Image preview - the first page of the document
>> Download ma documenatation <<
Text preview - extract from the document
MAINTENANCE
L MAINTENANCE
A
SECTION
MAINTENANCE
MA B
C
D
E
CONTENTS
PREPARATION .......................................................... 2
. INSPECTION AFTER REMOVAL ...................... 17 . F
Special Service Tools .............................................. 2
. INSTALLATION .................................................. 17 .
Commercial Service Tools ....................................... 2 . Checking EVAP Vapor Lines ................................. 17 .
GENERAL MAINTENANCE ...................................... 3 . CHASSIS AND BODY MAINTENANCE .................. 18 . G
Explanation of General Maintenance ...................... 3 . Checking Exhaust System ..................................... 18 .
PERIODIC MAINTENANCE ...................................... 5 . Checking Clutch Fluid Level and Leaks ................ 18 .
Introduction of Periodic Maintenance ...................... 5 . Checking M/T Oil Leakage .................................... 18 .
H
Schedule 1 .............................................................. 6
. Changing M/T Oil ................................................... 19.
EMISSION CONTROL SYSTEM MAINTE- Checking A/T Fluid ................................................ 19 .
NANCE ................................................................. 6
. Changing A/T Fluid ................................................ 20 .
CHASSIS AND BODY MAINTENANCE .............. 7 . Checking Differential Gear Oil ............................... 21 . I
Schedule 2 .............................................................. 7
. Changing Differential Gear Oil ............................... 21 .
EMISSION CONTROL SYSTEM MAINTE- Balancing Wheels (Bonding Weight Type) ............ 22 .
NANCE ................................................................. 7
. REMOVAL .......................................................... 22. J
CHASSIS AND BODY MAINTENANCE .............. 8 . WHEEL BALANCE ADJUSTMENT .................... 22 .
RECOMMENDED FLUIDS AND LUBRICANTS ....... 9 . Checking Brake Fluid Level and Leaks ................. 23 .
Fluids and Lubricants .............................................. 9
. Checking Brake Lines and Cables ........................ 23 .
K
SAE Viscosity Number .......................................... 10 . Changing Brake Fluid ............................................ 23 .
GASOLINE ENGINE OIL ................................... 10 . Checking Disc Brake ............................................. 24 .
Anti-Freeze Coolant Mixture Ratio ........................ 10 . ROTOR ............................................................... 24
.
ENGINE MAINTENANCE .........................................11 . CALIPER ............................................................ 24
. MA
Checking Drive Belts ..............................................11
. PAD .................................................................... 24
.
Tension Adjustment ................................................11
. Checking Steering Gear and Linkage .................... 24 .
ALTERNATOR AND POWER STEERING OIL STEERING GEAR .............................................. 24 . M
PUMP BELT ....................................................... 12
. STEERING LINKAGE ........................................ 25 .
A/C COMPRESSOR BELT ................................ 12 . Checking Power Steering Fluid and Lines ............. 25 .
Changing Engine Coolant ..................................... 12 . Axle and Suspension Parts ................................... 25 .
DRAINING ENGINE COOLANT ........................ 12 . Drive Shaft ............................................................. 26
.
REFILLING ENGINE COOLANT ....................... 13 . Lubricating Locks, Hinges and Hood Latch ........... 26 .
FLUSHING COOLING SYSTEM ........................ 14 . Checking Seat Belt, Buckles, Retractors, Anchors
Checking Fuel Lines .............................................. 14
. and Adjusters ......................................................... 27
.
Changing Air Cleaner Filter ................................... 14 . SERVICE DATA AND SPECIFICATIONS (SDS) ..... 28 .
VISCOUS PAPER TYPE .................................... 14 . Standard and Limit ................................................. 28.
Changing Engine Oil ............................................. 15. BELT DEFLECTION AND TENSION ................. 28 .
Changing Oil Filter ................................................ 15
. ENGINE COOLANT CAPACITY ......................... 28 .
