Image preview - the first page of the document
fax


>> Download fax documenatation <<

Text preview - extract from the document
FRONT AXLE


D DRIVELINE/AXLE

                                                                                                                                                              A


                                                                                                                                                              B
                                                                                SECTION
                                                                                                                FRONT AXLE                                    C


                                                                                                                                                              FAX


                                                                                                                                                              E
                                                            CONTENTS
                                2WD                                           WHEEL BEARING INSPECTION ........................ 4                   .         F
                                                                            Removal and Installation ......................................... 4    .
PREPARATION .......................................................... 2
                                                                 .            REMOVAL ............................................................ 4.
 Special Service Tools (SST) .................................... 2
                                                                 .            INSPECTION AFTER REMOVAL ........................ 5                   .         G
 Commercial Service Tools ....................................... 2
                                                                 .            INSTALLATION .................................................... 6   .
NOISE, VIBRATION AND HARSHNESS (NVH)                                       SERVICE DATA ......................................................... 7 .
TROUBLESHOOTING ............................................... 3.          Wheel Bearing ......................................................... 7
                                                                                                                                                    .
 NVH Troubleshooting Chart .................................... 3.                                                                                            H
                                                                            Ball Joint .................................................................. 7
                                                                                                                                                    .
FRONT WHEEL HUB AND KNUCKLE ..................... 4              .
 On-Vehicle Inspection and Service ......................... 4   .
                                                                                                                                                               I


                                                                                                                                                               J



                                                                                                                                                              K


                                                                                                                                                               L



                                                                                                                                                              M




                                                                    FAX-1
                                            PREPARATION
                                                                                                                  [2WD]
PREPARATION
[2WD]                                                                                                            PFP:00002

Special Service Tools (SST)                                                                                         ADS000SB


The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
    Tool number
    (Kent-Moore No.)                                                   Description
    Tool name


    HT7252 0000
    (J25730-A)
    Ball joint remover
                                                                       Removing steering outer socket
     a: 33 mm (1.30 in)
     b: 50 mm (1.97 in)
     r: 11.5 mm (0.453 in)
                                                           NT546


    ST3127 S000
    (See J25742-1)
    Preload Gauge
    1. GG91030000
            Torque wrench (J25765)                                     Measuring rotating torque of ball joint
    2. HT62940000 ( -- )
             Socket adapter (1/2)
    3. HT62900000 ( -- )
                                                           NT124
             Socket adapter (3/8)

Commercial Service Tools                                                                                            ADS000SC



    Tool name                                                          Description



                                                                       q   Removing wheel nuts
    Power tool                                                         q   Removing undercover
                                                                       q   Removing brake caliper assembly

                                                           PBIC0190E




                                                   FAX-2
          NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING
                                                                                                                                                                                             [2WD]
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING                                                                                                                                 PFP:00003
                                                                                                                                                                                                                               A
NVH Troubleshooting Chart                                                                                                                                                                              ADS000SD


Use chart below to help you find the cause of the symptom. If necessary, repair or replace these parts.
                                                                                                                                                                                                                               B




                                                                                                                                                             NVH in WT section.


                                                                                                                                                                                  NVH in WT section.


                                                                                                                                                                                                          NVH in PS section.
                                                                              FAX-4




                                                                                                                                      FAX-4
                                                                                                                 --
Reference page                                                                                                                                                                                                                 C


                                                                                                                                                                                                                               FAX




                                                                              Improper installation, looseness




                                                                                                                                      Wheel bearing damage
                                                                                                                                                                                                                               E




                                                                                                                 Parts interference
Possible cause and SUSPECTED PARTS




                                                                                                                                                                                  ROAD WHEEL
                                                                                                                                                                                                                               F




                                                                                                                                                                                                          STEERING
                                                                                                                                                             TIRES
                                                                                                                                                                                                                               G
                                     Noise



◦ Jabse Service Manual Search 2022 ◦ Jabse PravopisonTap.bg ◦ Other service manual resources online : FixyaeServiceinfo
