Image preview - the first page of the document
ww


>> Download ww documenatation <<

Text preview - extract from the document
WIPER, WASHER & HORN


K ELECTRICAL

                                                                                                                                                                       A




                                                                                           SECTION
                                                                                     WIPER, WASHER & HORN
                                                                                                                      WW                                               B



                                                                                                                                                                       C


                                                                                                                                                                       D


                                                                                                                                                                       E
                                                                    CONTENTS
PRECAUTION ........................................................... 3   .          Only Front Wiper HI Does Not Operate ................. 26               .        F
 Precautions for Supplemental Restraint System                                        Only Front Wiper INT Does Not Operate ............... 27                .
 (SRS) "AIR BAG" and "SEAT BELT PRE-TEN-                                              Front Wiper Interval Time Is Not Controlled by Vehi-
 SIONER" ................................................................. 3
                                                                           .          cle Speed ............................................................... 27
                                                                                                                                                              .        G
 Precautions for Battery Service ............................... 3         .          Front Wiper Intermittent Operation Switch Position
 Wiring Diagrams and Trouble Diagnosis ................. 3                 .          Cannot Be Adjusted ............................................... 27   .
FRONT WIPER AND WASHER SYSTEM ................. 4                          .          Wipers Do Not Wipe When Front Washer Operates 27                        ...
                                                                                                                                                                       H
 Components Parts and Harness Connector Loca-                                         After Front Wipers Operate for 10 Seconds, They
 tion .......................................................................... 4
                                                                           .          Stop for 20 Seconds, and After Repeating the Oper-
 System Description ................................................. 4    .          ations Five Times, They Become Inoperative ....... 28                   .
    LOW SPEED WIPER OPERATION ..................... 5                      .          Front Wipers Do Not Stop ...................................... 29      .        I
    HI SPEED WIPER OPERATION .......................... 5                  .          Removal and Installation of Front Wiper Arms,
    INTERMITTENT OPERATION ............................. 5                 .          Adjustment of Wiper Arms Stop Location .............. 30                .
    AUTO STOP OPERATION ................................... 6              .            REMOVAL .......................................................... 30 .        J
    WASHER OPERATION ........................................ 6            .            INSTALLATION .................................................. 30    .
    MIST OPERATION ............................................... 6       .            ADJUSTMENT ................................................... 30     .
    FAIL-SAFE FUNCTION ........................................ 7          .          Removal and Installation of Front Wiper Motor and
                                                                                                                                                                       WW
    COMBINATION SWITCH READING FUNCTION 7                                  .....      Linkage .................................................................. 30
                                                                                                                                                              .
 CAN Communication System Description ............... 9                    .            REMOVAL .......................................................... 30 .
 CAN Communication Unit ....................................... 9          .            INSTALLATION .................................................. 31    .
 Schematic ............................................................. 10.          Disassembly and Assembly of Front Wiper Motor                                    L
 Wiring Diagram -- WIPER -- ................................11             .          and Linkage ........................................................... 31
                                                                                                                                                              .
 Terminals and Reference Values for BCM ............ 14                    .            DISASSEMBLY .................................................. 31     .
 Terminals and Reference Values for IPDM E/R .... 15                       .            ASSEMBLY ........................................................ 31  .        M
 How to Proceed With Trouble Diagnosis ............... 15                  .          Washer Nozzle Adjustment ................................... 32         .
 Preliminary Check ................................................. 15    .          Washer Tube Layout ............................................. 33     .
    CHECK POWER SUPPLY AND GROUND CIR-                                                Removal and Installation of Front Washer Nozzle... 33
    CUIT ................................................................... 15
                                                                           .          Removal and Installation of Front Washer Joint .... 33                  .
 CONSULT-II Functions (BCM) .............................. 17              .            REMOVAL .......................................................... 33 .
    CONSULT-II OPERATION ................................. 17              .            INSTALLATION .................................................. 33    .
    DATA MONITOR ................................................ 18       .          Inspection of Check Valve ..................................... 33      .
    ACTIVE TEST .................................................... 19    .          Removal and Installation of Front Wiper and Washer
 CONSULT-II Functions (IPDM E/R) ...................... 19                 .          Switch .................................................................... 34
                                                                                                                                                              .
    CONSULT-II OPERATION ................................. 19              .          Removal and Installation of Washer Tank ............. 34                .
    SELF-DIAG RESULTS ....................................... 20           .            REMOVAL .......................................................... 34 .
    DATA MONITOR ................................................ 20       .            INSTALLATION .................................................. 34    .
    ACTIVE TEST .................................................... 21    .          Removal and Installation of Washer Pump ............ 35                 .
 Front Wiper Does Not Operate ............................. 21             .            REMOVAL .......................................................... 35 .
 Front Wiper Does Not Return to Stop Position ...... 24                    .            INSTALLATION .................................................. 35    .
 Only Front Wiper LO Does Not Operate ............... 25                   .         CIGARETTE LIGHTER ............................................ 36        .