REMOVAL .......................................................... 15
. ENGINE OIL CAPACITY (APPROXIMATE) ....... 28 .
INSTALLATION .................................................. 16. SPARK PLUG (PLATINUM-TIPPED TYPE) ....... 28 .
INSPECTION AFTER INSTALLATION .............. 16 . WHEEL BALANCE ............................................. 28 .
Changing Spark Plugs (Platinum-Tipped Type) .... 16 . Tightening Torque .................................................. 29.
REMOVAL .......................................................... 16
.
MA-1
PREPARATION
PREPARATION PFP:00002
Special Service Tools ALS0006B
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Tool number
(Kent-Moore No.) Description
Tool name
KV10115801 Removing and installing oil filter
(J38956) a: 64.3 mm (2.531 in)
Oil filter wrench
S-NT375
Commercial Service Tools ALS0006C
Tool name
Description
(Kent-Moore No.)
Power tool Loosening bolts and nuts
PBIC0190E
Spark plug wrench Removing and installing spark plug
S-NT047
Belt tension gauge Checking drive belt tension
(BT3373-F)
AMA126
MA-2
GENERAL MAINTENANCE
GENERAL MAINTENANCE PFP:00000
A
Explanation of General Maintenance ALS0006D
General maintenance includes those items which should be checked during the normal day-to-day operation
of the vehicle. They are essential if the vehicle is to continue operating properly. The owners can perform B
checks and inspections themselves or have their INFINITI dealers do them.
OUTSIDE THE VEHICLE
The maintenance items listed here should be performed from time to time, unless otherwise specified. C
Item Reference page
Tires Check the pressure with a gauge, including the spare, at least once a month
and always prior to a long distance trips. Adjust to the specified pressure if nec- -- D
essary. Check carefully for damage, cuts or excessive wear.
Wheel nuts When checking the tires, make sure no nuts are missing, and check for any
--
loose nuts. Tighten if necessary.
E
Clean the windshield on a regular basis. Check the windshield at least every six
Windshield --
months for cracks or other damage. Repair as necessary.
Tire rotation For coupe models, tires cannot be rotated, as front tires are different size from F
--
rear tires and the direction of wheel rotation is fixed in each tire.
Wheel alignment and If the vehicle pulls to either side while driving on a straight and level road, or if
balance you detect uneven or abnormal tire wear, there may be a need for wheel align-
MA-22, FSU-6 G
ment. If the steering wheel or seat vibrates at normal highway speeds, wheel
balancing may be needed.
Windshield wiper
Check for cracks or wear if they do not wipe properly. -- H
blades
Doors and engine Check that all doors and the engine hood operate smoothly as well as the trunk
hood lid and back hatch. Also make sure that all latches lock securely. Lubricate if
necessary. Make sure that the secondary latch keeps the hood from opening I
MA-26
when the primary latch is released.
When driving in areas using road salt or other corrosive materials, check lubri-
cation frequently.
J
Lamps Make sure that the headlamps, stop lamps, tail lamps, turn signal lamps, and
other lamps are all operating properly and installed securely. Also check head- --
lamp aim. Clean the headlamps on a regular basis.
K
INSIDE THE VEHICLE
The maintenance items listed here should be checked on a regular basis, such as when performing periodic maintenance, cleaning the
vehicle, etc.
Item Reference page MA
Warning lamps and
Make sure that all warning lamps and chimes are operating properly. --
chimes
Windshield wiper and Check that the wipers and washer operate properly and that the wipers do not M
--
washer streak.
Windshield defroster Check that the air comes out of the defroster outlets properly and in sufficient
--
quantity when operating the heater or air conditioner.
Steering wheel Check that it has the specified play. Be sure to check for changes in the steering
condition, such as excessive play, hard steering or strange noises. --
Free play: Less than 35 mm (1.38 in)
Seats Check seat position controls such as seat adjusters, seatback recliner, etc. to
make sure they operate smoothly and that all latches lock securely in every
position. Check that the head restrains move up and down smoothly and that --
the locks (if equipped) hold securely in all latched positions. Check that the
latches lock securely for folding-down rear seatbacks.
