worksheet during the interview to document the facts and conditions when the noise occurs and any
customer's comments; refer to EI-9, "Diagnostic Worksheet" . This information is necessary to duplicate the
conditions that exist when the noise occurs.
                                                                                                                       EI
q    The customer may not be able to provide a detailed description or the location of the noise. Attempt to
     obtain all the facts and conditions that exist when the noise occurs (or does not occur).
q    If there is more than one noise in the vehicle, be sure to diagnose and repair the noise that the customer
                                                                                                                        J
     is concerned about. This can be accomplished by test driving the vehicle with the customer.
q    After identifying the type of noise, isolate the noise in terms of its characteristics. The noise characteristics
     are provided so the customer, service adviser and technician are all speaking the same language when
     defining the noise.                                                                                                K
q    Squeak --(Like tennis shoes on a clean floor)
     Squeak characteristics include the light contact/fast movement/brought on by road conditions/hard sur-
     faces=higher pitch noise/softer surfaces=lower pitch noises/edge to surface=chirping                               L
q    Creak--(Like walking on an old wooden floor)
     Creak characteristics include firm contact/slow movement/twisting with a rotational movement/pitch
     dependent on materials/often brought on by activity.                                                               M
q    Rattle--(Like shaking a baby rattle)
     Rattle characteristics include the fast repeated contact/vibration or similar movement/loose parts/missing
     clip or fastener/incorrect clearance.
q    Knock --(Like a knock on a door)
     Knock characteristics include hollow sounding/sometimes repeating/often brought on by driver action.
q    Tick--(Like a clock second hand)
     Tick characteristics include gentle contacting of light materials/loose components/can be caused by driver
     action or road conditions.
q    Thump--(Heavy, muffled knock noise)
     Thump characteristics include softer knock/dead sound often brought on by activity.
q    Buzz--(Like a bumble bee)
     Buzz characteristics include high frequency rattle/firm contact.
q    Often the degree of acceptable noise level will vary depending upon the person. A noise that you may
     judge as acceptable may be very irritating to the customer.
q    Weather conditions, especially humidity and temperature, may have a great effect on noise level.


Revision: 2006 December                                EI-5                                       2006 FX35/FX45
                       SQUEAK AND RATTLE TROUBLE DIAGNOSES

DUPLICATE THE NOISE AND TEST DRIVE
If possible, drive the vehicle with the customer until the noise is duplicated. Note any additional information on
the Diagnostic Worksheet regarding the conditions or location of the noise. This information can be used to
duplicate the same conditions when you confirm the repair.
If the noise can be duplicated easily during the test drive, to help identify the source of the noise, try to dupli-
cate the noise with the vehicle stopped by doing one or all of the following:
1) Close a door.
2) Tap or push/pull around the area where the noise appears to be coming from.
3) Rev the engine.
4) Use a floor jack to recreate vehicle "twist".
5) At idle, apply engine load (electrical load, half-clutch on M/T model, drive position on A/T model).
6) Raise the vehicle on a hoist and hit a tire with a rubber hammer.
q    Drive the vehicle and attempt to duplicate the conditions the customer states exist when the noise occurs.
q    If it is difficult to duplicate the noise, drive the vehicle slowly on an undulating or rough road to stress the
     vehicle body.
CHECK RELATED SERVICE BULLETINS
After verifying the customer concern or symptom, check ASIST for Technical Service Bulletins (TSBs) related
to that concern or symptom.
If a TSB relates to the symptom, follow the procedure to repair the noise.
LOCATE THE NOISE AND IDENTIFY THE ROOT CAUSE
1.   Narrow down the noise to a general area. To help pinpoint the source of the noise, use a listening tool
     (Chassis Ear: J-39570,Engine Ear and mechanics stethoscope).
2.   Narrow down the noise to a more specific area and identify the cause of the noise by:
q    removing the components in the area that you suspect the noise is coming from.
     Do not use too much force when removing clips and fasteners, otherwise clips and fastener can be broken
     or lost during the repair, resulting in the creation of new noise.
q    tapping or pushing/pulling the component that you suspect is causing the noise.
     Do not tap or push/pull the component with excessive force, otherwise the noise will be eliminated only
     temporarily.
q    feeling for a vibration with your hand by touching the component(s) that you suspect is (are) causing the
     noise.
q    placing a piece of paper between components that you suspect are causing the noise.
q    looking for loose components and contact marks.
     Refer to EI-7, "Generic Squeak and Rattle Troubleshooting" .
REPAIR THE CAUSE
q   If the cause is a loose component, tighten the component securely.
q   If the cause is insufficient clearance between components:



◦ Jabse Service Manual Search 2022 ◦ Jabse PravopisonTap.bg ◦ Other service manual resources online : FixyaeServiceinfo
