Image preview - the first page of the document
>> Download rsu documenatation <<
Text preview - extract from the document
REAR SUSPENSION
E SUSPENSION
A
B
SECTION
REAR SUSPENSION C
D
RSU
CONTENTS
PRECAUTIONS ......................................................... 2. SUSPENSION ARM ................................................. 11 . F
Cautions .................................................................. 2
. Removal and Installation ....................................... 11 .
PREPARATION .......................................................... 3
. REMOVAL .......................................................... 11 .
Special Service Tools .............................................. 3. INSPECTION AFTER REMOVAL ...................... 11 . G
Commercial Service Tools ....................................... 3 . INSTALLATION .................................................. 12 .
NOISE, VIBRATION AND HARSHNESS (NVH) RADIUS ROD ........................................................... 13.
TROUBLESHOOTING ............................................... 4 . Removal and Installation ....................................... 13 .
H
NVH Troubleshooting Chart .................................... 4 . REMOVAL .......................................................... 13 .
REAR SUSPENSION ASSEMBLY ............................ 5 . INSPECTION AFTER REMOVAL ...................... 13 .
On-Vehicle Inspection and Service ......................... 5 . INSTALLATION .................................................. 13 .
INSPECTION OF BALL JOINT END PLAY ......... 5 . FRONT LOWER LINK ............................................. 14 . I
SHOCK ABSORBER INSPECTION .................... 5 . Removal and Installation ....................................... 14 .
Wheel Alignment Inspection .................................... 5 . REMOVAL .......................................................... 14 .
DESCRIPTION ..................................................... 5 . INSPECTION AFTER REMOVAL ...................... 14 . J
PRELIMINARY INSPECTION .............................. 5 . INSTALLATION .................................................. 14 .
GENERAL INFORMATION AND RECOMMEN- REAR LOWER LINK & COIL SPRING .................... 15 .
DATIONS ............................................................. 5
. Removal and Installation ....................................... 15 .
K
THE ALIGNMENT PROCESS ............................. 6 . REMOVAL .......................................................... 15 .
CAMBER INSPECTION ....................................... 6 . INSPECTION AFTER REMOVAL ...................... 15 .
TOE-IN ................................................................. 6
. INSTALLATION .................................................. 15 .
Removal and installation ......................................... 7 . STABILIZER BAR .................................................... 16 . L
COMPONENTS ................................................... 7 . Removal and Installation ....................................... 16 .
REMOVAL ............................................................ 8
. REMOVAL .......................................................... 16 .
INSTALLATION .................................................... 8 . INSPECTION AFTER REMOVAL ...................... 16 . M
SHOCK ABSORBER ................................................. 9 . INSTALLATION .................................................. 16 .
Removal and Installation ......................................... 9 . REAR SUSPENSION MEMBER .............................. 17 .
REMOVAL ............................................................ 9
. Removal and Installation ....................................... 17 .
INSPECTION AFTER REMOVAL ........................ 9 . REMOVAL .......................................................... 17 .
INSTALLATION .................................................... 9 . INSPECTION AFTER REMOVAL ...................... 17 .
Disassembly and Assembly .................................... 9 . INSTALLATION .................................................. 17 .
DISASSEMBLY .................................................... 9 . SERVICE DATA AND SPECIFICATIONS (SDS) ..... 18 .
INSPECTION AFTER DISASSEMBLY .............. 10 . Wheel Alignment (Unladen*) ................................. 18 .
ASSEMBLY ........................................................ 10. Ball Joint ................................................................ 18
.
Wheelarch Height (Unladen*) ................................ 18 .
Revision: 2006 July RSU-1 2007 FX35/FX45
PRECAUTIONS
PRECAUTIONS PFP:00001
Cautions NES000G0
q When installing rubber bushings, final tightening must be carried out under unladen conditions with tires
on level ground. Oil will shorten the life of rubber bushings. Be sure to wipe off any spilled oil.
q Unladen conditions means that fuel, engine coolant and lubricant are full. Spare tire, jack, hand tools and
mats are in designated positions.
q After servicing suspension parts, be sure to check wheel alignment.
q Caulking nuts are not reusable. Always use new ones when installing. Since new caulking nuts are pre-
oiled, tighten as they are.
Revision: 2006 July RSU-2 2007 FX35/FX45
PREPARATION
PREPARATION PFP:00002
A
Special Service Tools NES000G1
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Tool number B
(Kent-Moore No.) Description
Tool name
ST3127S000 Measuring rotating torque of ball joint C
(See J-25765-A)
Preload gauge
D
ZZA0806D
RSU
Commercial Service Tools NES000G2
Tool name Description
F
Power tool Loosening bolts and nuts
G
PBIC0190E
H
I
J
K
L
M
Revision: 2006 July RSU-3 2007 FX35/FX45
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING PFP:00003
NVH Troubleshooting Chart NES000G3
Use chart below to help you find the cause of the symptom. If necessary, repair or replace these parts.
NVH in RAX and RSU section
NVH in RFD section
NVH in RAX section
NVH in WT section
NVH in WT section
NVH in PR section
NVH in BR section
NVH in PS section
RSU-16
RSU-7
RSU-9
RSU-7
FSU-6
--
--
--
Reference page
Shock absorber deformation, damage or deflection
REAR AXLE AND REAR SUSPENSION
Bushing or mounting deterioration
Improper installation, looseness
Possible cause and SUSPECTED PARTS
Incorrect wheel alignment
Suspension looseness
PROPELLER SHAFT
Stabilizer bar fatigue
Parts interference
ROAD WHEEL
DIFFERENTIAL
DRIVE SHAFT
Spring fatigue
STEERING
BRAKES
TIRES