                                                                              WW-1
 Wiring Diagram -- CIGAR -- ................................ 36          .           INSTALLATION ...................................................39      .
 Removal and Installation of Cigarette Lighter ........ 37               .         Removal and Installation of Console Power Socket
  REMOVAL .......................................................... 37  .         (A/T) .......................................................................39
                                                                                                                                                             .
  INSTALLATION ................................................... 37    .           REMOVAL ...........................................................39   .
POWER SOCKET .................................................... 38     .           INSTALLTION .....................................................39     .
 Wiring Diagram -- P/SCKT -- ............................... 38          .        HORN .......................................................................40
                                                                                                                                                             .
 Removal and Installation of Instrument Power                                      Wiring Diagram -- HORN -- .................................40             .
 Socket .................................................................... 39
                                                                         .         Removal and Installation ........................................41       .
  REMOVAL .......................................................... 39  .           REMOVAL ...........................................................41   .
                                                                                     INSTALLATION ...................................................41      .




                                                                            WW-2
                                               PRECAUTION

PRECAUTION                                                          PFP:00011
                                                                                                                         A
Precautions for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT
BELT PRE-TENSIONER"                                                                                           AKS00AIK


The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along                            B
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front              C
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING:                                                                                                                 D
q    To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
     in the event of a collision which would result in air bag inflation, all maintenance must be per-
     formed by an authorized NISSAN/INFINITI dealer.                                                                     E
q    Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
     sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
     Bag Module, see the SRS section.                                                                                    F
q    Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
     Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
     harness connectors.
                                                                                                                         G
Precautions for Battery Service                                                                              AKS00AUR


Before disconnecting the battery, lower both the driver and passenger windows. This will prevent any interfer-
ence between the window edge and the vehicle when the door is opened/closed. During normal operation, the                H
window slightly raises and lowers automatically to prevent any window to vehicle interference. The automatic
window function will not work with the battery disconnected.
                                                                                                                         I
Wiring Diagrams and Trouble Diagnosis                                                                         AKS00AIM


When You Read Wiring Diagrams, Refer to the Following:
q  Refer to GI-15, "How to Read Wiring Diagrams" .                                                                       J
q  Refer to PG-4, "POWER SUPPLY ROUTING CIRCUIT" for power distribution circuit.
When You Perform Trouble Diagnosis, Refer to the Following:
q  Refer to GI-11, "How to Follow Trouble Diagnoses" .                                                                   WW
q  Refer to GI-27, "How to Perform Efficient Diagnosis for an Electrical Incident" .

                                                                                                                         L



                                                                                                                         M




                                                     WW-3
                           FRONT WIPER AND WASHER SYSTEM

FRONT WIPER AND WASHER SYSTEM                                                                       PFP:28810

Components Parts and Harness Connector Location                                                           AKS009YC




                                                                                                   PKIA7608E



System Description                                                                                        AKS009YD


q  All front wiper relays (HI, LO) are included in IPDM E/R (intelligent power distribution module engine
   room).
q  Wiper switch (combination switch) is composed of a combination of 5 output terminals and 5 input termi-
   nals. Terminal combination status is read by BCM when switch is turned ON.
q  BCM (body control module) controls front wiper LO, HI, and INT (intermittent) operation.
q  IPDM E/R (intelligent power distribution module engine room) operates wiper motor according to CAN
   communication signals from BCM (body control module).
Power is supplied at all times
q  through 50 A fusible link (letter F, located in fusible link block.)
q  to BCM (body control module) terminal 55,
q  through 10 A fuse [No. 18, located in fuse block (J/B)]
q  to BCM (body control module) terminal 42
q  through 20 A fuse [No. 73, located in IPDM E/R (intelligent power distribution module engine room)]
q  to front wiper relay [located in IPDM E/R (intelligent power distribution module engine room)]
q  through 15 A fuse [No. 78, located in IPDM E/R (intelligent power distribution module engine room)]
q  to CPU (central processing unit) [located in IPDM E/R (intelligent power distribution module engine room)]
q  through 10 A fuse [No. 71, located in IPDM E/R (intelligent power distribution module engine room)]
q  to CPU (central processing unit) [located in IPDM E/R (intelligent power distribution module engine
   room)].

