Image preview - the first page of the document
>> Download ww documenatation <<Text preview - extract from the documentWIPER, WASHER & HORN
K ELECTRICAL
A
SECTION
WIPER, WASHER & HORN
WW B
C
D
E
CONTENTS
PRECAUTION ........................................................... 3 . Only Front Wiper LO Does Not Operate ................ 25 . F
Precautions for Supplemental Restraint System Only Front Wiper HI Does Not Operate ................. 26 .
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN- Only Front Wiper INT Does Not Operate ............... 27 .
SIONER" ................................................................. 3
. Front Wiper Interval Time Is Not Controlled by Vehi- G
Precautions for Battery Service ............................... 3 . cle Speed ............................................................... 27
.
Wiring Diagrams and Trouble Diagnosis ................. 3 . Front Wiper Intermittent Operation Switch Position
FRONT WIPER AND WASHER SYSTEM ................. 4 . Cannot Be Adjusted ............................................... 27 .
H
Components Parts and Harness Connector Loca- Wipers Do Not Wipe When Front Washer Operates 27 ...
tion .......................................................................... 4
. After Front Wipers Operate for 10 Seconds, They
System Description ................................................. 4 . Stop for 20 Seconds, and After Repeating the Oper-
LOW SPEED WIPER OPERATION ..................... 5 . ations Five Times, They Become Inoperative ....... 28 . I
HI SPEED WIPER OPERATION .......................... 5 . Front Wipers Do Not Stop ...................................... 29 .
INTERMITTENT OPERATION ............................. 5 . Removal and Installation of Front Wiper Arms,
AUTO STOP OPERATION ................................... 6 . Adjustment of Wiper Arms Stop Location .............. 30 . J
WASHER OPERATION ........................................ 6 . REMOVAL .......................................................... 30 .
MIST OPERATION ............................................... 6 . INSTALLATION .................................................. 30 .
FAIL-SAFE FUNCTION ........................................ 7 . ADJUSTMENT ................................................... 30 .
WW
COMBINATION SWITCH READING FUNCTION 7 ..... Removal and Installation of Front Wiper Motor and
CAN Communication System Description ............... 9 . Linkage .................................................................. 30
.
CAN Communication Unit ....................................... 9 . REMOVAL .......................................................... 30 .
Schematic ............................................................. 10. INSTALLATION .................................................. 31 . L
Wiring Diagram -- WIPER -- ................................11 . Disassembly and Assembly of Front Wiper Motor
Terminals and Reference Values for BCM ............ 14 . and Linkage ........................................................... 31
.
Terminals and Reference Values for IPDM E/R .... 15 . DISASSEMBLY .................................................. 31 . M
How to Proceed With Trouble Diagnosis ............... 15 . ASSEMBLY ........................................................ 31 .
Preliminary Check ................................................. 15 . Washer Nozzle Adjustment ................................... 32 .
CHECK POWER SUPPLY AND GROUND CIR- Washer Tube Layout ............................................. 33 .
CUIT ................................................................... 15
. Removal and Installation of Front Washer Nozzle... 33
CONSULT-II Functions (BCM) .............................. 17 . Removal and Installation of Front Washer Joint .... 33 .
CONSULT-II OPERATION ................................. 17 . Inspection of Check Valve ..................................... 33 .
DATA MONITOR ................................................ 18 . Removal and Installation of Front Wiper and Washer
ACTIVE TEST .................................................... 19 . Switch .................................................................... 33
.
CONSULT-II Functions (IPDM E/R) ...................... 19 . Removal and Installation of Washer Tank ............. 34 .
CONSULT-II OPERATION ................................. 19 . REMOVAL .......................................................... 34 .
SELF-DIAG RESULTS ....................................... 20 . INSTALLATION .................................................. 34 .
DATA MONITOR ................................................ 20 . Removal and Installation of Washer Pump ............ 34 .
ACTIVE TEST .................................................... 21 . REMOVAL .......................................................... 34 .
Front Wiper Does Not Operate ............................. 21 . INSTALLATION .................................................. 35 .
Front Wiper Does Not Return to Stop Position ...... 24 . CIGARETTE LIGHTER ............................................ 36 .
