Image preview - the first page of the document



>> Download pr documenatation <<

Text preview - extract from the document

PROPELLER SHAFT


D DRIVELINE/AXLE

                                                                                                                                                        A




                                                                                            SECTION
                                                                                        PROPELLER SHAFT
                                                                                                                      PR                                B



                                                                                                                                                        C


                                                                                                                                                        PR


                                                                                                                                                        E
                                                            CONTENTS
PREPARATION .......................................................... 2
                                                                 .            REMOVAL ............................................................ 5
                                                                                                                                              .         F
 Special Service Tools .............................................. 2
                                                                 .            INSTALLATION .................................................... 5
                                                                                                                                              .
 Commercial Service Tools ....................................... 2
                                                                 .            INSPECTION ....................................................... 6
                                                                                                                                              .
NOISE, VIBRATION AND HARSHNESS (NVH)                                        Disassembly and Assembly ..................................... 7  .         G
TROUBLESHOOTING ............................................... 3.            DISASSEMBLY .................................................... 7
                                                                                                                                              .
 NVH Troubleshooting Chart .................................... 3.            ASSEMBLY .......................................................... 8
                                                                                                                                              .
REAR PROPELLER SHAFT ..................................... 4     .         SERVICE DATA ......................................................... 9
                                                                                                                                              .
                                                                                                                                                        H
 On-Vehicle Service .................................................. 4
                                                                 .          General Specifications ............................................. 9
                                                                                                                                              .
   PROPELLER SHAFT VIBRATION ....................... 4           .          Journal Axial Play .................................................... 9
                                                                                                                                              .
   APPEARANCE CHECKING ................................. 4       .          Propeller Shaft Runout Limit .................................... 9
                                                                                                                                              .
 Removal and Installation ......................................... 4
                                                                 .                                                                                       I


                                                                                                                                                        J



                                                                                                                                                        K


                                                                                                                                                        L



                                                                                                                                                        M




                                                                      PR-1
                                              PREPARATION

PREPARATION                                                                                                   PFP:00002

Special Service Tools                                                                                             ADS000CY


The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
    Tool name
                                                                        Description
     Tool number (Kent-Moore No.)

    ST38060002 (J34311)                                                 Removing and installing propeller shaft lock
    Companion flange wrench                                             nut




                                                           NT113


    Drift pinion rear inner race puller set                             Remove center bearing
    1.ST30031000 (J22912