                                                  WW-4
                             FRONT WIPER AND WASHER SYSTEM

When the ignition switch ON or START position, power is supplied
q  through 10 A fuse [No. 1, located in fuse block (J/B)]                                                               A
q  to BCM (body control module) terminal 38
q  through ignition relay [located in IPDM E/R (intelligent power distribution module engine room)]
                                                                                                                        B
q  to front wiper relay [located in IPDM E/R (intelligent power distribution module engine room)] and
q  to front wiper high relay [located in IPDM E/R (intelligent power distribution module engine room)]
q  through 10 A fuse [No. 84, located in IPDM E/R (intelligent power distribution module engine room)] and              C
q  through IPDM E/R (intelligent power distribution module engine room) terminal 44
q  to front washer motor terminal 2.
Ground is supplied                                                                                                      D
q  to BCM (body control module) terminal 52
q  through grounds M30 and M66,
q  to IPDM E/R (intelligent power distribution module engine room) terminals 38 and 60                                  E
q  through grounds E17and E43,
q  to combination switch (wiper switch) terminal 12
                                                                                                                        F
q  through grounds M30 and M66.
LOW SPEED WIPER OPERATION
When wiper switch is in LO position, BCM detects low speed wiper ON signal by BCM wiper switch reading G
function.
BCM sends front wiper request signal (LO) with CAN communication line
q   from BCM terminals 39 and 40                                                                              H
q   to IPDM E/R terminals 48 and 49.
When IPDM E/R receives front wiper request signal (LO), it turns ON front wiper relay (located in IPDM E/R),
power is supplied                                                                                             I
q   to front wiper motor terminal 3
q   through IPDM E/R terminal 21 and front wiper relay and front wiper HI relay.
Ground is supplied                                                                                            J
q   to front wiper motor terminal 4
q   through grounds E17 and E43.
                                                                                                             WW
With power and ground supplied, the front wiper motor operates at low speed.
HI SPEED WIPER OPERATION
When wiper switch is in HI position, BCM detects high speed wiper ON signal by BCM wiper switch reading                 L
function.
BCM sends front wiper request signal (HI) with CAN communication line
q   from BCM terminals 39 and 40                                                                                        M
q   to IPDM E/R terminals 48 and 49.
When IPDM E/R receives front wiper request signal (HI), it turns ON front wiper relay (located in IPDM E/R),
power is supplied
q   to front wiper motor terminal 2
q   through IPDM E/R terminal 31 and front wiper relay and front wiper HI relay.
Ground is supplied
q   to front wiper motor terminal 4
q   through grounds E17 and E43.
With power and ground supplied, the front wiper motor operates at high speed.
INTERMITTENT OPERATION
Wiper intermittent operation delay interval is determined from a combination of 3 switches (intermittent opera-
tion dial position 1, intermittent operation dial position 2, and intermittent operation dial position 3) and vehicle
speed signal.
During each intermittent operation delay interval, BCM sends front wiper request signal to IPDM E/R.


                                                      WW-5
                               FRONT WIPER AND WASHER SYSTEM

Wiper Dial Position Setting
                                                                                   Combination switch
                                 Intermittent operation
        Wiper dial position                               Intermittent operation   Intermittent operation   Intermittent operation
                                        interval
                                                              dial position 1          dial position 2          dial position 3
       Wiper dial position 1                                       ON                       ON                       ON
                                         Small
       Wiper dial position 2                                       ON                       ON                      OFF
       Wiper dial position 3                                       ON                      OFF                      OFF
       Wiper dial position 4                                      OFF                      OFF                      OFF
       Wiper dial position 5                                      OFF                      OFF                       ON
       Wiper dial position 6                                      OFF                       ON                       ON
                                         Large
       Wiper dial position 7                                      OFF                       ON                      OFF

