Image preview - the first page of the document
fsu


>> Download fsu documenatation <<

Text preview - extract from the document
FRONT SUSPENSION


E SUSPENSION

                                                                                                                                                                    A


                                                                                                                                                                    B
                                                                                     SECTION
                                                                                           FRONT SUSPENSION                                                         C


                                                                                                                                                                    D


                                                                                                                                                                    FSU
                                                                  CONTENTS
PRECAUTIONS ......................................................... 2 .            REMOVAL .......................................................... 11 .        F
 Caution .................................................................... 2
                                                                        .            INSTALLATION .................................................. 11    .
PREPARATION .......................................................... 3.          Disassembly and Assembly ................................... 12         .
 Special Service Tools .............................................. 3 .            DISASSEMBLY .................................................. 12     .        G
 Commercial Service Tools ....................................... 4     .            INSPECTION AFTER DISASSEMBLY ............... 12                       .
NOISE, VIBRATION AND HARSHNESS (NVH)                                                 ASSEMBLY ........................................................ 13  .
TROUBLESHOOTING ............................................... 5       .         TRANSVERSE LINK ................................................ 14      .
                                                                                                                                                                    H
 NVH Troubleshooting Chart .................................... 5       .          Removal and Installation ....................................... 14     .
FRONT SUSPENSION ASSEMBLY .......................... 6                  .            REMOVAL .......................................................... 14 .
 On-Vehicle Inspection and Service ......................... 6          .            INSPECTION AFTER REMOVAL ...................... 14                    .
   INSPECTION LOWER BALL JOINT END PLAY 6                               .....        INSTALLATION .................................................. 15    .         I
   STRUT INSPECTION .......................................... 6        .         STABILIZER BAR .................................................... 16   .
 Wheel Alignment Inspection .................................... 6      .          Removal and Installation ....................................... 16     .
   DESCRIPTION ..................................................... 6  .            REMOVAL .......................................................... 16 .         J
   PRELIMINARY CHECK ....................................... 6          .            INSPECTION AFTER REMOVAL ...................... 16                    .
   GENERAL INFORMATION AND RECOMMEN-                                                 INSTALLATION .................................................. 16    .
   DATIONS ............................................................. 6
                                                                        .         FRONT SUSPENSION MEMBER ............................ 17                  .
                                                                                                                                                                    K
   THE ALIGNMENT PROCESS ............................. 7                .          Removal and Installation ....................................... 17     .
   INSPECTION OF CAMBER, CASTER AND                                                  REMOVAL .......................................................... 17 .
   KINGPIN INCLINATION ANGLES ....................... 7                 .            INSPECTION AFTER REMOVAL ...................... 17                    .
 Removal and Installation ......................................... 8   .            INSTALLATION .................................................. 17    .        L
   COMPONENTS ................................................... 8     .         SERVICE DATA AND SPECIFICATIONS (SDS) ..... 18                           .
   REMOVAL ............................................................ 9
                                                                        .          Wheel Alignment (Unladen*) ................................. 18         .
   INSTALLATION .................................................. 10   .          Ball Joint ................................................................ 18
                                                                                                                                                           .        M
COIL SPRING AND STRUT .....................................11           .          Wheelarch Height (Unladen*) ................................ 18         .
 Removal and Installation ........................................11    .




Revision: 2006 July                                                        FSU-1                                                         2007 FX35/FX45
                                            PRECAUTIONS

PRECAUTIONS                                                                                          PFP:00001

Caution                                                                                                 NES000FK


q   When installing rubber bushings, final tightening must be carried out under unladen conditions with tires
    on ground. Oil will shorten the life of rubber bushings. Be sure to wipe off any spilled oil.
q   Unladen conditions mean that fuel, engine coolant and lubricant are full. Spare tire, jack, hand tools and
    mats are in designated positions.
q   After servicing suspension parts, be sure to check wheel alignment.
q   Caulking nuts are not reusable. Always use new ones when installing. Since new caulking nuts are pre-
    oiled, tighten as they are.
q   Avoid burden to front cross bar.




Revision: 2006 July                               FSU-2                                      2007 FX35/FX45
                                            PREPARATION

PREPARATION                                                                                                  PFP:00002
                                                                                                                             A
Special Service Tools                                                                                             NES000FL


The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
  Tool number
                                                                                                                             B
   (Kent-Moore No.)                                                          Description
  Tool name

  KV991040S0                                                                 Measuring wheel alignment                       C
  (      --    )
  CCK gauge attachment
  1. Plate
                                                                                                                             D
  2. Guide bolts
  3. Nuts
  4. Springs
  5. Center plate                                                                                                            FSU
  6. KV9910 4020 Adapter A
    a: 72 mm (2.83 in) dia.
  7. KV9910 4030 Adapter B
    b: 65 mm (2.56 in) dia.                                     S-NT498                                                      F
  8. KV9910 4040 Adapter C
    c: 57 mm (2.24 in) dia.
  9. KV9910 4050 Adapter D
    d: 53.4 mm (2.102 in) dia.                                                                                               G
  HT72520000                                                                 q   Removing steering outer socket
  (J-25730-A)                                                                q   Removing transverse link
  Ball joint remover                                                                                                         H
  a: 33 mm (1.30 in)
  b: 50 mm (1.97 in)
  r: 11.5 mm (0.453 in)
                                                                                                                              I
                                                                NT546


  ST35652000                                                                 Disassembling and assembling strut
  (     --     )                                                                                                              J
  Strut attachment


                                                                                                                             K
                                                                ZZA0807D


  ST3127 S000                                                                Measuring rotating torque of ball joint         L
  (See J-25765-A)
  Preload gauge

                                                                                                                             M

                                                                ZZA0806D




Revision: 2006 July                                FSU-3                                           2007 FX35/FX45
                           PREPARATION

Commercial Service Tools                                                              NES000FM


  Tool name                                       Description
  Spring compressor                               Removing coil spring




                                      S-NT717


  Power tool                                      Loosening bolts and nuts




                                      PBIC0190E




Revision: 2006 July           FSU-4                                          2007 FX35/FX45