WW-1
Wiring Diagram -- CIGAR -- ................................ 36 . INSTALLATION ...................................................39 .
Removal and Installation of Cigarette Lighter ........ 37 . Removal and Installation of Console Power Socket
REMOVAL .......................................................... 37 . (A/T) .......................................................................39
.
INSTALLATION ................................................... 37 . REMOVAL ...........................................................39 .
POWER SOCKET .................................................... 38 . INSTALLTION .....................................................39 .
Wiring Diagram -- P/SCKT -- ............................... 38 . HORN .......................................................................40
.
Removal and Installation of Instrument Power Wiring Diagram -- HORN -- .................................40 .
Socket .................................................................... 39
. Removal and Installation ........................................41 .
REMOVAL .......................................................... 39 . REMOVAL ...........................................................41 .
INSTALLATION ...................................................41 .
WW-2
PRECAUTION
PRECAUTION PFP:00011
A
Precautions for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT
BELT PRE-TENSIONER" AKS00AIK
The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along B
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front C
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING: D
q To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer. E
q Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section. F
q Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
G
Precautions for Battery Service AKS00B6J
Before disconnecting the battery, lower both the driver and passenger windows. This will prevent any interfer-
ence between the window edge and the vehicle when the door is opened/closed. During normal operation, the H
window slightly raises and lowers automatically to prevent any window to vehicle interference. The automatic
window function will not work with the battery disconnected.
I
Wiring Diagrams and Trouble Diagnosis AKS00AIM
When You Read Wiring Diagrams, Refer to the Following:
q Refer to GI-15, "How to Read Wiring Diagrams" . J
q Refer to PG-4, "POWER SUPPLY ROUTING CIRCUIT" for power distribution circuit.
When You Perform Trouble Diagnosis, Refer to the Following:
q Refer to GI-11, "How to Follow Trouble Diagnoses" . WW
q Refer to GI-27, "How to Perform Efficient Diagnosis for an Electrical Incident" .
L
M
WW-3
FRONT WIPER AND WASHER SYSTEM
FRONT WIPER AND WASHER SYSTEM PFP:28810
Components Parts and Harness Connector Location AKS009YC
PKIA4937E
System Description AKS009YD
q All front wiper relays (HI, LO) are included in IPDM E/R (intelligent power distribution module engine
room).
q Wiper switch (combination switch) is composed of a combination of 5 output terminals and 5 input termi-
nals. Terminal combination status is read by BCM when switch is turned ON.
q BCM (body control module) controls front wiper LO, HI, and INT (intermittent) operation.
q IPDM E/R (intelligent power distribution module engine room) operates wiper motor according to CAN
communication signals from BCM (body control module).
Power is supplied at all times
q through 50 A fusible link (letter F, located in fusible link block)
q to BCM (body control module) terminal 55
q through 10 A fuse [No. 18, located in fuse block (J/B)]
q to BCM (body control module) terminal 42
q through 20 A fuse [No. 73, located in IPDM E/R (intelligent power distribution module engine room)]
q to front wiper relay [located in IPDM E/R (intelligent power distribution module engine room)]
q through 15 A fuse [No. 78, located in IPDM E/R (intelligent power distribution module engine room)]
q to CPU (central processing unit) [located in IPDM E/R (intelligent power distribution module engine room)]
q through 10 A fuse [No. 71, located in IPDM E/R (intelligent power distribution module engine room)]
q to CPU (central processing unit) [located in IPDM E/R (intelligent power distribution module engine
room)].
WW-4
FRONT WIPER AND WASHER SYSTEM
When the ignition switch ON or START position, power is supplied
q through 10 A fuse [No. 1, located in fuse block (J/B)] A
q to BCM (body control module) terminal 38
q through ignition relay [located in IPDM E/R (intelligent power distribution module engine room)]
B
q to front wiper relay [located in IPDM E/R (intelligent power distribution module engine room)] and
q to front wiper high relay [located in IPDM E/R (intelligent power distribution module engine room)]
q through 10 A fuse [No. 84, located in IPDM E/R (intelligent power distribution module engine room)] and C
q through IPDM E/R (intelligent power distribution module engine room) terminal 44
q to front washer motor terminal 2.