Example: For wiper dial position 1...
Using combination switch reading function, BCM detects ON/OFF status of intermittent operation dial posi-
tions 1, 2, and 3.
When combination switch status is as listed below, BCM determines that it is wiper dial position 1.
q    Intermittent operation dial position 1: ON (Combination switch output 3 and input 1 are performing.)
q    Intermittent operation dial position 2: ON (Combination switch output 5 and input 1 are performing.)
q    Intermittent operation dial position 3: ON (Combination switch output 4 and output 2 are performing.)
BCM determines front wiper intermittent operation delay interval from wiper dial position 1 and vehicle speed,
and sends wiper request signal (INT) to IPDM E/R.
AUTO STOP OPERATION
With wiper switch turned OFF, wiper motor will continue to operate until wiper arms reach windshield base.
When wiper arms are not located at base of windshield with wiper switch OFF, ground is provided
q   from IPDM E/R terminal 21
q   to front wiper motor terminal 3, in order to continue wiper motor operation at low speed.
When wiper arms reach base of windshield, front wiper motor terminals 1 and 4 are connected,
and ground is supplied
q   to IPDM E/R terminal 32
q   through front wiper motor terminals 1 and 4
q   through grounds E17 and E43.
Then IPDM E/R sends auto stop operation signal to BCM with CAN communication line.
When BCM receives auto-stop operation signal, BCM sends wiper stop signal to IPDM E/R with CAN commu-
nication line.
IPDM E/R stops wiper motor. Wiper motor will then stop wiper arms at the STOP position.
WASHER OPERATION
When wiper switch is in front wiper washer position with ignition switch on, BCM detects front wiper switch is
on the washer position by BCM wiper switch reading function. (Refer to WW-7, "COMBINATION SWITCH
READING FUNCTION" .) Combination switch (wiper switch) ground is supplied
q   to front washer motor terminal 1
q   through combination switch (wiper switch) terminal 11
q   to combination switch (wiper switch) terminal 12
q   through grounds M30 and M66.
With ground supplied, front washer motor is operated.
When BCM detects that front washer motor has operated for 0.4 seconds or linger, BCM operates front wiper
motor for low speed.
When BCM detects washer switch is OFF, low speed operation cycles approximately 3 times and stops.
MIST OPERATION
When wiper switch is turned to MIST position, wiper low speed operation cycles once and then stops.
For additional information about wiper operation under this condition, refer to WW-5, "LOW SPEED WIPER
OPERATION" .
If the switch is held in MIST position, low speed operation continues.
                                                          WW-6
                            FRONT WIPER AND WASHER SYSTEM

FAIL-SAFE FUNCTION
IPDM E/R includes a fail-safe function to prevent malfunction of electrical components controlled by CAN com-       A
munications in CAN communications occurs.
When fail-safe status is initiated, IPDM E/R remains in steady unit signals are received.
COMBINATION SWITCH READING FUNCTION                                                                                 B
Description
q   BCM reads combination switch (wiper) status, and controls related systems such as head lamps and wip-
    ers, according to the results.                                                                                  C
q   BCM reads information of a maximum of 20 switches by combining five output terminals (OUTPUT 1-5)
    and five input terminals (INPUT 1-5).
                                                                                                                    D
Operation Description
q   BCM activates transistors of output terminals (OUTPUT 1-5) periodically, and allows current to flow in
    turn.                                                                                                           E
q   If any (1 or more) switches are turned ON, circuit of output terminals (OUTPUT 1-5) and input terminals
    (INPUT 1-5) becomes active.
q   At this time, transistors of output terminals (OUTPUT 1-5) are activated to allow current to flow. When volt-   F
    age of input terminals (INPUT 1-5) corresponding to that switch changes, interface in BCM detects volt-
    age change, and BCM determines that switch is ON.
                                                                                                                    G


                                                                                                                    H



                                                                                                                    I


                                                                                                                    J


                                                                                                                    WW


                                                                                                                    L



                                                                                                                    M




                                                                                                      SKIA8639E




                                                   WW-7
                          FRONT WIPER AND WASHER SYSTEM

BCM - Operation Table of Combination Switches
q   BCM reads operation status of combination switch using combinations shown in table below.




