Image preview - the first page of the document
fax


>> Download fax documenatation <<

Text preview - extract from the document
FRONT AXLE


D DRIVELINE/AXLE

                                                                                                                                                        A




                                                                               SECTION                   FAX FRONT AXLE
                                                                                                                                                        B



                                                                                                                                                        C


                                                                                                                                                        FAX


                                                                                                                                                        E
                                                            CONTENTS
PREPARATION .......................................................... 2
                                                                 .            WHEEL BEARING INSPECTION ........................ 4             .         F
 Special Service Tools (SST) .................................... 2
                                                                 .          Removal and Installation ......................................... 4
                                                                                                                                              .
 Commercial Service Tools ....................................... 2
                                                                 .            REMOVAL ............................................................ 4
                                                                                                                                              .
NOISE, VIBRATION AND HARSHNESS (NVH)                                          INSPECTION AFTER REMOVAL ........................ 5             .         G
TROUBLESHOOTING ............................................... 3.            INSTALLATION .................................................... 6
                                                                                                                                              .
 NVH Troubleshooting Chart .................................... 3.         SERVICE DATA ......................................................... 7
                                                                                                                                              .
FRONT WHEEL HUB AND KNUCKLE ..................... 4              .          Wheel Bearing ......................................................... 7
                                                                                                                                              .
                                                                                                                                                        H
 On-Vehicle Inspection and Service ......................... 4   .            BALL JOINT ......................................................... 7
                                                                                                                                              .


                                                                                                                                                         I


                                                                                                                                                         J



                                                                                                                                                        K


                                                                                                                                                         L



                                                                                                                                                        M




Edition: 2004 September                                             FAX-1                                                     2005 G35 Coupe
                                            PREPARATION

PREPARATION                                                                                                      PFP:00002

Special Service Tools (SST)                                                                                         ADS00098


The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
    Tool number
    (Kent-Moore No.)                                                   Description
    Tool name


    HT72520000
    (J25730-A)
    Ball joint remover
                                                                       Removing steering outer socket
     a: 33 mm (1.30 in)
     b: 50 mm (1.97 in)
     r: 11.5 mm (0.453 in)
                                                           NT546


    ST3127S000
    (See J25742-1)
    Preload Gauge
    1. GG91030000
            Torque wrench (J25765)                                     Measuring rotating torque of ball joint
    2. HT62940000 ( -- )
             Socket adapter (1/2)
    3. HT62900000 ( -- )
                                                           NT124
             Socket adapter (3/8)

Commercial Service Tools                                                                                            ADS00099



    Tool name                                                          Description



                                                                       q   Removing wheel nuts
    Power tool                                                         q   Removing undercover
                                                                       q   Removing brake caliper assembly

                                                           PBIC0190E




Edition: 2004 September                            FAX-2                                            2005 G35 Coupe
           NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING

NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING                                                                                                                                  PFP:00003
                                                                                                                                                                                                                               A
NVH Troubleshooting Chart                                                                                                                                                                               ADS0009A


Use chart below to help you find the cause of the symptom. If necessary, repair or replace these parts.
                                                                                                                                                                                                                               B




                                                                                                                                                              NVH in WT section.


                                                                                                                                                                                   NVH in WT section.


                                                                                                                                                                                                          NVH in PS section.
                                                                              FAX-4




                                                                                                                                      FAX-4
                                                                                                                 --
 Reference page                                                                                                                                                                                                                C


                                                                                                                                                                                                                               FAX




                                                                              Improper installation, looseness




                                                                                                                                      Wheel bearing damage
                                                                                                                                                                                                                               E




                                                                                                                 Parts interference
 Possible cause and SUSPECTED PARTS




                                                                                                                                                                                   ROAD WHEEL
                                                                                                                                                                                                                               F




                                                                                                                                                                                                          STEERING
                                                                                                                                                              TIRES
                                                                                                                                                                                                                               G
                                      Noise