Seat belts Check that all parts of the seat belt system (e.g. buckles, anchors, adjusters and
retractors) operate properly and smoothly, and are installed securely. Check the MA-27
belt webbing for cuts, fraying, wear or damage.
Accelerator pedal Check the pedal for smooth operation and make sure the pedal does not catch
--
or require uneven effort. Keep the floor mats away from the pedal.
MA-3
GENERAL MAINTENANCE
Item Reference page
Brakes Check that the brake does not pull the vehicle to one side when applied. --
Brake pedal and Check the pedal for smooth operation and make sure it has the proper distance
booster under it when depressed fully. Check the brake booster function. Be sure to BR-6, BR-19
keep the floor mats away from the pedal.
Parking brake Check that the pedal or lever has the proper travel and make sure that the vehi-
PB-3, PB-4
cle is held securely on a fairly steep hill when only the parking brake is applied.
Automatic transmis- Check that the lock release button on the selector lever operates properly and
sion "Park" mecha- smoothly. On a fairly steep hill check that the vehicle is held securely with the --
nism selector lever in the "P" position without applying any brakes.
UNDER THE HOOD AND VEHICLE
The maintenance items listed here should be checked periodically (e.g. each time you check the engine oil or refuel).
Item Reference page
Windshield washer
Check that there is adequate fluid in the tank. --
fluid
Engine coolant level Check the coolant level when the engine is cold. MA-12
Radiator and hoses Check the front of the radiator and clean off any dirt, insects, leaves, etc., that
may have accumulated. Make sure the hoses have no cracks, deformation, --
deterioration or loose connections.
Brake fluid level Make sure that the brake fluid level is between the "MAX" and "MIN" lines on the
MA-23
reservoir.
Battery Check the fluid level in each cell. It should be between the "MAX" and "MIN"
lines. Vehicles operated in high temperatures or under severe conditions require --
frequent checks of the battery fluid level.
Engine drive belts Make sure that no belt is frayed, worn, cracked or oily. MA-11
Engine oil level Check the level on oil level gauge after parking the vehicle on a level spot and
MA-15
turning off the engine.
Power steering fluid Check the level on the dipstick with the engine off. Check the lines for improper
MA-25
level and lines attachment, leaks, cracks, etc.
Exhaust system Make sure there are no loose supports, cracks or holes. If the sound of the
exhaust seems unusual or there is a smell of exhaust fumes, immediately locate MA-18
the trouble and correct it.
Underbody The underbody is frequently exposed to corrosive substances such as those
used on icy roads or to control dust. It is very important to remove these sub-
stances, otherwise rust will form on the floor pan, frame, fuel lines and around
--
the exhaust system. At the end of winter, the underbody should be thoroughly
flushed with plain water, being careful to clean those areas where mud and dirt
can easily accumulate.
Fluid leaks Check under the vehicle for fuel, oil, water or other fluid leaks after the vehicle
has been parked for a while. Water dripping from the air conditioner after use is
--
normal. If you should notice any leaks or gasoline fumes are evident, check for
the cause and correct it immediately.
MA-4
PERIODIC MAINTENANCE
PERIODIC MAINTENANCE PFP:00026
A
Introduction of Periodic Maintenance ALS0006E
Two different maintenance schedules are provided, and should be used, depending upon the conditions in
which the vehicle is mainly operated. After 60,000 miles (96,000 km) or 48 months, continue the periodic B
maintenance at the same mileage/time intervals.
Follow Periodic Maintenance Schedule 1 if the driving habits frequently include Emission Control Sys-
one or more of the following driving conditions: tem Maintenance C
q Repeated short trips of less than 5 miles (8 km).
MA-6
q Repeated short trips of less than 10 miles (16 km) with outside temperatures
remaining below freezing.
