Image preview - the first page of the document
fsu


>> Download fsu documenatation <<

Text preview - extract from the document
FRONT SUSPENSION


E SUSPENSION

                                                                                                                                                                 A


                                                                                                                                                                 B
                                                                                  SECTION
                                                                                        FRONT SUSPENSION                                                         C


                                                                                                                                                                 D


                                                                                                                                                                 FSU
                                                               CONTENTS
PRECAUTIONS ......................................................... 2
                                                                     .         TRANSVERSE LINK ................................................ 12      .        F
 Precautions ............................................................. 2
                                                                     .          Removal and Installation ....................................... 12     .
PREPARATION .......................................................... 3
                                                                     .            REMOVAL .......................................................... 12 .
 Special Service Tools .............................................. 3
                                                                     .            INSPECTION AFTER REMOVAL ...................... 12                    .        G
 Commercial Service Tools ....................................... 3  .            INSTALLATION .................................................. 12    .
NOISE, VIBRATION AND HARSHNESS (NVH)                                           STABILIZER BAR .................................................... 13   .
TROUBLESHOOTING ............................................... 5    .          Removal and Installation ....................................... 13     .
                                                                                                                                                                 H
 NVH Troubleshooting Chart .................................... 5    .            REMOVAL .......................................................... 13 .
FRONT SUSPENSION ASSEMBLY .......................... 6               .            INSPECTION AFTER REMOVAL ...................... 13                    .
 Components ............................................................ 6
                                                                     .            INSTALLATION .................................................. 13    .
 On-Vehicle Inspection and Service ......................... 7       .         FRONT SUSPENSION MEMBER ............................ 14                  .         I
   LOOSENESS, BACKLASH AND DAMAGE OF                                            Removal and Installation ....................................... 14     .
   MOUNTING PARTS AND CONNECTIONS ......... 7                        .            REMOVAL .......................................................... 14 .
 Wheel Alignment Inspection .................................... 7   .            INSTALLATION .................................................. 14    .         J
   DESCRIPTION ..................................................... 7
                                                                     .         UPPER LINK ............................................................ 15
                                                                                                                                                        .
   PRELIMINARY INSPECTION .............................. 7           .          Removal and Installation ....................................... 15     .
   INSPECTION OF CAMBER, CASTER AND                                               REMOVAL .......................................................... 15 .
                                                                                                                                                                 K
   KINGPIN INCLINATION ANGLES. ...................... 7              .            INSPECTION AFTER REMOVAL ...................... 15                    .
COIL SPRING AND SHOCK ABSORBER ................ 9                    .            INSTALLATION .................................................. 15    .
 Removal and Installation ......................................... 9.         COMPRESSION ROD .............................................. 16        .
   REMOVAL ............................................................ 9
                                                                     .          Removal and Installation ....................................... 16     .        L
   INSTALLATION .................................................... 9
                                                                     .            REMOVAL .......................................................... 16 .
 Disassembly and Assembly .................................... 9     .            INSPECTION AFTER REMOVAL ...................... 16                    .
   DISASSEMBLY .................................................... 9.            INSTALLATION .................................................. 16    .        M
   INSPECTION AFTER DISASSEMBLY ................ 9                   .         SERVICE DATA ....................................................... 17  .
   ASSEMBLY ........................................................ 10
                                                                     .          Wheel Alignment (Unladen) ................................... 17        .
                                                                                Ball Joint ................................................................ 17
                                                                                                                                                        .
                                                                                Wheelarch Height (Unladen*) ................................ 17         .




Revision; 2004 April                                                    FSU-1                                                         2003 G35 Sedan
                                             PRECAUTIONS

PRECAUTIONS                                                                                             PFP:00001

Precautions                                                                                                 AES00001


q   When installing rubber parts, final tightening must be carried out under unladen condition*: with tires on
    ground.
    Oil will shorten the life of rubber bushes. Be sure to wipe off any spilled oil.
    *: Fuel, radiator coolant and engine oil full. Spare tire, jack, hand tools and mats in designated positions.
q   After installing removed suspension parts, check wheel alignment and adjust if necessary.
q   Lock nuts are unreusable parts; always use new ones. When replacing, do not wipe oil off the new lock
    nut before tightening.
q   Use flare nut wrench when removing or installing brake tubes.
q   Always torque brake lines when installing.




                                                                                                         SBR686C




Revision; 2004 April                                FSU-2                                       2003 G35 Sedan
                                            PREPARATION

PREPARATION                                                                                                  PFP:00002
                                                                                                                             A
Special Service Tools                                                                                             AES00002


The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
  Tool number
                                                                                                                             B
   (Kent-Moore No.)                                                          Description
  Tool name

  KV991040S0                                                                                                                 C
  (     --     )
  CCK gauge
  1. Plate
                                                                                                                             D
  2. Guide bolts
  3. Nuts
  4. Springs
  5. Center plate                                                                                                            FSU
                                                                             Measuring wheel alignment
  6. KV9910 4030 Adapter A
   a: 72 mm (2.83 in) dia.
  7. KV9910 4030 Adapter B
   b: 65 mm (2.56 in) dia.                                      S-NT498                                                      F
  8. KV9910 4040 Adapter C
   c: 57 mm (2.24 in) dia.
  9. KV9910 4050 Adapter D
   d: 53.4 mm (2.102 in) dia.                                                                                                G



  ST35652000                                                                                                                 H
  ( -- )                                                                     Strut disassembly/re-asassembly
  Strut attachment
                                                                                                                              I
                                                                ZZA0807D


  ST3127S000
  (See J25742-1)                                                                                                              J
  Preload Gauge
  1. GG91030000
          Torque wrench (J25765)                                             Measuring sliding torque of ball joint
  2. HT62940000 ( -- )                                                                                                       K
           Socket adapter (1/2)
  3. HT62900000 ( -- )
                                                                NT124
           Socket adapter (3/8)
                                                                                                                             L
Commercial Service Tools                                                                                          AES00003


 Tool name                                                                  Description
                                                                                                                             M


 1.Flare nut crowfoot
                                                                            Removing and installing each brake pip-
  a: 10 mm (0.39 in)
                                                                            ing
 2.Torque wrench


                                                               S-NT360




Revision; 2004 April                               FSU-3                                           2003 G35 Sedan
                       PREPARATION




 Spring compressor                            Removing coil spring



                                  S-NT717




                                              q   Removing wheel nuts
 Power tool                                   q   Removing engine under cover
                                              q   Removing stabilizer assembly

                                  PBIC0190E




Revision; 2004 April      FSU-4                                      2003 G35 Sedan