                                                                                                SKIA8640E


Sample Operation: (When Wiper Switch Turned ON)
q   When wiper switch is turned ON, contact in combination switch turns ON. At this time if OUTPUT 1 tran-
    sistor is activated, BCM detects that voltage changes in INPUT 3.
q   When OUTPUT 1 transistor is ON, BCM detects that voltage changes in INPUT 3, and judges that front
    wiper low is ON. Then BCM sends front wiper request signal (LO) to IPDM E/R using CAN communica-
    tion.
q   When OUTPUT 1 transistor is activated again, BCM detects that voltage changes in INPUT 3, and recog-
    nizes that wiper switch is continuously ON.




                                                                                                PKIA4848E




                                                 WW-8
                            FRONT WIPER AND WASHER SYSTEM

NOTE:
Each OUTPUT terminal transistor is activated at 10 ms intervals. Therefore after switch is turned ON, electri-          A
cal loads are activated with time delay. But this time delay is so short that it cannot be detected by human
senses.
Operation Mode                                                                                                          B
Combination switch reading function has operation modes shown below.
1. Normal status
   q When BCM is not in sleep status, OUTPUT terminals (1-5) each turn ON-OFF every 10 ms.
                                                                                                                        C
2. Sleep status
   q When BCM is in sleep status, transistors of OUTPUT (1 and 5) stop the output, and BCM enters low
                                                                                                                        D
     current consumption mode. OUTPUT (2, 3, and 4) turn ON-OFF every 10 ms, and only input from light
     switch system is accepted.

                                                                                                                        E



                                                                                                                        F


                                                                                                                        G


                                                                                                                        H



                                                                                                                        I


                                                                                                                        J


                                                                                                                        WW


                                                                                                                        L


                                                                                                      SKIA4961E
                                                                                                                        M
CAN Communication System Description                                                                         AKS009YE


CAN (Controller Area Network) is a serial communication line for real time application. It is an on-board multi-
plex communication line with high data communication speed and excellent error detection ability. Many elec-
tronic control units are equipped onto a vehicle, and each control unit shares information and links with other
control units during operation (not independent). In CAN communication, control units are connected with 2
communication lines (CAN H line, CAN L line) allowing a high rate of information transmission with less wiring.
Each control unit transmits/receives data but selectively reads required data only.
CAN Communication Unit                                                                                       AKS009YF


Refer to LAN-4, "CAN Communication Unit" .




                                                   WW-9
            FRONT WIPER AND WASHER SYSTEM

Schematic                                         AKS009YG




                                            TKWM0906E




                       WW-10
                  FRONT WIPER AND WASHER SYSTEM

Wiring Diagram -- WIPER --                              AKS009YH

                                                                   A


                                                                   B



                                                                   C


                                                                   D


                                                                   E



                                                                   F


                                                                   G


                                                                   H



                                                                   I


                                                                   J


                                                                   WW


                                                                   L



                                                                   M




                                                  TKWM0907E




                             WW-11
FRONT WIPER AND WASHER SYSTEM




                                TKWM0908E




           WW-12
FRONT WIPER AND WASHER SYSTEM


                                            A


                                            B



                                            C


                                            D


                                            E



                                            F


                                            G


                                            H



                                            I


                                            J


                                            WW


                                            L



                                            M




                                TKWM0909E




           WW-13
                                FRONT WIPER AND WASHER SYSTEM

Terminals and Reference Values for BCM                                                                           AKS009YI


                                                            Measuring condition
Terminal No.
                         Signal name         Ignition                                          Reference value
(Wire color)                                                     Operation or condition
                                              switch



                                                        q   Lighting switch and wiper switch
  2 (G/R)      Combination switch input 5      ON           OFF
                                                        q   Wiper dial position 4

                                                                                                             SKIA5291E




                                                        q   Lighting switch and wiper switch
   3 (G)       Combination switch input 4      ON           OFF
                                                        q   Wiper dial position 4

                                                                                                             SKIA5292E




                                                        q   Lighting switch and wiper switch
  4 (W/L)      Combination switch input 3      ON           OFF
                                                        q   Wiper dial position 4

                                                                                                             SKIA5291E


  5 (W/G)      Combination switch input 2      ON

                                                        q   Lighting switch and wiper switch
                                                            OFF
  6 (W/R)      Combination switch input 1      ON
                                                        q   Wiper dial position 4

                                                                                                             SKIA5292E




                                                        q   Lighting switch and wiper switch
  32 (GY)      Combination switch output 5     ON           OFF
                                                        q   Wiper dial position 4

                                                                                                             SKIA5291E




                                                        q   Lighting switch and wiper switch
   33 (L)      Combination switch output 4     ON           OFF
                                                        q   Wiper dial position 4

