Image preview - the first page of the document
>> Download lu documenatation <<Text preview - extract from the documentENGINE LUBRICATION SYSTEM
B ENGINE
A
ENGINE LUBRICATION SYSTEM
SECTION LU LU
C
D
E
CONTENTS
PRECAUTIONS ......................................................... 2. OIL COOLER ........................................................... 10
. F
Precautions for Battery Service ............................... 2 . Removal and Installation ....................................... 10 .
Precautions for Liquid Gasket ................................. 2 . REMOVAL .......................................................... 10
.
LIQUID GASKET APPLICATION PROCEDURE 2 ..... INSPECTION AFTER REMOVAL ...................... 10 . G
PREPARATION .......................................................... 3
. INSTALLATION .................................................. 11 .
Special Service Tools .............................................. 3. INSPECTION AFTER INSTALLATION ............... 11 .
Commercial Service Tools ....................................... 3 . OIL PUMP ................................................................ 12
.
H
LUBRICATION SYSTEM ........................................... 4 . Removal and Installation ....................................... 12 .
Lubrication Circuit ................................................... 4
. REMOVAL .......................................................... 12
.
System Chart .......................................................... 5
. INSTALLATION .................................................. 12 .
ENGINE OIL .............................................................. 6
. INSPECTION AFTER INSTALLATION ............... 12 . I
Inspection ................................................................ 6
. Disassembly and Assembly ................................... 12 .
OIL LEVEL ........................................................... 6
. DISASSEMBLY .................................................. 12 .
OIL APPEARANCE .............................................. 6 . INSPECTION AFTER DISASSEMBLY ............... 13 . J
OIL LEAKAGE ...................................................... 6. ASSEMBLY ........................................................ 14
.
OIL PRESSURE CHECK ..................................... 7 . SERVICE DATA AND SPECIFICATIONS (SDS) ..... 15 .
Changing Engine Oil ............................................... 8 . Standard and Limit ................................................. 15
.
K
OIL FILTER ................................................................ 9
. OIL PRESSURE ................................................. 15 .
Removal and Installation ......................................... 9 . OIL CAPACITY (APPROXIMATE) ...................... 15 .
REMOVAL ............................................................ 9
. OIL PUMP .......................................................... 15
.
INSTALLATION .................................................... 9 . REGULATOR VALVE ......................................... 15 . L
INSPECTION AFTER INSTALLATION ................ 9 . Tightening Torque .................................................. 15
.
M
LU-1
PRECAUTIONS
PRECAUTIONS PFP:00001
Precautions for Battery Service ABS00B3L
Before disconnecting the battery, lower both the driver and passenger windows. This will prevent any interfer-
ence between the window edge and the vehicle when the door is opened/closed. During normal operation, the
window slightly raises and lowers automatically to prevent any window to vehicle interference. The automatic
window function will not work with the battery disconnected.
Precautions for Liquid Gasket ABS00A1A
LIQUID GASKET APPLICATION PROCEDURE
1. Remove old liquid gasket adhering to the liquid gasket application surface and the mating surface.
q Remove liquid gasket completely from the liquid gasket application surface, mounting bolts, and bolt
holes.
2. Wipe the liquid gasket application surface and the mating surface with white gasoline (lighting and heating
use) to remove adhering moisture, grease and foreign materials.
3. Attach liquid gasket tube to tube presser [SST: WS39930000
( -- )].
Use Genuine RTV Silicone Sealant or equivalent. Refer to
GI-47, "RECOMMENDED CHEMICAL PRODUCTS AND
SEALANTS" .
q Within five minutes of liquid gasket application, install the mat-
ing component.
q If liquid gasket protrudes, wipe it off immediately.
q Do not retighten mounting bolts or nuts after the installation.
q After 30 minutes or more have passed from the installation, fill
EMA0622D
engine oil and engine coolant.
LU-2
PREPARATION
PREPARATION PFP:00002
A
Special Service Tools ABS00A1B
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Tool number LU
(Kent-Moore No.) Description
Tool name
ST25051001 Measuring oil pressure
C
(J25695-1) Maximum measuring range: 2,452 kPa (25
Oil pressure gauge kg-cm2 , 356 psi)
D
NT050
ST25052000 Adapting oil pressure gauge to upper oil pan
E
(J25695-2) (upper)
Hose
F
S-NT559
G
KV10115801 Removing oil filter
(J38956) a: 64.3 mm (2.531 in)
Oil filter wrench
H
I
S-NT375
WS39930000 Pressing the tube of liquid gasket
( -- )
Tube presser J
K
NT052
L
Commercial Service Tools ABS00A1C
Tool name Description M
Deep socket Removing and installing oil pressure switch
a: 27 mm (1.06 in)
PBIC2072E
Power tool Loosening bolts and nuts
PBIC0190E
LU-3
LUBRICATION SYSTEM
LUBRICATION SYSTEM PFP:15010
Lubrication Circuit ABS00A1D
PBIC1933E
LU-4
LUBRICATION SYSTEM
System Chart ABS00A1E
A
LU
C
D
E
F
G
H
PBIC2071E I
J
K
L
M
LU-5
ENGINE OIL
ENGINE OIL PFP:KLA92
Inspection ABS00A1F
OIL LEVEL
NOTE:
Before starting engine, put vehicle horizontally and check the oil level. If engine is already started, stop it and
allow 10 minutes before checking.
1. Pull out oil level gauge and wipe it clean.
2. Insert oil level gauge and make sure the oil level is within the
range shown in the figure.
3. If it is out of range, adjust it.
PBIC0249E
NOTE:
When checking oil level, insert oil level gauge with its tip aligned with
oil level gauge guide on cylinder head. (In the figure, air cleaner case
and air duct are removed.)
KBIA1343E
OIL APPEARANCE
q Check the engine oil for white turbidity or heavy contamination.
q If the engine oil becomes turbid and white, it is highly probable that it is contaminated with engine coolant.
Repair or replace damaged parts.
OIL LEAKAGE
Check for oil leakage around the following areas:
q Oil pan
q Oil pan drain plug
q Oil pressure switch
q Oil filter
q Oil cooler
q Water pump cover
q Chain tensioner cover
q Intake valve timing control cover and intake valve timing control solenoid valve
q Mating surface between cylinder block and cylinder head
q Mating surface between cylinder head and rocker cover
q Mating surface between front timing chain case and rear timing chain case
q Mating surface between rear timing chain case and cylinder block
q Crankshaft oil seals (front and rear)
LU-6
ENGINE OIL
OIL PRESSURE CHECK
WARNING: A
q Be careful not to burn yourself, as engine oil may be hot.
q Oil pressure check should be done in "Neutral position" (M/T models) or "Parking position" (A/T
models). LU
1. Check oil level. Refer to LU-6, "OIL LEVEL" .
2. Remove undercover with power tool.
3. Disconnect oil pressure switch harness connector. C
4. Remove oil pressure switch.
D
E
F
PBIC0818E
5. Install oil pressure gauge and hose (SST).
G
H
I
SLC926
J
6. Start engine and warm it up to normal operating temperature.
7. Check oil pressure with engine running under no-load.
NOTE: K
When engine oil temperature is low, engine oil pressure becomes high.
Engine oil pressure [Engine oil temperature at 80