Ground is supplied D
q to BCM (body control module) terminal 52
q through grounds M30 and M66,
q to IPDM E/R (intelligent power distribution module engine room) terminals 38 and 60 E
q through grounds E17and E43,
q to combination switch (wiper switch) terminal 12
F
q through grounds M30 and M66.
LOW SPEED WIPER OPERATION
When wiper switch is in LO position, BCM detects low speed wiper ON signal by BCM wiper switch reading G
function.
BCM sends front wiper request signal (LO) with CAN communication line
q from BCM terminals 39 and 40 H
q to IPDM E/R terminals 48 and 49.
When IPDM E/R receives front wiper request signal (LO), it turns ON front wiper relay (located in IPDM E/R),
power is supplied I
q to front wiper motor terminal 3
q through IPDM E/R terminal 21 and front wiper relay and front wiper HI relay.
Ground is supplied J
q to front wiper motor terminal 4
q through grounds E17 and E43.
WW
With power and ground supplied, the front wiper motor operates at low speed.
HI SPEED WIPER OPERATION
When wiper switch is in HI position, BCM detects high speed wiper ON signal by BCM wiper switch reading L
function.
BCM sends front wiper request signal (HI) with CAN communication line
q from BCM terminals 39 and 40 M
q to IPDM E/R terminals 48 and 49.
When IPDM E/R receives front wiper request signal (HI), it turns ON front wiper relay (located in IPDM E/R),
power is supplied
q to front wiper motor terminal 2
q through IPDM E/R terminal 31 and front wiper relay and front wiper HI relay.
Ground is supplied
q to front wiper motor terminal 4
q through grounds E17 and E43.
With power and ground supplied, the front wiper motor operates at high speed.
INTERMITTENT OPERATION
Wiper intermittent operation delay interval is determined from a combination of 3 switches (intermittent opera-
tion dial position 1, intermittent operation dial position 2, and intermittent operation dial position 3) and vehicle
speed signal.
During each intermittent operation delay interval, BCM sends front wiper request signal to IPDM E/R.
WW-5
FRONT WIPER AND WASHER SYSTEM
Wiper Dial Position Setting
Combination switch
Intermittent operation
Wiper dial position Intermittent operation Intermittent operation Intermittent operation
interval
dial position 1 dial position 2 dial position 3
Wiper dial position 1 ON ON ON
Small
Wiper dial position 2 ON ON OFF
Wiper dial position 3 ON OFF OFF
Wiper dial position 4 OFF OFF OFF
Wiper dial position 5 OFF OFF ON
Wiper dial position 6 OFF ON ON
Large
Wiper dial position 7 OFF ON OFF
Example: For wiper dial position 1...
Using combination switch reading function, BCM detects ON/OFF status of intermittent operation dial posi-
tions 1, 2, and 3.
When combination switch status is as listed below, BCM determines that it is wiper dial position 1.
q Intermittent operation dial position 1: ON (Combination switch output 3 and input 1 are performing.)
q Intermittent operation dial position 2: ON (Combination switch output 5 and input 1 are performing.)
q Intermittent operation dial position 3: ON (Combination switch output 4 and output 2 are performing.)
BCM determines front wiper intermittent operation delay interval from wiper dial position 1 and vehicle speed,
and sends wiper request signal (INT) to IPDM E/R.
AUTO STOP OPERATION
With wiper switch turned OFF, wiper motor will continue to operate until wiper arms reach windshield base.
When wiper arms are not located at base of windshield with wiper switch OFF, ground is provided
q from IPDM E/R terminal 21
q to front wiper motor terminal 3, in order to continue wiper motor operation at low speed.
When wiper arms reach base of windshield, front wiper motor terminals 1 and 4 are connected,
and ground is supplied
q to IPDM E/R terminal 32
q through front wiper motor terminals 1 and 4
q through grounds E17 and E43.
Then the IPDM E/R sends auto stop operation signal to BCM with CAN communication line.
When BCM receives auto-stop operation signal, BCM sends wiper stop signal to IPDM E/R with CAN commu-
nication line.
