Image preview - the first page of the document
fwd


>> Download fwd documenatation <<

Text preview - extract from the document
3
1803
2
                                                                                                                  Attachment No.5

TEST VALUE AND TEST LIMIT (GST ONLY -- NOT APPLICABLE TO CONSULT-II)
The following is the information specified in Mode 6 of SAE J1979.
The test value is a parameter used to determine whether a system/circuit diagnostic test is "OK" or "NG" while
being monitored by the ECM during self-diagnosis. The test limit is a reference value which is specified as the
maximum or minimum value and is compared with the test value being monitored.
Items for which these data (test value and test limit) are displayed are the same as SRT code items.
These data (test value and test limit) are specified by Test ID (TID) and Component ID (CID) and can be dis-
played on the GST screen.
                                                                                                  : Applicable : Not applicable
                                                                     Test value
  SRT item             Self-diagnostic test item           DTC     (GST display)   Te s t limit     Application         Unit
                                                                    TID     CID
   CATALYST          Three way catalyst function           P0420   01H     01H        Max.               X                -
                                                           P0440   05H     03H        Max.               X                -
                   EVAP control system (Small leak)
 EVAP SYSTEM                                               P1440   05H     03H        Max.               X                -
               EVAP control system purge flow monitoring   P1447   06H     83H        Min.               X               mV
                                                           P0133   09H     04H        Max.               X               ms
                                                           P0131   0AH     84H        Min.               X               mV
                        Heated oxygen sensor 1             P0130   0BH     04H        Max.               X               mV
                                                           P0132   0CH     04H        Max.               X               mV
     HO2S                                                  P0134   0DH     04H        Max.               X                s
                                                           P0139   19H     86H        Min.               X            mV/500ms
                                                           P0137   1AH     86H        Min.               X               mV
                        Heated oxygen sensor 2
                                                           P0140   1BH     06H        Max.               X               mV
                                                           P0138   1CH     06H        Max.               X               mV
                                                           P0135   29H     08H        Max.               X               mV
                    Heated oxygen sensor 1 heater
                                                           P0135   2AH     88H        Min.               X               mV
   HO2S HTR
                                                           P0141   2DH     0AH        Max.               X               mV
                    Heated oxygen sensor 2 heater
                                                           P0141   2EH     8AH        Min.               X               mV
                                                           P0400   31H     8CH        Min.               X
                                                           P0400   32H     8CH        Min.               X
                             EGR function                  P0400   33H     8CH        Min.               X
  EGR SYSTEM                                               P0400   34H     8CH        Min.               X
                                                           P1402   35H     0CH        Max.               X
                                                           P0402   36H     0CH        Max.               X                -
                        EGRC-BPT valve function
                                                           P0402   37H     8CH        Min.               X                -