                                                                                                             SKIA5292E




                                                        q   Lighting switch and wiper switch
  34 (PU)      Combination switch output 3     ON           OFF
                                                        q   Wiper dial position 4

                                                                                                             SKIA5291E




                                                        WW-14
                                   FRONT WIPER AND WASHER SYSTEM

                                                                       Measuring condition
Terminal No.                                                                                                                                  A
                           Signal name                 Ignition                                              Reference value
(Wire color)                                                                Operation or condition
                                                        switch
     35 (Y/R)   Combination switch output 2
                                                                                                                                              B
                                                                   q   Lighting switch and wiper switch
                                                         ON            OFF
      36 (Y)    Combination switch output 1                                                                                                   C
                                                                   q   Wiper dial position 4

                                                                                                                                SKIA5292E


     38 (W/L)   Ignition switch (ON)                     ON                           --                      Battery voltage                 D
      39 (L)    CAN H                                     --                          --                            --
      40 (R)    CAN L                                     --                          --                            --
                                                                                                                                              E
     42 (GY)    Battery power supply                    OFF                           --                      Battery voltage
      52 (B)    Ground                                   ON                           --                        Approx. 0V
     55 (W/R)   Battery power supply                    OFF                           --                      Battery voltage                 F
Terminals and Reference Values for IPDM E/R                                                                                        AKS009YJ



Terminal No.                                                        Measuring condition                                                       G
                          Signal name                                                                        Reference value
(Wire color)                                        Ignition switch           Operation or condition
                                                                                               OFF             Approx. 0V
     21 (PU)    Low speed signal                          ON              Wiper switch                                                        H
                                                                                                LO           Battery voltage
                                                                                               OFF             Approx. 0V
     31 (L/B)   High speed signal                         ON              Wiper switch
                                                                                                HI           Battery voltage                  I
                                                                                 Wiper operating             Battery voltage
     32 (L/Y)   Wiper auto - stop signal                  ON
                                                                                  Wiper stopped                Approx. 0V
      38 (B)    Ground                                    ON                             --                    Approx. 0V
                                                                                                                                              J
     44 (OR)    Washer motor power supply                 ON                             --                  Battery voltage
      48 (L)    CAN H                                         --                         --                         --
                                                                                                                                              WW
      49 (R)    CAN L                                         --                         --                         --
      60 (B)    Ground                                    ON                             --                    Approx. 0V
                                                                                                                                              L
How to Proceed With Trouble Diagnosis                                                                                              AKS009YK


1.     Confirm the symptoms and customer complaint.
2.     Understand operation description and function description. Refer to WW-4, "System Description" .                                       M
3.     Perform the preliminary check. Refer to WW-15, "Preliminary Check" .
4.     Check symptom and repair or replace the cause of malfunction.
5.     Does the front wiper and washer operate normally? If YES, GO TO 6. If NO, GO TO 4.
6.     INSPECTION END
Preliminary Check                                                                                                                  AKS009YL

CHECK POWER SUPPLY AND GROUND CIRCUIT
Inspection Procedure
1. CHECK FUSE
q      Check if wiper and washer fuse is blown.
                            Unit                                               Power source               Fuse and fusible link No.
 Front washer motor                                                     Ignition switch ON or START                  84
 Front wiper motor, front wiper relay, front wiper HI relay                        Battery                           73



                                                                   WW-15
                                         FRONT WIPER AND WASHER SYSTEM

                                Unit                                           Power source         Fuse and fusible link No.
                                                                                                               F
                                                                                  Battery
 BCM                                                                                                           18
                                                                      Ignition switch ON or START              1
Refer to WW-11, "Wiring Diagram -- WIPER --" .
OK or NG
 OK      >> GO TO 2
 NG      >> If fuse is blown, be sure to eliminate cause of malfunction before installing new fuse. Refer to PG-
            4, "POWER SUPPLY ROUTING CIRCUIT" .

2. CHECK POWER SUPPLY CIRCUIT
1.    Turn ignition switch OFF.
2.    Disconnect BCM connector.
3.    Check voltage between BCM harness connector terminal and
      ground.
                   Terminals                          Ignition switch position
             (+)
                  Terminal               (-)         OFF                  ON
 Connector
                 (Wire color)
      M2           42 (GY)                      Battery voltage     Battery voltage                                    SKIA9169E

      M2           55 (W/R)            Ground   Battery voltage     Battery voltage
      M1           38 (W/L)                           0V            Battery voltage
OK or NG
 OK    >> GO TO 3.
 NG    >> Check harness for open or short between fuse, fusible link and BCM.