IPDM E/R stops wiper motor. Wiper motor will then stop wiper arms at the STOP position.
WASHER OPERATION
When wiper switch is in front wiper washer position with ignition switch ON, BCM detects front wiper switch is
on the washer position by BCM wiper switch reading function (Refer to WW-7, "COMBINATION SWITCH
READING FUNCTION" ).
Combination switch (wiper switch) ground is supplied
q to front washer motor terminal 1
q through combination switch (wiper switch) terminal 11
q to combination switch (wiper switch) terminal 12
q through grounds M30 and M66.
With ground supplied, front washer motor is operated.
When BCM detects that front washer motor has operated for 0.4 seconds or linger, BCM operates front wiper
motor for low speed.
When BCM detects washer switch is OFF, low speed operation cycles approximately 3 times and stops.
MIST OPERATION
When the wiper switch is turned to the MIST position, wiper low speed operation cycles once and then stops.
For additional information about wiper operation under this condition, refer to WW-5, "LOW SPEED WIPER
OPERATION" .
WW-6
FRONT WIPER AND WASHER SYSTEM
If the switch is held in the MIST position, low speed operation continues.
A
FAIL-SAFE FUNCTION
IPDM E/R includes a fail-safe function to prevent malfunction of electrical components controlled by CAN com-
munications in CAN communications occurs.
When fail-safe status is initiated, IPDM E/R remains in steady unit signals are received. B
COMBINATION SWITCH READING FUNCTION
Description C
q BCM reads combination switch (wiper) status, and controls related systems such as head lamps and wip-
ers, according to the results.
q BCM reads information of a maximum of 20 switches by combining five output terminals (OUTPUT 1-5) D
and five input terminals (INPUT 1-5).
Operation Description
q BCM activates transistors of output terminals (OUTPUT 1-5) periodically, and allows current to flow in E
turn.
q If any (1 or more) switches are turned ON, circuit of output terminals (OUTPUT 1-5) and input terminals
(INPUT 1-5) becomes active. F
q At this time, transistors of output terminals (OUTPUT 1-5) are activated to allow current to flow. When volt-
age of input terminals (INPUT 1-5) corresponding to that switch changes, interface in BCM detects volt-
age change, and BCM determines that switch is ON. G
H
I
J
WW
L
M
SKIA8639E
WW-7
FRONT WIPER AND WASHER SYSTEM
BCM - Operation Table of Combination Switches
q BCM reads operation status of combination switch using combinations shown in table below.
SKIA8640E
Sample Operation: (When Wiper Switch Turned ON)
q When wiper switch is turned ON, contact in combination switch turns ON. At this time if OUTPUT 1 tran-
sistor is activated, BCM detects that voltage changes in INPUT 3.
q When OUTPUT 1 transistor is ON, BCM detects that voltage changes in INPUT 3, and judges that front
wiper low is ON. Then BCM sends front wiper request signal (LO) to IPDM E/R using CAN communica-
tion.
q When OUTPUT 1 transistor is activated again, BCM detects that voltage changes in INPUT 3, and recog-
nizes that wiper switch is continuously ON.
PKIA4848E
WW-8
FRONT WIPER AND WASHER SYSTEM
NOTE:
Each OUTPUT terminal transistor is activated at 10 ms intervals. Therefore after switch is turned ON, electri- A
cal loads are activated with time delay. But this time delay is so short that it cannot be detected by human
senses.
Operation Mode B
Combination switch reading function has operation modes shown below.
1. Normal status
q When BCM is not in sleep status, OUTPUT terminals (1-5) each turn ON-OFF every 10 ms.
C
2. Sleep status
q When BCM is in sleep status, transistors of OUTPUT (1 and 5) stop the output, and BCM enters low
D
current consumption mode. OUTPUT (2, 3, and 4) turn ON-OFF every 10 ms, and only input from light
switch system is accepted.
E
F
G
H
I
J
WW
L
SKIA4961E
M
CAN Communication System Description AKS009YE
CAN (Controller Area Network) is a serial communication line for real time application. It is an on-board multi-
plex communication line with high data communication speed and excellent error detection ability. Many elec-
tronic control units are equipped onto a vehicle, and each control unit shares information and links with other
control units during operation (not independent). In CAN communication, control units are connected with 2
communication lines (CAN H line, CAN L line) allowing a high rate of information transmission with less wiring.
