Image preview - the first page of the document
>> Download rsu documenatation <<
Text preview - extract from the document
REAR SUSPENSION
E SUSPENSION
A
SECTION RSU
REAR SUSPENSION
B
C
D
RSU
CONTENTS
PRECAUTIONS ......................................................... 2. SUSPENSION ARM ................................................. 11 . F
Cautions .................................................................. 2
. Removal and Installation ....................................... 11 .
PREPARATION .......................................................... 3
. REMOVAL .......................................................... 11 .
Special Service Tools (SST) .................................... 3 . INSPECTION AFTER REMOVAL ...................... 11 . G
Commercial Service Tools ....................................... 3 . INSTALLATION .................................................. 12 .
NOISE, VIBRATION AND HARSHNESS (NVH) RADIUS ROD ........................................................... 13.
TROUBLESHOOTING ............................................... 4 . Removal and Installation ....................................... 13 .
H
NVH Troubleshooting Chart .................................... 4 . REMOVAL .......................................................... 13 .
REAR SUSPENSION ASSEMBLY ............................ 5 . INSPECTION AFTER REMOVAL ...................... 13 .
On-Vehicle Inspection and Service ......................... 5 . INSTALLATION .................................................. 13 .
INSPECTION OF BALL JOINT END PLAY ......... 5 . FRONT LOWER LINK ............................................. 14 . I
SHOCK ABSORBER INSPECTION .................... 5 . Removal and Installation ....................................... 14 .
Wheel Alignment Inspection .................................... 5 . REMOVAL .......................................................... 14 .
DESCRIPTION ..................................................... 5 . INSPECTION AFTER REMOVAL ...................... 14 . J
PRELIMINARY INSPECTION .............................. 5 . INSTALLATION .................................................. 14 .
CAMBER INSPECTION ....................................... 5 . REAR LOWER LINK & COIL SPRING .................... 15 .
TOE-IN ................................................................. 6
. Removal and Installation ....................................... 15 .
K
Components ............................................................ 7
. REMOVAL .......................................................... 15 .
Removal and Installation ......................................... 8 . INSPECTION AFTER REMOVAL ...................... 15 .
REMOVAL ............................................................ 8
. INSTALLATION .................................................. 15 .
INSTALLATION .................................................... 8 . STABILIZER BAR .................................................... 16 . L
SHOCK ABSORBER ................................................. 9 . Removal and Installation ....................................... 16 .
Removal and Installation ......................................... 9 . REMOVAL .......................................................... 16 .
REMOVAL ............................................................ 9
. INSPECTION AFTER REMOVAL ...................... 16 . M
INSPECTION AFTER REMOVAL ........................ 9 . INSTALLATION .................................................. 16 .
INSTALLATION .................................................... 9 . REAR SUSPENSION MEMBER .............................. 17 .
Disassembly and Assembly .................................... 9 . Removal and Installation ....................................... 17 .
DISASSEMBLY .................................................... 9 . REMOVAL .......................................................... 17 .
INSPECTION AFTER DISASSEMBLY .............. 10 . INSPECTION AFTER REMOVAL ...................... 17 .
ASSEMBLY ........................................................ 10. INSTALLATION .................................................. 17 .
SERVICE DATA ....................................................... 18 .
Wheel Alignment ................................................... 18 .
Ball Joint ................................................................ 18
.
Wheelarch Height (Unladen*) ................................ 18 .
Edition: 2004 September RSU-1 2005 G35 Coupe
PRECAUTIONS
PRECAUTIONS PFP:00001
Cautions AES000EA
q When installing rubber bushings, final tightening must be carried out under unladen conditions with tires
on level ground. Oil will shorten the life of rubber bushings. Be sure to wipe off any spilled oil.
q Unladen conditions means that fuel, engine coolant and lubricant are full. Spare tire, jack, hand tools and
mats are in designated positions.
q After servicing suspension parts, be sure to check wheel alignment.
q Caulking nuts are not reusable. Always use new ones when installing. Since new caulking nuts are pre-
oiled, tighten as they are.
Edition: 2004 September RSU-2 2005 G35 Coupe
PREPARATION
PREPARATION PFP:00002
A
Special Service Tools (SST) AES000EB
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Tool number B
(Kent-Moore No.) Description
Tool name
ST3127S000 C
(See J25742-1)
Preload Gauge
1. GG91030000
Torque wrench (J25765) Measuring rotating torque of ball joint D
2. HT62940000 ( -- )
Socket adapter (1/2)
3. HT62900000 ( -- )
Socket adapter (3/8)
NT124 RSU
Commercial Service Tools AES000EC
Tool name Description F
q Removing wheel nuts G
q Removing brake caliper assembly
Power tool
q Removing rear suspension component
parts H
PBIC0190E
I
J
K
L
M
Edition: 2004 September RSU-3 2005 G35 Coupe
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING PFP:00003
NVH Troubleshooting Chart AES000ED
Use chart below to help you find the cause of the symptom. If necessary, repair or replace these parts.
NVH in RAX and RSU sections.
NVH in RFD section.
NVH in RAX section.
NVH in WT section.
NVH in WT section.
NVH in PR section.
NVH in BR section.
NVH in PS section.
RSU-16
RSU-7
RSU-9
RSU-7
RSU-5
--
--
--
Reference page
Shock absorber deformation, damage or deflection
REAR AXLE AND REAR SUSPENSION
Bushing or mounting deterioration
Improper installation, looseness
Possible cause and SUSPECTED PARTS
Incorrect wheel alignment
Suspension looseness
PROPELLER SHAFT
Stabilizer bar fatigue
Parts interference
ROAD WHEEL
DIFFERENTIAL
DRIVE SHAFT
Spring fatigue
STEERING
BRAKES
TIRES