3. CHECK GROUND CIRCUIT
Check continuity between BCM harness connector and ground.
                               Terminals
                                                                     Continuity
     Connector          Terminal (Wire color)
        M2                        52 (B)               Ground            Yes
OK or NG
 OK    >> INSPECTION END
 NG    >> Repair harness or connector.

                                                                                                                       PKIA4851E




                                                                  WW-16
                              FRONT WIPER AND WASHER SYSTEM

CONSULT-II Functions (BCM)                                                                                                 AKS009YM

                                                                                                                                      A
CONSULT-II performs the following functions communicating with BCM.
BCM diagnosis position   Check item, Diagnosis mode                                   Description
                              DATA MONITOR            Displays BCM input data in real time.                                           B
        Wiper
                               ACTIVE TEST            Device operation can be checked by applying a drive signal to device.
         BCM             CAN DAIG SUPPORT MNTR        The result of transmit/receive diagnosis CAN communication can be read.
                                                                                                                                      C
CONSULT-II OPERATION
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be                                               D
detected in self-diagnosis depending on control unit which carry out CAN communication.
1. With the ignition switch OFF, connect CONSULT-II and CON-
    SULT-II CONVERTER to the data link connector, then turn the                                                                       E
    ignition switch ON.

                                                                                                                                      F


                                                                                                                                      G

                                                                                                                        PIIA1095E

                                                                                                                                      H
2.   Touch "START (NISSAN BASED VHCL)".

                                                                                                                                      I


                                                                                                                                      J


                                                                                                                                      WW
                                                                                                                        SKIA3098E



3.   Touch "BCM" on "SELECT SYSTEM" screen.                                                                                           L
     If "BCM" is not indicated, refer to GI-39, "CONSULT-II Data Link
     Connector (DLC) Circuit" .

                                                                                                                                      M




                                                                                                                        PKIA4849E




                                                        WW-17
                                        FRONT WIPER AND WASHER SYSTEM

4.    Touch "WIPER".




                                                                                                                                      PKIA6100E


DATA MONITOR
Operation Procedure
1.    Touch "WIPER" on the "SELECT TEST ITEM" screen.
2.    Touch "DATA MONITOR" on "SELECT DIAG MODE" screen.
3.    Touch either "ALL SIGNALS" or "SELECTION FROM MENU" on "DATA MONITOR" screen.
 ALL SIGNALS                             All items will be monitored.
 SELECTION FROM MENU                     Selects and monitors individual items.
4.    Touch "START".
5.    When "SELECTION FROM MENU" is selected, touched items to be monitored. If "ALL SIGNALS" is
      selected, all items will be monitored.
6.    Touch "RECORDING START" while monitoring to record the status of the item being monitored. To stop
      recording, touch "RECORDING STOP".
Display Item List
     Monitor item [operation or unit]                                                Display content
                                           Displays "ignition switch ON (ON)/Other OFF or ACC (OFF)" status as judged from ignition
 IGN ON SW                   [ON/OFF]
                                           switch signal.
                                           Displays "ignition switch ON (ON)/Other OFF or ACC (OFF)" status as judged from CAN commu-
 IGN SW CAN                  [ON/OFF]
                                           nication signal.
 FR WIPER HI                 [ON/OFF]      Displays "FRONT WIPER HI (ON)/Other (OFF)" status as judged from wiper switch signal.
 FR WIPER LOW                [ON/OFF]      Displays "FRONT WIPER LOW (ON)/Other (OFF)" status as judged from wiper switch signal.
 FR WIPER INT                [ON/OFF]      Displays "FRONT WIPER INT (ON)/Other (OFF)" status as judged from wiper switch signal.
 FR WASHER SW                [ON/OFF]      Displays "FRONT WASHER Switch (ON)/Other (OFF)" status as judged from wiper switch signal.
 INT VOLUME                    [1 - 7]     Displays intermittent operation dial position setting (1 - 7) as judged from wiper switch signal.
 FR WIPER STOP               [ON/OFF]      Displays "Stopped (ON)/Operating (OFF)" status as judged from the auto-stop signal.
 VEHICLE SPEED                 [km/h]      Displays vehicle speed status as judged from vehicle speed signal.