Each control unit transmits/receives data but selectively reads required data only.
CAN Communication Unit AKS009YF
Refer to LAN-4, "CAN Communication Unit" .
WW-9
FRONT WIPER AND WASHER SYSTEM
Schematic AKS009YG
TKWM0906E
WW-10
FRONT WIPER AND WASHER SYSTEM
Wiring Diagram -- WIPER -- AKS009YH
A
B
C
D
E
F
G
H
I
J
WW
L
M
TKWM0907E
WW-11
FRONT WIPER AND WASHER SYSTEM
TKWM0908E
WW-12
FRONT WIPER AND WASHER SYSTEM
A
B
C
D
E
F
G
H
I
J
WW
L
M
TKWM0909E
WW-13
FRONT WIPER AND WASHER SYSTEM
Terminals and Reference Values for BCM AKS009YI
Measuring condition
Terminal No.
Signal name Ignition Reference value
(Wire color) Operation or condition
switch
q Lighting switch and wiper switch
2 (G/R) Combination switch input 5 ON OFF
q Wiper dial position 4
SKIA5291E
q Lighting switch and wiper switch
3 (G) Combination switch input 4 ON OFF
q Wiper dial position 4
SKIA5292E
q Lighting switch and wiper switch
4 (W/L) Combination switch input 3 ON OFF
q Wiper dial position 4
SKIA5291E
5 (W/G) Combination switch input 2 ON
q Lighting switch and wiper switch
OFF
6 (W/R) Combination switch input 1 ON
q Wiper dial position 4
SKIA5292E
q Lighting switch and wiper switch
32 (GY) Combination switch output 5 ON OFF
q Wiper dial position 4
SKIA5291E
q Lighting switch and wiper switch
33 (L) Combination switch output 4 ON OFF
q Wiper dial position 4
SKIA5292E
q Lighting switch and wiper switch
34 (PU) Combination switch output 3 ON OFF
q Wiper dial position 4
SKIA5291E
WW-14
FRONT WIPER AND WASHER SYSTEM
Measuring condition
Terminal No. A
Signal name Ignition Reference value
(Wire color) Operation or condition
switch
35 (Y/R) Combination switch output 2
B
q Lighting switch and wiper switch
ON OFF
36 (Y) Combination switch output 1 C
q Wiper dial position 4
SKIA5292E
38 (W/L) Ignition switch (ON) ON -- Battery voltage D
39 (L) CAN H -- -- --
40 (R) CAN L -- -- --
E
42 (G/Y) Battery power supply OFF -- Battery voltage
52 (B) Ground ON -- Approx. 0 V
55 (W/R) Battery power supply OFF -- Battery voltage F
Terminals and Reference Values for IPDM E/R AKS009YJ
Terminal No. Measuring condition G
Signal name Reference value
(Wire color) Ignition switch Operation or condition
OFF Approx. 0 V
21 (PU) Low speed signal ON Wiper switch H
LO Battery voltage
OFF Approx. 0 V
31 (L/B) High speed signal ON Wiper switch
HI Battery voltage I
Wiper operating Battery voltage
32 (L/Y) Wiper auto - stop signal ON
Wiper stopped Approx. 0 V
38 (B) Ground ON -- Approx. 0 V
J
44 (OR) Washer motor power supply ON -- Battery voltage
48 (L) CAN H -- -- --
WW
49 (R) CAN L -- -- --
60 (B) Ground ON -- Approx. 0 V
L
How to Proceed With Trouble Diagnosis AKS009YK
1. Confirm the symptoms and customer complaint.
2. Understand operation description and function description. Refer to WW-4, "System Description" . M
3. Perform the preliminary check. Refer to WW-15, "Preliminary Check" .
4. Check symptom and repair or replace the cause of malfunction.
5. Does the front wiper and washer operate normally? If YES, GO TO 6. If NO, GO TO 4.
6. INSPECTION END
Preliminary Check AKS009YL
CHECK POWER SUPPLY AND GROUND CIRCUIT
Inspection Procedure
1. CHECK FUSE
q Check if wiper and washer fuse is blown.