D
Schedule 1 q Operating in hot weather in stop-and-go "rush hour" traffic.
q Extensive idling and/or low speed driving for long distances, such as police, Chassis and Body
taxi or door-to-door delivery use. Maintenance
E
q Driving in dusty conditions. MA-7
q Driving on rough, muddy, or salt spread roads.
q Towing a trailer, using a camper or a car-top carrier. F
Follow Periodic Maintenance Schedule 2 if none of driving conditions shown in Emission Control Sys-
MA-7
Schedule 1 apply to the driving habits. tem Maintenance
Schedule 2
Chassis and Body G
MA-8
Maintenance
H
I
J
K
MA
M
MA-5
PERIODIC MAINTENANCE
Schedule 1 ALS0006F
EMISSION CONTROL SYSTEM MAINTENANCE
Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary. [ ]: At the mileage intervals only
MAINTENANCE OPERATION MAINTENANCE INTERVAL Reference
Perform at number of miles, Miles x 1,000 3.75 7.50 11.25 15 18.75 22.5 26.25 30 Section -
kilometers or months, which- (km x 1,000) (6) (12) (18) (24) (30) (36) (42) (48) Page or -
ever comes first. Months 3 6 9 12 15 18 21 24 Content Title
Drive belts NOTE (1) MA-11
Air cleaner filter NOTE (2) [R] MA-14
EVAP vapor lines I* MA-17
Fuel lines I* MA-14
Fuel filter NOTE (3) -
Engine coolant NOTE (4) MA-12
Engine oil R R R R R R R R MA-15
Engine oil filter (Use part No.
15208 31U00 or 15208 R R R R R R R R MA-15
65F00 or equivalent.)
Spark plugs (PLATINUM-
Replace every 105,000 miles (169,000 km). MA-16
TIPPED type)
EM-82,
Intake & exhaust valve clear-
NOTE (5) "Valve Clear-
ance*
ance"
MAINTENANCE OPERATION MAINTENANCE INTERVAL Reference
Perform at number of miles, Miles x 1,000 33.75 37.5 41.25 45 48.75 52.5 56.25 60 Section -
kilometers or months, which- (km x 1,000) (54) (60) (66) (72) (78) (84) (90) (96) Page or -
ever comes first. Months 27 30 33 36 39 42 45 48 Content Title
Drive belts NOTE (1) I* MA-11
Air cleaner filter NOTE (2) [R] MA-14
EVAP vapor lines I* MA-17
Fuel lines I* MA-14
Fuel filter NOTE (3) -
Engine coolant NOTE (4) R* MA-12
Engine oil R R R R R R R R MA-15
Engine oil filter (Use part No.
15208 31U00 or 15208 65F00 R R R R R R R R MA-15
or equivalent.)
Spark plugs (PLATINUM-
Replace every 105,000 miles (169,000 km). MA-16
TIPPED type)
EM-82,
Intake & exhaust valve clear-
NOTE (5) "Valve Clear-
ance*
ance"
NOTE:
(1) After 60,000 miles (96,000 km) or 48 months, inspect every 15,000 miles (24,000 km) or 12 months. Replace the drive belts if found
damaged.
(2) If operating mainly in dusty conditions, more frequent maintenance may be required.
(3) Maintenance-free item. For service procedures, refer to FL section.
(4) After 60,000 miles (96,000 km) or 48 months, replace every 30,000 miles (48,000 km) or 24 months.
(5) If valve noise increases, inspect valve clearance.
* Maintenance items and intervals with "*" are recommended by INFINITI for reliable vehicle operation. The owner need not perform
such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are
required.
