Image preview - the first page of the document
>> Download lu documenatation <<
Text preview - extract from the document
ENGINE LUBRICATION SYSTEM
B ENGINE
A
LU
SECTION
ENGINE LUBRICATION SYSTEM C
D
E
CONTENTS
VQ35DE REMOVAL .......................................................... 17
. F
INSTALLATION .................................................. 17
.
PRECAUTIONS ......................................................... 3. INSPECTION AFTER INSTALLATION ............... 17 .
Precautions for Liquid Gasket ................................. 3 . Disassembly and Assembly ................................... 17 . G
LIQUID GASKET APPLICATION PROCEDURE 3 ..... DISASSEMBLY .................................................. 17
.
PREPARATION .......................................................... 4
. INSPECTION AFTER DISASSEMBLY ............... 18 .
Special Service Tools .............................................. 4. ASSEMBLY ........................................................ 19
.
Commercial Service Tools ....................................... 4 . H
SERVICE DATA AND SPECIFICATIONS (SDS) ..... 20 .
LUBRICATION SYSTEM ........................................... 5 . Standard and Limit ................................................. 20
.
Lubrication Circuit ................................................... 5
. ENGINE OIL PRESSURE .................................. 20 .
System Chart .......................................................... 6
. ENGINE OIL CAPACITY (APPROXIMATE) ....... 20 . I
ENGINE OIL .............................................................. 7
. OIL PUMP .......................................................... 20
.
Inspection ................................................................ 7
. REGULATOR VALVE ......................................... 20 .
ENGINE OIL LEVEL ............................................ 7 . J
ENGINE OIL APPEARANCE ............................... 7 .
ENGINE OIL LEAKAGE ....................................... 7 .
VK45DE
OIL PRESSURE CHECK ..................................... 8 . PRECAUTIONS ....................................................... 21 .
Changing Engine Oil ............................................... 9 . K
Precautions for Liquid Gasket ............................... 21 .
OIL FILTER .............................................................. 10
. LIQUID GASKET APPLICATION PROCEDURE 21 ...
Removal and Installation ....................................... 10 . PREPARATION ........................................................ 22.
REMOVAL .......................................................... 10
. Special Service Tools ............................................ 22 . L
INSTALLATION .................................................. 10 . Commercial Service Tools ..................................... 22 .
INSPECTION AFTER INSTALLATION .............. 10 . LUBRICATION SYSTEM ......................................... 23 .
OIL FILTER BRACKET (AWD) ................................ 12 . Lubrication Circuit .................................................. 23
. M
Components .......................................................... 12
. System Chart ......................................................... 24
.
Removal and Installation ....................................... 12 . ENGINE OIL ............................................................. 25
.
REMOVAL .......................................................... 12
. Inspection .............................................................. 25
.
INSTALLATION .................................................. 12 . ENGINE OIL LEVEL ........................................... 25 .
INSPECTION AFTER INSTALLATION .............. 13 . ENGINE OIL APPEARANCE ............................. 25 .
OIL COOLER ........................................................... 14
. ENGINE OIL LEAKAGE ..................................... 25 .
Components .......................................................... 14
. OIL PRESSURE CHECK ................................... 25 .
Removal and Installation ....................................... 15 . Changing Engine Oil .............................................. 27 .
REMOVAL .......................................................... 15
. OIL FILTER .............................................................. 28
.
INSPECTION AFTER REMOVAL ...................... 16 . Removal and Installation ....................................... 28 .
INSTALLATION .................................................. 16 . REMOVAL .......................................................... 28
.
INSPECTION AFTER INSTALLATION .............. 16 . INSTALLATION .................................................. 28 .
OIL PUMP ................................................................ 17
. INSPECTION AFTER INSTALLATION ............... 28 .
Components .......................................................... 17
.
Removal and Installation ....................................... 17 .
Revision: 2006 July LU-1 2007 FX35/FX45
OIL COOLER ........................................................... 29
. INSPECTION AFTER INSTALLATION ...............32 .
Components .......................................................... 29
. Disassembly and Assembly ...................................32 .
Removal and Installation ....................................... 29 . DISASSEMBLY ...................................................32.
REMOVAL .......................................................... 29
. INSPECTION AFTER DISASSEMBLY ...............32 .
INSPECTION AFTER REMOVAL ....................... 30 . ASSEMBLY .........................................................33
.
INSTALLATION ................................................... 30. SERVICE DATA AND SPECIFICATIONS (SDS) .....34 .
INSPECTION AFTER INSTALLATION ............... 30 . Standard and Limit .................................................34
.
OIL PUMP ................................................................ 31
. OIL PRESSURE .................................................34 .
Components .......................................................... 31
. ENGINE OIL CAPACITY (APPROXIMATE) .......34 .
Removal and Installation ....................................... 31 . OIL PUMP ...........................................................34
.
REMOVAL .......................................................... 31
. REGULATOR VALVE ..........................................34 .
INSTALLATION ................................................... 31.