Unit Power source Fuse and fusible link No.
Front washer motor Ignition switch ON or START 84
Front wiper motor, front wiper relay, front wiper HI relay Battery 73
WW-15
FRONT WIPER AND WASHER SYSTEM
Unit Power source Fuse and fusible link No.
F
Battery
BCM 18
Ignition switch ON or START 1
Refer to WW-11, "Wiring Diagram -- WIPER --" .
OK or NG
OK >> GO TO 2.
NG >> If fuse is blown, be sure to eliminate cause of malfunction before installing new fuse. Refer to PG-
4, "POWER SUPPLY ROUTING CIRCUIT" .
2. CHECK POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect BCM connector.
3. Check voltage between BCM harness connector terminal and
ground.
Terminals Ignition switch position
(+)
(-) OFF ON
Connector Terminal (Wire color)
M2 42 (GY) Battery voltage Battery voltage
M2 55 (W/R) Ground Battery voltage Battery voltage SKIA9169E
M1 38 (W/L) 0V Battery voltage
OK or NG
OK >> GO TO 3.
NG >> Check harness for open or short between fuse, fusible link and BCM.
3. CHECK GROUND CIRCUIT
Check continuity between BCM harness connector and ground.
Terminals
Continuity
Connector Terminal (Wire color)
M2 52 (B) Ground Yes
OK or NG
OK >> INSPECTION END
NG >> Repair harness or connector.
PKIA4851E
WW-16
FRONT WIPER AND WASHER SYSTEM
CONSULT-II Functions (BCM) AKS009YM
A
CONSULT-II performs the following functions communicating with BCM.
BCM diagnosis position Check item, Diagnosis mode Description
DATA MONITOR Displays BCM input data in real time. B
Wiper
ACTIVE TEST Device operation can be checked by applying a drive signal to device.
BCM CAN DIAG SUPPORT MNTR The result of transmit/receive diagnosis of CAN communication can be read.
C
CONSULT-II OPERATION
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be D
detected in self-diagnosis depending on control unit which carry out CAN communication.
1. With the ignition switch OFF, connect CONSULT-II and CON-
SULT-II CONVERTER to the data link connector, then turn the E
ignition switch ON.
F
G
PIIA1095E
H
2. Touch "START (NISSAN BASED VHCL)".
I
J
WW
SKIA3098E
3. Touch "BCM" on "SELECT SYSTEM" screen. L
If "BCM" is not indicated, refer to GI-39, "CONSULT-II Data Link
Connector (DLC) Circuit" .
M
PKIA4849E
WW-17
FRONT WIPER AND WASHER SYSTEM
4. Touch "WIPER".
PKIA6100E
DATA MONITOR
Operation Procedure
1. Touch "WIPER" on "SELECT TEST ITEM" screen.
2. Touch "DATA MONITOR" on "SELECT DIAG MODE" screen.
3. Touch either "ALL SIGNALS" or "SELECT FROM MENU" on "DATA MONITOR" screen.
ALL SIGNALS Monitors all the signals.
SELECTION FROM MENU Selects and monitors individual signal.
4. Touch "START".
5. When "SELECTION FROM MENU" is selected, touched items to be monitored. If "ALL SIGNALS" is
selected, all items will be monitored.
6. Touch "RECORDING START" while monitoring to record the status of the item being monitored. To stop
recording, touch "RECORDING STOP".
Display Item List
Monitor item [operation or unit] Display content
Displays "ignition switch ON (ON)/Other OFF or ACC (OFF)" status as judged from ignition
IGN ON SW [ON/OFF]
switch signal.
Displays "ignition switch ON (ON)/Other OFF or ACC (OFF)" status as judged from CAN commu-
IGN SW CAN [ON/OFF]
nication signal.
FR WIPER HI [ON/OFF] Displays "FRONT WIPER HI (ON)/Other (OFF)" status as judged from wiper switch signal.
FR WIPER LOW [ON/OFF] Displays "FRONT WIPER LOW (ON)/Other (OFF)" status as judged from wiper switch signal.
