Image preview - the first page of the document
rax

>> Download rax documenatation <<

Text preview - extract from the document

REAR AXLE

D DRIVELINE/AXLE

B
SECTION
REAR AXLE C

RAX

E
CONTENTS
PRECAUTIONS ......................................................... 2
. REAR DRIVE SHAFT ................................................ 9 . F
Precautions ............................................................. 2
. Removal and Installation ......................................... 9 .
PREPARATION .......................................................... 3
. REMOVAL ............................................................ 9
.
Special Service Tools .............................................. 3
. INSPECTION AFTER REMOVAL ........................ 9 . G
Commercial Service Tools ....................................... 3 . INSTALLATION .................................................... 9 .
NOISE, VIBRATION AND HARSHNESS (NVH) Disassembly and Assembly ..................................... 9 .
TROUBLESHOOTING ............................................... 4 . INSPECTION BEFORE DISASSEMBLY ............ 10 .
H
NVH Troubleshooting Chart .................................... 4 . DISASSEMBLY .................................................. 10 .
WHEEL HUB ............................................................. 5
. INSPECTION AFTER DISASSEMBLY ............... 11 .
On-Vehicle Service Inspection ................................ 5 . ASSEMBLY ........................................................ 11.
REAR WHEEL BEARING .................................... 5 . SERVICE DATA ....................................................... 15. I
Removal and Installation ......................................... 5. Wheel Bearing ....................................................... 15
.
REMOVAL ............................................................ 5
. Drive Shaft ............................................................. 15
.
INSTALLATION .................................................... 6
. Z100D90F .......................................................... 15
. J
Disassembly and Assembly .................................... 6 .
DISASSEMBLY .................................................... 6.
INSPECTION AFTER DISASSEMBLY ................ 7 .
K
ASSEMBLY .......................................................... 7
.

Revision; 2004 April RAX-1 2003 G35 Sedan
PRECAUTIONS

PRECAUTIONS PFP:00001

Precautions ADS00009

q When installing rubber parts, final tightening must be carried out under unladen condition*: with tires on
ground.
Oil will shorten the life of rubber bushes. Be sure to wipe off any spilled oil.
*: Fuel, radiator coolant and engine oil full. Spare tire, jack, hand tools and mats in designated positions.
q After installing removed suspension parts, check wheel alignment and adjust if necessary.
q Do not jack up at lower arm.
q Use flare nut wrench when removing or installing brake lines.
q Always torque brake lines when installing.

SBR686C

CAUTION:
Observe the following precautions when disassembling and servicing drive shaft.
q Perform work in a location which is as dust-free as possible.
q Before disassembling and servicing, clean the outside of parts.
q Disassembly and service location must be taken to prevent the entry of foreign objects.
q Disassembled parts must be carefully reassembled in the correct order. If work is interrupted, a clean
cover must be placed over parts.
q Paper shop cloths must be used. Fabric shop cloths must not be used because of the danger of lint adher-
ing to parts.
q Disassembled parts (except for rubber parts) should be cleaned with kerosene which shall be removed by
blowing with air or wiping with paper shop cloths.

Revision; 2004 April RAX-2 2003 G35 Sedan
PREPARATION

PREPARATION PFP:00002
A
Special Service Tools ADS0001E

The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Tool number
B
(Kent-Moore No.) Description
Tool name
C
ST33061000
(J 8107-2)
Removing inner race of outer-side
Drift RAX
bearing
a: 28.5 mm (1.122 in) dia.
b: 38.0 mm (1.496 in) dia.
ZZA0969D
E

KV381 00500
( -- ) F
Drift Installing drive shaft plug
a: 80 mm (3.15 in) dia.
b: 60 mm (2.36 in) dia.
G
ZZA0701D

H
KV381 02200
( -- )
Drift Installing drive shaft plug
a: 90 mm (3.54 in) dia. I
b: 31 mm (1.22 in) dia.

ZZA0920D

J
Commercial Service Tools ADS0000B

Tool name Description
K

1. Flare nut crowfoot L
Removing and installing each brake
a: 10 mm (0.39 in)
piping
2. Torque wrench

M
S-NT360

q Removing wheel nuts
Power tool
q Removing brake caliper assembly

PBIC0190E

Revision; 2004 April RAX-3 2003 G35 Sedan
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING

NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING PFP:00003

NVH Troubleshooting Chart ADS0000C

Use chart below to help you find the cause of the symptom. If necessary, repair or replace these parts.

Refer to DRIVE SHAFT in this chart.
Refer to REAR AXLE in this chart.
NVH in FAX and FSU sections.
NVH in RFD section.

NVH in WT section.

NVH in WT section.
NVH in PR section.

NVH in BR section.
--

NVH in PS section.
Reference page

Refer to RAX-11 .

Refer to RAX-5 .

FRONT AXLE AND FRONT SUSPENSION
Improper installation, looseness
Joint sliding resistance

Possible cause and SUSPECTED PARTS

PROPELLER SHAFT
Excessive joint angle

Parts interference

DIFFERENTIAL

ROAD WHEEL

DRIVE SHAFT
REAR AXLE

STEERING
Imbalance

BRAKES
TIRES
DRIVE Noise
