Image preview - the first page of the document
ei


>> Download ei documenatation <<

Text preview - extract from the document
EXTERIOR & INTERIOR


I BODY

                                                                                                                                                              A




                                                                                    EXTERIOR & INTERIOR
                                                                                                           SECTION                   EI                       B



                                                                                                                                                              C


                                                                                                                                                              D


                                                                                                                                                              E
                                                                CONTENTS
PRECAUTIONS ......................................................... 3
                                                                      .         FRONT GRILLE ....................................................... 19
                                                                                                                                                    .         F
 Precautions for Supplemental Restraint System                                   Removal and Installation ....................................... 19.
 (SRS) "AIR BAG" and "SEAT BELT PRE-TEN-                                           REMOVAL .......................................................... 19
                                                                                                                                                    .
 SIONER" ................................................................. 3
                                                                      .            INSTALLATION .................................................. 19
                                                                                                                                                    .         G
 Precautions for Battery Service ............................... 3    .         COWL TOP .............................................................. 20
                                                                                                                                                    .
 Precautions for Work ............................................... 3
                                                                      .          Removal and Installation ....................................... 20.
PREPARATION .......................................................... 4
                                                                      .            REMOVAL .......................................................... 20
                                                                                                                                                    .
                                                                                                                                                              H
 Special Service Tools .............................................. 4
                                                                      .            INSTALLATION .................................................. 20
                                                                                                                                                    .
 Commercial Service Tool ........................................ 4   .         FENDER PROTECTOR ........................................... 21     .
SQUEAK AND RATTLE TROUBLE DIAGNOSES..... 5                                       Removal and Installation ....................................... 21.
 Work Flow ............................................................... 5
                                                                      .            RE MOVAL ......................................................... 21
                                                                                                                                                    .        EI
   CUSTOMER INTERVIEW .................................... 5          .            INSTALLATION .................................................. 21
                                                                                                                                                    .
   DUPLICATE THE NOISE AND TEST DRIVE ...... 6                        .         DOOR OUTSIDE MOLDING .................................... 22        .
   CHECK RELATED SERVICE BULLETINS .......... 6                       .          Removal and Installation ....................................... 22.         J
   LOCATE THE NOISE AND IDENTIFY THE                                               REMOVAL .......................................................... 22
                                                                                                                                                    .
   ROOT CAUSE ..................................................... 6 .            INSTALLATION .................................................. 22
                                                                                                                                                    .
   REPAIR THE CAUSE .......................................... 6      .         FRONT PILLAR FINISHER ..................................... 23      .
                                                                                                                                                              K
   CONFIRM THE REPAIR ...................................... 7        .          Removal and Installation ....................................... 23.
 Generic Squeak and Rattle Troubleshooting .......... 7               .            REMOVAL .......................................................... 23
                                                                                                                                                    .
   INSTRUMENT PANEL ......................................... 7       .            INSTALLATION .................................................. 23
                                                                                                                                                    .
   CENTER CONSOLE ............................................ 7      .         CENTER MUD GUARD ........................................... 24     .         L
   DOORS ................................................................ 7
                                                                      .          Removal and Installation ....................................... 24.
   TRUNK ................................................................. 8
                                                                      .            REMOVAL .......................................................... 24
                                                                                                                                                    .
   SUNROOF/HEADLINING .................................... 8          .            INSTALLATION .................................................. 24
                                                                                                                                                    .         M
   SEATS .................................................................. 8
                                                                      .         WINDSHIELD MOLDING ......................................... 25     .
   UNDERHOOD ...................................................... 8 .          Removal and Installation ....................................... 25.
 Diagnostic Worksheet ............................................. 9 .            REMOVAL .......................................................... 25
                                                                                                                                                    .
CLIP AND FASTENER .............................................11     .            INSTALLATION .................................................. 25
                                                                                                                                                    .
 Clip and Fastener ...................................................11
                                                                      .         REAR WINDOW MOLDING ..................................... 27        .
FRONT BUMPER .................................................... 14  .          Removal and Installation ....................................... 27.
 Removal and Installation ....................................... 14  .            REMOVAL .......................................................... 27
                                                                                                                                                    .
   REMOVAL .......................................................... 16
                                                                      .            INSTALLATION .................................................. 27
                                                                                                                                                    .
   INSTALLATION .................................................. 16 .         REAR SPOILER ....................................................... 28
                                                                                                                                                    .
REAR BUMPER ...................................................... 17 .          Removal and Installation ....................................... 28.
 Removal and Installation ....................................... 17  .            REMOVAL .......................................................... 28
                                                                                                                                                    .
   REMOVAL .......................................................... 17
                                                                      .            INSTALLATION .................................................. 28
                                                                                                                                                    .
   INSTALLATION .................................................. 18 .         ROOF SIDE MOLDING ............................................ 29   .
                                                                                 Removal and Installation ....................................... 29.
                                                                                   REMOVAL .......................................................... 29
                                                                                                                                                    .
                                                                                   INSTALLATION .................................................. 29
                                                                                                                                                    .