FR WIPER INT [ON/OFF] Displays "FRONT WIPER INT (ON)/Other (OFF)" status as judged from wiper switch signal.
FR WASHER SW [ON/OFF] Displays "FRONT WASHER Switch (ON)/Other (OFF)" status as judged from wiper switch signal.
INT VOLUME [1 - 7] Displays intermittent operation dial position setting (1 - 7) as judged from wiper switch signal.
FR WIPER STOP [ON/OFF] Displays "Stopped (ON)/Operating (OFF)" status as judged from the auto-stop signal.
VEHICLE SPEED [km/h] Displays vehicle speed status as judged from vehicle speed signal.
RR WIPER ONNOTE [ON/OFF] --
RR WIPER INTNOTE [ON/OFF] --
NOTE [ON/OFF] --
RR WASHER SW
RR WIPER STOPNOTE [ON/OFF] --
NOTE:
This item is displayed, but cannot monitor it.
WW-18
FRONT WIPER AND WASHER SYSTEM
ACTIVE TEST
Operation Procedure A
1. Touch "WIPER" on the "SELECT TEST ITEM" screen.
2. Touch "ACTIVE TEST" on "SELECT DIAG MODE" screen.
B
3. Touch items to be tested, and check operation.
4. During operation check, touching "STOP" deactivates operation.
Display Item List C
Indication on
Test item Description
CONSULT-II display
Front wiper output FR WIPER With a certain operation (OFF, HI, LO, INT), the front wiper can be operated. D
Rear wiper output NOTE RR WIPER --
NOTE:
E
This item is displayed, but cannot test it.
CONSULT-II Functions (IPDM E/R) AKS009YN
CONSULT-II performs the following functions communicating with IPDM E/R. F
Check Item, Diagnosis Mode Description
SELF-DIAG RESULTS The IPDM E/R performs diagnosis of the CAN communication and self-diagnosis.
G
DATA MONITOR The input/output data of the IPDM E/R is displayed in real time.
CAN DIAG SUPPORT MNTR The result of transmit/receive diagnosis of CAN communication can be read.
ACTIVE TEST The IPDM E/R sends a drive signal to electronic components to check their operation. H
CONSULT-II OPERATION
CAUTION: I
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detected in self-diagnosis depending on control unit which carry out CAN communication.
1. With the ignition switch OFF, connect CONSULT-II and CON- J
SULT-II CONVERTER to the data link connector, then turn the
ignition switch ON.
WW
L
PIIA1095E M
2. Touch "START (NISSAN BASED VHCL)".
SKIA3098E
WW-19
FRONT WIPER AND WASHER SYSTEM
3. Touch "IPDM E/R" on "SELECT SYSTEM" screen.
If "IPDM E/R" is not displayed, print "SELECT SYSTEM" screen,
then refer to GI-39, "CONSULT-II Data Link Connector (DLC)
Circuit" .
PKIA4849E
4. Select the desired part to be diagnosed on the "SELECT DIAG
MODE" screen.
PKIA6016E
SELF-DIAG RESULTS
Refer to PG-20, "SELF-DIAG RESULTS" .
DATA MONITOR
Operation Procedure
1. Touch "DATA MONITOR" on "SELECT DIAG MODE " screen.
2. Touch "ALL SIGNALS", "MAIN SIGNALS" or "SELECTION FROM MENU" on "DATA MONITOR" screen.
ALL SIGNALS All items will be monitored.
MAIN SIGNALS Monitor the predetermined item.
SELECTION FROM MENU Select any item for monitoring.
3. Touch "START".
4. Touch the required monitoring item on "SELECTION FROM MENU". In "ALL SIGNALS", all items are
monitored. In "MAIN SIGNALS", predetermined items are monitored.
5. Touch "RECORD" while monitoring to record the status of the item being monitored. To stop recording,
touch "STOP".
All Signals, Main Signals, Selection From Menu
Monitor item selection
CONSULT-II SELECTION
Item name Display or unit ALL MAIN Description
screen display FROM
SIGNALS SIGNALS
MENU
FR wiper request FR WIP REQ STOP/1LOW/LOW/HI
◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