MA-6
PERIODIC MAINTENANCE
CHASSIS AND BODY MAINTENANCE
Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary. A
MAINTENANCE OPERATION MAINTENANCE INTERVAL Reference
Perform at number of miles, Miles x 1,000 3.75 7.50 11.25 15 18.75 22.5 26.25 30 Section -
kilometers or months, which- (km x 1,000) (6) (12) (18) (24) (30) (36) (42) (48) Page or - B
ever comes first. Months 3 6 9 12 15 18 21 24 Content Title
Brake lines & cables
I I MA-23
C
Brake pads & rotors
I I I I MA-24
Manual transmission gear oil MA-18, MA- D
or automatic transmission NOTE (1) I I 19 , MA-20 ,
fluid & differential gear oil MA-21
Steering gear & linkage, axle MA-24, RSU- E
I I I I
& suspension parts 5 , MA-25
Exhaust system
I I I I MA-18
F
In-cabin microfilter R R ATC-126
MAINTENANCE OPERATION MAINTENANCE INTERVAL Reference
Section -
G
Perform at number of miles, Miles x 1,000 33.75 37.5 41.25 45 48.75 52.5 56.25 60
kilometers or months, which- (km x 1,000) (54) (60) (66) (72) (78) (84) (90) (96) Page or -
ever comes first. Months 27 30 33 36 39 42 45 48 Content Title
Brake lines & cables
H
I I MA-23
Brake pads & rotors
I I I I MA-24
I
Manual transmission gear oil MA-18, MA-19
or automatic transmission NOTE (1) I I , MA-20 , MA-
fluid & differential gear oil 21 J
Steering gear & linkage, axle
MA-24, RSU-
& suspension parts I I I I
5 , MA-25
K
Exhaust system
I I I I MA-18
In-cabin microfilter R R ATC-126 MA
NOTE:
(1) If towing a trailer, using a camper or a car-top carrier, or driving on rough or muddy roads, change (not just inspect) oil at every
30,000 miles (48,000 km) or 24 months. Using automatic transmission fluid other than Genuine Nissan Matic J ATF will cause
M
deterioration in driveability and automatic transmission durability, and may damage the automatic transmission, which is
not covered by the INFINITI new vehicle limited warranty.
Schedule 2 ALS0006G
EMISSION CONTROL SYSTEM MAINTENANCE
Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary. [ ]: At the mileage intervals only
MAINTENANCE OPERATION MAINTENANCE INTERVAL
Reference Sec-
Perform at number of miles, Miles x 1,000 7.5 15 22.5 30 37.5 45 52.5 60 tion - Page or -
kilometers or months, whichever (km x 1,000) (12) (24) (36) (48) (60) (72) (84) (96) Content Title
comes first. Months 6 12 18 24 30 36 42 48
Drive belts NOTE (1) I* MA-11
Air cleaner filter [R] [R] MA-14
EVAP vapor lines I* I* MA-17
Fuel lines I* I* MA-14
Fuel filter NOTE (2) -
Engine coolant NOTE (3) R* MA-12
MA-7
PERIODIC MAINTENANCE
MAINTENANCE OPERATION MAINTENANCE INTERVAL
Reference Sec-
Perform at number of miles, Miles x 1,000 7.5 15 22.5 30 37.5 45 52.5 60 tion - Page or -
kilometers or months, whichever (km x 1,000) (12) (24) (36) (48) (60) (72) (84) (96) Content Title
comes first. Months 6 12 18 24 30 36 42 48
Engine oil R R R R R R R R MA-15
Engine oil filter (Use part No.
15208 31U00 or 15208 65F00 R R R R R R R R MA-15
or equivalent.)
Spark plugs (PLATINUM-
Replace every 105,000 miles (169,000 km). MA-16
TIPPED type)
Intake & exhaust valve clear- EM-82, "Valve
NOTE (4)
ance* Clearance"
NOTE:
(1) After 60,000 miles (96,000 km) or 48 months, inspect every 15,000 miles (24,000 km) or 12 months. Replace the drive belts if found
damaged.
(2) Maintenance-free item. For service procedures, refer to FL section.
(3) After 60,000 miles (96,000 km) or 48 months, replace every 30,000 miles (48,000 km) or 24 months.
(4) If valve noise increases, inspect valve clearance.