                                                                           EI-1
DOOR FINISHER ..................................................... 30
                                                                 .        FLOOR TRIM ............................................................36
                                                                                                                                              .
 Removal and Installation ....................................... 30
                                                                 .         Removal and Installation ........................................36.
  REMOVAL .......................................................... 30
                                                                 .           REMOVAL ...........................................................36
                                                                                                                                              .
  INSTALLATION ................................................... 31
                                                                 .           INSTALLATION ...................................................37
                                                                                                                                              .
BODY SIDE TRIM .................................................... 32
                                                                 .        HEADLINING ............................................................38
                                                                                                                                              .
 Removal and Installation ....................................... 32
                                                                 .         Removal and Installation ........................................38.
  REAR SIDE FINISHER ...................................... 32   .           REMOVAL ...........................................................39
                                                                                                                                              .
  REAR PILLAR GARNISH ................................... 33     .           INSTALLATION ...................................................39
                                                                                                                                              .
  FRONT PILLAR GARNISH ................................ 33       .        TRUNK ROOM TRIM & TRUNK LID FINISHER ......40                       .
  KICKING PLATE ................................................. 33
                                                                 .         Removal and Installation for Trunk Room Trim ......40              .
  CENTER MUD GUARD FINISHER .................... 33              .           TRUNK ROOM TRIM ..........................................40     .
  DASH SIDE FINISHER ...................................... 33   .           TRUNK LID FINISHER .......................................41     .
REAR PARCEL SHELF FINISHER ......................... 35          .
 Removal and Installation ....................................... 35
                                                                 .
  REMOVAL .......................................................... 35
                                                                 .
  INSTALLATION ................................................... 35
                                                                 .




                                                                      EI-2
                                              PRECAUTIONS

PRECAUTIONS                                                         PFP:00001
                                                                                                                          A
Precautions for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT
BELT PRE-TENSIONER"                                                                                           AIS001AW


The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along                             B
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front               C
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING:                                                                                                                  D
q    To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
     in the event of a collision which would result in air bag inflation, all maintenance must be per-
     formed by an authorized NISSAN/INFINITI dealer.                                                                      E
q    Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
     sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
     Bag Module, see the SRS section.                                                                                     F
q    Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
     Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
     harness connectors.
                                                                                                                          G
Precautions for Battery Service                                                                               AIS002MP


Before disconnecting the battery, lower both the driver and passenger windows. This will prevent any interfer-
ence between the window edge and the vehicle when the door is opened/closed. During normal operation, the                 H
window slightly raises and lowers automatically to prevent any window to vehicle interference. The automatic
window function will not work with the battery disconnected.
                                                                                                                         EI
Precautions for Work                                                                                          AIS001AX


q   After removing and installing the opening/closing parts, be sure to carry out fitting adjustments to check
    their operation.                                                                                                      J
q   Check the lubrication level, damage, and wear of each part. If necessary, grease or replace it.

                                                                                                                          K


                                                                                                                          L



                                                                                                                          M




                                                       EI-3
                                            PREPARATION

PREPARATION                                                                                              PFP:00002

Special Service Tools                                                                                        AIS004Y5


The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
 Tool number
 (Kent-Moore No.)                                                       Description
 Tool name




 (J-39570)
                                                                        Locating the noise
 Chassis ear


                                                      SIIA0993E




 (J-43980)
 NISSAN Squeak and Rattle                                               Repairing the cause of noise
 Kit


                                                      SIIA0994E



Commercial Service Tool                                                                                      AIS004Y6



 Tool name                                                              Description




 Engine ear                                                             Locating the noise



                                                      SIIA0995E




                                                     EI-4
                       SQUEAK AND RATTLE TROUBLE DIAGNOSES

SQUEAK AND RATTLE TROUBLE DIAGNOSES                                                                      PFP:00000
                                                                                                                            A
Work Flow                                                                                                        AIS004Y7




                                                                                                                            B



                                                                                                                            C


                                                                                                                            D


                                                                                                                            E



                                                                                                                            F



                                                                                                        SBT842
                                                                                                                            G