Revision: 2006 July LU-2 2007 FX35/FX45
PRECAUTIONS
[VQ35DE]
PRECAUTIONS
[VQ35DE] PFP:00001
A
Precautions for Liquid Gasket NBS003IV
LIQUID GASKET APPLICATION PROCEDURE
1. Remove old liquid gasket adhering to the liquid gasket application surface and the mating surface.
LU
q Remove liquid gasket completely from the liquid gasket application surface, mounting bolts, and bolt
holes.
2. Wipe the liquid gasket application surface and the mating surface with white gasoline (lighting and heating
C
use) to remove adhering moisture, grease and foreign materials.
3. Apply liquid gasket to the liquid gasket application surface.
Use Genuine RTV Silicone Sealant or equivalent. Refer to GI-48, "RECOMMENDED CHEMICAL
PRODUCTS AND SEALANTS" . D
q Within five minutes of liquid gasket application, install the mating component.
q If liquid gasket protrudes, wipe it off immediately.
E
q Do not retighten after mounting bolts and nuts the installation.
q After 30 minutes or more have passed from the installation, fill engine oil and engine coolant.
F
G
H
I
J
K
L
M
Revision: 2006 July LU-3 2007 FX35/FX45
PREPARATION
[VQ35DE]
PREPARATION PFP:00002
Special Service Tools NBS003IW
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Tool number
(Kent-Moore No.) Description
Tool name
ST25051001 Measuring oil pressure
(J25695-1) Maximum measuring range: 2,452 kPa (25
Oil pressure gauge kg-cm2 , 356 psi)
NT050
ST25052000 Adapting oil pressure gauge to oil pan (upper)
(J25695-2)
Hose
S-NT559
KV10115801 Removing and installing oil filter
(J38956) a: 64.3 mm (2.531 in)
Oil filter wrench
S-NT375
Commercial Service Tools NBS003IX
Tool name Description
Power tools Loosening nuts and bolts
PBIC0190E
Deep socket Removing and installing oil pressure switch
a: 26 mm (1.02 in)
PBIC2072E
Revision: 2006 July LU-4 2007 FX35/FX45
LUBRICATION SYSTEM
[VQ35DE]
LUBRICATION SYSTEM PFP:15010
A
Lubrication Circuit NBS003IY
LU
C
D
E
F
G
H
I
PBIC1933E
J
K
L
M
Revision: 2006 July LU-5 2007 FX35/FX45
LUBRICATION SYSTEM
[VQ35DE]
System Chart NBS003IZ
PBIC2071E
Revision: 2006 July LU-6 2007 FX35/FX45
ENGINE OIL
[VQ35DE]
ENGINE OIL PFP:KLA92
A
Inspection NBS003J0
ENGINE OIL LEVEL
NOTE: LU
Before starting engine, put vehicle horizontally and check the engine oil level. If engine is already started, stop
it and allow 10 minutes before checking.
1. Pull out oil level gauge and wipe it clean.
C
2. Insert oil level gauge and make sure the engine oil level is within
the range shown in the figure.
3. If it is out of range, adjust it.
D
E
F
PBIC3101E
NOTE: G
When checking the engine oil level, insert oil level gauge with its
tip aligned with oil level gauge guide on cylinder head. (In figure,
air cleaner case and air duct are removed.)
H
I
J
KBIA1343E
ENGINE OIL APPEARANCE
q Check engine oil for white turbidity or heavy contamination. K
q If engine oil becomes turbid and white, it is highly probable that it is contaminated with engine coolant.
Repair or replace damaged parts.
L
ENGINE OIL LEAKAGE
Check for engine oil leakage around the following areas:
q Oil pans (lower and upper) M
q Oil pan drain plug
q Oil pressure switch
q Oil filter
q Oil filter bracket (AWD models)
q Oil cooler
q Water pump cover
q Chain tensioner cover
q Intake valve timing control cover and intake valve timing control solenoid valve
q Mating surface between cylinder head and rocker cover
q Mating surface between front timing chain case and rear timing chain case
q Mating surface between rear timing chain case and cylinder head
q Mating surface between rear timing chain case and cylinder block.
q Mating surface between rear timing chain case and oil pan (upper)
q Mating surface between cylinder block and cylinder head
Revision: 2006 July LU-7 2007 FX35/FX45
ENGINE OIL
[VQ35DE]
q Crankshaft oil seals (front and rear)
q Camshaft position sensor (PHASE)
OIL PRESSURE CHECK
WARNING:
q Be careful not to get burn yourself, as engine oil may be hot.
q Oil pressure check should be done in "Parking position".
1. Check the engine oil level. Refer to LU-7, "ENGINE OIL LEVEL" .
2. Remove front engine undercover with power tool.
3. Disconnect harness connector at oil pressure sensor, and
remove oil pressure sensor using deep socket (commercial ser-
vice tool).
CAUTION:
Do not drop or shock oil pressure switch.
SBIA0452E
SBIA0453E
4. Install the oil pressure gauge (SST) and hose (SST).
SLC926
5. Start the engine and warm it up to normal operating temperature.
6. Check the engine oil pressure with engine running under no-load.
NOTE:
When the engine oil temperature is low, the engine oil pressure becomes high.
Engine oil pressure [Engine oil temperature at 80 ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