* Maintenance items and intervals with "*" are recommended by INFINITI for reliable vehicle operation. The owner need not perform
such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are
required
CHASSIS AND BODY MAINTENANCE
Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary.
MAINTENANCE OPERATION MAINTENANCE INTERVAL
Reference Sec-
Perform at number of miles, kilo- Miles x 1,000 7.5 15 22.5 30 37.5 45 52.5 60 tion - Page or -
meters or months, whichever (km x 1,000) (12) (24) (36) (48) (60) (72) (84) (96) Content Title
comes first. Months 6 12 18 24 30 36 42 48
Brake lines & cables
I I I I MA-23
Brake pads & rotors
I I I I MA-24
Manual transmission gear oil or
MA-18, MA-19 ,
automatic transmission fluid & NOTE (1) I I I I
MA-21
differential gear oil
Steering gear & linkage, axle &
MA-24,
suspension parts I I
RSU-5, MA-25
Exhaust system
I I MA-18
In-cabin microfilter R R R R ATC-126
NOTE:
(1) Using automatic transmission fluid other than Genuine Nissan Matic J ATF will cause deterioration in driveability and auto-
matic transmission durability, and may damage the automatic transmission, which is not covered by the INFINITI new vehicle
limited warranty.
MA-8
RECOMMENDED FLUIDS AND LUBRICANTS
RECOMMENDED FLUIDS AND LUBRICANTS PFP:00000
A
Fluids and Lubricants ALS0006H
Capacity (Approximate)
Recommended Fluids/Lubricants B
US measure Imp measure Liter
With oil filter
5 qt 4-1/8 qt 4.7 q API Certification Mark*1
Engine oil change
Drain and refill q API grade SG/SH, Energy Conserving I & II or C
Without oil fil-
4-5/8 qt 3-7/8 qt 4.4 API grade SJ or SL, Energy Conserving*1
ter change
q ILSAC grade GF-I, GF-II & GF-III *1
Dry engine (Overhaul) 5-3/4 qt 4-3/4 qt 5.4
D
With reservoir
Cooling sys- 9-1/4 qt 7-5/8 qt 8.7 Genuine Nissan Long Life Antifreeze /Coolant or
tank
tem equivalent
Reservoir tank 7/8 qt 3/4 qt 0.8
E
Genuine Nissan Manual Transmission fluid
Manual transmission gear oil 3-1/8 qt 2-1/2 qt 2.9 (MTF) HQ Multi 75W-85 or API GL-4, Viscosity
SAE 75W-85 or 75W-90
F
Automatic transmission fluid 10-7/8 qt 9-1/8 qt 10.3 Genuine Nissan Matic J ATF *2
Power steering fluid (PSF) 1-1/8 qt 7/8 qt 1.0 Genuine NISSAN PSF or equivalent*3
Genuine Nissan Super Heavy Duty Brake Fluid*4 G
Brake fluid -- -- --
or equivalent DOT 3 (US FMVSS No. 116)
Differential gear oil 3 pt 2-1/2 pt 1.4 API GL-5, Viscosity SAE 80 W-90 *5
Multi-purpose grease -- -- -- NLGI No. 2 (Lithium soap base) H
Genuine Nissan Windshield Washer Concentrate
Windshield washer fluid -- -- --
Cleaner & Antifreeze fluid or equivalent
*1: For further details, see "SAE Viscosity Number". I
*2: Using automatic transmission fluid other than Genuine Nissan Matic J ATF will cause deterioration in driveability and auto-
matic transmission durability, and may damage the automatic transmission, which is not covered by the INFINITI new vehicle
limited warranty.
J
*3: For Canada, NISSAN Automatic Transmission Fluid (ATF), DEXRONTM III/ MERCONTM , or equivalent ATF may also be used.
*4: Available in mainland U.S.A. through your INFINITI dealer.
*5: For hot climates, viscosity SAE 90 is suitable for ambient temperatures above 0◦ Jabse Service Manual Search 2025 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
