Image preview - the first page of the document
>> Download fax documenatation <<
Text preview - extract from the document
FRONT AXLE
D DRIVELINE/AXLE
A
SECTION FAX FRONT AXLE
B
C
FAX
E
CONTENTS
PREPARATION .......................................................... 2
. WHEEL BEARING INSPECTION ........................ 4 . F
Special Service Tools (SST) .................................... 2
. Removal and Installation ......................................... 4
.
Commercial Service Tools ....................................... 2
. REMOVAL ............................................................ 4
.
NOISE, VIBRATION AND HARSHNESS (NVH) INSPECTION AFTER REMOVAL ........................ 5 . G
TROUBLESHOOTING ............................................... 3. INSTALLATION .................................................... 6
.
NVH Troubleshooting Chart .................................... 3. SERVICE DATA ......................................................... 7
.
FRONT WHEEL HUB AND KNUCKLE ..................... 4 . Wheel Bearing ......................................................... 7
.
H
On-Vehicle Inspection and Service ......................... 4 . BALL JOINT ......................................................... 7
.
I
J
K
L
M
FAX-1
PREPARATION
PREPARATION PFP:00002
Special Service Tools (SST) ADS00098
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Tool number
(Kent-Moore No.) Description
Tool name
HT72520000
(J25730-A)
Ball joint remover
Removing steering outer socket
a: 33 mm (1.30 in)
b: 50 mm (1.97 in)
r: 11.5 mm (0.453 in)
NT546
ST3127S000
(See J25742-1)
Preload Gauge
1. GG91030000
Torque wrench (J25765) Measuring rotating torque of ball joint
2. HT62940000 ( -- )
Socket adapter (1/2)
3. HT62900000 ( -- )
NT124
Socket adapter (3/8)
Commercial Service Tools ADS00099
Tool name Description
q Removing wheel nuts
Power tool q Removing undercover
q Removing brake caliper assembly
PBIC0190E
FAX-2
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING PFP:00003
A
NVH Troubleshooting Chart ADS0009A
Use chart below to help you find the cause of the symptom. If necessary, repair or replace these parts.
B
NVH in WT section.
NVH in WT section.
NVH in PS section.
FAX-4
FAX-4
--
Reference page C
FAX
Improper installation, looseness
Wheel bearing damage
E
Parts interference
Possible cause and SUSPECTED PARTS
ROAD WHEEL
F
STEERING
TIRES
G