CUSTOMER INTERVIEW
Interview the customer if possible, to determine the conditions that exist when the noise occurs.Use the Diag- H
nostic Worksheet during the interview to document the facts and conditions when the noise occurs and any
customer's comments; refer to EI-9, "Diagnostic Worksheet" . This information is necessary to duplicate the
conditions that exist when the noise occurs.
                                                                                                                      EI
q    The customer may not be able to provide a detailed description or the location of the noise. Attempt to
     obtain all the facts and conditions that exist when the noise occurs (or does not occur).
q    If there is more than one noise in the vehicle, be sure to diagnose and repair the noise that the customer
                                                                                                                       J
     is concerned about. This can be accomplished by test driving the vehicle with the customer.
q    After identifying the type of noise, isolate the noise in terms of its characteristics.The noise characteristics
     are provided so the customer, service adviser and technician are all speaking the same language when
     defining the noise.                                                                                               K
q    Squeak --(Like tennis shoes on a clean floor)
     Squeak characteristics include the light contact/fast movement/brought on by road conditions/hard sur-
     faces=higher pitch noise/softer surfaces=lower pitch noises/edge to surface=chirping                              L
q    Creak--(Like walking on an old wooden floor)
     Creak characteristics include firm contact/slow movement/twisting with a rotational movement/pitch
     dependent on materials/often brought on by activity.                                                              M
q    Rattle--(Like shaking a baby rattle)
     Rattle characteristics include the fast repeated contact/vibration or similar movement/loose parts/missing
     clip or fastener/incorrect clearance.
q    Knock --(Like a knock on a door)
     Knock characteristics include hollow sounding/sometimes repeating/often brought on by driver action.
q    Tick--(Like a clock second hand)
     Tick characteristics include gentle contacting of light materials/loose components/can be caused by driver
     action or road conditions.
q    Thump--(Heavy, muffled knock noise)
     Thump characteristics include softer knock/dead sound often brought on by activity.
q    Buzz--(Like a bumble bee)
     Buzz characteristics include high frequency rattle/firm contact.
q    Often the degree of acceptable noise level will vary depending upon the person. A noise that you may
     judge as acceptable may be very irritating to the customer.
q    Weather conditions, especially humidity and temperature, may have a great effect on noise level.


                                                      EI-5
                       SQUEAK AND RATTLE TROUBLE DIAGNOSES

DUPLICATE THE NOISE AND TEST DRIVE
If possible, drive the vehicle with the customer until the noise is duplicated. Note any additional information on
the Diagnostic Worksheet regarding the conditions or location of the noise. This information can be used to
duplicate the same conditions when you confirm the repair.
If the noise can be duplicated easily during the test drive, to help identify the source of the noise, try to dupli-
cate the noise with the vehicle stopped by doing one or all of the following:
1) Close a door.
2) Tap or push/pull around the area where the noise appears to be coming from.
3) Rev the engine.
4) Use a floor jack to recreate vehicle "twist".
5) At idle, apply engine load (electrical load, half-clutch on M/T model, drive position on A/T model).
6) Raise the vehicle on a hoist and hit a tire with a rubber hammer.
q    Drive the vehicle and attempt to duplicate the conditions the customer states exist when the noise occurs.
q    If it is difficult to duplicate the noise, drive the vehicle slowly on an undulating or rough road to stress the
     vehicle body.
CHECK RELATED SERVICE BULLETINS
After verifying the customer concern or symptom, check ASIST for Technical Service Bulletins (TSBs) related
to that concern or symptom.
If a TSB relates to the symptom, follow the procedure to repair the noise.
LOCATE THE NOISE AND IDENTIFY THE ROOT CAUSE
1.   Narrow down the noise to a general area.To help pinpoint the source of the noise, use a listening tool
     (Chassis Ear: J-39570,Engine Ear and mechanics stethoscope).
2.   Narrow down the noise to a more specific area and identify the cause of the noise by:
q    removing the components in the area that you suspect the noise is coming from.
     Do not use too much force when removing clips and fasteners, otherwise clips and fastener can be broken
     or lost during the repair, resulting in the creation of new noise.
q    tapping or pushing/pulling the component that you suspect is causing the noise.
     Do not tap or push/pull the component with excessive force, otherwise the noise will be eliminated only
     temporarily.
q    feeling for a vibration with your hand by touching the component(s) that you suspect is (are) causing the
     noise.
q    placing a piece of paper between components that you suspect are causing the noise.
q    looking for loose components and contact marks.
     Refer to EI-7, "Generic Squeak and Rattle Troubleshooting" .
REPAIR THE CAUSE
q   If the cause is a loose component, tighten the component securely.
q   If the cause is insufficient clearance between components:



◦ Jabse Service Manual Search 2024 ◦ Jabse PravopisonTap.bg ◦ Other service manual resources online : FixyaeServiceinfo
