Image preview - the first page of the document
fax


>> Download fax documenatation <<

Text preview - extract from the document
FRONT AXLE


D DRIVELINE/AXLE

                                                                                                                                                            A


                                                                                                                                                            B
                                                                                   SECTION
                                                                                                                 FRONT AXLE                                 C


                                                                                                                                                            FAX


                                                                                                                                                            E
                                                               CONTENTS
PRECAUTIONS ......................................................... 2
                                                                     .          On-Vehicle Service Inspection ................................. 5 .         F
 Precautions ............................................................. 2
                                                                     .            FRONT WHEEL BEARING .................................. 5        .
PREPARATION .......................................................... 3
                                                                     .          Removal and Installation ......................................... 5
                                                                                                                                                  .
 Special Service Tools .............................................. 3
                                                                     .            REMOVAL ............................................................ 6
                                                                                                                                                  .         G
 Commercial Service Tools ....................................... 3  .            INSPECTION AFTER REMOVAL ........................ 6             .
NOISE, VIBRATION AND HARSHNESS (NVH)                                              INSTALLATION .................................................... 7
                                                                                                                                                  .
TROUBLESHOOTING ............................................... 4    .         SERVICE DATA ......................................................... 8
                                                                                                                                                  .
                                                                                                                                                            H
 NVH Troubleshooting Chart .................................... 4    .          Wheel Bearing ......................................................... 8
                                                                                                                                                  .
FRONT WHEEL HUB AND KNUCKLE ..................... 5                  .            BALL JOINT ......................................................... 8
                                                                                                                                                  .

                                                                                                                                                             I


                                                                                                                                                             J



                                                                                                                                                            K


                                                                                                                                                             L



                                                                                                                                                            M




Revision; 2004 April                                                    FAX-1                                                     2003 G35 Sedan
                                             PRECAUTIONS

PRECAUTIONS                                                                                             PFP:00001

Precautions                                                                                                 ADS00001


q   When installing rubber parts, final tightening must be carried out under unladen condition* with tires on
    ground.
    Oil will shorten the life of rubber bushes. Be sure to wipe off any spilled oil.
    *: Fuel, radiator coolant and engine oil full. Spare tire, jack, hand tools and mats in designated positions.
q   After installing removed suspension parts, check wheel alignment and adjust if necessary.
q   Lock nuts are unreusable parts; always use new ones. When replacing, do not wipe oil off the new lock
    nut before tightening.
q   Use flare nut wrench when removing or installing brake tubes.
q   Always torque brake lines when installing.




                                                                                                         SBR686C




Revision; 2004 April                                FAX-2                                       2003 G35 Sedan
                                            PREPARATION

PREPARATION                                                                                                    PFP:00002
                                                                                                                             A
Special Service Tools                                                                                             ADS00002


The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
    Tool number
                                                                                                                             B
    (Kent-Moore No.)                                                   Description
    Tool name
                                                                                                                             C
    HT7252 0000
    (J25730-A)
    Ball joint remover
                                                                       Removing tie-rod and lower ball joint                 FAX
     a: 33 mm (1.30 in)
     b: 50 mm (1.97 in)
     r: 11.5 mm (0.453 in)
                                                           NT546
                                                                                                                             E
    ST3127 S000
    (See J25742-1)
    Preload Gauge
    1. GG91030000                                                                                                            F
            Torque wrench (J25765)                                     Measurement ball joint of sliding torque
    2. HT62940000 ( -- )
             Socket adapter (1/2)
                                                                                                                             G
    3. HT62900000 ( -- )
                                                           NT124
             Socket adapter (3/8)

Commercial Service Tools                                                                                          ADS00003   H
    Tool name                                                          Description

                                                                                                                              I

    1. Flare nut crowfoot
    a: 10 mm (0.39 in)                                                 Removing and installing each brake piping              J
    2. Torque wrench


                                                           S-NT360
                                                                                                                             K


                                                                       q   Removing wheel nuts
                                                                                                                              L
    Power tool                                                         q   Removing engine under cover
                                                                       q   Removing brake caliper assembly
                                                                                                                             M
                                                           PBIC0190E




Revision; 2004 April                               FAX-3                                           2003 G35 Sedan
           NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING

NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING                                                                                                                                 PFP:00003

NVH Troubleshooting Chart                                                                                                                                                                                ADS00004


Use chart below to help you find the cause of the symptom. If necessary, repair or replace these parts.




                                                                                                                                                               NVH in WT section.


                                                                                                                                                                                    NVH in WT section.


                                                                                                                                                                                                           NVH in PS section.
                                                                               Refer to FAX-5 .




                                                                                                                                       Refer to FAX-5 .
                                                                                                                  --
 Reference page




                                                                               Improper installation, looseness




                                                                                                                                       Wheel bearing damage
                                                                                                                  Parts interference
 Possible cause and SUSPECTED PARTS




                                                                                                                                                                                    ROAD WHEEL


                                                                                                                                                                                                           STEERING
                                                                                                                                                               TIRES
                                      Noise