 RR WIPER ONNOTE             [ON/OFF]                                                       --

 RR WIPER INTNOTE            [ON/OFF]                                                       --
                     NOTE    [ON/OFF]                                                       --
 RR WASHER SW

 RR WIPER STOPNOTE           [ON/OFF]                                                       --
NOTE:
This item is displayed, but cannot monitor it.




                                                                   WW-18
                                    FRONT WIPER AND WASHER SYSTEM

ACTIVE TEST
Operation Procedure                                                                                                                           A
1.   Touch "WIPER" on "SELECT TEST ITEM" screen.
2.   Touch "ACTIVE TEST" on "SELECT DIAG MODE" screen.
                                                                                                                                              B
3.   Touch items to be tested, and check operation.
4.   During operation check, touching "STOP" deactivates operation.
Display Item List                                                                                                                             C
                                      Indication on
            Test item                                                                       Description
                                    CONSULT-II display
 Front wiper output                      FR WIPER          With a certain operation (OFF, HI, LO, INT), the front wiper can be operated.      D
 Rear wiper output NOTE                  RR WIPER                                                --
NOTE:
                                                                                                                                              E
This item is displayed, but cannot test it.

CONSULT-II Functions (IPDM E/R)                                                                                                    AKS009YN


CONSULT-II performs the following functions communicating with IPDM E/R.                                                                      F
       Check Item, Diagnosis Mode                                                     Description
 SELF-DIAG RESULTS                            The IPDM E/R performs diagnosis of the CAN communication and self-diagnosis.
                                                                                                                                              G
 DATA MONITOR                                 The input/output data of the IPDM E/R is displayed in real time.
 CAN DIAG SUPPORT MNTR                        The result of transmit/receive diagnosis of CAN communication can be read.
 ACTIVE TEST                                  The IPDM E/R sends a drive signal to electronic components to check their operation.            H

CONSULT-II OPERATION
CAUTION:                                                                                                                                      I
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detected in self-diagnosis depending on control unit which carry out CAN communication.
1. With the ignition switch OFF, connect CONSULT-II and CON-                                                                                  J
    SULT-II CONVERTER to the data link connector, then turn the
    ignition switch ON.
                                                                                                                                              WW


                                                                                                                                              L



                                                                                                                                PIIA1095E     M

2.   Touch "START (NISSAN BASED VHCL)".




                                                                                                                                SKIA3098E




                                                               WW-19
                                 FRONT WIPER AND WASHER SYSTEM

3.   Touch "IPDM E/R" on "SELECT SYSTEM" screen.
     If "IPDM E/R" is not displayed, print "SELECT SYSTEM" screen,
     then refer to GI-39, "CONSULT-II Data Link Connector (DLC)
     Circuit" .




                                                                                                                           PKIA4849E



4.   Select the desired part to be diagnosed on the "SELECT DIAG
     MODE" screen.




                                                                                                                           PKIA7594E


SELF-DIAG RESULTS
Refer to PG-20, "SELF-DIAG RESULTS" .
DATA MONITOR
Operation Procedure
1.   Touch "DATA MONITOR" on "SELECT DIAG MODE " screen.
2.   Touch "ALL SIGNALS", "MAIN SIGNALS" or "SELECTION FROM MENU" on the "DATA MONITOR"
     screen.
 ALL SIGNALS                      All items will be monitored.
 MAIN SIGNALS                     Monitor the predetermined item.
 SELECTION FROM MENU              Select any item for monitoring.

3.   Touch "START".
4.   Touch the required monitoring item on "SELECTION FROM MENU". In "ALL SIGNALS", all items are
     monitored. In "MAIN SIGNALS", predetermined items are monitored.
5.   Touch "RECORD" while monitoring to record the status of the item being monitored. To stop recording,
     touch "STOP".
All signals, Main signals, Selection From Menu
                                                                        Monitor item selection
                      CONSULT-II                                                        SELECTION
     Item name                            Display or unit          ALL        MAIN                           Description
                     screen display                                                       FROM
                                                                 SIGNALS    SIGNALS
                                                                                          MENU
 FR wiper request   FR WIP REQ        STOP/1LOW/LOW/HI



◦ Jabse Service Manual Search 2023 ◦ Jabse PravopisonTap.bg ◦ Other service manual resources online : FixyaeServiceinfo
